USER'S

MANUAL

CT-ARL01

Intel R680E Industrial Computer

Board

Table of Contents

Need help?

Do you have a question about the CT-ARL01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Premio CT-ARL01

Page 1 USER’S MANUAL CT-ARL01 Intel R680E Industrial Computer Board...
Page 2: Table Of Contents
CT-ARL01 l User’s Manual Table of Contents Prefaces …………………………….………………………………………………………………..…. 04 Disclaimer…………………………………………………………..……………….……………………………………..….. 04 Copyright Notice………………………..…….…….………………………….……………………..…………..……….. 04 Trademarks Acknowledgment ……….……………………………………………….…………………………….… 04 Environmental Protection Announcement ……….………………………………………………………..…… 04 Safety Precautions ………………………………………………………………………..……..…………………………. 05 Technical Support and Assistance …………………………………………….…………..………………………… 06 Conventions Used in this Manual …………………………………………………….………………………….…. 06 Chapter 1 Product Introductions …………………………………………………..…..…...
Page 3 Chipset ………………..…….…..….…………..…………………………………..……………… 59 Power ………………..…….…..….…………..…………………………………..………………… 60 Save & Exit ………………..……...…………..…………………………………..………………… 61 Appendix WDT & GPIO …………………………………………………………………………… 62 GPIO WDT BKL Programming ….………………………………………………………………………. 63 General Purpose IO .……………….………….…….……………………..….…….……….…………... 64 Watchdog Timer …...……………….………….…….……………………..….…….……….…………... 66 SMBusAccess …..…...……………….………….…….……………………..….…….……….…………... 68 CT-ARL01 Block Diagram ……………………………………………………………..……….… 70...
Page 4: Prefaces
2024/08/01 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.
Page 5: Safety Precautions
Preface CT-ARL01 l User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible.
Page 6: Technical Support And Assistance
Preface CT-ARL01 l User’s Manual Technical Support and Assistance 1. Visit the Premio Inc website at premioinc.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.
Page 7: Chapter 1 Product Introductions
Chapter 1 Product Introductions...
Page 8: Industrial Computer Board
CT-ARL01 l User’s Manual Chapter 1: Product Introductions CT-ARL01 Intel R680E Industrial Computer Board...
Page 9: Specifications
CT-ARL01 l User’s Manual Chapter 1: Product Introductions Specifications Model CT-ARL01 Dimensions 305(L)mm x 244(W)mm x 1.6(H)mm, ATX-Size ∙ Intel® IOTG Raptor Lake-S Refresh Processor Core i9/i7/i5/i3 - i9-14900K (125W) / i9-14900KF (125W)/ i9-14900 (65W)/ i9-14900F (65W)/ i9-14900T (35W) - i7-14700K (125W) / i7-14700KF (125W)/...
Page 10 CT-ARL01 l User’s Manual Chapter 1: Product Introductions Specifications Model CT-ARL01 ∙ 2 x PCIe 5.0 x16 slots (PCIE1, 4*) ∙ 1 x PCIe 4.0 x4 slot (PCIE5**) ∙ 3 x PCIe 3.0 x4 slots (PCIE3, 6, 7) ∙ 1 x PCIe 3.0 x1 slot (PCIE2) ∙...
Page 11 CT-ARL01 l User’s Manual Chapter 1: Product Introductions Specifications Model CT-ARL01 ∙ 1 x 4-pin PWM CPU fan connector ∙ 3 x 4-pin PWM system fan connectors ∙ 1 x Front Audio header (Line-out & Mic-in) ∙ 1 x S/PDIF header ∙...
Page 12: Chapter 2 Mechanical Specifications
Chapter 2 Mechanical Specifications...
Page 13: Switch And Connector Locations
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.1 Switch and Connector Locations 2.1.1 Top View DIMMB2 DIMMB1 DIMMA2 DIMMA1 JPMBUS1 CPUFAN1 JPWR2 SYSFAN1 SYSFAN2 JSMB1 JI2C1 Rear JPWR1 I/O Panel JUSB2 M2_M1 PCIE1 SATA3_4 PCIE2 SATA1_2 PCIE3 JLAN_LED PCIE4...
