USER'S
MANUAL
RCO-6000-CML
Industrial AI Edge Inference Computer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RCO-6000-CML-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Premio RCO-6000-CML-2

Summary of Contents for Premio RCO-6000-CML-2

  • Page 1 USER’S MANUAL RCO-6000-CML Industrial AI Edge Inference Computer...

  • Page 2: Table Of Contents

    RCO-6000-CML l User’s Manual Table of Contents Prefaces …………………………………………………….……………………………………………. 04 Revision …………………………………………………………………………………………..……………….……….. 04 Disclaimer ………………………………………………………..…….…….………………………….……………….. 04 Copyright Notice …………………………………….…………………….…………………………………………… 04 Trademarks Acknowledgment …………..………………………………………………………....04 Environmental Protection Announcement …………………………….………………….……………….. 04 Safety Precautions ………………………………………….……………………………….…………….………….. 05 Technical Support and Assistance …………………………………….…………….…………….…………….06 Conventions Used in this Manual ………………………………………………………………….….………..06 Package Contents …………………………………………………………………………………………….…………...
  • Page 3 RCO-6000-CML l User’s Manual Chapter 3 System Setup …………………………..…………………………………………… 88 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing .…………………………………………………………………………………..…..…... 89 Disconnecting expansion module from computing module …………..……... 89 Removing chassis top cover ……….…………….…………………………………………….. 91 Install HDD/SSD on the internal SATA bay ……….…....………………… 92 Installing HDD on removable SATA HDD/SSD bay ..…….………….….…………..

  • Page 4: Prefaces

    2022/04/01 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.

  • Page 5: Safety Precautions

    Preface RCO-6000-CML l User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions:  Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage.  The power outlet shall be installed near the equipment and shall be easily accessible. ...

  • Page 6: Technical Support And Assistance

    RCO-6000-CML l User’s Manual Technical Support and Assistance 1. Visit the Premio Inc website at www.premioinc.comwhere you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.

  • Page 7: Package Contents

    Preface RCO-6000-CML l User’s Manual Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty ： Choosing one • RCO-6000-CML Superior Fanless Embedded System • RCO-6000-CML-2C Superior Fanless Embedded System •...
  • Page 8 Preface RCO-6000-CML l User’s Manual Model No. Product Description GPU Computing System w/ LGA 1200 for Intel 10th Gen Processor or RCO-6000-CML-2C-2PWR Optional Intel XEON-W Processors and W480E PCH, 1x PCIe x16, 1x PCI, 2x Power input Available Expansion： 2C：1x PCI and 1x PCIe x16 2I：...
  • Page 9 Preface RCO-6000-CML l User’s Manual Model No. Product Description RCO-6000-CML-4NS AI Edge Inference Computer With LGA 1200 for Intel 10th Gen Processor or Optional Intel XEON-W Processors and W480E PCH, 4x U.2 15mm NVMe, Software RAID Available Module： • 4LM12：4x M12 LAN Ports •...

  • Page 10: Optional Accessory

    Preface RCO-6000-CML l User’s Manual Model No. Product Description RCO-6000-CML-4N-2060S AI Edge Inference Computer With LGA 1200 for Intel 10th Gen Processor or Optional Intel XEON-W Processors and W480E PCH, 4x U.2 7mm, RTX 2060S Integrated Available Module： • 4LM12：4x M12 LAN Ports •...

  • Page 11: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 12: Overview

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.1 Overview The Superior Embedded Systems RCO-6000-CML series are designed with rich I/O, high flexibility and easy expansion capabilities which are ideal for diverse industrial applications.Support 10th Gen. Intel® Xeon® W-1290TE (4.5GHz, 10 Cores) / Intel® Xeon® W-1270TE (4.4GHz, 8 Cores) / Intel® Xeon® W- 1250TE (3.8GHz, 6 Cores) or Intel®...
  • Page 13 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions Model No. Rear Panel Front Panel RCO-6000-CML-4NS (4x U.2 15mm NVMe, Software RAID) RCO-6000-CML-4NH (4x U.2 15mm NVMe, Hardware RAID) RCO-6000-CML-8NS (8x U.2 NVMe Bay) RCO-6000-CML-2N-2060S (RTX 2060 Super integrated) RCO-6000-CML-4N-2060S (1x PCIe x16, 1x PCI, 4 Bay 7mm)

  • Page 14: Key Feature

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.1.1 Key Features  LGA 1200 socket for 10th Gen. Intel® CML S Processor or Optional Intel XEON-W Processors (65W/35W TDP)  Intel® W480E chipset  2x DDR4 2666/2933MHz SODIMM. Max. up to 64GB ...

  • Page 15: Hardware Specification

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.2 Hardware Specification System System Intel® W480E Chipset Chipset Processor LAN Chipset GbE1: Intel I219 (Support Wake-on-LAN and Support 10th Gen Intel® CML S Processor (LGA 1200, 65W/35W TDP) PXE) • Intel® Xeon® W-1290TE, 10 Cores, 20MB Cache, up to 4.5 GHz GbE2: Intel I210 (Support Wake-on-LAN and •...
  • Page 16 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions Storage SIM Socket SSD/HDD RCO-6000-CML-4NS RCO-6000-CML-4NH 1x Internal 2.5" SATA/SSD HDD Bay (support 1x M.2 (E Key, PCIe 2x External SIM socket (Mini H=9mm) x1, USB 2.0, 2230, PCIE attached) 2x Removable 2.5" SATA HDD Bay (support RCO-6000-CML-8NS Support CNVi) H=7mm, Hot-swappable)
  • Page 17 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions Operating System Windows Windows 10 Linux Linux kernel Audio 1x Mic-in, 1x Line-out 2x CAN 2.0 A/B 2-pin Internal header 2x RS-232/422/485 ; 6x RS-232/422/485 (internal) 8 in / 8 out (Isolated) 2x RJ45 Universal I/O Bracket 2x Universal I/O Bracket (By mini PCIe interface)
  • Page 18 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions Environment -25 ° C to 70 ° C (35W/65W CPU) Operating Temp. RCO-6000-CML-2C-20-2060S / RCO-6000-CML-2N-2060S / RCO-6000-CML-4N-2060S ： -25 ° C to 60 ° C (35W/65W CPU) -30 ° C to 85 ° C Storage Temp.

