multicomp pro MP780967 Operating Manual

MP780967
Mini Temperature Humidity Meter
(Bluetooth Version)
Operating Manual
1.Introduction
MP780967 with Bluetooth function is a stable, safe, reliable mini
storage and transportation, file management, material management,
forestry and animal husbandry, health care, teaching experiment,
public sector, home, and others. This operating manual includes
relevant safety information and warnings. Please read this manual
carefully and observe all the cautions strictly.
Warning:
Before using the product, please read the operation safety rules
carefully.
2.Contents
Open the packing box and take out the meter. Please check carefully
if items are missing or damaged.
Meter--------------------------------------- 1
1.
Operating manual --------------------- 1
2.
Operation Safety Rules
3.
Please check the meter and the accessories before using and beware
1.
of any damage or abnormal phenomenon. If you find the case is
damaged or the LCD shows nothing, or you consider that the meter
could not work properly anymore, please stop using it.
Observe the operating instructions while measuring.
2.
Do not open the meter at will or change internal wiring to avoid damages
3.
to the mater.
When the LCD displays " ", replace the battery.
4.
Remove the battery if the meter is not used for a long time.
5.
Do not store or use the meter in high temperature, high humidity,
6.
flammable, combustible, or strong electromagnetic environment.
Please use soft cloth and neutral detergent to clean the case for
7.
maintenance. Do not use any solvent to avoid damaging the meter.
Product Exterior
4.
Temperature and humidity sensing module
1.
Meter case
2.
LCD display
3.
①
Function keys
4.
②
③
④
5. Display Interface
① ②
⑨
⑧
10
Maximum measurement
1
Minimum measurement
2
Data hold
3
Low battery
4
Relative humidity
5
Celsius
6
Fahrenheit
7
Temperature value
8
Humidity value
9
Bluetooth communication symbol indication
10
6. Key Functions and Setup
NOTE: "short press" means: about 1 second continuous press, "long
press" means: about 2 second continuous press）
1. ON OFF / Bluetooth communication
/
Short press once to start up; short press again to power off.
Bluetooth communication: Under the state of boosting unit, long press
to enter Bluetooth communication mode, and then long press again to
quit Bluetooth communication mode
2. ℃/℉: Unit conversion key:
Short press this key to select Celsius or Fahrenheit at the time of measuring.
3. MAX/MIN:
Pressing this key can select maximum, minimum or normal value
measurement; select maximum and the meter will always show the
maximum reading; select minimum and the meter will show minimum
reading.
4. HOLD/BL:
HOLD: Short press this key once to hold the measurement; short press
this key again to exit data hold and continue normal measurement.
BL: Long press this key to turn on backlight; long press this key again
to turn off backlight.
Automatic shutdown
5.
After 5 minutes idle the unit will shut down the automatically (the
default mode is automatic shutdown mode on)
When you want to remove the automatic shutdown function, hold down
the "hold" + " " key to restart. LCD shows "APO OFF" character
prompt, the automatic shutdown function will be turned off.
③ ④
⑤
⑥
⑦
