Premio RCO-3000-RPL User Manual

Small form factor computer
Hide thumbs

Advertisement

Quick Links

Download this manual
USER'S
MANUAL
RCO-3000-RPL
Small Form Factor Computer

Advertisement

loading
Need help?

Need help?

Do you have a question about the RCO-3000-RPL and is the answer not in the manual?

Questions and answers

Related Manuals for Premio RCO-3000-RPL

Summary of Contents for Premio RCO-3000-RPL

  • Page 1 USER’S MANUAL RCO-3000-RPL Small Form Factor Computer...
  • Page 2 RCO-3000-RPL l User’s Manual Table of Contents Prefaces …………………………………………………….……………………………………………. 04 Revision …………………………………………………………………………………………..……………….……….. 04 Disclaimer ………………………………………………………..…….…….………………………….……………….. 04 Copyright Notice …………………………………….…………………….…………………………………………… 04 Trademarks Acknowledgment …………..………………………………………………………....04 Environmental Protection Announcement …………………………….………………….……………….. 04 Safety Precautions ………………………………………….……………………………….…………….………….. 05 Technical Support and Assistance …………………………………….…………….…………….…………….06 Conventions Used in this Manual ………………………………………………………………….….………..06 Package Contents …………………………………………………………………………………………….…………...
  • Page 3 RCO-3000-RPL l User’s Manual 4.3.2 CPU Configuration …………………………….………..…………………..…....86 4.3.3 PCH-FW Configuration ……………………………………..……………………..….….. 88 4.3.4 Trusted Computing ………………………….....…………..………………..89 4.3.5 ACPI Settings ………………………………………..………………….………….….………. 90 4.3.6 Super IO Configuration ……...……………………………………….…………………… 91 4.3.7 Hardware Monitor ..………………………..…….………………………………………… 98 4.3.8 Power IGN Mode ……….…………………………………………….…..…..…………... 100 4.3.9 Wake system from S5 ……………………....……………………………..…...
  • Page 4 2024/5/23 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.
  • Page 5 Preface RCO-3000-RPL l User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible.
  • Page 6 Preface RCO-3000-RPL l User’s Manual Technical Support and Assistance 1. Visit the Premio Inc website at www.premioinc.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.
  • Page 7 Preface RCO-3000-RPL l User’s Manual Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty RCO-3000-RPL Series Wall Mounting kit with Vibration Isolation Accessory Kit Ordering Information Model No.
  • Page 8 Preface RCO-3000-RPL l User’s Manual Optional Accessories Model No. Product Description 1-E09A12002 Adapter AC/DC 24V 9.2A 220W with 3pin Terminal Block Plug 5.0mm Pitch 1-E09A22801 Adapter AC/DC 24V 11.6A 280W with 3pin Terminal Block Plug 5.0mm Pitch 1-TPCD00005 Power Cord, 3-pin US Type, 180cm...
  • Page 9 Chapter 1 Product Introductions...
  • Page 10 RCO-3000-RPL l User’s Manual Chapter 1: Product Introductions 1.1 Overview The Advanced Fanless Embedded Systems RCO-3000-RPL series are designed with rich I/O, high flexibility and easy expansion capabilities which are ideal for diverse industrial applications.Support 12/13/14th Gen. Intel® Core processor, RCO-3000-RPL Series is an extreme features integration, outstanding system performance, versatile I/O connections, and rugged reliability fanless embedded systems.
  • Page 11 RCO-3000-RPL l User’s Manual Chapter 1: Product Introductions 1.2 Hardware Specification System Processor Support 12/13/14th Gen Intel® ADL & RPL S Processor (LGA 1700, 35W TDP) - Intel® Core i9-14900T/i9-13900TE/i9-12900TE, up to 24 Cores, 36MB Cache, up to 5.5 GHz - Intel®...
  • Page 12 RCO-3000-RPL l User’s Manual Chapter 1: Product Introductions Expansion 1x M.2 B key Type: 2242/3042/3052 • Support PCIe x2/PCIe x1 & USB 3.2 Gen1 • Support NVMe Storage/AI Module/4G/5G 1x M.2 B key Type: 2242/3042/3052 • Support PCIe x2/SATA signal •...