  • Page 19: System I/O

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3 System I/O 1.3.1 RCO-6000-CML Front Panel ATX power on/off switch SIM card Press to power-on or power-off the system Used to insert SIM card Power LED Line-out Indicates the power status of the system Used to connect a speaker HDD LED Mic-in...
  • Page 20 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions RCO-6000-CML Rear Panel DVI-I port USB 3.2 Gen 2 port (10 Gbps) Used to connect a DVI monitor or connect Used to connect USB 3.2 device optional split cable for dual display mode LAN port Digital I/O Terminal Block Used to connect the system to a local area...

  • Page 21: Rco-6000-Cml-2C

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3.2 RCO-6000-CML-2C Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch SIM card Press to power-on or power-off the system Used to insert SIM card Power LED Line-out Indicates the power status of the system Used to connect a speaker HDD LED...
  • Page 22 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions RCO-6000-CML-2C Rear Panel Top Module (Industrial Fanless PC on Top) DVI-I port USB 3.2 Gen 2 port (10 Gbps) Used to connect a DVI monitor or connect Used to connect USB 3.2 device optional split cable for dual display mode LAN port Digital I/O Terminal Block...

  • Page 23: Rco-6000-Cml-2C-4B7M

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3.3 RCO-6000-CML-2C-4B7M Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch SIM card Press to power-on or power-off the system Used to insert SIM card Power LED Line-out Indicates the power status of the system Used to connect a speaker HDD LED...
  • Page 24 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions RCO-6000-CML-2C-4B7M Rear Panel Top Module (Industrial Fanless PC on Top) DVI-I port USB 3.2 Gen 2 port (10 Gbps) Used to connect a DVI monitor or connect Used to connect USB 3.2 device optional split cable for dual display mode LAN port Digital I/O Terminal Block...

  • Page 25: Rco-6000-Cml-2C-2B15M

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3.4 RCO-6000-CML-2C-2B15M Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch SIM card Press to power-on or power-off the system Used to insert SIM card Power LED Line-out Indicates the power status of the system Used to connect a speaker HDD LED...
  • Page 26 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions RCO-6000-CML-2C-2B15M Rear Panel Top Module (Industrial Fanless PC on Top) DVI-I port USB 3.2 Gen 2 port (10 Gbps) Used to connect a DVI monitor or connect Used to connect USB 3.2 device optional split cable for dual display mode LAN port Digital I/O Terminal Block...

  • Page 27: Rco-6000-Cml-2C-2Pwr

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3.5 RCO-6000-CML-2C-2PWR Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch SIM card Press to power-on or power-off the system Used to insert SIM card Power LED Line-out Indicates the power status of the system Used to connect a speaker HDD LED...
  • Page 28 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions RCO-6000-CML-2C-2PWR Rear Panel Top Module (Industrial Fanless PC on Top) DVI-I port USB 3.2 Gen 2 port (10 Gbps) Used to connect a DVI monitor or connect Used to connect USB 3.2 device optional split cable for dual display mode LAN port Digital I/O Terminal Block...

  • Page 29: Rco-6000-Cml-20-2060S

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3.6 RCO-6000-CML-20-2060S Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch SIM card Press to power-on or power-off the system Used to insert SIM card Power LED Line-out Indicates the power status of the system Used to connect a speaker HDD LED...
  • Page 30 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions RCO-6000-CML-20-2060S Rear Panel Top Module (Industrial Fanless PC on Top) DVI-I port USB 3.2 Gen 2 port (10 Gbps) Used to connect a DVI monitor or connect Used to connect USB 3.2 device optional split cable for dual display mode LAN port Digital I/O Terminal Block...

  • Page 31: Rco-6000-Cml-4Nh

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3.7 RCO-6000-CML-4NH Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch SIM card Press to power-on or power-off the system Used to insert SIM card Power LED Line-out Indicates the power status of the system Used to connect a speaker HDD LED...
  • Page 32 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions RCO-6000-CML-4NH Rear Panel Top Module (Industrial Fanless PC on Top) DVI-I port USB 3.2 Gen 2 port (10 Gbps) Used to connect a DVI monitor or connect Used to connect USB 3.2 device optional split cable for dual display mode LAN port Digital I/O Terminal Block...

  • Page 33: Rco-6000-Cml-4Ns

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3.8 RCO-6000-CML-4NS Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch SIM card Press to power-on or power-off the system Used to insert SIM card Power LED Line-out Indicates the power status of the system Used to connect a speaker HDD LED...
  • Page 34 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions RCO-6000-CML-4NS Rear Panel Top Module (Industrial Fanless PC on Top) DVI-I port USB 3.2 Gen 2 port (10 Gbps) Used to connect a DVI monitor or connect Used to connect USB 3.2 device optional split cable for dual display mode LAN port Digital I/O Terminal Block...

