Premio WCO-3000-EHL Series User Manual

Waterproof computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S
MANUAL
WCO-3000-EHL Series
Waterproof Computer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WCO-3000-EHL Series and is the answer not in the manual?

Questions and answers

Related Manuals for Premio WCO-3000-EHL Series

Summary of Contents for Premio WCO-3000-EHL Series

  • Page 1 USER’S MANUAL WCO-3000-EHL Series Waterproof Computer...

  • Page 2: Table Of Contents

    WCO-3000-EHL l User’s Manual Table of Contents Prefaces …………………………………………………….……………………………………………. 04 Revision …………………………………………………………………………………………..……………….……….. 04 Disclaimer ………………………………………………………..…….…….………………………….……………….. 04 Copyright Notice …………………………………….…………………….…………………………………………… 04 Trademarks Acknowledgment …………..………………………………………………………....04 Environmental Protection Announcement …………………………….………………….……………….. 04 Safety Precautions ………………………………………….……………………………….…………….………….. 05 Technical Support and Assistance …………………………………….…………….…………….…………….06 Conventions Used in this Manual ………………………………………………………………….….………..06 Package Contents …………………………………………………………………………………………….…………...
  • Page 3 WCO-3000-EHL l User’s Manual 4.3.8 Power IGN Mode ..…………………………………………………………..…………..59 4.3.9 S5 RTC Wake Settings ……………..………………….…………………………………. 60 4.3.10 Serial Port Console Redirection …………………………………..………..…….. 61 4.3.11 USB Configuration ….……………………………………………………………..…….. 62 4.3.12 Network Stack Configuration ………………………………………………..…….. 63 4.3.13 NVMe Configuration ……………………………………………………………..…….. 64 Chipset …………...……….………………….…..….…..………………………………………..…...

  • Page 4: Prefaces

    2023/12/26 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.

  • Page 5: Safety Precautions

    Preface WCO-3000-EHL l User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible. ⚫...

  • Page 6: Technical Support And Assistance

    Preface WCO-3000-EHL l User’s Manual Technical Support and Assistance 1. Visit the Premio Inc website at www.premioinc.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.

  • Page 7: Package Contents

    Preface WCO-3000-EHL l User’s Manual Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty WCO-3000-EHL Waterproof Computer Wall Mount KIT Waterproof Connector Cover Set Ordering Information Model No. Product Description IP69K Waterproof System with Intel Celeron Processor J6413, WCO-3000-EHL-J6413...

  • Page 8: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 9: Overview

    Chapter 1: Product Introductions 1.1 Overview Based on Intel® Celeron® Processor J6413, WCO-3000-EHL series IP69K waterproof system are designed for wet conditions applications such as food & beverage processing, outdoor digital signage and surveillance applications. These systems are built with an extremely rugged enclosure, as well as the industrial-grade components, making these units dustproof and waterproof.

  • Page 10: Hardware Specification

    WCO-3000-EHL l User’s Manual Chapter 1: Product Introductions 1.2 Hardware Specification System Processor Support Intel® EHL Processor (Up to 10W TDP) • Intel® Celeron® Processor J6413, Quad Core, 1.5 MB Cache, 1.8 GHz, TDP 10W System Chipset SoC integrated • 1 GbE1: Intel I210 (Support Wake-on-LAN and PXE) LAN Chipset •...
  • Page 11 Dimension • Wall Mounting Mounting *Considering that the system meets the IP69K waterproof rating, we recommend that customers allow Premio to install the required device before shipping to avoid damage to the device and ensure its waterproof and dustproof effect.

  • Page 12: System I/O

    WCO-3000-EHL l User’s Manual Chapter 1: Product Introductions 1.3 System I/O WCO-3000-EHL Front Panel • Antenna hole • ATX power on/off switch Used to connect an antenna for optional Press to power-on or power-off the system Wi-Fi / 5G / GPS •...
  • Page 13 WCO-3000-EHL l User’s Manual Chapter 1: Product Introductions Rear Panel • DC IN 9-36V (M12 S-Coded) • LAN Port Optional: 48~110C 2x RJ45 by M12 X-Code Used to plug a DC power input with terminal • USB Port block 2x USB 3.2 Gen 2 Type A (Waterproof) •...

