Premio RCO-6000-CFL Series User Manual

Ai edge inference computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S
MANUAL
RCO-6000-CFL Series
AI Edge Inference Computer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RCO-6000-CFL Series and is the answer not in the manual?

Questions and answers

Related Manuals for Premio RCO-6000-CFL Series

Summary of Contents for Premio RCO-6000-CFL Series

  • Page 1 USER’S MANUAL RCO-6000-CFL Series AI Edge Inference Computer...

  • Page 2: Table Of Contents

    RCO-6000-CFL l User’s Manual Table of Contents Prefaces ……………………………………………………………………………………………….. 04 Revision ………………………………………………………..……………………………..……………….……….. 04 Disclaimer ……………………………………………………….…….……………….………………….………….. Copyright Notice …………………………………….…….….………………………………….………………… Trademarks Acknowledgment …………..………….………………………………………....Environmental Protection Announcement ……………………………………..……..……………….. Safety Precautions ……………………………………………………………………………………….….…….. Technical Support and Assistance ………………………………...……………………..…….…….……. Conventions Used in this Manual …………………………………..……………………..….……….. Package Contents ……………………………………………………………………..…..…………………….… Ordering Information …………………………..……………………………………..………..….….…………...
  • Page 3 RCO-6000-CFL l User’s Manual Installing SODIMM ……………...…………………………..….……………………………..74 Installing CPU ……………………...………………………………….….……………………..75 Installing Mini PCIe card ………..............80 Installing M.2 2280 NVMe SSD ​ ..............81 3.10 Installing WiFi Module ..………...…….………………….……………………..…………..82 3.11 Installing Mini PCIe card / 4GLTE………..…………………………………………………... 85 3.12 Installing Antenna ………………...…….………………….……………………..…………..

  • Page 4: Prefaces

    2020/11/01 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.

  • Page 5: Safety Precautions

    Preface RCO-6000-CFL l User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions:  Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage.  The power outlet shall be installed near the equipment and shall be easily accessible. ...

  • Page 6: Technical Support And Assistance

    Preface RCO-6000-CFL l User’s Manual Technical Support and Assistance 1. Visit the Premio Inc website at https://premioinc.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.

  • Page 7: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty RCO-6000-CFL Series AI Edge Inference Computer Wall Mount Kit Accessory Kit DVI to VGA Adapter Ordering Information Model No.

  • Page 8: Optional Accessory

    Preface RCO-6000-CFL l User’s Manual Model No. Product Description Industrial Computer with LGA 1151 for Intel® 8 Gen CPU & Q370 PCH, 2x LAN, RCO-6000-CFL-2060S RTX 2060 Super Integrated Available Module： • 4L：4x LAN Ports • 4LM12：4x M12 LAN Ports •...

  • Page 9: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 10: Overview

    RCO-6000-CFL series are ruggedized systems that can operate in harsh environments and easy to install and maintain. A build in over voltage protection (OVP), over current protection (OCP), reverse protection, and wide range DC power input makes RCO-6000-CFL series are safety system for all industrial applications.

  • Page 11: Key Feature

    Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual 1.1.1 Key Features  LGA 1151 socket for 8th/9th Gen. Intel® CFL-R S Processor Pentium® / Celeron® Desktop Processor  Intel® Q370 chipset  2x DDR4 2400/2666Hz SODIMM. Max. up to 64GB ...

  • Page 12: Hardware Specification

    Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual 1.2 Hardware Specification System Chipset Intel® Q370 Express Chipset System LAN Chipset GbE1: Intel I219LM (Support Wake-on-LAN Processor and PXE) GbE2: Intel I210-AT (Support Wake-on-LAN Support 8th/9th Gen Intel® CFL-R S Processor (LGA 1151, 65W/35W and PXE) TDP) GbE3~GbE6: Intel I350-AM4 (Optional)
  • Page 13 Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual Operating System Windows Windows 10 Linux Linux kernel 5.X Audio 1x Mic-in, 1x Line-out 4x RS-232/422/485, 2x RS-232/422/485 (internal) 8 in / 8 out (Isolated) 2x RJ45 Universal I/O Bracket 1x Universal I/O Bracket (By mini PCIe interface) 4x USB 3.2 Gen 2 (10 Gbps) 5x USB 3.2 Gen 1 (5 Gbps) 1x USB 3.2 Gen 1 header (5 Gbps, internal)
  • Page 14 Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual Environment -25 ° C to 70 ° C (35W CPU) ; -25 ° C to 60 ° C (65W CPU) Operating Temp. RCO-6000-CFL-2060S ： -25 ° C to 60 ° C (35W/65W CPU) -30 °...