  • Page 35: Rco-6000-Cml-8Ns

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3.9 RCO-6000-CML-8NS Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch SIM card Press to power-on or power-off the system Used to insert SIM card Power LED Line-out Indicates the power status of the system Used to connect a speaker HDD LED...
  • Page 36 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions RCO-6000-CML-8NS Rear Panel Top Module (Industrial Fanless PC on Top) DVI-I port USB 3.2 Gen 2 port (10 Gbps) Used to connect a DVI monitor or connect Used to connect USB 3.2 device optional split cable for dual display mode LAN port Digital I/O Terminal Block...

  • Page 37: Rco-6000-Cml-2N-2060S

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3.10 RCO-6000-CML-2N-2060S Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch SIM card Press to power-on or power-off the system Used to insert SIM card Power LED Line-out Indicates the power status of the system Used to connect a speaker HDD LED...
  • Page 38 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions RCO-6000-CML-2N-2060S Rear Panel Top Module (Industrial Fanless PC on Top) DVI-I port USB 3.2 Gen 2 port (10 Gbps) Used to connect a DVI monitor or connect Used to connect USB 3.2 device optional split cable for dual display mode LAN port Digital I/O Terminal Block...

  • Page 39: Rco-6000-Cml-4N-2060S

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3.11 RCO-6000-CML-4N-2060S Front Panel Top Module (Industrial Fanless PC on Top) ATX power on/off switch SIM card Press to power-on or power-off the system Used to insert SIM card Power LED Line-out Indicates the power status of the system Used to connect a speaker HDD LED...
  • Page 40 RCO-6000-CML l User’s Manual Chapter 1: Product Introductions RCO-6000-CML-4N-2060S Rear Panel Top Module (Industrial Fanless PC on Top) DVI-I port USB 3.2 Gen 2 port (10 Gbps) Used to connect a DVI monitor or connect Used to connect USB 3.2 device optional split cable for dual display mode LAN port Digital I/O Terminal Block...

  • Page 41: Universal I/O Bracket (Available Module)

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.3.12 Universal I/O Bracket Model No : • • RCO-6000-CML RCO-6000-CML-4NH • • RCO-6000-CML-2C-4B7M RCO-6000-CML-4NS • • RCO-6000-CML-2C-2B15M RCO-6000-CML-8NS • • RCO-6000-CML-2N-2060S RCO-6000-CML-2C • • RCO-6000-CML-4N-2060S RCO-6000-CML-2C-2PWR • RCO-6000-CML-20-2060S Available Module : LAN/PoE Module 4x RJ45 LAN/PoE Ports M12 Module...

  • Page 42: Mechanical Dimension

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.4 Mechanical Dimensions 1.4.1 RCO-6000-CML Unit: mm...

  • Page 43: Rco-6000-Cml-2C

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.4.2 RCO-6000-CML-2C Unit: mm...

  • Page 44: Rco-6000-Cml-2C-4B7M

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.4.3 RCO-6000-CML-2C-4B7M Unit: mm...

  • Page 45: Rco-6000-Cml-2C-2B15M

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.4.4 RCO-6000-CML-2C-2B15M Unit: mm...

  • Page 46: Rco-6000-Cml-2C-2Pwr

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.4.5 RCO-6000-CML-2C-2PWR Unit: mm...

  • Page 47: Rco-6000-Cml-20-2060S

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.4.6 RCO-6000-CML-20-2060S Unit: mm...

  • Page 48: Rco-6000-Cml-4Nh

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.4.7 RCO-6000-CML-4NH Unit: mm...

  • Page 49: Rco-6000-Cml-4Ns

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.4.8 RCO-6000-CML-4NS Unit: mm...

  • Page 50: Rco-6000-Cml-8Ns

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.4.9 RCO-6000-CML-8NS Unit: mm...

  • Page 51: Rco-6000-Cml-2N-2060S

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.4.10 RCO-6000-CML-2N-2060S Unit: mm...

  • Page 52: Rco-6000-Cml-4N-2060S

    RCO-6000-CML l User’s Manual Chapter 1: Product Introductions 1.4.11 RCO-6000-CML-4N-2060S Unit: mm...

  • Page 53: Chapter 2 Mechanical Specifications

    Chapter 2 Mechanical Specifications...

  • Page 54: Switch And Connector Locations

    RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.1 Switch and Connector Locations 2.1.1 Top View PWRBTN2 DC_IN1 COM1, COM2 DVI-I LAN2 LAN1 DC_IN2 CPU1 FAN_CPU COM5 COM7 COM6 COM8 USB1 USB2 PCIE3_L PCIE4_R PWR1 PWR3 COM3 BAT_F1 PWR4 PWR2 COM4 PWR_SW3 PWRBTN...

  • Page 55: Bottom View

    RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.1.2 Bottom View PCIE1 PCIE2 SATA4 SATA1 SATA2 SATA3 SIM2...

  • Page 56: Connector / Switch Definition

    RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.2 Connector / Switch Definition Connector Location Definition AT_ATX1 AT / ATX Power Mode Switch PWRBTN,2 Power Switch RESET Reset Switch DC_IN1 5-pin DC +9~48V Power Input Connector DC_IN2 6-pin DC +9~48V Power Input Connector DIO1 8DI / 8DO Connector COM1-8...

