INSTALLATION AND MAINTENANCE INSTRUCTIONS
M500SAP Supervised Control Module
SPECIFICATIONS
Normal Operating Voltage: 15 to 32 VDC
Maximum Current Draw: 6.5 mA (LED on)
Average Operating Current: 375µA (LED flashing - in group poll mode) 350µA (LED flashing - in direct poll mode); 485µA Max. (LED flashing, NAC shorted)
Maximum NAC Line Loss: 4 VDC
External Supply Voltage (between Terminals T10 and T11)
Maximum (NAC): Regulated 24 VDC
Maximum (Speakers): 70.7 V RMS, 50 W
Drain on External Supply: 1.7 mA Maximum using 24 VDC supply; 2.2 mA Maximum using 80 VRMS supply
Max NAC Current Ratings: For class B wiring system, the current rating is 3A; For class A wiring system, the current rating is 2A
Temperature Range: 32°F to 120°F (0°C to 49°C)
Humidity: 10% to 93% Non-condensing
Dimensions: 4.67" H x 4.26" W x 1.40" D (119 mm H x 108 mm W x 36 mm D) Mounts to a 4" square (102 mm) by 2
Accessories: SMB500-WH Electrical Box; CB500 Module Barrier
POWER INPUT/OUTPUT RATINGS
CURRENT RATING
2 A
3 A
2 A
0.46 A
0.7 A
0.9 A
0.5 A
0.3 A
BEFORE INSTALLING
This information is included as a quick reference installation guide. Refer to
the control panel installation manual for detailed system information. If the
modules will be installed in an existing operational system, inform the opera-
tor and local authority that the system will be temporarily out of service. Dis-
connect power to the control panel before installing the modules.
NOTICE: This manual should be left with the owner/user of this equipment.
GENERAL DESCRIPTION
M500SAP Supervised Control Modules are intended for use in intelligent,
two-wire systems, where the individual address of each module is selected
using the built-in rotary switches. This module is used to switch an external
power supply, which can be a listed, regulated, supervised, power-limited DC
power supply or an audio amplifier (up to 80 VRMS), to notification appli-
ances. It also supervises the wiring to the connected loads and reports their
status to the panel as NORMAL, OPEN, or SHORT CIRCUIT. The M500SAP
has two pairs of output termination points available for fault-tolerant wiring
and a panel-controlled LED indicator.
COMPATIBILITY REQUIREMENTS
To ensure proper operation, this module shall be connected to a compatible
System Sensor control panels only (list available from System Sensor).
MOUNTING
The M500SAP mounts directly to 4-inch square (10 mm) electrical boxes.
(See Figure 2A.) The box must have a minimum depth of 2
Surface mounted electrical boxes (SMB500-WH) are available from System
Sensor. The module can also mount to the DNR(W) duct housing.
WIRING
NOTE: All wiring must conform to applicable local codes, ordinances, and
regulations. When using control modules in nonpower limited applications, the
CB500 Module Barrier must be used to meet UL requirements for the separa-
tion of power-limited and nonpower-limited terminals and wiring. The barrier
MAXIMUM VOLTAGE
25 VAC
30 VDC
30 VDC
30 VDC
70.7 VAC
125 VDC
125 VAC
125 VAC
1 / inches (54 mm).
8
1
LOAD DESCRIPTION
PF = 0.35
Resistive
Resistive, NAC, and Door Holder
(L/R = 20ms)
PF = 0.35
Resistive
PF = 0.75
PF = 0.35
must be inserted into a 4" × 4" × 2
box, and the control module must be placed into the barrier and attached to
the junction box. (See Figure 2A.) The power-limited wiring must be placed
into the isolated quadrant of the module barrier. (See Figure 2B.)
1. Install module wiring in accordance with the job drawings and appropri-
ate wiring diagrams.
2. Set the address on the module per job drawings.
3. Secure module to electrical box (supplied by installer). (See Figure 2A.)
Wire should be stripped to the appropriate length (recommended strip length
is 1 / " to 3 / ") (6 mm to 10 mm). Exposed conductor should be secured under
4 8
the clamping plate and should not protrude beyond the terminal block area.
CAUTION: Do not loop wire under terminals. Break wire run to provide super-
vision of connections.
IMPORTANT: When using the M500SAP for fire fighter telephone applica-
tions, remove Jumper (J1) and discard. The Jumper is located on the back as
shown in figure 1B. The module does not provide ring back when used as a
fire fighter telephone circuit.
J1 must be removed whenever power supply monitoring feature is not required.
NOTE: All references to power limited represent "Power Limited (Class 2)".
All references to Class A also include Class X.
3825 Ohio Avenue, Illinois 60174
1-800-SENSOR2, FAX: 630-377-6495
www.systemsensor.com
1 / " (54 mm) deep box.
8
APPLICATION
Non-coded
Non-coded
Coded
Non-coded
Non-coded
Non-coded
Non-coded
Non-coded
1 / " (102 mm × 102 mm × 54 mm) junction
8
I56-6790-001
4/17/2023
