Preface BCO-2000-AMD l User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible. ⚫...
Preface BCO-2000-AMD l User’s Manual Technical Support and Assistance 1. Visit the Premio Inc website at www.premioinc.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.
Accessory Kit Ordering Information Model No. Product Description Basic Fanless Embedded System with AMD Ryzen™ Embedded V1605B, BCO-2000-V1605B 2xLAN, 4x USB, 2x LAN Basic Fanless Embedded System with AMD Ryzen™ Embedded R1606G, BCO-2000-R1606G 2xLAN, 4x USB, 2x LAN Optional Accessories Model No.
Chapter 1: Product Introductions 1.1 Overview Premio Basic Fanless Embedded Systems are designed for entry-level applications and basic needs. The BCO series can oversee connected devices and manage the collection, storage, and transmission of sensor data, and is capable of distilling unexplored value in data. It is not only robust and can withstand dust, shock, and vibration, but also can suitable for industrial automation, industrial control, kiosk &...
BCO-2000-AMD l User’s Manual Chapter 1: Product Introductions 1.2 Hardware Specification System Display DisplayPort 1x DisplayPort 1.4, DP++, Processor Support resolution 3840 x 2160 Support AMD Ryzen™ Embedded R1000/V1000 Series @60 Hz • AMD Ryzen™ Embedded V1605B with Radeon™ Vega 8 Graphics, 4M Cache, 4 Cores, 8 Threads, Up to 3.6 GHz 1x HDMI 2.0b, •...
Page 11
BCO-2000-AMD l User’s Manual Chapter 1: Product Introductions Power Power Adaptor Optional AC/DC 14V/5A, 60W, Power Mode AT, ATX 12VDC Power Protection Reserve Protection Environment -20 ° C to 55 ° C (25W CPU) Operating Temperature -30 ° C to 85 ° C Storage Temperature Relative Humidity 10% to 95% (non-condensing)
BCO-2000-AMD l User’s Manual Chapter 1: Product Introductions 1.3 System I/O Front Panel LAN port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network Power LED Antenna hole Indicates the power status of the system Used to connect an antenna for optional Mini- PCIe WiFi module...
Page 13
BCO-2000-AMD l User’s Manual Chapter 1: Product Introductions Rear Panel DC IN Expandable I/O bracket Used to plug a DC power input with terminal • COM Port: block COM2 or COM4 Support RS232/422/485 serial COM port device COM1 ~ COM2 support RS232/422/485 serial •...
BCO-2000-AMD l User’s Manual Chapter 2: Mechanical Specifications 2.2 Connector / Switch Definition Connector Location Definition Clear CMOS Panel PWR setting Backlight PWR setting Front Panel AT/ATX setting Panel Control M.2 B key USB 2.0 port USB 3.2 Gen 2 Expansion I/O COM1 COM Port...
Page 41
BCO-2000-AMD l User’s Manual Chapter 2: Mechanical Specifications 2.3 I/O Interface Descriptions 2.3.23 SIM Card SIM2 Signal Signal DATA...
Page 42
BCO-2000-AMD l User’s Manual Chapter 2: Mechanical Specifications 2.3 I/O Interface Descriptions 2.3.24 Battery BAT1 Signal Signal Battery Power 2.3.25 Buzzer Signal Signal Passive Negative...
BCO-2000-AMD l User’s Manual Chapter 3: System Setup 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.2 Removing the chassis bottom cover In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.
Page 46
BCO-2000-AMD l User’s Manual Chapter 3: System Setup 3. Remove the sata cable、power cable & remove the bottom cover.
BCO-2000-AMD l User’s Manual Chapter 3: System Setup 3.3 Installing SODIMM 1. SODIMM sockets are available for BCO-2000 series on the top side. Insert memory module from 45 degree direction. 2. Press the memory module vertically downward until you hear the “click” sound.
BCO-2000-AMD l User’s Manual Chapter 3: System Setup 3.4 Installing Mini PCIe card / mSATA 1. Mini PCIe can support mSATA. Insert mini PCIe card or mSATA module from 45 degree direction. 2. Press the mini PCIe card or mSATA module down and lock it with one screws (M2.5x5L).
BCO-2000-AMD l User’s Manual Chapter 3: System Setup 3.5 Installing antenna 1. Remove antenna hole cover on the system panel. Rear Front 2. Have antenna jack penetrate through the hole. 3. Put on washer and fasten the nut with antenna jack.
Page 50
BCO-2000-AMD l User’s Manual Chapter 3: System Setup 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at the cable-end onto the communication module.
BCO-2000-AMD l User’s Manual Chapter 3: System Setup 3.7 Installing SATA HDD 1. Lock the 2.5” HDD with HDD bracket using four screws (M3x4L).
Page 53
BCO-2000-AMD l User’s Manual Chapter 3: System Setup 2. Fasten the four screws (M3x5L) to lock the HDD bracket in place. 3. insert power cable and sata cable.