  • Page 57: I/O Interface Descriptions

    RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3 I/O Interface Descriptions 2.3.1 Power Con PWR1-4 Signal +12V 2.3.2 DC IN/IGN IN (+9V ~ +48V) DC_IN1 Signal +DC_IN +DC_IN IGN_SENSE...
  • Page 58 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.3 COM Con COM3, COM4, COM5, COM6, COM7, COM8 Signal Signal DCD# DSR# RTS# CTS# DTR# RS232 / RS422 / RS485 Connector 2x5 10-pin box header, 2.0mm pitch RS422 / 485 Full Duplex Signal RS485 Half Duplex Definition Definition...
  • Page 59 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.4 RS232 / RS422 / RS485 Connector Type: 9-pin D-Sub COM1, COM2 RS422 / 485 Full Duplex RS232 Definition RS485 Half Duplex Definition Definition DCD# DATA- DATA+ DTR# DSR# RTS# CTS#...
  • Page 60 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.5 AT / ATX Power Mode Switch AT_ATX1 Switch Definition 1-2 (Left) ATX Power Mode (Default) 2-3 (Right) AT Power Mode...
  • Page 61 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.6 PC / Car Mode Switch CAR_PWR1 Switch Definition 1-2 (Left) PC Power Mode (Default) 2-3 (Right) Power Ignition Mode...
  • Page 62 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.7 Power off delay time setup Switch DELAY_TIME1 Switch 1 / 2 / 3 Definition ON / ON / ON 3 sec.（Default Shutdown Timer by O.S） ON / ON / OFF 1 min. ON / OFF / ON 5 min.
  • Page 63 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.8 Line-out Jack (Green) Connector Type: 5-pin Phone Jack LINE_OUT1 Switch Definition OUT_R OUT_L 2.3.9 Microphone Jack (Pink) Connector Type: 5-pin Phone Jack MIC_IN1 Switch Definition MIC_R MIC_L...
  • Page 64 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.10 Clear BIOS Switch LR_CMOS Switch Definition 1-2 (Left) Normal Status (Default) 2-3 (Right) Clear BIOS 2.3.11 Power Button PWR_SW1 Switch Definition Power Button...
  • Page 65 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.12 Reset Button RESET1 Switch Definition RESET 2.3.13 USB3.2 Connector, GEN2 , Type A USB3_1, USB3_2 Definition USB2_D- USB2_D+ USB3_RX- USB3_RX+ USB3_TX- USB3_TX+...
  • Page 66 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.14 USB 3.2 Gen1 Connector, GEN1, Type A USB3_3, USB3_4 Definition Definition USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX-...
  • Page 67 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.15 USB2.0 Connector 2x5 10-pin box header, 2.0mm pitch USB1 Definition Definition USB2_D- USB2_D- USB2_D+ USB2_D+...
  • Page 68 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.16 USB3.0 Connector 2x5 10-pin header, 2.0mm pitch USB2 Definition Definition USB3_TX- USB2_D- USB3_TX+ USB2_D+ USB3_RX- USB3_RX+...
  • Page 69 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.17 Top size SIM Card Socket SIM1 SIM1 Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK...
  • Page 70 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.18 Bottom size SIM Card Socket SIM2 SIM2 Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK...
  • Page 71 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.19 DVI-I Connector DVI_I1 Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0- DVI_TX0+ VGA_DDC_CLOCK DVI_DDC_CLOCK VGA_DDC_DATA DVI_DDC_DATA VGA VSYNC DVI_TXCLK+ DVI_TX1- DVI_TXCLK- DVI_TX1+ VGA_RED VGA_GREEN VGA_BLUE VGA_HSYNC...
  • Page 72 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.20 Display Port Connector DP1 DP2 Definition Definition DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P DP_LANE1_N DP_LANE2_P DP_AUX_N DP_HPD DP_LANE2_N DP_LANE3_P +3.3V...
  • Page 73 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.21 Digital Input / Output Connector Type: Terminal Block 2x9 18-pin, 3.5mm pitch Definition Definition DIN1 DOUT1 DIN2 DOUT2 DIN3 DOUT3 DIN4 DOUT4 DIN5 DOUT5 DIN6 DOUT6 DIN7 DOUT7 DIN8 DOUT8 DC power input (+5V~+30V)
  • Page 74 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.22 Remote Power Switch Type: Terminal Block 1x2 2-pin, 3.5mm pitch PWRBTN2 Definition Power Button...
  • Page 75 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.23 Remote Power Switch 1x4 pin box header, 2.0mm pitch PWR_SW3 Definition Power Button PWR_LED HDD_LED...
  • Page 76 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.24 Connector Type, RJ45 port with LEDs and dual USB 3.2 Gen2 ports X2 LAN1 LAN2 USB3.2 GEN 2 x4 Ports Definition Definition Definition LAN1_MDI0P USB2_D1- USB2_D2- LAN1_MDI0N USB2_D1+ USB2_D2+ LAN1_MDI1P LAN1_MDI2P USB3_RX1- USB3_RX2- LAN1_MDI2N...
  • Page 77 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.25 LED Status Act LED Status Definition Blinking Yellow Data Activity No Activity Link LED Status Definition Steady Orange 1Gbps Network Link Steady Green 100Mbps Network Link 10Mbps Network Link PWR_LED1: Power LED Status Definition POWER LED + POWER LED -...
  • Page 78 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.26 Mini PCI-Express Socket MINIPCIE1, MINIPCIE2 Definition Definition WAKE# +3.3V +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST UIM_VPP RESET# +3.3VAUX +1.5V...
  • Page 79 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications Definition Definition SMB_CLK SMB_DATA USB2_D- USB2_D+ +3.3V +3.3V +1.5V +3.3V...
  • Page 80 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.27 SATA with Power Connector SATA1, SATA2, SATA3, SATA4 Definition Definition +12V DEVSLP +12V +12V...
  • Page 81 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.28 PCI-Express x1 Slot PCIE1 Definition Definition +12V FAN_P4 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# FAN_P3 REFCLK+ TxP0 REFCLK- TxN0 RxP0 FAN_PER RxN0...
  • Page 82 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.29 PCI-Express x8 Slot PCIE3_L, PCIE4_R Definition Definition +12V +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# REFCLK+ TxP0 REFCLK- TxN0...
  • Page 83 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications Definition Definition RxP0 RxN0 TxP1 TxN1 RxP1 RxN1 TxP2 TxN2 RxP2 RxN2 TxP3 TxN3 RxP3 RxN3 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN 9_48VSB_IN...
  • Page 84 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.30 PCI-Express x16 Slot PCIE2 Definition Definition +12V FAN_P4 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3VAUX +3.3V WAKE# RESET# FAN_P3 REFCLK+...
  • Page 85 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications Definition Definition TxP0 REFCLK- TxN0 RxP0 FAN_PWR RxN0 TxP1 TxN1 RxP1 RxN1 TxP2 TxN2 RxP2 RxN2 TxP3 TxN3 RxP3 RxN3 CFG_5 TxP4 CFG_6 TxN4 RxP4 RxN4 TxP5 TxN5...
  • Page 86 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications Definition Definition RxP5 RxN5 TxP6 TxN6 RxP6 RxN6 TxP7 TxN7 RxP7 RxN7 TxP8 TxN8 RxP8 RxN8 TxP9 TxN9 RxP9 RxN9 TxP10 TxN10 RxP10 RxN10 TxP11 TxN11...
  • Page 87 RCO-6000-CML l User’s Manual Chapter 2: Mechanical Specifications Definition Definition RxP11 RxN11 TxP12 TxN12 RxP12 RxN12 TxP13 TxN13 RxP13 RxN13 TxP14 TxN14 RxP14 RxN14 TxP15 TxN15 RxP15 RxN15...