  • Page 14: Mechanical Dimension

    WCO-3000-EHL l User’s Manual Chapter 1: Product Introductions 1.4 Mechanical Dimensions WCO-3000-EHL Unit: mm...

  • Page 15: Chapter 2 Switches And Connectors

    Chapter 2 Switches and Connectors...

  • Page 16: Switch And Connector Locations

    WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.1 Switch and Connector Locations 2.1.1 Top View PWR_SW2 COM2 MIC_IN1 SODIMM1 LINE_OUT1 LAN1 COM1 LAN2 USB3_1 USB3_2 USB3_3 USB2_1 HDD_LED1 DC_IN1 PWR_SW1 PWR_LED1...

  • Page 17: Bottom View

    WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.1.2 Bottom View SATA1 AT_ATX1 BTB_FH1 MPCIE1 M.2_KB1 RESET1 RST_LED1 CAN1 CAN2...

  • Page 18: Daughter Board View

    WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.1.3 Daughter board view...

  • Page 19: Connector / Switch Definition

    WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition DC_IN1 3-pin DC +9~36V Power Input Connector PWR_SW1 Power Switch PWR_SW2 Remote Power Switch DP1 - 2 Display Port COM1 - 2 RS232 / RS422 / RS485 Connector USB2_1...

  • Page 20: Switch Definitions

    WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3 Switches Definitions 2.3.1 DC Power Input Connector (+9~36V) DC_IN1 Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Switch Definition 9~36 VIN 2.3.2 Power Button PWR_SW1 Definition Definition Power Button 2.3.3 Remote Power Switch PWR_SW2 Connector Type: Terminal Block 1X2 2-pin, 3.5mm pitch Definition...
  • Page 21 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.4 DisplayPort Connector DP1-2 Definition Definition DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P DP_LANE1_N DP_LANE2_P DP_AUX_N DP_HPD DP_LANE2_N DP_LANE3_P DP_PWR...
  • Page 22 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.5 RS232 / RS422 / RS485 Connector COM1-2 Connector Type: 9-pin D-Sub RS422 / 485 Full Duplex RS485 Half Duplex RS232 Definition Definition Definition DCD2 TX2- DATA2- RxD2 TX2+ DATA2+ TxD2 RX2+ DTR2 RX2-...
  • Page 23 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.6 USB2.0 Connector, Type A USB2_1 Definition USB2_D2- USB2_D2+ 2.3.7 USB 3.2 Connector, Type A USB3_1-3 Definition Definition USB3_RX+ USB2_DATA1- USB2_DATA1+ USB3_TX- USB3_TX+ USB3_RX-...
  • Page 24 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.8 RJ45 with LEDs Port LAN1 Definition Definition LAN1_MDI0P LAN1_MDI2N LAN1_MDI0N LAN1_MDI1N LAN1_MDI1P LAN1_MDI3P LAN1_MDI2P LAN1_MDI3N Link LED Status Definition Act LED Status Definition Steady Orange 1Gbps Network Link Blinking Yellow Data Activity Steady Green 100Mbps Network Link...
  • Page 25 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.9 Microphone Jack (Pink) MIC_IN1 Connector Type: 5-pin Phone Jack Definition MIC_R MIC_L 2.3.10 Line-out Jack (Green) LINE_OUT1 Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L PWR_LED1: Power LED Status RESET1 : Reset Button Definition Definition POWER LED+...
  • Page 26 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.11 AT / ATX Power Mode Switch AT_ATX1 Switch Definition 1-2 (Right) ATX Power Mode（Default） 2-3 (Left) AT Power Mode 2.3.12 SATA with Power Connector SATA1 Definition Definition SATA_TXP1 SATA_TXN1 SATA_RXN1 SATA_RXP1 +3.3V +3.3V...
  • Page 27 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.13 Smart FAN Connector Definition +12V FANIN FANCTL 2.3.14 CAN Bus Connector CAN 1-2 Definition CAN_H CAN_L...
  • Page 28 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.15 Mini PCI-Express / mSATA Socket MPCIE1 Definition Definition Definition WAKE# +3.3V +3.3V USB_DP1 +3.3V MINIPCIE RST# MINIPCIE_RXN1 +3.3V +1.5V +3.3V CLKREQ1# MINIPCIE_RXP1 USIM_VCC USIM_DATA +1.5V MINIPCIE_CLKN1 USIM_CLK SMB_CLK +1.5V MINIPCIE_CLKP1 MINIPCIE_TXN1 USIM_RST SMB_DATA...
  • Page 29 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.16 M.2 B Key Socket M2_KB1 Definition Definition +3.3V +3.3V +3.3V +1.8S USB2_D+ +3.3V USB2_D- +3.3V USB_RxN0 USB_RxP0 SIM_RST SIM_CLK USB_TxN0 SIM_DATA USB_TxP0 SIM_VDD PCIE_RxN0 PCIE_RxP0 PCIE_TxN0 PCIE_TxP0 PCIE_RST# REFCLK1- CLK_REQ# REFCLK1+ PCIE_WAKE# +3.3V...
  • Page 30 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.17 SIM Card Socket SIM1 - 2 Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK 2.3.18 Digital Input / Output Connector DIO1 Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition DC INPUT...
  • Page 31 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors...
  • Page 32 WCO-3000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.19 RS232 / RS422 / RS485 Connector CN1 – 2 Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DCD3 (DCD5) TX3- (TX5-) DATA3- (DATA5-) RxD3 (RxD5) TX3+ (TX5+) DATA3+ (DATA5+)