  • Page 13 RCO-3000-RPL l User’s Manual Chapter 1: Product Introductions 1.3 System I/O RCO-3000-RPL Rear Panel DP/HDMI port USB 3.2 Gen 2 Port Used to connect a DP/HDMI monitor or connect Used to connect USB 3.2 Gen 2 optional split cable for dual display mode...
  • Page 14 RCO-3000-RPL l User’s Manual Chapter 1: Product Introductions RCO-3000-RPL Front Panel Remote Power on/off Terminal Block ATX power on/off switch Used to plug a remote power on/off terminal Press to power-on or power-off the system block Power LED PC/Car mode select switch...
  • Page 15 RCO-3000-RPL l User’s Manual Chapter 1: Product Introductions 1.3.1 EDGEBoost I/O Bracket [EBIO] Model No : • • RCO-3000-RPL-D10G RCO-3000-RPL-4L • • RCO-3000-RPL-4U3 RCO-3000-RPL-4LM12 • • RCO-3000-RPL-2M2BK RCO-3000-RPL-4P • • RCO-3000-RPL-M2MK RCO-3000-RPL-4PM12...
  • Page 16 RCO-3000-RPL l User’s Manual Chapter 1: Product Introductions 1.4 Mechanical Dimensions RCO-3000-RPL Unit: mm...
  • Page 17 Chapter 2 Mechanical Specifications...
  • Page 18 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications 2.1 Switch and Connector Locations 2.1.1 Top View LAN1, LAN2 DP1, DP2, DP3 DC IN DP_HDMI FAN_SIO POWER1 JESPI1 M2_KB2 CN1 , CN2 POWER3 CAN1 JP4, JP5 M2_KE PSE_M1 CAN2 MIC_IN LAN_L1...
  • Page 19 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications 2.1.2 Bottom View SATA SATA SW17 COM5 , COM6 M2_KB1 PWR_SW3 SIM1 SIM2 PWR_SW2 LINE_OUT USB3_1 , USB3_3 PWR_SW1...
  • Page 20 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications 2.2 Connector / Switch Definition Connector Location Definition AT_ATX AT / ATX Power Mode Switch PWR_SW 1~3 Power Switch RESET Reset Switch DC_IN 3-pin DC +9V~48V Power Input Connector DIO1 8DI / 8DO Connector...
  • Page 21 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications 2.3 I/O Interface Descriptions 2.3.1 ESPI Debug Con JESPI1 Signal Signal ESPI_IO_0 3.3V ESPI_IO_1 ESPI_RESET# ESPI_IO_2 ESPI_CS# ESPI_IO_3 ESPI_CLOCK...
  • Page 22 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications 2.3.2 Power Con POWER1 Signal +12V DC IN : +9V ~ +48V 3-pin DC Power Input Connector Signal +9V ~ +48V...
  • Page 23 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications POWER3 : +9V ~ +36V Signal +9V ~ +36V +9V ~ +36V...
  • Page 24 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications 2.3.3 COM Con COM5 COM6 COM5 , COM6 Signal Signal DCD# DSR# RTS# CTS# DTR# RS232 / RS422 / RS485 Connector 2x5 10-pin box header, 2.0mm pitch RS232 Definition RS422 / 485 Full Duplex...
  • Page 25 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications COM1 , COM2 , COM3 COM1_2_3 RS232 / RS422 / RS485 Connector Type: 9-pin D-Sub RS422 / 485 Full Duplex RS485 Half Duplex RS232 Definition Definition Definition DCD# DATA- DATA+ DTR# DSR#...
  • Page 26 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications 2.3.4 SF100 SPI Con Signal Signal Power ( 3V ) MISO MOSI SPI_GATE# AT_ATX AT / ATX Power Mode Switch Switch Definition ATX Power Mode 1-2 (Left) (Default) 2-3 (Right) AT Power Mode...
  • Page 27 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications CAR_PWR PC / Car Mode Switch Switch Definition PC Power Mode 1-2 (Left) (Default) 2-3 (Right) Power Ignition Mode LINE_OUT Line-out Jack (Green) Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L...
  • Page 28 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications Mic-in Connector MIC_IN Definition MICIN_L MICIN_R Clear BIOS Switch CLR_CMOS Switch Definition 1 , 2 RTCRST-L 3 , 4...
  • Page 29 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications Power Switch PWR_SW1 Power Button Definition Definition Power Button PWR_SW2 Remote Power Switch Type: Terminal Block 1x2 2-pin, 3.5mm pitch Definition Power Button...