  • Page 88: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 89: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.2 Disconnecting expansion module from computing module In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.
  • Page 90 RCO-6000-CML l User’s Manual Chapter 3: System Setup 2. Remove the 5 screws highlighted below. 3. Now you can separate the expansion module from the computing module.

  • Page 91: Removing Chassis Top Cover

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.3 Removing chassis top cover 1. Unscrew the four screws (M3x5L) highlighted below. 2. Hold the body of the system and lift it vertically away from the top cover. 3. Top cover separated from the system body.

  • Page 92: Install Hdd/Ssd On The Internal Sata Bay

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.4 Install HDD/SSD on the internal SATA bay 1. One internal SATA HDD/SSD bays are available for RCO-6000-CML series. Unscrew the 4 screws (M3x5L) to remove the internal SATA HDD/SSD bay. 2. Lock the 2.5” HDD with HDD/SSD bracket using four screws (M3x4L).
  • Page 93 RCO-6000-CML l User’s Manual Chapter 3: System Setup 3. Install the HDD/SSD bracket following the direction below. 4. Fasten the 4 screws to lock the internal HDD/SSD bracket.

  • Page 94: Installing Hdd On Removable Sata Hdd/Ssd Bay

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.5 Installing HDD on removable SATA HDD/SSD bay 1. Open the tray lock (red circle) ,and remove the tray in the direction of the arrow. 2. Unlock the drive lock (red circle) 3.

  • Page 95: Installing Sodimm

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.6 Installing SODIMM 1. Place the system body with SODIMM socket facing upward. Two SODIMM sockets are available for RCO-6000-CML series on the top side. 2. Insert memory module from 45 degree direction. 3.

  • Page 96: Installing Cpu

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.7 Installing CPU 1. Press down the CPU socket lever in order to open the socket cover. 2. Remove the CPU protective cover.
  • Page 97 RCO-6000-CML l User’s Manual Chapter 3: System Setup 3. Insert CPU gently. 4. Press down the lever again to hold the socket cover.
  • Page 98 RCO-6000-CML l User’s Manual Chapter 3: System Setup 5. Paste thermal pad on the CPU. 6. Place the designated heat block onto the CPU with thermal pad.
  • Page 99 RCO-6000-CML l User’s Manual Chapter 3: System Setup 7. Lock the heat block with three screws (M3x5L). Screw driver will able to penetrate through the holes on the top in order to fasten the screws with copper stud. 8. Paste the thermal pad onto the installed heat block.
  • Page 100 RCO-6000-CML l User’s Manual Chapter 3: System Setup 9. Paste the thermal pad onto the installed heat block.

  • Page 101: Installing Mini Pcie Card

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.8 Installing Mini PCIe card The RCO-6000-CML series has two Mini PCIe slots, both of which are on the top. The MINI-PCIE1 supports mSATA. MINI-PCIE1 1. Insert Mini PCIe card from 45 degree direction. 2.

  • Page 102: Installing Wifi Module

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.9 Installing WiFi Module RCO-6000-CML series PCBA has an M.2 E key slot on the top, M2_KE currently supports WiFi application 1. Insert M.2 E Key card from 45 degree direction. M2_KE 2.
  • Page 103 RCO-6000-CML l User’s Manual Chapter 3: System Setup 3. RCO-6000-CML series system has 5 antenna holes, 2 on the rear panel, 3 on the front panel. 4. Have antenna jack penetrate through the hole, and fasten the nut with SMA jack.
  • Page 104 RCO-6000-CML l User’s Manual Chapter 3: System Setup 5. Assemble the antenna and SMA jack together. 6. Attach the RF connector at the cable-end onto the communication module.

  • Page 105: Installing Mini Pcie Card / 4G Lte

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.10 Installing Mini PCIe card / 4G LTE RCO-6000-CML series PCBA has two Mini PCIe slots on the top, both currently supports 4G LTE applications. MINI-PCIE2 1. Insert Mini PCIe card from 45 degree direction. 2.

  • Page 106: Installing Antenna

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.11 Installing Antenna 1. Remove antenna hole cover on the system panel. 2. Have antenna jack penetrate through the hole, and fasten the nut with SMA jack...
  • Page 107 RCO-6000-CML l User’s Manual Chapter 3: System Setup 3. Assemble the antenna and SMA jack together. 4. Attach the RF connector at the cable-end onto the communication module.