Page 14: Rear View
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.1.2 Rear View 2.5 GbE RJ-45 LAN Jacks Serial Line-Out Jack Display 1 LAN1 LAN2 LAN3 LAN4 Display 2 VGA Port USB 10Gbps Ports Mic-in Jack...
Page 15 CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications DisplayPort DisplayPort is a digital display interface standard. This connector is used to connect a monitor with DisplayPort inputs. RS232/422/485 Serial Port The serial port is a 16550A high speed communications port that sends/receives 16 bytes FIFOs.
Page 16: Cpu Socket
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.2 CPU Socket Introduction to the LGA1700 CPU The surface of the LGA1700 CPU has four notches and a golden triangle to assist in correctly lining up the CPU for motherboard placement. The golden triangle is the Pin 1 indicator.
Page 17 CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications CPU & Heatsink Installation Use appropriate ground straps, gloves and ESD mats to protect yourself from electrostatic discharge (ESD) while installing the processor. Important Images are for illustration purposes only; actual parts may vary.
Page 18: Memory Slots
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.3 Memory Slots 2.3.1 DIMM1~2: DDR5 DIMM Slots The DIMM slots are intended for memory modules. DIMMA1 DIMMB1 Channel B Channel A DIMMA2 DIMMB2 Recommended Memory Population Quantity of DIMMs DIMMA1 Channel A...
Page 19: Installing Memory Modules
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.3.2 Installing Memory Modules Open the side clips to unlock the DIMM slot. Insert the DIMM vertically into the slot, ensuring that the off-center notch at the bottom aligns with the slot.
Page 20: Storage Connectors
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.4 Storage Connectors SATA1_2, 3_4: SATA 3.0 6Gb/s Ports These ports are SATA 6Gb/s interface port, it can connect to one SATA device. SATA3_4 SATA1_2 Important • These SATA connectors support hot plug.
Page 21: Expansion Slots
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.5 Expansion Slots 2.5.1 PCIe Slots PCIE1: PCIe 5.0 x16 PCIE2: PCIe 4.0 x4 (SKU1 Only) PCIE3: PCIe 3.0 x4 PCIE4: PCIe 5.0 x16 (Signal share with PCIE1) PCIE5: PCIe 4.0 x4 (Signal share with M2_M2) PCIE6: PCIe 3.0 x4...
Page 22: Slots
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.5.2 M.2 Slots M2_M1 M2_M2 M2_B1 (SKU1 Only) M2_E1 (SKU1 Only) M2_M1: M.2 Slot (M Key, PCIe 4.0 x4, 2280/ 22110) M2_M2: M.2 Slot (M Key, PCIe 4.0 x4/x2/x1, 2242/ 2280) Please install the M.2 solid-state drive (SSD) into the M.2 slot as shown below.
Page 23: Slot (E Key)
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.5.3 M2_E1: M.2 Slot (E Key, 2230) Please install the Wi-Fi/ Bluetooth card into the M.2 slot as shown below. Feature • Supports PCIe x1 signal. • Supports Intel® AX210 Wi-Fi 6E, Intel® Wireless-AC 9260. CNVI devices are not supported.
Page 24: Power Connectors
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.6 Power Connectors JPWR2 JPWR1 2.6.1 JPWR1: +3.3V +3.3V +3.3V -12V 24-Pin ATX Power Connector PS-ON# This connector allows you to connect an ATX power supply. PWR OK 5VSB +12V +12V +3.3V 2.6.2 JPWR2:...
Page 25: Cooling Connectors
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.7 Cooling Connectors CPUFAN1 SYSFAN1 SYSFAN2 CPUFAN1, SYSFAN1~3: CPU/ System Fan Connectors The fan connector supports CPU/ system cooling fans with +12V. When connecting the wire to the connectors, always note that the red wire is the positive and should be connected to the +12V;...
Page 26: Audio Connectors
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.8 Audio Connectors JSPDIF1 JAUD1 2.8.1 JAUD1: Front Audio Header (Line-out/ MIC-in) This header allows you to connect front panel audio. MIC_L MIC_R JAUD1 LINE_OUT_R MIC_JD HP_ON No pin LINE_OUT_L LINE_OUT_JD 2.8.2 JSPDIF1: S/PDIF Header This pinheader is used to connect S/PDIF (Sony &...
