  • Page 1 AXEON HYDRO RO – SERIES High Efficiency Hyperfiltration System USER MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PRECAUTIONS 2–3 FILTER REPLACEMENT SCHEDULE 4–5 SYSTEM INCLUDES 6–7 HYDRO RO–1250 HYDRO RO–750 SYSTEM INSTALLATION 10–19 SMART CONTROLLER FUNCTIONALITY EXPLAINED PERFORMANCE COMPONENT SPECIFICATIONS 22–23 WARRANTY AND SUPPORT TROUBLESHOOTING FLOW DIAGRAMS 26–27 DIMENSIONAL DRAWINGS 28–31 FILTER REPLACEMENT LOG NOTES...
  • Page 3 WATER PURIFICATION SYSTEMS SINCE 1989 AXEON Water systems use advanced reverse osmosis ® membrane technology for removing +96% contaminants from feed water sources. These systems are designed and engineered for maximum flow and efficiency rates, meaning less water down the drain and more purified water for use.

  • Page 4: Precautions

    PRECAUTIONS WARNING LABELS Caution: Indicates statements that are used to identify conditions or practices that could result in equipment or other property damage. Warning: Indicates statements that are used to identify conditions or practices that could result in injury or loss of life. Failure to follow warnings could result in serious injury or even death. Electrical Hazard: Indicates statements that are used to identify high-voltage and potential shock/electrocution.
  • Page 5 This is the case with all reverse osmosis technology, and it is not unique to the AXEON HYDRO RO system. The ratio of product water to wastewater can also get worse due to low pressure and low temperature. You can overcome some of these issues by choosing the HYDRO RO–1250, which is equipped with an AXEON 1250 booster pump...

  • Page 6: Filter Replacement Schedule

    FILTER REPLACEMENT SCHEDULE STAGE 1: EZ-TWIST 5-MICRON SEDIMENT (212254) The 5-micron sediment filter reduces rust, sand, silt, and other particulates and impurities from the water. Depending on water use and the number of impurities, this filter should be replaced at a minimum of 6,500 gallons of purified water produced. FILTER PART # REPLACEMENT SCHEDULE...
  • Page 7 FILTER REPLACEMENT SCHEDULE STAGE 4: HYPERFILTER MEMBRANES (212269) The AXEON HF–3213–375 HyperFilter is a proprietary membrane that filters down to 0.0001 micron and removes bacteria, viruses, heavy metals, pesticidal residues, and other harmful substances from water. Functional life will vary based on the feed water quality.

  • Page 8: System Includes

    SYSTEM INCLUDES HYDRO RO System EZ-Twist Sediment Filter (x2) EZ-Twist Carbon Filter (x2) HyperFilter Membrane (pre-installed inside the housing) HYDRO System Power Supply HyperFilter Housing Wrench Garden Hose Connector 3/8" x 1/4" Branch Tee (RO – 1250) Shutoff Valve Spare Locking Cotter Clips Leak Detector Float Valve...
  • Page 9 SYSTEM INCLUDES (CONT.) Black Tubing 1/4" (10 ft) White Tubing 1/4" (10 ft) (RO – 1250) (x2) White Tubing 3/8" (10 ft) Blue Tubing 3/8" (10 ft) Booster Pump (RO – 1250) Booster Pump Transformer (RO – 1250) Booster pump only comes with RO –1250. Booster pump kit (AH1010) can be purchased separately.

  • Page 10: Hydro Ro-1250

    HYDRO RO –1250...

  • Page 11: Hydro Ro-750

    HYDRO RO – 750...