  • Page 33: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 34: Set Torque Force To 3.5 Kgf Cm To Execute All The Screwing And Unscrewing

    WCO-3000-EHL l User’s Manual Chapter 3: System Setup 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source. 3.2 Replace HDD on the internal SATA HDD bay 1.

  • Page 35: Installing Mini Pcie Wifi Card / Msata

    Chapter 3: System Setup 3.3 Installing mini PCIe WiFi card / mSATA 1. One mini PCIe slot is available for the WCO-3000-EHL series. PCIe WiFi card or mSATA module. This installation uses an mSATA card. Mini PCIE WiFi Card or mSATA 2.

  • Page 36: Installing M.2 B Key

    WCO-3000-EHL l User’s Manual Chapter 3: System Setup 3.4 Installing M.2 B Key 1. . One M.2 B Key slots are available for WCO-3000-EHL series. 5G LTE Card module. M.2 B Key 2. Insert 5G LTE card module from 45 degree direction.

  • Page 37: Installing Antenna

    Chapter 3: System Setup 3.5 Installing antenna 1. five antenna holes are available for WCO-3000-EHL series. (WCO-3000-EHL only) 2. Remove the antenna hole cover on the computer 3. Have the antenna jack penetrate through the hole, put on the washer, and fasten the nut with the antenna jack.

  • Page 38: Assemble Chassis Bottom Cover

    WCO-3000-EHL l User’s Manual Chapter 3: System Setup 3.6 Assemble chassis bottom cover 1. Place the bottom cover according to the below direction and make sure the rail is facing inside the system. 2. Lock the bottom cover with the sixteen screws(3X5L).

  • Page 39: Assemble Waterproof Cable

    WCO-3000-EHL l User’s Manual Chapter 3: System Setup 3.7 Assemble waterproof cable 1. Please remove the external waterproof cover on the connectors that you need to connect to mating waterproof cables. 2. Install external M12 A-CODE 4P power cable. Please align the foolproof opening and tighten the locking ring to secure the waterproof cable.
  • Page 40 WCO-3000-EHL l User’s Manual Chapter 3: System Setup 4.Install external M12 A-CODE 8P COM cable. Please align the connector direction and tighten the locking ring to secure the waterproof cable. 5.Install two external M12 X-CODE 8P LAN cable. Please align the foolproof opening and tighten the locking ring to secure the waterproof cable.

  • Page 41: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 42: Bios Introduction

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.1 BIOS Introduction The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del> immediately allows you to enter the setup screens.

  • Page 43: Main Setup

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu. ■...

  • Page 44: Advanced Setup

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3 Advanced Setup...

  • Page 45: Cpu Configuration

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.1 CPU Configuration Item Options Description Intel (VMX) Virtualization When enabled, a VMM can utilize the Disabled, Technology additional hardware capabilities provided by Enabled[Default] Virtualization Technology. All[Default] Number of cores to enable in each processor Active Processor Cores package.

  • Page 46: Pch-Fw Configuration

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.2 PCH-FW Configuration...

