  • Page 1 USER’S MANUAL RCO-1000-EHL Series Compact Fanless Embedded System...

  • Page 2: Table Of Contents

    RCO-1000-EHL l User’s Manual Table of Contents Prefaces …………………………………………………….……………………………………………. 04 Revision …………………………………………………………………………………………..……………….……….. 04 Disclaimer ………………………………………………………..…….…….………………………….……………….. 04 Copyright Notice …………………………………….…………………….…………………………………………… 04 Trademarks Acknowledgment …………..………………………………………………………....04 Environmental Protection Announcement …………………………….………………….……………….. 04 Safety Precautions ………………………………………….……………………………….…………….………….. 05 Technical Support and Assistance …………………………………….…………….…………….…………….06 Conventions Used in this Manual ………………………………………………………………….….………..06 Package Contents …………………………………………………………………………………………….…………...
  • Page 3 RCO-1000-EHL l User’s Manual 3.12 Installing wall mount kit …………………….…………..….…………………..………….…..55 3.13 Installing VESA mount kit …….…………..….…..….………………………………………….. 57 3.14 Installing side mount kit …….…………..….…….….………………………………………….. 59 3.15 Installing DIN rail holder …….…………..….…..…...…………………………………………..61 Chapter 4 BIOS Setup …………………………………………………………………………… 62 BIOS Introduction …….……….……………………………………..….…….…..….…………...63 Main Setup ……..……….………………….…………………………..…….….………………..64 Advanced Setup ………………………………………………………..……………………………..

  • Page 4: Prefaces

    2022/11/22 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Solution Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.

  • Page 5: Safety Precautions

    Preface RCO-1000-EHL l User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible. ⚫...

  • Page 6: Technical Support And Assistance

    Preface RCO-1000-EHL l User’s Manual Technical Support and Assistance 1. Visit the Premio Inc website at www.premioinc.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.

  • Page 7: Package Contents

    RCO-1000-EHL l User’s Manual Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty RCO-1000-EHL Series Embedded System L-Shaped Wall Mount KIT Accessory Kit Ordering Information • RCO-1000-EHL-10 Series Model No.

  • Page 8: Optional Accessory

    Preface RCO-1000-EHL l User’s Manual • RCO-1000-EHL-20 Series Model No. Product Description Compact fanless embedded system with Intel x6425E CPU, RCO-1000-EHL-X6425E-20C 3x DP, 2x COM, DIO, 1x 2.5" SATA HDD Bay Compact fanless embedded system with Intel x6425E CPU, RCO-1000-EHL-X6425E-20D 2x DP, 4x COM, 1x 2.5"...

  • Page 9: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 10: Overview

    Based on Intel® Atom™ x6425E (2.0GHz) Quad Core processor or Celeron® J6413 (1.8GHz) Quad Core processor, RCO-1000-EHL series is a high variety and diversity fanless embedded system. It offers modularize expansion I/O, rich connectivity interfaces, wide range (9~36V) DC power input, and high °...

  • Page 11: Key Feature

    RCO-1000-EHL l User’s Manual Chapter 1: Product Introductions Model No. Rear Panel Front Panel RCO-1000-EHL-20 RCO-1000-EHL-20C Expanslon Modules: 2x COM Ports, 1x DP Port and 1x DIO (4in/4out, Isolated) RCO-1000-EHL-20D Expanslon Modules: 4x COM Ports Model No. Rear Panel Front Panel RCO-1000-EHL-30C Expanslon Modules: 4x COM Ports,...

