Leviton Toughbay Pro LEV71950 Instructions

Toughbay ™ Pro PIR dim sensor
PIR dimming Sensor: LEV71950
To fit sensor to the Toughbay™ Pro - remove the blank cap from the centre of the lens, then fit the sensor making
sure not to cross thread by rotating clockwise until hand tight- do not over tighten.
When the sensor is powered on for the first time, the light will be turned on at 100% brightness, and it will be turned
off after 45±5s. During the initialization, the external movement induction signal will not be detected.
NOTE: AFTER A POWER FAILURE THE SENSOR WILL MAINTAIN ITS SETTINGS.
For use with Toughbay™ Pro. The default settings below cannot be changed on the sensor manually.
Default settings are: Detection area 100%, Hold time 3min, Stand-by Period: 5min, Stand-by dim level: 50%, Daylight sensor: Disable.
To commission or adjust settings for individual requirements or individual applications;
Please order LEV71808 Hand Held Remote(one remote can be used for multiple sensors)
To avoid interference between luminaires with sensors installed, we recommend the minimum distance between each luminaire is 3m.
PIR sensors should be kept away from air conditioners, refrigerators, exhaust vents, furnaces and other sensitive places where air
temperature changes. The detection range of the PIR sensor should not be blocked by screens, furniture or other barriers. Ensure the PIR
sensor away from electromagnetic wave products, such as WIFI router /WIFI camera, away from more than 2 meters to prevent
electromagnetic wave interference.
SPECIFICATION:
Input Voltage
Working current
Detection area
Hold Time
Daylight Sensor
Standby Period
Stand-by dimming level
Sensor principle
Mounting height(sensor)
Motion detection
Operating temperature
IP rating
Factory Setting
FAQ'S
QUESTION
THE LUMINAIRE WILL NOT COME ON
THE LOAD IS PERMINANTLY ON
WILL NOT ILLUMINATE EVEN
THOUGH THERE IS MOVEMENT
THE REMOTE CONTROL IS NOT
WORKING
JCC Lighting Products Ltd. Lux Park, Chichester Business Park, City Fields Way, Tangmere, Chichester, West Sussex, PO20 2FT
Technical Support: +44(0)1243 838986 Customer Services: +44(0)1243 838999
12 + 1 VDC
15 + 3mA
25%/50%/75%/100%
5s/30s/1 min/3min/5min/10min/20min/30min
51ux/15Lux/30Lux/50Lux/1001ux/1501ux/Disable
0s/105/1 min/3min/5min/1 0min/30min/+ ∞
10% / 20% / 30% / 50%
PIR motion detector
10m (12m) Max.(when mounted at 12m, do not set detection area 25% or 50%, it will not detect correctly)
(0.5-1 m/s) @10m
0°C TO 40°c
IP65
Detection area:100%,Hold time:3 min, Stand-by Period: 5 min, Stand-by dim level:50%, Daylight Sensor: Disable
CAUSE
INCORRECT DAYLIGHT SENSOR SETTING
SELECTED
LOAD HAS FAILED
POWER IS SWITCHED OFF
CONTINUOUS MOVEMENT IN DETECTION
AREA
THE LUMINAIRE IS INSTALLED IN AN AREA TO
CLOSE TO REFLECTIVE SURFACES i.e. GLASS,
METAL OR CONCRETE WALLS
SPEED OF MOVING OBJECT IS NOT IN THE
RANGE OF 0.5-1M/S OR THE DETECTION
RADIUS IS TOO SMALL
BATTERY IS DEAD
THE REMOTE CONTROL IS NOT ALIGNED WITH
THE SENSOR
IP20 /IP65
(REMOTE)
ISO9001 - 2015 - Registered Firm Certificate No. GB 1552
REMEDY
ADJUST SETTING
REPLACE LOAD
SWITCH ON POWER
CHECK DETECTION AREA SETTING
1. ENSURE THAT LUMINAIRE IS INSTALLED WITH A MINIMUM
100CM SPACE BETWEEN ANY REFLECTIVE SURFACES
2.REDUCE SENSITIVITY(DETECTION AREA)
CHECK DETECTION SETTINGS
REPLACE BATTERY
CHANGE THE POSITION/ANGLE OF THE REMOTE/CHECK TOGGLE
BUTTON SETTING FOR CORRECT HEIGHT
(SENSOR WHEN INSTALLED)