  • Page 15: System I/O

    Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual 1.3 System I/O 1.3.1 RCO-6000-CFL Front Panel ATX power on/off switch Power LED Press to power-on or power-off the system Indicates the power status of the system Reset switch HDD LED Press to reset the system Indicates the status of the hard drive USB 3.2 Gen 2 port (10 Gbps) Watchdog LED...
  • Page 16 Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual RCO-6000-CFL Rear Panel DC IN DisplayPort Used to plug a DC power input with terminal Used to connect a DisplayPort monitor block USB 3.2 Gen 2 port (10 Gbps) Digital I/O Terminal Block Used to connect USB 3.2 device The Digital I/O terminal block supports 8 digital input and 8 digital output...

  • Page 17: Rco-6000-Cfl-2

    Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual 1.3.2 RCO-6000-CFL-2 Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch Power LED Press to power-on or power-off the system Indicates the power status of the system Reset switch HDD LED Press to reset the system Indicates the status of the hard drive...
  • Page 18 Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual RCO-6000-CFL-2 Rear Panel Top Module (Industrial Fanless PC on Top) DC IN DisplayPort Used to plug a DC power input with terminal Used to connect a DisplayPort monitor block USB 3.2 Gen 2 port (10 Gbps) Digital I/O Terminal Block Used to connect USB 3.2 device The Digital I/O terminal block supports 8 digital...

  • Page 19: Rco-6000-Cfl-2-2Pwr

    Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual 1.3.3 RCO-6000-CFL-2-2PWR Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch Power LED Press to power-on or power-off the system Indicates the power status of the system Reset switch HDD LED Press to reset the system Indicates the status of the hard drive...
  • Page 20 Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual RCO-6000-CFL-2-2PWR Rear Panel Top Module (Industrial Fanless PC on Top) DC IN DisplayPort Used to plug a DC power input with terminal Used to connect a DisplayPort monitor block USB 3.2 Gen 2 port (10 Gbps) Digital I/O Terminal Block Used to connect USB 3.2 device The Digital I/O terminal block supports 8 digital...

  • Page 21: Rco-6000-Cfl-2060S

    Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual 1.3.4 RCO-6000-CFL-2060S Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch Power LED Press to power-on or power-off the system Indicates the power status of the system Reset switch HDD LED Press to reset the system Indicates the status of the hard drive...
  • Page 22 Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual RCO-6000-CFL-2060S Rear Panel Top Module (Industrial Fanless PC on Top) DC IN DisplayPort Used to plug a DC power input with terminal Used to connect a DisplayPort monitor block USB 3.2 Gen 2 port (10 Gbps) Digital I/O Terminal Block Used to connect USB 3.2 device The Digital I/O terminal block supports 8 digital...

  • Page 23: Universal I/O Bracket

    Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual 1.3.5 Universal I/O Bracket Available Module : LAN/PoE Module 4x RJ45 LAN/PoE Ports M12 Module 4x M12 LAN/PoE Ports D10G Module 2x 10Gb Ports USB Module 4x USB 3.2 Gen 1 Ports 5G Module 2x 5G SIM Slot (Support 1x Universal Slot Only)

  • Page 24: Mechanical Dimension

    Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual 1.4 Mechanical Dimensions 1.4.1 RCO-6000-CFL Unit: mm...

  • Page 25: Rco-6000-Cfl-2

    Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual 1.4.2 RCO-6000-CFL-2 Unit: mm...

  • Page 26: Rco-6000-Cfl-2-2Pwr

    Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual 1.4.3 RCO-6000-CFL-2-2PWR Unit: mm...

  • Page 27: Rco-6000-Cfl-2060S

    Chapter 1: Product Introductions RCO-6000-CFL l User’s Manual 1.4.4 RCO-6000-CFL-2-2060S Unit: mm...