  • Page 12: Hardware Specification

    1x Mic-in, 1x Line-out 2x CAN 2.0 A/B 2-pin Internal header RCO-1000-EHL-10 ： 1x Universal I/O Bracket (By mini PCIe interface, Premio Priority Module) RCO-1000-EHL-20 ： 3x Universal I/O Bracket (By mini PCIe interface, Premio Priority Module) Universal I/O Bracket RCO-1000-EHL-30 ：...
  • Page 13 RCO-1000-EHL l User’s Manual Chapter 1: Product Introductions Power Power Mode AT, ATX Power Supply Voltage 9~36VDC Power Ignition Sensing 6-mode and Adjustable Power Ignition Management, Optional Power Connector 3-pin Terminal Block Power Adaptor Optional AC/DC 12V/5A, 60W OVP (Over Voltage Protection) Power Protection OCP (Over Current Protection) Reverse Protection...

  • Page 14: System I/O

    RCO-1000-EHL l User’s Manual Chapter 1: Product Introductions 1.3 System I/O 1.3.1 RCO-1000-EHL-10 Front Panel • SIM card • ATX power on/off switch Used to insert a SIM card Press to power-on or power-off the system • AT/ATX mode select switch •...
  • Page 15 RCO-1000-EHL l User’s Manual Chapter 1: Product Introductions 1.3.1 RCO-1000-EHL-10 Rear Panel • DC IN • Antenna hole Used to plug a DC power input with terminal Used to connect an antenna for optional block Mini-PCIe WiFi module • DisplayPort •...

  • Page 16: Rco-1000-Ehl-20

    RCO-1000-EHL l User’s Manual Chapter 1: Product Introductions 1.3.2 RCO-1000-EHL-20 Front Panel • SIM card • ATX power on/off switch Used to insert a SIM card Press to power-on or power-off the system • AT/ATX mode select switch • LAN port Used to select AT or ATX power mode Used to connect the system to a local area network...
  • Page 17 RCO-1000-EHL l User’s Manual Chapter 1: Product Introductions 1.3.2 RCO-1000-EHL-20 Rear Panel • DC IN • Antenna hole Used to plug a DC power input with terminal Used to connect an antenna for optional block Mini-PCIe WiFi module • DisplayPort •...

  • Page 18: Rco-1000-Ehl-30

    RCO-1000-EHL l User’s Manual Chapter 1: Product Introductions 1.3.3 RCO-1000-EHL-30 Front Panel • SIM card • ATX power on/off switch Used to insert a SIM card Press to power-on or power-off the system • AT/ATX mode select switch • LAN port Used to select AT or ATX power mode Used to connect the system to a local area network...
  • Page 19 RCO-1000-EHL l User’s Manual Chapter 1: Product Introductions 1.3.3 RCO-1000-EHL-30 Rear Panel • DC IN • Antenna hole Used to plug a DC power input with terminal Used to connect an antenna for optional block Mini-PCIe WiFi module • DisplayPort •...

  • Page 20: Mechanical Dimension

    RCO-1000-EHL l User’s Manual Chapter 1: Product Introductions 1.4 Mechanical Dimensions 1.4.1 RCO-1000-EHL-10 Unit: mm...

  • Page 21: Rco-1000-Ehl-20

    RCO-1000-EHL l User’s Manual Chapter 1: Product Introductions 1.4.2 RCO-1000-EHL-20 Unit: mm...

  • Page 22: Rco-1000-Ehl-30

    RCO-1000-EHL l User’s Manual Chapter 1: Product Introductions 1.4.3 RCO-1000-EHL-30 Unit: mm...

  • Page 23: Chapter 2 Switches And Connectors

    Chapter 2 Switches and Connectors...

  • Page 24: Switch And Connector Locations

    RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.1 Switch and Connector Locations 2.1.1 Top View PWR_SW2 COM2 MIC_IN1 SODIMM1 LINE_OUT1 LAN1 COM1 LAN2 USB3_1 USB3_2 USB3_3 USB2_1 HDD_LED1 DC_IN1 PWR_SW1 PWR_LED1...

  • Page 25: Bottom View

    RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.1.2 Bottom View SATA1 AT_ATX1 BTB_FH1 MPCIE1 M.2_KB1 RESET1 RST_LED1 CAN1 CAN2...

  • Page 26: Daughterboard View

    RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.1.3 Daughter board view...