  • Page 108: Installing Hdd On Removable Hddbay (For Rco-6000-Cml-2C-4B7M)

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.12 Installing HDD on removable HDD bay (for RCO-6000-CML-2C- 4B7M) 1. Unscrew the toolless screw circled below to take out the HDD bracket 2. Open the tray lock (red circle) ,and remove the tray in the direction of the arrow...
  • Page 109 RCO-6000-CML l User’s Manual Chapter 3: System Setup 3. Unlock the drive lock and insert the HDD/SSD 4. Put the tray in the direction of the arrow and close the tray lock...

  • Page 110: Installing Hdd On Removable Hdd Bay (For Rco-6000-Cml-2C-2B15M)

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.13 Installing HDD on removable HDD bay (for RCO-6000-CML-2C- 2B15M) 1. Unscrew the toolless screw circled below to take out the HDD bracket. Open the tray lock ,and remove the tray in the direction of the arrow 2.
  • Page 111 RCO-6000-CML l User’s Manual Chapter 3: System Setup 3. Using HDD single side screw hole to align the HDD tray fix-pin. 4. Make a little bit force press down another side like the picture shows, has a “click” sound, and the HDD is fully fixed on the HDD tray.
  • Page 112 RCO-6000-CML l User’s Manual Chapter 3: System Setup 5. Put the tray in the direction of the arrow and close the tray lock.

  • Page 113: Installing Hdd On Removable Hdd Bay (For Rco-6000-Cml-8Ns)

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.14 Installing HDD on removable HDD bay (for RCO-6000-CML-8NS) 1. Unscrew the toolless screw circled below to take out the HDD bracket Lock Unlock 2. Open the tray lock (red circle) ,and remove the tray in the direction of the arrow...
  • Page 114 RCO-6000-CML l User’s Manual Chapter 3: System Setup 3. Unlock the drive lock and insert the HDD/SSD 4. Put the tray in the direction of the arrow and close the tray lock...

  • Page 115: Installing Pcie/Pci Expansion Card (For Rco-6000-Cml-2X)

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.15 Installing PCIe/PCI expansion Card (for RCO-6000-CML-2X) 1. Remove the 4 screws in the circle below.
  • Page 116 RCO-6000-CML l User’s Manual Chapter 3: System Setup 2. Remove the screw in the circle below. 3. Install the PCIe/PCI extension card and ensure the gold finger is inserted into the slot. and then fasten the screw.

  • Page 117: Installing Pcie/Pci Expansion Card (For Rco-6000-Cml-8Ns)

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.16 Installing PCIe/PCI expansion Card (for RCO-6000-CML-8NS) 1. Remove the 4 screws in the circle below.
  • Page 118 RCO-6000-CML l User’s Manual Chapter 3: System Setup 2. Take out the PCIe/PCI expansion card bracket. 3. Remove the screw in the circle below.
  • Page 119 RCO-6000-CML l User’s Manual Chapter 3: System Setup 4. Install the PCIe/PCI extension card and ensure the gold finger is inserted into the slot. and then fasten the screw. 5. Put back the PCIe/PCI expansion card bracket. and then fasten the 5 screws.

  • Page 120: Installing Graphic Card (Rco-6000-Cml-2C-2Pwr)

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.17 Installing graphic Card (RCO-6000-CML-2C-2PWR) 1. Unscrew the 2 screws to remove the I/O shield 2. Unscrew the card bracket screws to remove the bracket from the expansion slots...
  • Page 121 RCO-6000-CML l User’s Manual Chapter 3: System Setup 3. Install the graphic card and ensure the gold finger is inserted into the slot. and then fasten the screws. 4. Adjust the arm until it holds the card firmly in place. Then fasten the screw on the holder.
  • Page 122 RCO-6000-CML l User’s Manual Chapter 3: System Setup 5. Insert power cable from the power board to the graphic card. 6. Put the graphic expansion module into the expansion chassis.
  • Page 123 RCO-6000-CML l User’s Manual Chapter 3: System Setup 7. Fasten the 4 screws in the circle...

  • Page 124: Installing Graphic Card (Rco-6000-Cml-2C-4N-2060S)

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.18 Installing graphic Card (RCO-6000-CML-4N-2060S) 1. Unscrew the 2 screws to remove the I/O shield...
  • Page 125 RCO-6000-CML l User’s Manual Chapter 3: System Setup 2. Unscrew the 2 screws to remove the I/O shield 3. Unscrew the card bracket screws to remove the bracket from the expansion slots...
  • Page 126 RCO-6000-CML l User’s Manual Chapter 3: System Setup 4. Install the graphic card and ensure the gold finger is inserted into the slot. and then fasten the screws. 5. Adjust the arm until it holds the card firmly in place. Then fasten the screw on the holder.
  • Page 127 RCO-6000-CML l User’s Manual Chapter 3: System Setup 6. Fasten the 2 screws and Insert power cable from the power board to the graphic card.

  • Page 128: Appendix A Optional Canbus Cable

    RCO-6000-CML l User’s Manual Chapter 3: System Setup 3.19 Appendix A Optional CANBus Cable 1. 1-TCAN00001 > Dual Channel 2. 1-TCAN00002 > Single Channel...
  • Page 129 RCO-6000-CML l User’s Manual Chapter 3: System Setup 3. Remove the cutting hole 4. Install CANBus cable to the universal bracket...
  • Page 130 RCO-6000-CML l User’s Manual Chapter 3: System Setup 5. Insert CANBus cable to the Motherboard...