Page 27: Usb Connectors
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.9 USB Connectors JUSB2 JUSB1 USB1 2.9.1 JUSB2: USB 5Gbps Header This port is backward-compatible with USB 2.0 devices and supports data transfer rate up to 5 Gbps. USB_D+ USB 3.2 RX- USB_D- USB 3.2 RX+...
Page 28: Usb 2.0 Header
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.9.2 JUSB1: USB 2.0 Header This header is ideal for connecting USB devices such as keyboard, mouse, or other USB-compatible devices. It supports data transfer rate up to 480 Mbps. USB_D- USB_D-...
Page 29: Other Connectors And Components
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.10 Other Connectors and Components JFP1 JGPIO2 JGPIO1 2.10.1 Front Panel Header 2 POWER LED HDD LED+ 4 POWER LED HDD LED- This front-panel header is provided for electrical RESET POWER connection to the front...
Page 30: Pmbusheader
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications JPMBUS1 JSMB1 JI2C1 2.10.4 JPMBUS1: SMBCLK PMBus Header SMBDATA Power Management Bus SMBALERT# (PMBus) is a variant of the System Management Bus JPMBUS1 (SMBus) which is targeted at digital management of power supplies.
Page 31: Serial Port Headers
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.10.7 COM2~6: Serial Port Headers These headers are 16550A high speed communications port that sends/ receives 16 bytes FIFOs. You can attach a serial device to it. COM6 COM4 COM2 COM5 COM3...
Page 32: Sku1 (Intel® R680E)
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.10.8 SKU1 (Intel® R680E) • COM2 Supports RS-232/ 422/ 485, With Ring/ 0V/ 5V/ 12V (Default set to Ring). • COM3~6 Supports RS-232/ 422/ 485, With 5V/ 12V (Default set to 5V).
Page 33: Lan Led Header
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications JLAN_LED JKBMS1 2.10.9 JLAN_LED: LAN LED Header This header is provided for rear panel LAN LEDs. I225_ACT_LINK_1 I225_LED2_LINK#_1 I225_ACT_LINK_2 I225_LED2_LINK#_2 JLAN_LED I225_ACT_LINK_3 I225_LED2_LINK#_3 I225_ACT_LINK_4 I225_LED2_LINK#_4 2.10.10 JKBMS1: PS/2® Keyboard & Mouse Connector This connector is provided to connect a keyboard and a mouse.
Page 34: Chassis Intrusion Header
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.10.11 JCASE1: Chassis Intrusion Header This connector connects to the chassis intrusion switch cable. If the chassis is opened, the chassis intrusion mechanism will be activated. The system will record this status and show a warning message on the screen.
Page 35: Cmos Battery
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.10.13 BAT1: CMOS Battery If the CMOS battery is out of charge, the time in the BIOS will be reset and the data of system configuration will be lost. In this case, you need to replace the CMOS battery.
Page 36: Jumpers
CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications 2.11 Jumpers Important Avoid adjusting jumpers when the system is on; it will damage the motherboard. JCOMP1 JCMOS1 JATX1 JCOMP3 JCOMP6 JCOMP5 JCOMP4 JCOMP2 JME_DIS1 Jumper Name Default Setting Description COM Voltage Select Jumper...
Page 37 CT-ARL01 l User’s Manual Chapter 2: Mechanical Specifications Jumper Name Default Setting Description ME Jumper 1-2: ME enabled (Default) JME_DIS1 2-3: ME disabled Clear CMOS Jumper JCMOS1 1-2: Normal (Default) 2-3: Clear CMOS...
Page 38: Chapter 3 System Bios
Chapter 3 System BIOS...
Page 39: Bios Introduction
CT-ARL01 l User’s Manual Chapter 3: BIOS Setup 3.1 BIOS Introduction BIOS Setup This chapter provides information on the BIOS Setup program and allows users to configure the system for optimal use. Users may need to run the Setup program when: ∙...
Page 40: Control Keys
CT-ARL01 l User’s Manual Chapter 3: BIOS Setup Control Keys ← → Select Screen ↑ ↓ Select Item Enter Select Change Value Exit General Help Previous Values Optimized Defaults Save & Reset* Screenshot capture <K> Scroll help area upwards Scroll help area downwards <M>...