  • Page 28: Chapter 2 Switches And Connectors

    Chapter 2 Switches and Connectors...

  • Page 29: Switch And Connector Locations

    Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.1 Switch and Connector Locations 2.1.1 Top View...

  • Page 30: Bottom View

    Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.1.2 Bottom View...

  • Page 31: Connector / Switch Definition

    Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition AT_ATX1 AT / ATX Power Mode Switch PWR_SW1 Power Switch RESET1 Reset Switch USB 3.2 Gen 2 、 USB 3.2 Gen 1 、 USB2.0 SIM1, SIM2 SIM Card Socket COM3_4, COM1_2...

  • Page 32: I/O Interface Descriptions

    Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions 2.3.1 LPC Debug Con Signal Signal +3.3V LPC_AD3 LPC_AD2 Reset LPC_AD1 LPC_FRAME-L LPC_AD0 Clock...

  • Page 33: Power Con

    Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions 2.3.2 Power Con POWER1 Signal +12V...

  • Page 34: Dc In/Ign In (+9V ~ +48V)

    Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions 2.3.3 DC IN/IGN IN (+9V ~ +48V) DC_IN1 Signal +DC_IN IGN_SENSE...

  • Page 35: Com Con

    Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions 2.3.4 COM Con COM5_1 , COM6_1 Signal Signal DCD# DSR# RTS# CTS# DTR# RS232 / RS422 / RS485 Connector 2x5 10-pin box header, 2.0mm pitch RS232 Definition RS422 / 485 Full Duplex Definition RS485 Half Duplex Definition DCD# DATA-...
  • Page 36 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions COM1_2 , COM3_4 RS232 / RS422 / RS485 Connector Type: 9-pin D-Sub RS422 / 485 Full Duplex RS232 Definition RS485 Half Duplex Definition Definition 1(10) DCD# DATA- 2(11) DATA+ 3(12)