  • Page 47: Sata And Rst Configuration

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.3 SATA and RST Configuration Item Options Description Disabled, Port0 ~1 Enable or Disable SATA Port. Enabled[Default] Hard Disk Drive[Default] , Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive.

  • Page 48: Trusted Computing

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.4 Trusted Computing Item Options Description Enable/Disable BIOS support for security device. O.S. will not show Security Enabled[Default] , Security Device Support Disabled, Device.TCG EFI protocol and INT1A interface will not be available. Schedule an Operation for the Security Device.

  • Page 49: Acpi Settings

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.5 ACPI Settings Item Options Description Enables or Disables System ability to Disabled , Hibernate (OS/S4 Sleep State). This option Enable Hibernation Enabled[Default], may not be effective with some operating systems. Select the highest ACPI sleep state the Suspend Disabled, ACPI Sleep State system will enter when the SUSPEDN...

  • Page 50: Super Io Configuration

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.6 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB).
  • Page 51 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 1 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=3F8h; IRQ=4; , IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; , This item allows you to change the address & Change Settings IO=2F8h;...
  • Page 52 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 2 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=2F8h; IRQ=3; , IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; , This item allows you to change the address Change Settings IO=2F8h;...
  • Page 53 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 3 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=3E8h; IRQ=7; , IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; , This item allows you to change the address & Change Settings IO=2E8h;...
  • Page 54 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 4 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=2E8h; IRQ=7; , IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; , This item allows you to change the address & Change Settings IO=2E8h;...
  • Page 55 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 5 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=2F0h; IRQ=7; , IO=3E8h; This item allows you to change the address Change Settings IRQ=3,4,5,6,7,9,10,11,12;...
  • Page 56 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 6 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=2E0h; IRQ=7; , IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; , This item allows you to change the address & Change Settings IO=2E8h;...

  • Page 57: Hardware Monitor

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.7 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. Item Options Description Smart Fan Function Disabled[Default], Enabled or Disable Smart Fan Enabled...
  • Page 58 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ Smart Fan Mode Configuration Item Options Description Manual Duty Mode, Fan1 SmartFan Control Smart Fan Mode Select Auto Duty-Cycle Mode[Default], Temperature 1~4 1~100 Auto fan speed control. SMART FAN IV 20~100 Duty Cycle 1~4 Auto fan speed control.

  • Page 59: Power Ign Mode

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.8 Power IGN Mode Item Options Description Read IGN: BIOS will only read settings from Read mode[Default] IGN Setting IGN module. Write IGN: BIOS will overwrite Write IGN settings in IGN module. 10 Sec[Default] 20 Sec 30 Sec...

  • Page 60: S5 Rtc Wake Settings

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.9 S5 RTC Wake Settings Item Options Description Enable or disable System wake on alarm event. Select FixedTime, system will wake Disabled[Default] on the hr::min::sec specified. Wake system from Fixed Time Select DynamicTime , System will wake on Dynamic Time the current time + Increase minute(s), Bypass...

  • Page 61: Serial Port Console Redirection

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.10 Serial Port Console Redirection Item Options Description Disabled[Default], These items allows you to enable or Console Redirection Enabled disable COM1 console redirection...

  • Page 62: Usb Configuration

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.11 USB Configuration Item Options Description Enables Legacy USB support. AUTO option Enabled[Default] disables legacy support if no USB devices are Legacy USB Support Disabled connected. DISABLE option will keep USB Auto devices available only for EFI applications.

  • Page 63: Network Stack Configuration

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.12 Network Stack Configuration Item Options Description Disabled[Default] , Network Stack Enable/Disable UEFI Network Stack. Enabled Enable/Disable IPv4 PXE boot support. If Disabled[Default] , IPv4 PXE Support disabled, IPv4 PXE boot support will not be Enabled available.

  • Page 64: Nvme Configuration

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.13 NVMe Configuration...

  • Page 65: Chipset

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference.