  • Page 27: Connector / Switch Definition

    RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition DC_IN1 3-pin DC +9~36V Power Input Connector PWR_SW1 Power Switch PWR_SW2 Remote Power Switch DP1 - 2 Display Port COM1 - 2 RS232 / RS422 / RS485 Connector USB2_1...

  • Page 28: Switch Definitions

    RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3 Switches Definitions 2.3.1 DC Power Input Connector (+9~36V) DC_IN1 Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Switch Definition 9~36 VIN 2.3.2 Power Button PWR_SW1 Definition Definition Power Button 2.3.3 Remote Power Switch PWR_SW2 Connector Type: Terminal Block 1X2 2-pin, 3.5mm pitch Definition...
  • Page 29 RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.4 DisplayPort Connector DP1-2 Definition Definition DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P DP_LANE1_N DP_LANE2_P DP_AUX_N DP_HPD DP_LANE2_N DP_LANE3_P DP_PWR...
  • Page 30 RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.5 RS232 / RS422 / RS485 Connector COM1-2 Connector Type: 9-pin D-Sub RS422 / 485 Full Duplex RS485 Half Duplex RS232 Definition Definition Definition DCD2 TX2- DATA2- RxD2 TX2+ DATA2+ TxD2 RX2+ DTR2 RX2-...
  • Page 31 RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.6 USB2.0 Connector, Type A USB2_1 Definition USB2_D2- USB2_D2+ 2.3.7 USB 3.2 Connector, Type A USB3_1-3 Definition Definition USB3_RX+ USB2_DATA1- USB2_DATA1+ USB3_TX- USB3_TX+ USB3_RX-...
  • Page 32 RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.8 RJ45 with LEDs Port LAN1 Definition Definition LAN1_MDI0P LAN1_MDI2N LAN1_MDI0N LAN1_MDI1N LAN1_MDI1P LAN1_MDI3P LAN1_MDI2P LAN1_MDI3N Link LED Status Definition Act LED Status Definition Steady Orange 1Gbps Network Link Blinking Yellow Data Activity Steady Green 100Mbps Network Link...
  • Page 33 RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.9 Microphone Jack (Pink) MIC_IN1 Connector Type: 5-pin Phone Jack Definition MIC_R MIC_L 2.3.10 Line-out Jack (Green) LINE_OUT1 Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L PWR_LED1: Power LED Status RESET1 : Reset Button Definition Definition POWER LED+...
  • Page 34 RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.11 AT / ATX Power Mode Switch AT_ATX1 Switch Definition 1-2 (Right) ATX Power Mode（Default） 2-3 (Left) AT Power Mode 2.3.12 SATA with Power Connector SATA1 Definition Definition SATA_TXP1 SATA_TXN1 SATA_RXN1 SATA_RXP1 +3.3V +3.3V...
  • Page 35 RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.13 Smart FAN Connector Definition +12V FANIN FANCTL 2.3.14 CAN Bus Connector CAN 1-2 Definition CAN_H CAN_L...
  • Page 36 RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.15 Mini PCI-Express / mSATA Socket MPCIE1 Definition Definition Definition WAKE# +3.3V +3.3V USB_DP1 +3.3V MINIPCIE RST# MINIPCIE_RXN1 +3.3V +1.5V +3.3V CLKREQ1# MINIPCIE_RXP1 USIM_VCC USIM_DATA +1.5V MINIPCIE_CLKN1 USIM_CLK SMB_CLK +1.5V MINIPCIE_CLKP1 MINIPCIE_TXN1 USIM_RST SMB_DATA...
  • Page 37 RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.16 M.2 B Key Socket M2_KB1 Definition Definition +3.3V +3.3V +3.3V +1.8S USB2_D+ +3.3V USB2_D- +3.3V USB_RxN0 USB_RxP0 SIM_RST SIM_CLK USB_TxN0 SIM_DATA USB_TxP0 SIM_VDD PCIE_RxN0 PCIE_RxP0 PCIE_TxN0 PCIE_TxP0 PCIE_RST# REFCLK1- CLK_REQ# REFCLK1+ PCIE_WAKE# +3.3V...
  • Page 38 RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.17 SIM Card Socket SIM1 - 2 Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK 2.3.18 Digital Input / Output Connector DIO1 Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition DC INPUT...
  • Page 39 RCO-1000-EHL l User’s Manual Chapter 2: Switches and Connectors 2.3.19 RS232 / RS422 / RS485 Connector CN1 – 2 Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DCD3 (DCD5) TX3- (TX5-) DATA3- (DATA5-) RxD3 (RxD5) TX3+ (TX5+) DATA3+ (DATA5+)