  • Page 37: Sf100 Spi Con

    Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions 2.3.5 SF100 SPI Con Signal Signal Power ( 3V ) MISO MOSI SPI_GATE#...
  • Page 38 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions AT_ATX1 CAR_PWR1 CAR_PWR1 AT_ATX1 AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Left) ATX Power Mode (Default) 2-3 (Right) AT Power Mode CAR_PWR1: PC / Car Mode Switch Switch Definition 1-2 (Left)
  • Page 39 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions DELAY_TIME1 Power off delay time setup Switch Switch 1 / 2 / 3 Definition ON / ON / ON 3 sec.（Default Shutdown Timer by O.S） ON / ON / OFF 1 min.
  • Page 40 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions LINE_OUT1 MIC_IN1 LINE_OUT1 : MIC_IN1 : Line-out Jack (Green) Connector Type: 5- Microphone Jack (Pink) Connector Type: pin Phone Jack 5-pin Phone Jack Definition Definition OUT_R MIC_R OUT_L MIC_L...
  • Page 41 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions CLR_CMOS1: Clear BIOS Switch Switch Definition 1-2 (Left) Normal Status (Default) 2-3 (Right) Clear BIOS PWR_SW1: Power Button Definition Definition Power Button...
  • Page 42 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions RESET1 : Reset Button Definition RESET USB3_1 : USB3.1 Connector, Type A Definition Definition USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX-...
  • Page 43 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions CN7 : USB3.0 Connector 2x5 9-pin header, 2.0mm pitch Definition Definition USB3_TX- USB2_D- USB3_TX+ USB2_D+ USB3_RX- USB3_RX+...
  • Page 44 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions CN6 : USB3.1 Connector, Type A x 4 Definition Definition USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX-...
  • Page 45 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions SIM1 : Top side SIM Card Socket SIM2 : Bottom side SIM Card Socket SIM1 SIM2 Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK...
  • Page 46 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions DVI_I1: DVI-I Connector Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0- DVI_TX0+ VGA_DDC_CLOCK DVI_DDC_CLOCK VGA_DDC_DATA DVI_DDC_DATA VGA VSYNC DVI_TXCLK+ DVI_TX1- DVI_TXCLK- DVI_TX1+ VGA_RED VGA_GREEN VGA_BLUE VGA_HSYNC...
  • Page 47 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions DP1 DP2 : Display Port Connector Definition Definition DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P DP_LANE1_N DP_LANE2_P DP_AUX_N DP_HPD DP_LANE2_N DP_LANE3_P +3.3V...
  • Page 48 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions DIO : Digital Input / Output Connector Type: Terminal Block 2x9 18-pin, 3.5mm pitch Definition Definition DIN1 DOUT1 DIN2 DOUT2 DIN3 DOUT3 DIN4 DOUT4 DIN5 DOUT5 DIN6 DOUT6 DIN7 DOUT7...
  • Page 49 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions Digital Input Wurung Digital Output Wurung...
  • Page 50 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions PWR_SW2 : Remote Power Switch Type: Terminal Block 1x2 2-pin, 3.5mm pitch Definition Power Button...
  • Page 51 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions PWR_SW3 : Remote Power Switch 1x4 pin box header, 2.0mm pitch Definition Power Button PWR_LED HDD_LED...
  • Page 52 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions CN3 CN4 : LAN and USB3.1 GEN 2 Ports Connector Type:RJ45 port with LEDs and dual USB3.1 ports Definition Definition Definition LAN1_MDI0P USB2_D1- USB2_D2- LAN1_MDI0N USB2_D1+ USB2_D2+ LAN1_MDI1P LAN1_MDI2P USB3_RX1-...
  • Page 53 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions Act LED Status Definition Blinking Yellow Data Activity No Activity Link LED Status Definition Steady Orange 1Gbps Network Link Steady Green 100Mbps Network Link 10Mbps Network Link PWR_LED1: Power LED Status Definition POWER LED+...
  • Page 54 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions MINIPCIE2 : Mini PCI-Express Socket Definition Definition WAKE# +3.3V +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST UIM_VPP RESET# +3.3VAUX +1.5V SMB_CLK SMB_DATA USB2_D- USB2_D+ +3.3V +3.3V +1.5V +3.3V...
  • Page 55 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions MINIPCIE1 : Mini PCI-Express / mSATA Socket Definition Definition WAKE# +3.3V +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST UIM_VPP RESET# +3.3VAUX +1.5V SMB_CLK SMB_DATA USB2_D- USB2_D+ +3.3V +3.3V DEVSLP...
  • Page 56 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions SATA with Power Connector Definition Definition +12V DEVSLP +12V +12V...
  • Page 57 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x1 Slot Definition Definition +12V FAN_P4 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# FAN_P3 REFCLK+ TxP0 REFCLK- TxN0 RxP0 FAN_PER RxN0...
  • Page 58 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x8 Slot Definition Definition +12V +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# REFCLK+ TxP0 REFCLK- TxN0 RxP0 RxN0...
  • Page 59 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x8 Slot Definition Definition TxP1 TxN1 RxP1 RxN1 TxP2 TxN2 RxP2 RxN2 TxP3 TxN3 RxP3 RxN3 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN...
  • Page 60 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition +12V FAN_P4 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# FAN_P3 REFCLK+ TxP0 REFCLK- TxN0 RxP0 FAN_PWR RxN0...
  • Page 61 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition TxP1 TxN1 RxP1 RxN1 TxP2 TxN2 RxP2 RxN2 TxP3 TxN3 RxP3 RxN3 CFG_5 TxP4 CFG_6 TxN4 RxP4 RxN4 TxP5 TxN5 RxP5 RxN5 TxP6...
  • Page 62 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions PCIE : PCI-Express x16 Slot Definition Definition TxN8 RxP8 RxN8 TxP9 TxN9 RxP9 RxN9 TxP10 TxN10 RxP10 RxN10 TxP11 TxN11 RxP11 RxN11 TxP12 TxN12 RxP12 RxN12 TxP13 TxN13 RxP13 RxN13...
  • Page 63 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions CN1 : M.2 E Key Socket Definition Definition +3.3VAUX USB2_D+ +3.3VAUX USB2_D- LED1# LED2# TxP0 TxN0 RxP0 RxN0...
  • Page 64 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions CN1 : M.2 E Key Socket Definition Definition REFCLK0+ REFCLK0- SUSCLK PERST0# WAKE0# TxP1 TxN1 Pull Low RxP1 PERST1# RxN1 WAKE1# REFCLK1+ +3.3VAUX REFCLK1- +3.3VAUX...
  • Page 65 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions CN2 : M.2 M Key Socket Definition Definition +3.3V +3.3V RxN3 RxP3 LED# TxN3 +3.3V TxP3 +3.3V +3.3V RxN2 +3.3V RxP2 TxN2 TxP2 RxN1 RxP1 TxN1...
  • Page 66 Chapter 2: Switches and Connectors RCO-6000-CFL l User’s Manual 2.3 I/O Interface Descriptions CN2 : M.2 M Key Socket Definition Definition TxP1 Pull Low RxN0/SATA_B+ RxP0/SATA_B- TxN0 TxP0 PERST# Pull Hi REFCLK- WAKE# REFCLK+ SUSCLK PEDET +3.3V +3.3V +3.3V...