  • Page 66: System Agent (Sa) Configuration

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.4.1 System Agent (SA) Configuration Item Options Description Disabled, VT-d VT-d capability. Enabled [Default] Enable/Disable above 4GB MemoryMappedIO Above 4GB MMIO BIOS Enabled[Default] , BIOS assignment\n\nThis is enabled assignment Disabled automatically when Aperture Size is set to 2048MB.
  • Page 67 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ Memory Configuration Item Options Description Dynamic[Default], 1GB, 1.25GB, Maximum Value of TOLUD. Dynamic 1.5 GB, assignment would adjust TOLUD Max TOLUD 1.75 GB, automatically based on largest MMIO length 2 GB, of installed graphic controller 2.25 GB, 2.5 GB,...
  • Page 68 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ Graphic Configuration Item Options Description 2MB, GTT Size 4MB, Select the GTT Size . 8MB[Default] Select the Aperture Size. 128MB, Note : Above 4GB MMIO BIOS assignment is 256MB[Default] , Aperture Size automatically enabled when selecting 2048MB 512MB, aperture.

  • Page 69: Pch-Io Configuration

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.4.2 PCH-IO Configuration Item Options Description Power On, Specify what state to go to when power is re- Restore AC Power Loss Power Off [Default] , applied after a power failure (G3 state). Lase State...
  • Page 70 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ PCI Express Configuration...
  • Page 71 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup • PCI Express Root Port 3 /4 /5 /7 Item Options Description PCI Express Root Port Disabled, Control the PCI Express Root Port. Enabled [Default] 3 /4 /5 /7 Set the ASPM Level: Disabled [Default] , L0s, Force L0s - Force all links to L0s State,...
  • Page 72 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ USB Configuration Item Options Description Option to enable Compliance Mode. Default is Disabled [Default] , XHCI Compliance mode to disable Compliance Mode. Change to Enabled enabled for Compliance Mode testing.
  • Page 73 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ HD Audio Configuration Item Options Description Control Detection of the HD-Audio device. Disabled, HD Audio Disabled = HDA will be unconditionally disabled Enabled [Default] Enabled = HDA will be unconditionally enabled.

  • Page 74: Security

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.5 Security Security menu allow users to change administrator password and user password settings. ■ Administrator Password This item allows you to set Administrator Password. ■ User Password This item allows you to set User Password.
  • Page 75 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ Security Boot Item Options Description Secure Boot feature is Active if Secure Boot is Enabled,Platform Key(PK) is enrolled and the Disabled [Default] , Secure Boot System is in User mode. Enabled The mode change requires platform reset Secure Boot mode options:Standard or Custom.
  • Page 76 WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup ■ Key Management Item Options Description Install factory default Secure Boot keys after Disabled [Default] , Factory Key Provision the platform reset and while the System is in Enabled Setup mode...

  • Page 77: Boot

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.6 Boot This menu allows you to setup the system boot options. Item Options Description Number of seconds to wait for setup activation Setup Prompt Timeout 1[Default] key. 65535(0xFFFF) means indefinite waiting. On[Default] , Bootup NumLock State Select the Keyboard NumLock state.

  • Page 78: Save & Exit

    WCO-3000-EHL l User’s Manual Chapter 4: BIOS Setup 4.7 Save & Exit This setting allows users to configure the boot settings. ■ Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.

  • Page 79: Appendix Wdt & Gpio

    Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).

  • Page 80: Wdt Sample Code

    WCO-3000-EHL l User’s Manual Appendix – WDT & GPIO WDT Sample Code WDT Setting Psuedo Code // IO Address 0xA16 is time value(second) // IO Address 0xA15 is WDT enable and configuration Example, Set 0xA16=-0x02, 0xA15=0x31, it will reset after 2 seconds #define TimePort 0xA16 #define TimeEnablePort...

  • Page 81: Gpio Sample Code

    WCO-3000-EHL l User’s Manual Appendix – WDT & GPIO GPIO Sample Code GPIO Setting IO_DO4 I/O 0xA02h Bit3 IO_DO3 I/O 0xA02h Bit2 IO_DO2 I/O 0xA02h Bit1 IO_DO1 I/O 0xA02h Bit0 IO_DI4 I/O 0xA03h Bit7 IO_DI3 I/O 0xA03h Bit6 IO_DI2 I/O 0xA03h Bit5 IO_DI1 I/O 0xA03h Bit4 The GPIO function is provided by SIO, and it can be accessed through its GPIO port.
  • Page 82 © Premio Inc. All Rights Reserved www.premioinc.com...