  • Page 40: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 41: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.2 Removing the chassis bottom cover In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.

  • Page 42: Removing Hdd Bracket

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.3 Removing HDD bracket 1. This step is does not apply to RCO-1000 model as it has no HDD bracket. 2. Unscrew four screws (M3x5L) circled below. 3. Now you can remove the HDD bracket.

  • Page 43: Removing Chassis Top Cover

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.4 Removing chassis top cover 1. Unscrew the three screws (M3x5L) and two copper stud (M3x11L) highlighted below. 2. Hold the body of the system and lift it vertically away from the top cover. 3.

  • Page 44: Installing Sodimm

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.5 Installing SODIMM 1. Place the system body with SODIMM socket facing upward. 2. Insert memory module from 45 degree direction. 3. Press the memory module vertically downward until you hear the “click” sound. Make sure the memory module is firmly in place.

  • Page 45: Installing Mini Pcie Card / Msata

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.6 Installing Mini PCIe card / mSATA 1. Place the system body upside down so you can see the 2x mini card socket. Mini PCIe 2 (CN3) can support mSATA. Mini PCIe 2 / mSATA M.2 (B key) 2.

  • Page 46: Installing Antenna

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.7 Installing antenna 1. Remove antenna hole cover on the system panel. Front Rear 2. Have antenna jack penetrate through the hole. 3. Put on washer and fasten the nut with antenna jack.
  • Page 47 RCO-1000-EHL l User’s Manual Chapter 3: System Setup 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at the cable-end onto the communication module.

  • Page 48: Assemble Chassis Top Cover

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.8 Assemble chassis top cover 1. Place both top cover and system body upside down as shown below. 2. Ensure thermal pad is in place where the CPU is located or paste the thermal pad back on the CPU thermal block.
  • Page 49 RCO-1000-EHL l User’s Manual Chapter 3: System Setup 4. Push the system body down until it is firmly in place. 5. Fasten the three screws (M3x5L) and two copper stud (M3x11L) to lock the system body with top cover.

  • Page 50: Installing Sata Hdd

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.9 Installing SATA HDD 1. Lock the 2.5” HDD with HDD bracket using four screws (M3x4L). 2. Slide the iron plate into the opening on top cover and then place the entire bracket down.
  • Page 51 RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3. Press the entire bracket following the below direction so the SATA connector is firmly plugged into the HDD. 4. Fasten the four screws (M3x5L) to lock the HDD bracket in place.

  • Page 52: Assemble Chassis Bottom Cover

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.10 Assemble chassis bottom cover 1. Place the bottom cover according to the below direction and make sure the rail is facing inside the system. 2. Lock the bottom cover with the four screws (M3x5L).

  • Page 53: Installing Sim Card

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.11 Installing SIM card 1. SIM card socket is located on the front panel of the system. Unscrew one screw (M3x5L) to remove the SIM card socket cover. 2. Now you can insert SIM card into the socket. SIM 1 SIM 2...
  • Page 54 RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3. Please note that the installation of SIM 1 and SIM 2 has to match the installation of mini PCIe sockets. SIM Card Socket Number Matching Mini PCIe Slot SIM 1 Mini PCIe 1 SIM 2 Mini PCIe 2 / mSATA (CN3) 4.