  • Page 67: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 68: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing

    Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.2 Disconnecting expansion module from computing module In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.
  • Page 69 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 2. Remove the 5 screws highlighted below. 3. Now you can separate the expansion module from the computing module.

  • Page 70: Removing Chassis Top Cover

    Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.3 Removing chassis top cover 1. Unscrew the four screws (M3x5L) highlighted below. 2. Hold the body of the system and lift it vertically away from the top cover. 3. Top cover separated from the system body.

  • Page 71: Install Hdd/Ssd On The Internal Sata Bay

    RCO-6000-CFL l User’s Manual 3.4 Install HDD/SSD on the internal SATA bay 1. One internal SATA HDD/SSD bays are available for RCO-6000-CFL series. Unscrew the 4 screws (M3x5L) to remove the internal SATA HDD/SSD bay. 2. Lock the 2.5” HDD with HDD/SSD bracket using four screws (M3x4L).
  • Page 72 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3. Install the HDD/SSD bracket following the direction below. 4. Fasten the 4 screws to lock the internal HDD/SSD bracket.

  • Page 73: Installing Hdd On Removable Sata Hdd/Ssd Bay

    Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.5 Installing HDD on removable SATA HDD/SSD bay 1. Open the tray lock (red circle) ,and remove the tray in the direction of the arrow. 2. Unlock the drive lock (red circle) 3.

  • Page 74: Installing Sodimm

    3.6 Installing SODIMM 1. Place the system body with SODIMM socket facing upward. Two SODIMM sockets are available for RCO-6000-CFL series on the top side. 2. Insert memory module from 45 degree direction. 3. Press the memory module vertically downward until you hear the “click” sound. Make...

  • Page 75: Installing Cpu

    Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.7 Installing CPU 1. Press down the CPU socket lever in order to open the socket cover. 2. Remove the CPU protective cover.
  • Page 76 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3. Insert CPU gently. 4. Press down the lever again to hold the socket cover.
  • Page 77 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 5. Paste thermal pad on the CPU. 6. Place the designated heat block onto the CPU with thermal pad.
  • Page 78 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 7. Lock the heat block with three screws (M3x5L). Screw driver will able to penetrate through the holes on the top in order to fasten the screws with copper stud. 8. Paste the thermal pad onto the installed heat block.
  • Page 79 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 9. Paste the thermal pad onto the installed heat block.

  • Page 80: Installing Mini Pcie Card

    Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.8 Installing Mini PCIe card The RCO-6000-CFL series has two Mini PCIe slots, both of which are on the top. The MINI-PCIE1 supports mSATA. MINI-PCIE1 1. Insert Mini PCIe card from 45 degree direction.

  • Page 81: Installing M.2 2280 Nvme Ssd

    Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.9 Installing M.2 2280 NVMe SSD RCO-6100 series PCBA has an M.2 M key slot on the top, CN2 currently supports NVMe SSD applications 1. Insert M.2 M Key card from 45 degree direction. 2.

  • Page 82: Installing Wifi Module

    Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.10 Installing WiFi Module RCO-6000-CFL series PCBA has an M.2 E key slot on the top, M2_KE currently supports WiFi application 1. Insert M.2 E Key card from 45 degree direction. M2_KE...
  • Page 83 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3. RCO-6000-CFL series system has 5 antenna holes, 2 on the rear panel, 3 on the front panel. 4. Have antenna jack penetrate through the hole, and fasten the nut with SMA jack.
  • Page 84 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 5. Assemble the antenna and SMA jack together. 6. Attach the RF connector at the cable-end onto the communication module.