  • Page 30 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications Power Switch PWR_SW3 For RCO-3000-RPL Definition Power Button PWR_LED HDD_LED Reset Switch RESET Definition RESET...
  • Page 31 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications USB Connector USB3_1 , USB3_2 , USB3_3 : USB3.1 Connector, GEN2 x6 ports, Type A Definition Definition USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX- CN1 , CN2 USB3.0 Connector 2x5 10-pin header, 2.0mm pitch...
  • Page 32 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications LAN Connector LAN1 LAN2 LAN Ports Connector Type:RJ45 port with LEDs Definition LAN1_MDI0P LAN1_MDI0N LAN1_MDI1P LAN1_MDI2P LAN1_MDI2N LAN1_MDI1N LAN1_MDI3P LAN1_MDI3N Display Port Connector DP1 , DP2 , DP3 Definition Definition DP_LANE0_P DP_LANE3_N...
  • Page 33 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications Display Port / HDMI Connector DP_HDMI Definition Definition DP 0_P / HDMI 2_P DP 3_N / HDMI CK_N DP 0_N / HDMI 2_N GND / CEC DP 1_P / HDMI 1_P GND / Reserved...
  • Page 34 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications Digital Input / Output Connector DIO : Digital Input / Output Connector Type: Terminal Block 2x9 18-pin, 3.5mm pitch Definition Definition DIN1 DOUT1 DIN2 DOUT2 DIN3 DOUT3 DIN4 DOUT4 DIN5 DOUT5 DIN6...
  • Page 35 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications CAN1 CAN2 CAN1 CAN2 Signal CAN_L CAN_H FAN_SIO Signal +12V Sense Control...
  • Page 36 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications Signal SMB_CLK SMB_DATA LED Status Act LED Status Definition Blinking Yellow Data Activity No Activity Link LED Status LAN1 LAN2 Steady Green 2.5Gbps Network Link 2.5Gbps Network Link Steady Orange 1Gbps Network Link...
  • Page 37 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications LED Status PWR_LED1 Power LED Status Definition POWER LED + POWER LED - HDD_LED1 HDD Access LED Status Definition HDD LED+ HDD LED- WDT_LED WDTOUT LED Status Definition WDTOUT LED+ WDTOUT LED-...
  • Page 38 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications SIM Card Socket SIM1 (for Bottom size M.2 B Key) Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK...
  • Page 39 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications Dual Nano SIM Card Socket SIM2 (for Top size M.2 B Key) Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA I/O UIM_CLK Card Detect Switch...
  • Page 40 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications M.2 B Key Socket M2_KB2 Definition Definition CONFIG_3 +3.3V +3.3V FULL_CARD_POWER_OFF# USB_D+ W_DISABLE1# USB_D- WWAN_LED# CONFIG_0 GPIO_11(0/1.8V) W_DISABLE2# PERn1/USB3.0-Rx- USIM1_RST PERp1/USB3.0-Rx+ USIM1_CLK USIM1_DATA...
  • Page 41 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications PETn1/USB3.0-Tx- USIM1_VDD PETp1/USB3.0-Tx+ USIM2_DET PERn0 USIM2_DATA PERp0 USIM2_CLK USIM2_RST PETn0 USIM2_VDD PETp0 PCIE_RST_N PCIE_CLKREQ_N PCIE_REFCLK_M PCIE_WAKE_N PCIE_REFCLK_P USIM1_DET SUSCLK(32kHz) CONFIG_1 +3.3VAUX +3.3VAUX +3.3VAUX CONFIG_2...
  • Page 42 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications M.2 E Key Socket M2_KE Definition Definition +3.3VAUX USB2_D+ +3.3VAUX USB2_D- I2S2_SCLK CNV_WR_1_DN CNV_RF_RESET# CNV_WR_1_DP I2S2_RXD MODEM_CLKREQ CNV_WR_0_DN CNV_WR_0_DP UART_WAKE_L CNV_WR_CLK_DN CNV_BRI_RSP CNV_WR_CLK_DP CNV_RGI_DT CNV_RGI_RSP...