  • Page 131: Installing Wall Mount Kit

    RCO-6000-CML l User’s Manual Chapter 3: System Setup Chapter 3: System Setup 3.20 Installing wall mount kit 1. Wall mount kit is available for RCO-6000-CML included in the standard package. 2. Lock the wall mount kit with 8 screws...
  • Page 132 RCO-6000-CML l User’s Manual Chapter 3: System Setup Chapter 3: System Setup...

  • Page 133: Ac Adapter With 3P Terminal Block

    RCO-6000-CML l User’s Manual Chapter 3: System Setup Chapter 3: System Setup 3.21 AC Adapter with 3P terminal block 1. 3P Wiring Diagram of AC Adapter 2. DC power input 3P wiring diagram...

  • Page 134: Ac Adapterwith 4P Terminal Block

    RCO-6000-CML l User’s Manual Chapter 3: System Setup Chapter 3: System Setup 3.22 AC Adapter with 4P terminal block * 12V requires 4-pin terminal block for card/storage expansion 1. AC adapter 4P wiring diagram 2. DC power input 4P wiring diagram...

  • Page 135: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 136: Bios Introduction

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.1 BIOS Introduction The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del> immediately allows you to enter the setup screens.

  • Page 137: Main Setup

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu. ■...

  • Page 138: Advanced Setup

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3 Advanced Setup...

  • Page 139: Connectivity Configuration

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.1 Connectivity Configuration Item Options Description CNVi Mode Disable Integrated, This option configures Connectivity. [Auto Auto Detection[Default] Detection] means that if Discrete solution is discovered it will be enabled by default. Otherwise Integrated solution (CNVi) will be enabled;...

  • Page 140: Cpu Configuration

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.2 CPU Configuration Item Options Description Intel (VMX) Virtualization Disabled, When enabled, a VMM can utilize the Technology Enabled[Default] additional hardware capabilities provided by Virtualization Technology. Active Processor Cores All[Default] Number of cores to enable in each processor package.

  • Page 141: Pch-Fw Configuration

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.3 PCH-FW Configuration Item Options Description AMT BIOS Features Disabled, When disabled AMT BIOS Features are no Enabled[Default] longer supported and user is no longer able to access MEBx Setup. Note:This option does not disable Manageability Features in FW.

  • Page 142: Sata And Rst Configuration

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.4 SATA and RST Configuration Item Options Description SATA Controller(s) Disabled, Enable/Disable SATA Device. Enabled[Default] SATA Mode Selection AHCI[Default] , Determines how SATA controller(s) operate. Intel RST Premium With Intel Optane System Acceleration Port0 ~6 Disabled,...

  • Page 143: Rst (Uefi Raid) Configuration

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.5 RST (UEFI RAID) Configuration How to set the UEFI RAID: 1. When set to “Intel RST Premium With Intel Optane System Acceleration“, please save change reset system. 2. After reboot the system, please into BIOS utility and then will see “Intel (R) Rapid Storage Technology”...
  • Page 144 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 3. Into Intel(R) Rapid Storage Technology, and start create RAID volume. 4. Start Create the RAID ■ Select Disk that you want to do the RAID ■ Select [x]; No-Select [ ]...

  • Page 145: Trusted Computing

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.6 Trusted Computing Item Options Description Security Device Support Enabled, Enable/Disable BIOS support for security Disabled[Default] , device. O.S. will not show Security Device.TCG EFI protocol and INT1A interface will not be available. Pending operation None[Default] , Schedule an Operation for the Security...

  • Page 146: Acpi Settings

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.7 ACPI Settings Item Options Description Enable Hibernation Disabled , Enables or Disables System ability to Enabled[Default], Hibernate (OS/S4 Sleep State). This option may not be effective with some operating systems. ACPI Sleep State Suspend Disabled, Select the highest ACPI sleep state the S3 (Suspend to...

  • Page 147: Super Io Configuration

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.8 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB).
  • Page 148 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 1 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the IO=3F8h; IRQ=4; , address & IRQ settings of the specified IO=3F8h;...
  • Page 149 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 2 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the IO=2F8h; IRQ=3; , address & IRQ settings of the specified IO=3F8h;...
  • Page 150 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 3 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the IO=3E8h; IRQ=7; , address & IRQ settings of the specified IO=3E8h;...
  • Page 151 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 4 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the IO=2E8h; IRQ=7; , address & IRQ settings of the specified IO=3E8h;...
  • Page 152 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 5 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the IO=240h; IRQ=5; , address & IRQ settings of the specified IO=240h;...
  • Page 153 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 6 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the IO=248h; IRQ=5; , address & IRQ settings of the specified IO=240h;...
  • Page 154 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 7 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the IO=250h; IRQ=5; , address & IRQ settings of the specified IO=240h;...
  • Page 155 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 8 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the IO=258h; IRQ=5; , address & IRQ settings of the specified IO=240h;...

  • Page 156: Hardware Monitor

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.9 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. Item Options Description Smart Fan Function Disabled[Default], Enabled or Disable Smart Fan Enabled...
  • Page 157 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Smart Fan Mode Configuration Item Options Description Expansion Fan Manual Mode, Smart Fan Mode Select SmartFan Control SMART FAN IV Mode[Default], Temperature 1~4 1~100 Auto fan speed control. SMART FAN IV Duty Cycle 1~4 20~100 Auto fan speed control.

  • Page 158: Serial Port Console Redirection

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.10 Serial Port Console Redirection Item Options Description Console Redirection Disabled[Default], These items allows you to enable or Enabled disable COM1 console redirection...

  • Page 159: Usb Configuration

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.11 USB Configuration Item Options Description Legacy USB Support Enabled[Default] Enables Legacy USB support. AUTO option Disabled disables legacy support if no USB devices Auto are connected. DISABLE option will keep USB devices available only for EFI applications.