  • Page 85: Installing Mini Pcie Card / 4Glte

    Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.11 Installing Mini PCIe card / 4G LTE RCO-6000-CFL series PCBA has two Mini PCIe slots on the top, both currently supports 4G LTE applications. MINI-PCIE2 1. Insert Mini PCIe card from 45 degree direction.

  • Page 86: Installing Antenna

    Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.12 Installing Antenna 1. Remove antenna hole cover on the system panel. 2. Have antenna jack penetrate through the hole, and fasten the nut with SMA jack...
  • Page 87 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3. Assemble the antenna and SMA jack together. 4. Attach the RF connector at the cable-end onto the communication module.

  • Page 88: Installing Pcie/Pci Expansion Card(Rco-6000-Cfl-2)

    Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.13 Installing PCIe/PCI expansion Card (RCO-6000-CFL-2) 1. Remove the 4 screws in the circle below.
  • Page 89 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 2. Remove the screw in the circle below. 3. Install the PCIe/PCI extension card and ensure the gold finger is inserted into the slot. and then fasten the screw.

  • Page 90: Installing Graphic Card (Rco-6000-Cfl-2060S)

    Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.14 Installing graphic Card (RCO-6000-CFL-2060S) 1. Unscrew the 2 screws to remove the I/O shield 2. Unscrew the card bracket screws to remove the bracket from the expansion slots...
  • Page 91 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3. Install the graphic card and ensure the gold finger is inserted into the slot. and then fasten the screws. 4. Adjust the arm until it holds the card firmly in place. Then fasten the screw on the holder.
  • Page 92 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 5. Insert power cable from the power board to the graphic card. 6. Put the graphic expansion module into the expansion chassis.
  • Page 93 Chapter 3: System Setup RCO-6000-CFL l User’s Manual 7. Fasten the 4 screws in the circle...

  • Page 94: Installing Wall Mount Kit

    Chapter 3: System Setup Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.15 Installing wall mount kit 1. Wall mount kit is available for RCO-6000-CFL included in the standard package. 2. Lock the wall mount kit with 8 screws...
  • Page 95 Chapter 3: System Setup Chapter 3: System Setup RCO-6000-CFL l User’s Manual...

  • Page 96: Ac Adapter With 3P Terminal Block

    Chapter 3: System Setup Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.16 AC Adapter with 3P terminal block 1. 3P Wiring Diagram of AC Adapter 2. DC power input 3P wiring diagram...

  • Page 97: Ac Adapter With 4P Terminal Block

    Chapter 3: System Setup Chapter 3: System Setup RCO-6000-CFL l User’s Manual 3.17 AC Adapter with 4P terminal block * 12V requires 4-pin terminal block for card/storage expansion 1. AC adapter 4P wiring diagram 2. DC power input 4P wiring diagram...

  • Page 98: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 99: Bios Introduction

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.1 BIOS Introduction The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del> immediately allows you to enter the setup screens.

  • Page 100: Main Setup

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu. ■...

  • Page 101: Advanced Setup

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3 Advanced Setup...

  • Page 102: Connectivity Configuration

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.1 Connectivity Configuration Item Options Description CNVi Mode Disable Integrated, This option configures Connectivity. [Auto Auto Detection] means that if Discrete solution is Detection[Default] discovered it will be enabled by default. Otherwise Integrated solution (CNVi) will be enabled;...

  • Page 103: Cpu Configuration

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.2 CPU Configuration Item Options Description Intel (VMX) Virtualization Disabled, When enabled, a VMM can utilize the Technology Enabled[Default] additional hardware capabilities provided by Virtualization Technology. Active Processor Cores All[Default] Number of cores to enable in each processor package.

  • Page 104: Pch-Fw Configuration

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.3 PCH-FW Configuration Item Options Description AMT BIOS Features Disabled, When disabled AMT BIOS Features are no Enabled[Default] longer supported and user is no longer able to access MEBx Setup. Note:This option does not disable Manageability Features in FW.