  • Page 43 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications TxP0 CNV_BRI_DT TxN0 CL_RST# CL_DATA RxP0 CL_CLK RxN0 CNV_PA_BLANKING CNV_MFUART2_TXD REFCLK0+ CNV_MFUART2_RXD REFCLK0- SUSCLK PERST0# M2_KEY-E_BT_DIS2# WAKE0# M2_KEY-E_WIFI_DIS1# SMBDATAS_DUAL CNV_WT_1_DN SMBCLKS_DUAL CNV_WT_1_DP SMBALERT# Pull Low CNV_WT_0_DN PERST1# CNV_WT_0_DP WAKE1# CNV_WT_CLK_DN +3.3VAUX CNV_WT_CLK_DP...
  • Page 44 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications M.2 B Key Socket M2_KB1 Definition Definition CONFIG_3 +3.3V +3.3V FULL_CARD_POWER_OFF# USB_D+ W_DISABLE1# USB_D- WWAN_LED# CONFIG_0 GPIO_11(0/1.8V) P_UIM_VPP PERn1 USIM1_RST PERp1 USIM1_CLK USIM1_DATA...
  • Page 45 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications PETn1 USIM1_VDD PETp1 PERn0/SATA-B+ PERp0/SATA-B- PETn0/SATA-A- PETp0/SATA-A+ PCIE_RST_N PCIE_CLKREQ_N PCIE_REFCLK_M PCIE_WAKE_N PCIE_REFCLK_P USIM1_DET SUSCLK(32kHz) CONFIG_1 +3.3VAUX +3.3VAUX +3.3VAUX CONFIG_2...
  • Page 46 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications PCI-Express x1 Slot R/A LAN_L1 Definition Definition TxP0 RxP0 TxN0 RxN0 PSE_OUT1 TxP1 RxP1 TxN1 RxN1 PSE_OUT2 TxP2 RxP2 TxN2 RxN2 PSE_OUT3 TxP3 RxP3 TxN3 RxN3 WAKE# PSE_OUT4 RESET# REFCLK+ +3.3V REFCLK- +3.3V...
  • Page 47 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications PCI-Express x4 Slot PSE_M1 Definition Definition 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN...
  • Page 48 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications I2C DATA I2C CLOCK 3.3V PSE_OUT1 3.3V PSE_OUT2 3.3V PSE_OUT3 PSE_OUT4 PSE_OUT5 PSE_OUT6 PSE_OUT7 PSE_OUT8...
  • Page 49 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications SATA with Power Connector SATA Definition Definition +12V DEVSLP +12V +12V...
  • Page 50 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications OOB control signal Signal PWRBTN# SLP_RSTBTN# SYS_PWROK JP4 OOB Auto Link Signal COM4_Rx COM4_Tx JP5 OOB Remote Debug port Signal COM1_Rx COM1_Tx...
  • Page 51 RCO-3000-RPL l User’s Manual Chapter 2: Mechanical Specifications COM1 or OOB Remote Debug port selection 2PIN NHDS-02 SW17 SW17 COM1 Tx OOB Remote Tx COM1 Rx OOB Remote Rx...
  • Page 52 Chapter 3 System Setup...
  • Page 53 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.2 Removing chassis bottom cover In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.
  • Page 54 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 3.3 Removing chassis top cover 1. Unscrew the four screws (M3x5L) as highlighted below. 2. Hold the body of the system and remove from the external cover in an upward motion away from the external cover as pictured below.
  • Page 55 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 3.4 Installing CPU 1. CPU socket is located at the top side, as highlighted below. 2. Remove the CPU protective cover. 3. Press down the CPU socket lever in order to release the socket.
  • Page 56 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 4. Insert CPU gently. (Pay attention to the CPU fool-proof notch) 5. Put the CPU retainer bracket back in place. 6. Press down the CPU socket lever in order to secure the socket.
  • Page 57 RCO-3000-RPL l User’s Manual Chapter 3: System Setup Attach the thermal pad to the CPU and remove the plastic mold. (Note: Remove the plastic film of the thermal pad before attaching it to the CPU) 8. Place the designated heat block onto the CPU with thermal pad. Lock the heat block with three screws (M3x5L) as highlighted in red circles below.
  • Page 58 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 3.5 Installing SODIMM 1. Place the system body with SODIMM socket facing upward. 2. Insert memory module at a 45-degree angle. 3. Press the memory module vertically downward until you hear the “click” sound. Make sure the...
  • Page 59 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 4. Place the designated thermal pad heat block onto the Memory with thermal pad. Lock the heat block with four screws (M3x5L) as highlighted in red circles below. The four screws will safely lock the heat block onto the four copper studs that are screwed into the motherboard.