Page 41: The Menu Barmain
CT-ARL01 l User’s Manual Chapter 3: BIOS Setup 3.2 The Menu Bar Main Use this menu for basic system configurations, such as time, date, etc. Advanced Use this menu to set up the items of special enhanced features. Boot Use this menu to specify the priority of boot devices.
Page 42: Main
CT-ARL01 l User’s Manual Chapter 3: BIOS Setup 3.3 Main HDD Information • RAID (VMD) Disabled: Display HDD information as plugging in status. • RAID (VMD) Enabled: Display "Not Present" only. System Date This setting allows you to set the system date.
Page 43: Advanced
CT-ARL01 l User’s Manual Chapter 3: BIOS Setup 3.4 Advanced Full Screen Logo Display This BIOS feature determines if the BIOS should hide the normal POST messages with the motherboard or system manufacturer’s full-screen logo. BIOS will display the full-screen logo during the boot-up sequence, [Enabled] hiding normal POST messages.
Page 44 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup CPU Configuration Intel Virtualization Technology Enables or disables Intel Virtualization technology. Enables Intel Virtualization technology and allows a platform to run [Enabled] multiple operating systems in independent partitions. The system can function as multiple systems virtually.
Page 45 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup Intel(R) SpeedStep(TM) Enhanced Intel SpeedStep® Technology enables the OS to control and activate performance states (P-States) of the processor. [Enabled] When enabled, Intel SpeedStep® technology is activated. This technology allows the processor to manage its power consumption via performance state (P-State) transitions.
Page 46 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup Super IO Configuration Serial Port 1/ 2/ 3/ 4/ 5/ 6, Parallel Port This setting enables or disables the specified serial port. » Change Settings This setting is used to change the address & IRQ settings of the specified serial port.
Page 47 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup H/W Monitor (PC Health Status) These items display the current status of all monitored hardware devices/ components such as voltages, temperatures and all fans’ speeds. Smart Fan Configuration CPUFAN/ SYSFAN1~3 This setting enables or disables the Smart Fan function. Smart Fan is an excellent feature which will adjust the CPU/system fan speed automatically depending on the current CPU/system temperature, avoiding the overheating to damage your system.
Page 48 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup PCI/PCIE Device Configuration Audio Controller This setting enables or disables the detection of the onboard audio controller. Network Stack Configuration This menu provides Network Stack settings for users to enable network boot (PXE) from BIOS.
Page 49 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup GPIO Group Configuration GPO0 ~ GPO7 These settings control the operation mode of the specified GPIO. PCIE ASPM settings This menu provide settings for PCIe ASPM (Active State Power Management) level for different installed devices.
Page 50: Boot
CT-ARL01 l User’s Manual Chapter 3: BIOS Setup 3.5 Boot Boot Option #1-2 This setting allows users to set the sequence of boot devices where BIOS attempts to load the disk operating system.
Page 51: Security
CT-ARL01 l User’s Manual Chapter 3: BIOS Setup 3.6 Security Administrator Password Administrator Password controls access to the BIOS Setup utility. User Password User Password controls access to the system at boot and to the BIOS Setup utility. Chassis Intrusion Enables or disables recording messages while the chassis is opened.
Page 52 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup PCH-FW Configuration Firmware Information These settings show the ME Firmware SKU ME Firmware Version ME firmware information of ME Firmware Status 1-2 the Intel ME Firmware Mode (Management Engine). ME State This menu controls the Intel® Management Engine State (ME state) parameters, which provides various management and security capabilities.
Page 53 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup Firmware Update Configuration » ME FW Image Re-Flash Enables or disables the ME Firmware Image Re-flashing. » FW Update Enables or disables the capability to perform a firmware update of the ME locally.
Page 54 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup » HECI Message Check Disable This setting disables message check for BIOS boot path when sending messages. » MBP HOB Skip Setting this option will skip ME’s Memory-Based Protection (MBP) H0B region.
Page 55 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup Trusted Computing Security Device Support This item enables or disables BIOS support for security device. When set to [Disable], the OS will not show security device. SHA256, 384 PCR Bank These settings enables or disables the SHA-1 PCR Bank and SHA256, 384 PCR Bank.