  • Page 105: Sata And Rst Configuration

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.4 SATA and RST Configuration Item Options Description SATA Controller(s) Disabled, Enable/Disable SATA Device. Enabled[Default] SATA Mode Selection AHCI[Default] , Determines how SATA controller(s) operate. Intel RST Premium With Intel Optane System Acceleration Use RST Legacy OROM Disabled[Default] ,...

  • Page 106: Rst (Uefi Raid) Configuration

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.5 RST (UEFI RAID) Configuration How to set the UEFI RAID: 1. When set to “Intel RST Premium With Intel Optane System Acceleration“, please save change reset system. 2. After reboot the system, please into BIOS utility and then will see “Intel (R) Rapid Storage Technology”...
  • Page 107 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 3. Into Intel(R) Rapid Storage Technology, and start create RAID volume. 4. Start Create the RAID ■ Select Disk that you want to do the RAID ■ Select [x]; No-Select [ ]...

  • Page 108: Trusted Computing

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.6 Trusted Computing Item Options Description Security Device Enabled, Enable/Disable BIOS support for security Support Disabled[Default] , device. O.S. will not show Security Device.TCG EFI protocol and INT1A interface will not be available. Pending operation None[Default] , Schedule an Operation for the Security Device.

  • Page 109: Acpi Settings

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.7 ACPI Settings Item Options Description Enable Hibernation Disabled , Enables or Disables System ability to Enabled[Default], Hibernate (OS/S4 Sleep State). This option may not be effective with some operating systems. ACPI Sleep State Suspend Disabled, Select the highest ACPI sleep state the S3 (Suspend to RAM)[Default]...

  • Page 110: Super Io Configuration

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.8 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB).
  • Page 111 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ Serial Port 1 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=3F8h; IRQ=4; , &...
  • Page 112 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ Serial Port 2 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=2F8h; IRQ=3; , IRQ settings of the specified serial port.
  • Page 113 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ Serial Port 3 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=3E8h; IRQ=7; , IRQ settings of the specified serial port.
  • Page 114 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ Serial Port 4 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=2E8h; IRQ=7; , IRQ settings of the specified serial port.
  • Page 115 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ Serial Port 5 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2F0h; IRQ=7; , &...
  • Page 116 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ Serial Port 6 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address IO=2E0h; IRQ=7; , &...

  • Page 117: Hardware Monitor

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.9 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. Item Options Description Smart Fan Function Disabled[Default], Enabled or Disable Smart Fan Enabled...
  • Page 118 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ Smart Fan Mode Configuration Item Options Description Expansion Fan Manual Mode, Smart Fan Mode Select SmartFan Control SMART FAN IV Mode[Default], Temperature 1~4 1~100 Auto fan speed control. SMART FAN IV Duty Cycle 1~4 20~100 Auto fan speed control.

  • Page 119: Serial Port Console Redirection

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.10 Serial Port Console Redirection Item Options Description Console Redirection Disabled[Default], These items allows you to enable or Enabled disable COM1 console redirection...

  • Page 120: Network Stack Configuration

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.11 Network Stack Configuration Item Options Description Network Stack Disabled[Default] , Enable/Disable UEFI Network Stack. Enabled...

  • Page 121: Csm Configuration

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.12 CSM Configuration Item Options Description CSM Support Disabled, This item allows users to enable or disable Enabled[Default] for “CSM Support”. GateA20 Active Upon Request[Default] , This item allows users to set Upon Request Always or Always for "GateA20 Active“.

  • Page 122: Usb Configuration

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.3.13 USB Configuration Item Options Description Legacy USB Support Enabled[Default] Enables Legacy USB support. AUTO option Disabled disables legacy support if no USB devices are Auto connected. DISABLE option will keep USB devices available only for EFI applications.