  • Page 60 Antenna RCO-3000-RPL Series PCBA features two M.2 B Key slots, with the first one located on the top (M.2 B Key 2) and the second on the back (M.2 B Key 1). We will focus on the M.2 B Key 2 slot at the top first.
  • Page 61 3. Press the 4G/5G card down and secure with one screw (M2x4L). 4. RCO-3000-RPL Series system has 5 antenna holes, 2 are located on the rear panel and the other 3 are located on the front panel as pictured below.
  • Page 62 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 6. Install the SMA female jack through the antenna holes, and then fasten on the SMA male plug. 7. Fix the end of the cable of the Wireless RF connector onto the communication module as shown in the picture below.
  • Page 63 Chapter 3: System Setup RCO-3000-RPL l User’s Manual Now, let’s set up the other M.2 B Key slot at the back. M.2 B Key 1 1. Place a copper pillar (M.3x6.6L) at the location highlighted below. 2. Insert 4G/5G card at a 45-degree angle.
  • Page 64 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 4. Remove antenna hole cover on the system panel. 5. Install the SMA female jack through the antenna holes, and then fasten on the SMA male plug. 6. Fix the end of the cable of the Wireless RF connector onto the communication module as shown in the picture below.
  • Page 65 3.7 Installing Wi-Fi Module and Antenna RCO-3000-RPL Series PCBA has an M.2 E Key slot on the top, which currently supports Wi-Fi application. M.2 E Key 1. Insert Wi-Fi card at a 45-degree angle. 2. Press the Wi-Fi card down and secure with one screw (M2x4L).
  • Page 66 RCO-3000-RPL l User’s Manual Chapter 3: System Setup Remove antenna hole cover on the system panel. Install the SMA female jack through the antenna holes, and then fasten on the SMA male plug. Fix the end of the cable of the Wireless RF connector onto the communication module as shown in the picture below.
  • Page 67 Chapter 3: System Setup 3.8 Installing HDD on internal SATA HDD bay 1. One internal SATA HDD bay is available for RCO-3000-RPL series. 2. Unscrew the four screws (M3x5L) to remove the internal SATA HDD bay. 3. Lock the 2.5” HDD with HDD bracket using four screws (M3x4L).
  • Page 68 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 4. Install the HDD bracket following the direction below. 5. Fasten the four screws to lock the internal HDD bracket.
  • Page 69 Chapter 3: System Setup 3.9 Installing HDD on removable SATA HDD tray 1. One removable SATA HDD tray available for RCO-3000-RPL Series. Open the tray lock (as highlighted in red circle) ,and remove the tray. 2. Unlock the drive lock and insert the HDD/SSD.
  • Page 70 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 3.10 Assembling chassis top cover 1. Pictured below is the separated system body (left) and external cover (right). 2. Turn the system body upside down and place it vertically towards the external cover.
  • Page 71 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 3.11 Assembling chassis bottom cover 1. Place the bottom cover according to the below direction and make sure the rail is facing inside the system. 2. Secure the bottom cover with the six screws (M3x5L).
  • Page 72 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 3.12 Installing SIM card 1. Pull out the SIM card tray in order to put the Mini SIM cards. 2. Place the Mini SIM card on the front of the tray for SIM1.
  • Page 73 RCO-3000-RPL l User’s Manual Chapter 3: System Setup Insert SIM card into the socket for SIM3. Please note that the installation of SIM cards has to match the installation of M.2 B Key slots SIM Card Socket Number Matching M.2 B Key slots SIM 1/2 M.2 B Key 2...
  • Page 74 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 3.13 SIM OS Settings Place the Mini SIM card on front of the tray for SIM1. The Cellular menu will show the SIM 1/2 option. SIM 1 When the Mini SIM card on the front tray for SIM1 is inserted,...
  • Page 75 RCO-3000-RPL l User’s Manual Chapter 3: System Setup Place the Mini SIM card on back of the tray for SIM2. The Cellular menu will show the SIM 1/2 option. SIM 2 When the Mini SIM card on the back tray for SIM2 is inserted,...
  • Page 76 RCO-3000-RPL l User’s Manual Chapter 3: System Setup Insert a SIM card into the SIM 3 socket. The Cellular menu will show the SIM 1/2 option. Once the SIM card is inserted, the operating system will automatically connect to SIM1 (as shown in the image).
