Modern Forms Roboto Installation Instructions Manual page 23

9
Air-Gap
C
Switch*
Wall Control
* Air-Gap Switch only included
with wall control
9B
Fan On/Off
Press and hold
button for 4 seconds.
Fan On/Off: Press and hold
green and all connected fans will beep to indicate the message has been received. All
fans will turn off. This will bring all fans controlled by the remote into sync.
Light On/Off: Press and hold
flash
green and all connected fans will beep to indicate the message has been received. All
lights will turn off. This will bring all fans controlled by the remote into sync.
Fan Direction: Press and hold
flash green and all connected fans will beep to indicate the message has been
received. All fans will be set to summer mode (CCW rotation). This will bring all fans
controlled by the remote into sync.
FR- W 1 91 0
A
B
Remote
Control
Light On/Off
button for 4 seconds.
button for 4 seconds. The LED on the remote will flash
button for 4 seconds. The LED on the remote will
button for 4 seconds. The LED on the remote will
9A
A
B
C
Summer Mode
(Counter-Clockwise)
Press and hold
Winter Mode
(Clockwise)
Fan Direction
Press and hold
button for 4 seconds.
Roboto Instructions 23
