Audix OM11 Manual

OM11
Dynamic Vocal Microphone
OVERVIEW
The OM11 is a re-issue of the original OM1, a hand-made microphone first issued in
1985. Designed, assembled, machined and tested by Audix in the USA, the OM11 is
a dynamic vocal microphone used for a wide variety of live, studio, and broadcast
applications. The OM11 is known for its sharp, crisp vocal sound, resistance to
feedback and ability to handle high sound pressure levels without distortion.
The OM11 is characterized with a tight and uniformly controlled hypercardioid polar
pattern which helps to isolate the vocals from the rest of the instruments on stage.
With a wide frequency range of 50 Hz - 18 kHz, the OM11 employs a VLM™(Very
Low Mass) diaphragm for a very clean and natural sound with exceptional transient
response.
The OM11 response is tailored to cut through the mix, providing presence and
articulation to the vocals even at very high stage volumes. In addition to having
extremely low handling noise, the OM11 is well balanced, comfortable to hold,
durable and manufactured with very high standards and tight tolerances.
Roadworthy construction includes a two stage machined brass body, durable black
e-coat finish, dent resistent steel mesh grill and gold plated XLR connector.
SUPPLIED ACCESSORIES
MC1 - Heavy-duty nylon molded clip with brass insert
P1 - Carrying pouch
OPTIONAL ACCESSORIES
WS357 - Optional high quality external foam windscreen for reducing wind,
sibilance, and pop noise.
CBL20 - 20' premium XLR-XLR balanced mic cable. Quad conductor, twisted pair with
braided shield for maximum conductivity. 6mm PVC jacketed.
CBLDR25 - 25' premium right angle XLR-XLR balanced mic cable. Quad conductor,
twisted pair with braided shield for maximum conductivity. 6mm PVC jacketed.
T50K - Professional impedance matching transformer that allows a low impedance
mic to be connected to a high impedance input.
TRIPOD - Metal tripod desktop stand for use with any 5/8" threaded mic clip.
MC1 P1 WS357 CBL20 CBLDR25
FEATURES
· Concert level, professional vocal mic for live
sound, broadcast and studio
· Clear, accurate vocal sound that cuts
through the mix
· Precision machined brass construction
· Extremely low handling noise
· Handles exceptionally high SPLs without distortion
· VLM Capsule
· Designed, assembled & tested in the USA
· 5 year warranty
APPLICATIONS
· Lead or backing vocals
· Live recording
· Broadcast
· Home studio - vocal and instrument
T50K TRIPOD
OM11