BCO-2000-AMD l User’s Manual Chapter 3: System Setup 3.9 Installing wall mount kit 1. Wall mount kit is available for BCO-2000 series included in the standard package 2. Place the system upside down so you can see the bottom cover. The highlighted screw holes below will be used.
Page 56
BCO-2000-AMD l User’s Manual Chapter 3: System Setup 3. Lock the wall mount kit with eight screws (M3x5L, Nylok).
BCO-2000-AMD l User’s Manual Chapter 3: System Setup 3.10 Installing DIN rail holder 1. Din rail holder is available for BCO-2000 series as optional accessories. 2. Place the system upside down so you can see the bottom cover. The highlighted screw holes below will be used. 3.
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.1 BIOS Introduction The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del> immediately allows you to enter the setup screens.
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu. ■...
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.3.1 Trusted Computing Item Options Description Security Device Support Enabled, Enable/Disable BIOS support for security Disabled[Default] , device. O.S. will not show Security Device.TCG EFI protocol and INT1A interface will not be available. Pending operation None[Default] , Schedule an Operation for the Security...
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.3.2 ACPI Settings Item Options Description Enable Hibernation Disabled , Enables or Disables System ability to Enabled[Default], Hibernate (OS/S4 Sleep State). This option may not be effective with some operating systems. ACPI Sleep State Suspend Disabled, Select the highest ACPI sleep state the S3 (Suspend to...
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.3.4 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB).
Page 66
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 1 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the IO=3F8h; IRQ=4; , address & IRQ settings of the specified IO=3F8h;...
Page 67
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 2 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the IO=2F8h; IRQ=3; , address & IRQ settings of the specified IO=3F8h;...
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.3.5 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. Item Options Description Smart Fan Function Disabled[Default], Enabled or Disable Smart Fan Enabled...
Page 69
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup ■ Smart Fan Mode Configuration Item Options Description SYS Fan SmartFan Manual Mode, Smart Fan Mode Select Control Thermal Cruise Mode, SMART FAN IV Mode[Default], Temperature 1~4 1~100 Auto fan speed control. SMART FAN IV Duty Cycle 1~4 1~100 Auto fan speed control.
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.3.6 Serial Port Console Redirection Item Options Description Console Redirection Disabled[Default], These items allows you to enable or Enabled disable COM1 console redirection...
Page 71
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup Console Redirection Settings Item Options Description Terminal VT100 Emulation: ANSI: Extended ASCII char set. VT100: ASCII char set. VT100+: Type VT100+, Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8 VT-UTF8, encoding to map Unicode chars onto 1 or more bytes.
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.3.8 USB Configuration Item Options Description Legacy USB Enabled[Default] Enables Legacy USB support. AUTO option Support Disabled disables legacy support if no USB devices are Auto connected. DISABLE option will keep USB devices available only for EFI applications.
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.3.10 CSM Configuration Item Options Description CSM Support Disabled[Default] , This item allows users to enable or disable for “CSM Enabled Support”. GateA20 Active Upon Request[Default] , This item allows users to set Upon Request or Always for Always "GateA20 Active“.
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.3.11 AMD CBS Item Options Description AC Loss Control Power Off[Default] , Specify what state to go to when power is Power On, re-applied after a power failure (G3 state). Last State Hd Audio Enable Audio[Default] , HD Audio Control.
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your reference. 4.4.1 SB USB Configuration Item Options Description XHCI0 Port X Enabled[Default] , Enabled/Disabled XHCIO Port...
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.5 Security Security menu allow users to change administrator password and user password settings. ■ Administrator Password This item allows you to set Administrator Password. ■ User Password This item allows you to set User Password.
Page 80
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup ■ Security Boot Item Options Description Secure Boot Disabled [Default] , Secure Boot feature is Active if Secure Boot is Enabled Enabled,Platform Key(PK) is enrolled and the System is in User mode. The mode change requires platform reset Secure Boot Mode Standard,...
Page 81
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup ■ Key Management Item Options Description Factory Key Disabled [Default] , Install factory default Secure Boot keys Provision Enabled after the platform reset and while the System is in Setup mode...
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.6 Boot This menu allows you to setup the system boot options. Item Options Description Setup Prompt 1[Default] Number of seconds to wait for setup activation Timeout key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock On[Default] , Select the Keyboard NumLock state.
BCO-2000-AMD l User’s Manual Chapter 4: BIOS Setup 4.7 Save & Exit This setting allows users to configure the boot settings. ■ Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.
BCO-2000-AMD l User’s Manual Appendix – WDT & GPIO GPIO Sample Code GPIO Setting PIN# GPIO# Default Configuration +V5S DIO Input1 OUT1 DIO Output1 DIO Input2 OUT2 DIO Output2 DIO Input3 OUT3 DIO Output3 DIO Input4 OUT4 DIO Output4 The GPIO function is provided by Nuvoton NCT6106D, and it can be accessed through its GPIO index/data port. To access the GPIO register, write index to the index port, and then read/write from/to data port.