Page 56 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup Serial Port Console Redirection Console Redirection Console Redirection operates in host systems that do not have a monitor and keyboard attached. This setting enables or disables the operation of console redirection. When set to [Enabled], BIOS redirects and sends all contents that should be displayed on the screen to the serial COM port for display on the terminal screen.
Page 57 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup Console Redirection Settings (COM1) This option appears when Console Redirection is enabled. » Terminal Type To operate the system’s console redirection, you need a terminal supporting ANSI terminal protocol and a RS-232 null modem cable connected between the host system and terminal(s).
Page 58 CT-ARL01 l User’s Manual Chapter 3: BIOS Setup Secure Boot Secure Boot Secure Boot function can be enabled only when the Platform Key (PK) is enrolled and running accordingly. Secure Boot Mode Selects the secure boot mode. This item appears when Secure Boot is enabled.
Page 59: Chipset
CT-ARL01 l User’s Manual Chapter 3: BIOS Setup 3.7 Chipset DVMT Total Gfx Mem This setting specifies the total graphics memory size for Dynamic Video Memory Technology (DVMT).
Page 60: Power
CT-ARL01 l User’s Manual Chapter 3: BIOS Setup 3.8 Power Restore AC Power Loss This setting specifies whether your system will reboot after a power failure or interrupt occurs. Available settings are: [Power Off] Leaves the computer in the power off state. Leaves the [Power computer in the power on state.
Page 61: Save & Exit
CT-ARL01 l User’s Manual Chapter 3: BIOS Setup 3.9 Save & Exit Save Changes and Reset Save changes to CMOS and reset the system. Discard Changes and Exit Abandon all changes and exit the Setup Utility. Discard Changes Abandon all changes.
Page 62: Appendix Wdt & Gpio
Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).
Page 63: Gpio Wdt Bkl Programming
Appendix – WDT & GPIO CT-ARL01 l User’s Manual GPIO WDT BKL Programming This chapter provides WDT (Watch Dog Timer), GPIO (General Purpose Input/ Output) and LVDS Backlight programming guide. Abstract In this section, code examples based on C programming language provided for customer interest.
Page 64: General Purpose Io
CT-ARL01 l User’s Manual Appendix – WDT & GPIO General Purpose IO 1. General Purposed IO – GPIO/DIO The GPIO port configuration addresses are listed in the following table: Name IO Port IO address Name IO Port IO address N_GPI0...
Page 65 CT-ARL01 l User’s Manual Appendix – WDT & GPIO Read input value from GPI: 1. Read the value from GPI port. 2. Get the value of GPI address. Example: Get N_GPI2 input value. val = SMBus_ReadByte (0x6E, 0x12); // Read value from N_GPI2 port through SMBus.
Page 66: Watchdog Timer
CT-ARL01 l User’s Manual Appendix – WDT & GPIO Watchdog Timer Watchdog Timer – WDT The base address (WDT_BASE) of WDT configuration registers is 0xA10. 2.1 Set WDT Time Unit // Read current WDT setting val = Inportb (WDT_BASE + 0x05);...
Page 67 CT-ARL01 l User’s Manual Appendix – WDT & GPIO 2.5 Check WDT Reset Flag If the system has been reset by WDT function, this flag will set to 1. // Read current WDT setting. val = Inportb (WDT_BASE + 0x05);...
Page 68: Smbusaccess
CT-ARL01 l User’s Manual Appendix – WDT & GPIO SMBus Access SMBus Access The base address of SMBus must know before access. The relevant bus and device information are as following. #define IO_SC 0xCF8 #define IO_DA 0xCFC #define PCIBASEADDRESS 0x80000000...
Page 69 CT-ARL01 l User’s Manual Appendix – WDT & GPIO 3.3 SMBus_WriteByte (char DEVID, char offset, char DATA) Write DATA to OFFSET on SMBus device DEVID. Outportb (LOWORD (SMBUS_BASE), 0xFE); Outportb (LOWORD (SMBUS_BASE) + 0x04, DEVID); //out Base + 04, (DEVID) Outportb (LOWORD (SMBUS_BASE) + 0x03, OFFSET);...
Page 70: Ct-Arl01 Block Diagram
CT-ARL01 l User’s Manual Appendix – WDT & GPIO CT-ARL01 Block Diagram...