  • Page 12: System Installation

    SYSTEM INSTALLATION Follow the steps below to set up your AXEON HYDRO RO system. Let's get started! 1. HYPERFILTER MEMBRANE INSTALLATION Step 1A: Take the HYDRO RO system out from the package. Remove the two screws holding the cover. The screws are located at the bottom of the system towards the back.
  • Page 13 SYSTEM INSTALLATION—QUICK CONNECT (QC) FITTINGS LOCKING COTTER CLIPS Certain QC fittings come equipped with secure-lock cotter clips. Do not throw them away. The cotter clip provides an extra layer of protection by securely locking tubing into the QC fitting. Before disconnecting or connecting tubing into a QC fitting, first remove the cotter clip and set it aside.
  • Page 14 SYSTEM INSTALLATION (CONT.) Step 1D: Disconnect the locking cotter clips and tubing going to the HyperFilter housing cap, then unscrew the cap, using the included wrench, in a counterclockwise direction. Repeat this step for the 2 HyperFilter housing. Step 1E: Remove the HyperFilter membrane from the packaging and lightly lubricate the brine seal and O-rings with a non-petroleum-based lubricant, such as Dow Corning 111 silicone (not included).
  • Page 15 SYSTEM INSTALLATION (CONT.) Step 1H: Re-install the cover. Engage the tabs located in the back. Make sure the power cables connected to the cover are aligned in the middle of the cover and that the membrane housings are aligned to allow the cover to sit properly.
  • Page 16 SYSTEM INSTALLATION (CONT.) 3. TUBING CONNECTIONS FOR RO –750 AND RO –1250 Step 3A: Connect the 3/8" white tubing from the feed water source using the included garden hose adapter to the back of the system’s “FEED” port, which is labeled. Step 3B: Use the 1/4"...
  • Page 17 SYSTEM INSTALLATION (CONT.) Step 4B: Slide the filter up into the head vertically, then rotate the filter to the right until it stops. Do this for all three filter cartridges, making sure each filter stage matches the corresponding label on the head. If installing the RO –1250 system, skip to Stage 8 (page 17).
  • Page 18 SYSTEM INSTALLATION (CONT.) 6. POWER CONNECTION FOR FOR RO –750 Step 6A: Mount the system and connect the power supply to the RO system's power port located on the back right of the system. Now with the power connected and the HyperFilter membranes, filters, tubing connections, and float valve all installed, the system is now ready to operate! Continue to the Smart Controller Functionality Explained portion of the manual to learn how the system features operate.
  • Page 19 SYSTEM INSTALLATION (CONT.) 8. BOOSTER PUMP TUBING CONNECTIONS FOR RO – 1250 Step 8A: It's time to connect the tubing coming from INLET the RO system to the booster pump. For feed water connection, connect 3/8" white tubing from feed source using the included garden hose adapter to the port on the right side of the pump labeled “INLET”.
  • Page 20 SYSTEM INSTALLATION (CONT.) 9. FLOAT VALVE INSTALLATION FOR RO –1250 Step 9A: Begin by identifying the maximum water level height. Drill a 1/2" hole at the max water line and remove any plastic debris from inside the water tank. Step 9B: Next, push the threaded end of the float valve from inside the reservoir and out, making sure GASKET the gasket is on the inside of the water tank.
  • Page 21 SYSTEM INSTALLATION (CONT.) 10. POWER CONNECTIONS FOR RO –1250 Step 10A: Connect the larger pump Step 10B: Connect the smaller RO system power supply to the pump’s power port. power supply to the RO system’s power port. Now with the power connected and the HyperFilter membranes, filters, tubing connections, and float valve all installed, the system is now ready to operate! Continue to the Smart Controller Functionality Explained portion of the manual to learn how the system features operate.

  • Page 22: Smart Controller Functionality Explained

    SMART CONTROLLER FUNCTIONALITY EXPLAINED SYSTEM SCREEN KEY NOTE: Upon system start up, don't be alarmed by high TDS levels. TDS levels will slowly decline for up to the first 3 days of operation. Power On: After powering on, the system screen will flash all indicator lights. –...

  • Page 23: Performance

    PERFORMANCE HYPERFILTER MEMBRANE SYMBOL % REJECTION REJECTION CHART Aluminum Al+3 97 - 98 The HyperFilter membrane rejection Ammonium 85 - 95 chart can be very helpful as a general Borate 30 - 50 guideline, but is not a guarantee. Every water source has different chemistry, Boron 60 - 70...

  • Page 24: Component Specifications

    COMPONENT SPECIFICATIONS STAGE 1: EZ-TWIST 5-MIC SEDIMENT (212254) The melt blown sediment cartridges are made of 100% polypropylene material. These fibers are carefully woven using a proprietary process to ensure the highest level of filtration performance. These cartridges have the advantage of not using any glues or additives which could foam, discolor, or cause any other undesirable effects.
  • Page 25 COMPONENT SPECIFICATIONS (CONT.) SYSTEM SPECIFICATIONS MODELS RO − 750 RO −1250 Configuration Single Pass Single Pass Standard Recovery % Permeate Flow Rate (GPM) 0.52 0.87 Concentrate Flow Rate (GPM) 0.20 0.35 Feed (inch) Permeate (inch) Concentrate (inch) Membrane Quantity Membrane Size 3213 3213 Nominal TDS Rejection %...

  • Page 26: Warranty And Support

    Change both HyperFilter housings every three years (available through your local dealer or AXEON Water). The manufacturer believes the information and data contained herein to be accurate and useful. The information and data are...

  • Page 27: Troubleshooting

    PPMs are significantly higher, then you will experience less than the rated GPD flow rates. If your inlet feed pressure is too low, you may need to purchase the AXEON 1250 Booster Pump Kit to help the system reach operating pressure.

  • Page 28: Flow Diagrams

    FLOW DIAGRAMS HYPERFILTRATION RO – 750...
  • Page 29 FLOW DIAGRAMS (CONT.) HYPERFILTRATION RO – 1250...

  • Page 30: Dimensional Drawings

    DIMENSIONAL DRAWINGS RO SYSTEM MOUNTING DIAGRAM...
  • Page 31 DIMENSIONAL DRAWINGS (CONT.) RO SYSTEM MOUNTING DIAGRAM...
  • Page 32 DIMENSIONAL DRAWINGS (CONT.) RO SYSTEM MOUNTING DIAGRAM *True to size...
  • Page 33 DIMENSIONAL DRAWINGS (CONT.) BOOSTER PUMP MOUNTING DIAGRAM *True to size On center...

  • Page 34: Filter Replacement Log

    FILTER REPLACEMENT LOG MEMBRANE DATE CARBON OR PRE-FILTER DATE...

  • Page 35: Notes

    NOTES...
  • Page 36 AXEONhydro.com MKT– 694 – B 08/23...