  • Page 77 RCO-3000-RPL l User’s Manual Chapter 3: System Setup When SIM cards are inserted into both the SIM1/2 slot and the SIM3 socket, the Cellular menu will display two separate SIM options. Users can select which SIM card to use for external connections as...
  • Page 78 Chapter 3: System Setup 3.14 Installing Wall-Mount Kit 1. The Wall-Mount Kit is provided with the RCO-3000-RPL as a standard package. M4*13 2. Place the system upside down so you can see the bottom cover. Secure the wall-mount kit with...
  • Page 79 Chapter 3: System Setup 3.15 Installing DIN rail holder 1. Din rail holder is available for RCO-3000-RPL series as optional accessories. (3-DINR-0004) DinRail-2MountingKit 2. Place the system upside down so you can see the bottom cover with two screw holes for din rail...
  • Page 80 RCO-3000-RPL l User’s Manual Chapter 3: System Setup 3. Place the din rail holder on top of the bottom cover and secure with two screws (M4x5L, Nylok).
  • Page 81 Chapter 4 BIOS Setup...
  • Page 82 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.1 BIOS Introduction The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del> immediately allows you to enter the setup screens.
  • Page 83 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu.
  • Page 84 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3 Advanced Setup...
  • Page 85 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.1 Connectivity Configuration Item Options Description CNVi Mode Disable Integrated, This option configures Connectivity. [Auto Auto Detection[Default] Detection] means that if Discrete solution is discovered it will be enabled by default. Otherwise Integrated solution (CNVi) will be enabled;...
  • Page 86 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.2 CPU Configuration Item Options Description Intel (VMX) Virtualization Disabled, When enabled, a VMM can utilize the Technology Enabled[Default] additional hardware capabilities provided by Virtualization Technology. Active Performance-cores All[Default] , Number of P-cores to enable in each processor 5,4,3, package.
  • Page 87 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.2.1 Efficient-core Information 4.3.2.2 Performance-core Information...
  • Page 88 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.3 PCH-FW Configuration Item Options Description AMT BIOS Features Disabled, When disabled AMT BIOS Features are no longer Enabled[Default] supported and user is no longer able to access MEBx Setup. Note:This option does not disable Manageability Features in FW.
  • Page 89 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.4 Trusted Computing Item Options Description Security Device Support Enabled, Enable/Disable BIOS support for security Disabled[Default] , device. O.S. will not show Security Device.TCG EFI protocol and INT1A interface will not be available.
  • Page 90 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.5 ACPI Settings Item Options Description Enable Hibernation Disabled , Enables or Disables System ability to Enabled[Default], Hibernate (OS/S4 Sleep State). This option may not be effective with some operating systems. ACPI Sleep State...
  • Page 91 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.6 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA).
  • Page 92 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 1 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=3F8h; IRQ=4; , IRQ settings of the specified serial port.
  • Page 93 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 2 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=2F8h; IRQ=3; , IRQ settings of the specified serial port.
  • Page 94 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 3 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=3E8h; IRQ=7; , IRQ settings of the specified serial port.
  • Page 95 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 4 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=2F0h; IRQ=7; , IRQ settings of the specified serial port.
  • Page 96 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 5 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=2E0h; IRQ=7; , IRQ settings of the specified serial port.
  • Page 97 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 6 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=2E8h; IRQ=7; , IRQ settings of the specified serial port.
  • Page 98 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.7 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. Item Options Description Smart Fan Function Disabled, Enabled or Disable Smart Fan...
  • Page 99 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ Smart Fan Mode Configuration Item Options Description FanSIO SmartFan Manual Mode, Smart Fan Mode Select Control Auto Duty-Cycle Mode[Default], Temperature 1~4 1~100 Auto fan speed control. Temperature 1-100 Duty Cycle 1~4 20~100 Auto fan speed control.
  • Page 100 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.8. Power IGN Mode Item Options Description IGN Setting Read mode[Default] Read IGN: BIOS will only read settings from IGN Write IGN module. Write IGN: BIOS will overwrite settings in IGN module.
  • Page 101 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.9. Wake system from S5 Item Options Description Wake system from S5 Disabled[Default] , Enable or disable System wake on alarm event. Fixed Time, Select FixedTime, system will wake on the Dynamic Time, hr::min::sec specified.
  • Page 102 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.10 Serial Port Console Redirection Item Options Description Console Redirection Disabled[Default], These items allows you to enable or disable Enabled COM1 console redirection...