  • Page 160: Network Stack Configuration

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.12 Network Stack Configuration Item Options Description Network Stack Disabled[Default] , Enable/Disable UEFI Network Stack. Enabled IPv4 PXE Support Disabled[Default] , Enable/Disable IPv4 PXE boot support. If Enabled disabled, IPv4 PXE boot support will not be available.

  • Page 161: Csm Configuration

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.13 CSM Configuration Item Options Description CSM Support Disabled[Default] , This item allows users to enable or Enabled disable for “CSM Support”. GateA20 Active Upon Request[Default] , This item allows users to set Upon Always Request or Always for "GateA20 Active“.

  • Page 162: Chipset

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.4.1 System Agent (SA) Configuration...
  • Page 163 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Memory Configuration Item Options Description Max TOLUD Dynamic[Default], Maximum Value of TOLUD. Dynamic 1GB, assignment would adjust TOLUD 1.25GB, automatically based on largest MMIO 1.5 GB, length of installed graphic controller 1.75 GB, 2 GB, 2.25 GB,...
  • Page 164 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Graphic Configuration Item Options Description Primary Display Auto[Default] , Select which of IGFX/PEG Graphics device PEG + IGFX should be Primary Display. PEG+IGFX(Multiple-Displays): IGFX will be primary and only display under BIOS and DOS mode.
  • Page 165 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup PEG Port Configuration ■ Item Options Description Enable Root Port Enabled[Default] , Enable or Disable the Root Port Disabled Max Link Speed Auto[Default] , Configure PEG 0:X:X Max Speed Gen1, Gen3, Gen3, PEG0 Hotplug Disabled[Default] , PCI Express Hot Plug Enable/Disable...

  • Page 166: Pch-Io Configuration

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.4.2 PCH-IO Configuration Item Options Description PCH LAN Controller Enabled [Default] , Enable/Disable onboard NIC. Disabled Wake on LAN Enabled, Enable/Disable integrated LAN to wake Enable Disabled [Default] the system. Restore AC Power Power On, Specify what state to go to when power is Loss...
  • Page 167 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ PCI Express Configuration...
  • Page 168 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup  PCI Express Root Port 4 /5 /9 /10 /11 /20 /21 Item Options Description PCI Express Root Port Disabled [Default] , Control the PCI Express Root Port. Enabled 4 /5 /9 /10 /11 /20 /21 ASPM Disabled [Default] , Set the ASPM Level:...
  • Page 169 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ USB Configuration Item Options Description XHCI Compliance Disabled [Default] , Option to enable Compliance Mode. mode Enabled Default is to disable Compliance Mode. Change to enabled for Compliance Mode testing. USB Standby Power Disabled, Enable/Disable USB Standby Power during Enabled [Default]...
  • Page 170 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ HD Audio Configuration Item Options Description HD Audio Disabled, Control Detection of the HD-Audio device. Enabled [Default] Disabled = HDA will be unconditionally disabled Enabled = HDA will be unconditionally enabled.

  • Page 171: Security

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.5 Security Security menu allow users to change administrator password and user password settings. ■ Administrator Password This item allows you to set Administrator Password. ■ User Password This item allows you to set User Password.
  • Page 172 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Security Boot Item Options Description Secure Boot Disabled [Default] , Secure Boot feature is Active if Secure Enabled Boot is Enabled,Platform Key(PK) is enrolled and the System is in User mode. The mode change requires platform reset Secure Boot Mode Standard,...
  • Page 173 RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup ■ Key Management Item Options Description Factory Key Disabled [Default] , Install factory default Secure Boot keys Provision Enabled after the platform reset and while the System is in Setup mode...

  • Page 174: Boot

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.6 Boot This menu allows you to setup the system boot options. Item Options Description Setup Prompt 1[Default] Number of seconds to wait for setup Timeout activation key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock On[Default] , Select the Keyboard NumLock state.

  • Page 175: Save & Exit

    RCO-6000-CML l User’s Manual Chapter 4: BIOS Setup 4.7 Save & Exit This setting allows users to configure the boot settings. ■ Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.

  • Page 176: Appendix Wdt & Gpio

    Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).

  • Page 177: Wdt Sample Code

    RCO-6000-CML l User’s Manual Appendix – WDT & GPIO WDT Sample Code WDT Setting Psuedo Code #define AddrPort 0x2e #define DataPort 0x2f #define SIO_UnLock_Value 0x87 #define SIO_Lock_Value 0xaa #define WATCHDOG_LDN 0x08 #define GPIO_Port 0xF1 //Enter_Config WriteByte (AddrPort, SIO_UnLock_Value); WriteByte (AddrPort, SIO_UnLock_Value); //Enter WATCHDOG LDN WriteByte (AddrPort, 0x07);...

  • Page 178: Gpio Sample Code

    RCO-6000-CML l User’s Manual Appendix – WDT & GPIO GPIO Sample Code GPIO Setting PIN# GPIO# Default Configuration XCOM- XCOM+ OUT8 DIO Output8 DIO Input8 OUT7 DIO Output7 DIO Input7 OUT6 DIO Output6 DIO Input6 OUT5 DIO Output5 DIO Input5 OUT4 DIO Output4 DIO Input4...
  • Page 179 © 2022 Premio Inc. All Rights Reserved www.premioinc.com...

This manual is also suitable for:

Rco-6000-cml-2cRco-6000-cml-2c-4b7mRco-6000-cml-2c-2b15mRco-6000-cml-2c-2pwrRco-6000-cml-20-2060sRco-6000-cml-4nh ... Show all

Table of Contents
