Toughbay ™ Pro MW dim sensor
Microwave dimming Sensor: LEV71951
To fit sensor to the Toughbay™ Pro - remove the blank cap from the centre of the lens, then fit the sensor making sure not to
cross thread by rotating clockwise until hand tight- do not over tighten. On/off function - When the sensor is powered on for the
first time, the light will be turned on at 100% brightness, and it will be turned off after 10±5s. For Dim function- When the sensor
is powered on for the first time, the light will be turned on at 100% brightness, and it will be turned off after 10±5s, it will then
dim the light to a low level(set by standby dim level)During the initialization, the external movement induction signal will not be
detected.NOTE: AFTER A POWER FAILURE THE SENSOR WILL MAINTAIN ITS SETTINGS.
For use with Toughbay™ Pro. The default settings below cannot be changed on the sensor manually.
Default settings are: Detection area 100%, Hold time 5 secs, Stand-by Period: 0 secs, Stand-by dim level: 10%, Daylight sensor: Disable.
To commission or adjust settings for individual requirements or individual applications;
Please order LEV71808 Hand Held Remote(one remote can be used for multiple sensors)
To avoid interference between luminaires with sensors installed, we recommend the minimum distance between each luminaire is 3m.
MW sensors should be kept away from metal reflective surfaces, or a narrow enclosed environment, the microwave will be reflected
repeatedly and cause false triggering. Ensure the MW sensor is kept away from electromagnetic wave products, such as WIFI router /WIFI
camera, away from more than 2 meters to prevent electromagnetic wave interference.
SPECIFICATION:
Input Voltage
Working current
Detection area
Hold Time
Daylight Priority settings - on
Daylight Priority settings - off
Standby Period
Stand-by dimming level
Sensor principle
Mounting height(sensor)
Motion detection
Operating temperature
IP rating
Factory Setting
FAQ'S -
QUESTION
THE LUMINAIRE WILL NOT COME ON
THE LOAD IS PERMINANTLY ON
WILL NOT ILLUMINATE EVEN
THOUGH THERE IS MOVEMENT
THE REMOTE CONTROL IS NOT
WORKING
JCC Lighting Products Ltd. Lux Park, Chichester Business Park, City Fields Way, Tangmere, Chichester, West Sussex, PO20 2FT
Technical Support: +44(0)1243 838986 Customer Services: +44(0)1243 838999
12 + 2 VDC
25 + 5mA
25%/50%/75%/100%
5s/30s/1 min/3min/5min/10min/20min/30min
51ux/15Lux/30Lux/50Lux
150lux
0s/10s/1 min/3min/5min/1 0min/30min/+ ∞(for on/off function set to 0s)(for 2 step dimming set to + ∞)
(For 3 step dimming set to 10s/1 min/3min/5min/1 0min/30min + DH)
10% / 20% / 30% / 50%
Microwave motion detector(5.8GHz+75MHz)
10m (12m) Max.(when mounted at 12m, do not set detection area 25% or 50%, it will not detect correctly)
(0.3-1 m/s) @10m
0°C TO 40°c
IP65
Detection area:100%,Hold time:3 min, Stand-by Period: 5 min, Stand-by dim level:50%, Daylight Sensor: Disable
CAUSE
INCORRECT DAYLIGHT SENSOR SETTING
SELECTED
LOAD HAS FAILED
POWER IS SWITCHED OFF
CONTINUOUS MOVEMENT IN DETECTION
AREA
TOO CLOSE TO WIFI HUB/ROUTER
THE LUMINAIRE IS INSTALLED IN AN AREA TO
CLOSE TO REFLECTIVE SURFACES i.e. GLASS,
METAL OR CONCRETE WALLS
SPEED OF MOVING OBJECT IS NOT IN THE
RANGE OF 0.5-1M/S OR THE DETECTION
RADIUS IS TOO SMALL
BATTERY IS DEAD
THE REMOTE CONTROL IS NOT ALIGNED WITH
THE SENSOR
IP20 /IP65
(REMOTE)
ISO9001 - 2015 - Registered Firm Certificate No. GB 1552
1001ux
200lux
REMEDY
ADJUST SETTING
REPLACE LOAD
SWITCH ON POWER
CHECK DETECTION AREA SETTING
MOVE WIFI HUB/ROUTER RO REPOSITION FITTING
1. ENSURE THAT LUMINAIRE IS INSTALLED WITH A MINIMUM
100CM SPACE BETWEEN ANY REFLECTIVE SURFACES
2.REDUCE SENSITIVITY(DETECTION AREA)
CHECK DETECTION SETTINGS
REPLACE BATTERY
CHANGE THE POSITION/ANGLE OF THE REMOTE/CHECK TOGGLE
BUTTON SETTING FOR CORRECT HEIGHT
(SENSOR WHEN INSTALLED)
1501ux
300lux