  • Page 103 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.11 USB Configuration Item Options Description Legacy USB Support Enabled[Default] Enables Legacy USB support. AUTO option Disabled disables legacy support if no USB devices are Auto connected. DISABLE option will keep USB devices available only for EFI applications.
  • Page 104 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.12 Network Stack Configuration Item Options Description Network Stack Disabled[Default] , Enable/Disable UEFI Network Stack. Enabled IPv4 PXE Support Disabled[Default] , Enable/Disable IPv4 PXE boot support. If Enabled disabled, IPv4 PXE boot support will not be available.
  • Page 105 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.13 NVMe Configuration...
  • Page 106 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.3.14 RST (UEFI RAID) Configuration How to set the UEFI RAID: 1. When set to “Enable VMD controller“, please save change reset system. 2. After reboot the system, please into BIOS utility and then will see “Intel (R) Rapid Storage...
  • Page 107 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 3. Into Intel(R) Rapid Storage Technology, and start create RAID volume. 4. Start Create the RAID ■ Select Disk that you want to do the RAID ■ Select [x]; No-Select [ ]...
  • Page 108 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.4.1 System Agent (SA) Configuration Item Options...
  • Page 109 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ Memory Configuration...
  • Page 110 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ Graphic Configuration Item Options Description GTT Size 2MB, Select the GTT Size . 4MB, 8MB[Default] Aperture Size 128MB, Select the Aperture Size. 256MB[Default] , Note : Above 4GB MMIO BIOS assignment is...
  • Page 111 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ VMD Configuration Item Options Description Enable VMD Enabled[Default] , Enable/Disable to VMD controller controller Disabled...
  • Page 112 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.4.2 PCH-IO Configuration Item Options Description Restore AC Power Loss Power On, Specify what state to go to when power is re- Power Off [Default] , applied after a power failure (G3 state).
  • Page 113 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ PCI Express Configuration...
  • Page 114 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ PCI Express Root Port 1 /3 /7 /21 /23 /27 Item Options Description PCI Express Root Port Disabled, Control the PCI Express Root Port. Enabled [Default] 1 /3 /7 /21 /23 /27...
  • Page 115 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ SATA Configuration Item Options Description SATA Controller(s) Enabled[Default] Enable/Disable SATA Device. Disabled SATA Port Disabled, Enable/Disable SATA Port. Enabled[Default] Hot Plug Disabled, Designates this port as Hot Pluggable. Enabled[Default] SATA Device Type...
  • Page 116 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ HD Audio Configuration Item Options Description HD Audio Disabled, Control Detection of the HD-Audio device. Enabled [Default] Disabled = HDA will be unconditionally disabled Enabled = HDA will be unconditionally enabled.
  • Page 117 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.5 Security Security menu allow users to change administrator password and user password settings. ■ Administrator Password This item allows you to set Administrator Password. ■ User Password This item allows you to set User Password.
  • Page 118 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ Security Boot Item Options Description Secure Boot Disabled [Default] , Secure Boot feature is Active if Secure Boot is Enabled Enabled,Platform Key(PK) is enrolled and the System is in User mode.
  • Page 119 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup ■ Key Management Item Options Description Factory Key Provision Disabled [Default] , Install factory default Secure Boot keys after Enabled the platform reset and while the System is in Setup mode...
  • Page 120 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.6 Boot This menu allows you to setup the system boot options. Item Options Description Setup Prompt Timeout 1[Default] Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.
  • Page 121 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.7 Save & Exit This setting allows users to configure the boot settings. ■ Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.
  • Page 122 RCO-3000-RPL l User’s Manual Chapter 4: BIOS Setup 4.8 MEBx Item Options Description Intel(R) ME MEBx Login Password...
  • Page 123 Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).
  • Page 124 RCO-3000-RPL l User’s Manual Appendix – WDT & GPIO WDT Sample Code WDT Setting Psuedo Code // IO Address 0xA16 is time value(second) // IO Address 0xA15 is WDT enable and configuration Example, Set 0xA16=-0x02, 0xA15=0x31, it will reset after 2 seconds...
  • Page 125 DIO Input1 The GPIO function is provided by Nuvoton M058SSAN , and it can be accessed through Smbus/I2C port. The configuration on the RCO-3000-RPL is described as below. Psuedo Code #define GPI_ADDR 0x02 // Define Input port Address #define GPO_ADDR 0x01...