  • Page 123: Chipset

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.4.1 System Agent (SA) Configuration...
  • Page 124 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ Memory Configuration Item Options Description Max TOLUD Dynamic[Default], Maximum Value of TOLUD. Dynamic assignment 1GB, would adjust TOLUD automatically based on largest 1.25GB, MMIO length of installed graphic controller 1.5 GB, 1.75 GB, 2 GB, 2.25 GB,...
  • Page 125 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ Graphic Configuration Item Options Description Primary Display Auto[Default] , Select which of IGFX/PEG Graphics device PEG + IGFX should be Primary Display. PEG+IGFX(Multiple-Displays): IGFX will be primary and only display under BIOS and DOS mode.
  • Page 126 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ PEG Port Configuration Item Options Description Enable Root Port Enabled[Default] , Enable or Disable the Root Port Disabled Max Link Speed Auto[Default] , Configure PEG 0:X:X Max Speed Gen1, Gen3, Gen3, PEG0 Hotplug Disabled[Default] , PCI Express Hot Plug Enable/Disable...

  • Page 127: Pch-Io Configuration

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.4.2 PCH-IO Configuration Item Options Description PCH LAN Controller Enabled [Default] , Enable/Disable onboard NIC. Disabled Wake on LAN Enabled, Enable/Disable integrated LAN to wake the Enable Disabled [Default] system. ■ PCI Express Configuration Restore AC Power Power On, Specify what state to go to when power is...
  • Page 128 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ PCI Express Configuration...
  • Page 129 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual  PCI Express Root Port 8 / 9 / 16 Item Options Description PCI Express Root Disabled [Default] , Control the PCI Express Root Port. Port Enabled 5 /10 /14/15/16/19/21 ASPM Disabled [Default] , Set the ASPM Level: L0s, Force L0s - Force all links to L0s State,...
  • Page 130 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ USB Configuration Item Options Description XHCI Disable Disabled [Default] , Option to enable Compliance Mode. Compliance mode Enabled Default is to disable Compliance Mode. Change to enabled for Compliance Mode testing.
  • Page 131 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ HD Audio Configuration Item Options Description HD Audio Disabled, Control Detection of the HD-Audio device. Enabled [Default] Disabled = HDA will be unconditionally disabled Enabled = HDA will be unconditionally enabled.

  • Page 132: Security

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.5 Security Security menu allow users to change administrator password and user password settings. ■ Administrator Password This item allows you to set Administrator Password. ■ User Password This item allows you to set User Password.
  • Page 133 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ Security Boot Item Options Description Secure Boot Disabled [Default] , Secure Boot feature is Active if Secure Boot Enabled is Enabled,Platform Key(PK) is enrolled and the System is in User mode. The mode change requires platform reset Secure Boot Mode Standard,...
  • Page 134 Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual ■ Key Management Item Options Description Factory Key Provision Disabled [Default] , Install factory default Secure Boot keys Enabled after the platform reset and while the System is in Setup mode...

  • Page 135: Boot

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.6 Boot This menu allows you to setup the system boot options. Item Options Description Setup Prompt 1[Default] Number of seconds to wait for setup Timeout activation key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock On[Default] , Select the Keyboard NumLock state.

  • Page 136: Save & Exit

    Chapter 4: BIOS Setup RCO-6000-CFL l User’s Manual 4.7 Save & Exit This setting allows users to configure the boot settings. ■ Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.

  • Page 137: Appendix Wdt & Gpio

    Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).

  • Page 138: Wdt Sample Code

    Appendix – WDT & GPIO RCO-6000-CFL l User’s Manual WDT Sample Code WDT Setting Psuedo Code #define AddrPort 0x2e #define DataPort 0x2f #define SIO_UnLock_Value 0x87 #define SIO_Lock_Value 0xaa #define WATCHDOG_LDN 0x08 #define GPIO_Port 0xF1 //Enter_Config WriteByte (AddrPort, SIO_UnLock_Value); WriteByte (AddrPort, SIO_UnLock_Value); //Enter WATCHDOG LDN WriteByte (AddrPort, 0x07);...

  • Page 139: Gpio Sample Code

    Appendix – WDT & GPIO RCO-6000-CFL l User’s Manual GPIO Sample Code GPIO Setting PIN# GPIO# Default Configuration XCOM- XCOM+ OUT8 DIO Output8 DIO Input8 OUT7 DIO Output7 DIO Input7 OUT6 DIO Output6 DIO Input6 OUT5 DIO Output5 DIO Input5 OUT4 DIO Output4 DIO Input4...
  • Page 140 © 2022 Premio Inc. All Rights Reserved www.premioinc.com...