  • Page 55: Installing Wall Mount Kit

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.12 Installing wall mount kit 1. Wall mount kit is available for RCO-1000 series included in the standard package. 2. Slide in both of the wall mount support on the left and right side of the chassis.
  • Page 56 RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3. Screw in the wall mount base to the wall mount's side supports.

  • Page 57: Installing Vesa Mount Kit

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.13 Installing VESA mount kit 1. VESA mount kit is available for RCO-1000 series as optional accessories. For Panel For System 2. Place the system upside down so you can see the bottom cover. The highlighted screw holes below will be used.
  • Page 58 RCO-1000-EHL l User’s Manual Chapter 3: System Setup 4. Lock the VESA mount kit (for system) with four screws (M3x8L, Nylok). 5. VESA mount kit (for panel) should be locked on the back of the panel with four screws. 6. Now the system can be hang in the back of the panel using the hooks.

  • Page 59: Installing Side Mount Kit

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.14 Installing side mount kit 1. Side mount kit is available for RCO-1000 series as optional accessories. 2. Place the system upside down so you can see the bottom cover. The highlighted screw holes below will be used.
  • Page 60 RCO-1000-EHL l User’s Manual Chapter 3: System Setup 4. Lock the side mount kit with four screws (M3x8L, Nylok).

  • Page 61: Installing Din Rail Holder

    RCO-1000-EHL l User’s Manual Chapter 3: System Setup 3.15 Installing DIN rail holder 1. Din rail holder is available for RCO-1000 series as optional accessories. 2. Place the system upside down so you can see the bottom cover. The highlighted screw holes below will be used.

  • Page 62: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 63: Bios Introduction

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.1 BIOS Introduction The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del> immediately allows you to enter the setup screens.

  • Page 64: Main Setup

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu. ◼...

  • Page 65: Advanced Setup

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3 Advanced Setup...

  • Page 66: Cpu Configuration

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.1 CPU Configuration Item Options Description When enabled, a VMM can utilize the Intel (VMX) Virtualization Disabled, additional hardware capabilities provided by Technology Enabled[Default] Virtualization Technology. All[Default] Number of cores to enable in each processor Active Processor Cores package.

  • Page 67: Pch-Fw Configuration

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.2 PCH-FW Configuration...

  • Page 68: Sata And Rst Configuration

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.3 SATA and RST Configuration Item Options Description Disabled, Port0 ~1 Enable or Disable SATA Port. Enabled[Default] Hard Disk Drive[Default] , Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive.

  • Page 69: Trusted Computing

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.4 Trusted Computing Item Options Description Enable/Disable BIOS support for security device. O.S. will not show Security Enabled[Default] , Security Device Support Disabled, Device.TCG EFI protocol and INT1A interface will not be available. Schedule an Operation for the Security Device.

  • Page 70: Acpi Settings

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.5 ACPI Settings Item Options Description Enables or Disables System ability to Disabled , Hibernate (OS/S4 Sleep State). This option Enable Hibernation Enabled[Default], may not be effective with some operating systems. Select the highest ACPI sleep state the Suspend Disabled, ACPI Sleep State system will enter when the SUSPEDN...

  • Page 71: Super Io Configuration

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.6 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB).
  • Page 72 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ Serial Port 1 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=3F8h; IRQ=4; , IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; , This item allows you to change the address & Change Settings IO=2F8h;...
  • Page 73 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ Serial Port 2 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=2F8h; IRQ=3; , IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; , This item allows you to change the address & Change Settings IO=2F8h;...
  • Page 74 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ Serial Port 3 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=3E8h; IRQ=7; , IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; , This item allows you to change the address & Change Settings IO=2E8h;...
  • Page 75 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ Serial Port 4 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=2E8h; IRQ=7; , IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; , This item allows you to change the address & Change Settings IO=2E8h;...
  • Page 76 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ Serial Port 5 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=2F0h; IRQ=7; , IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; , This item allows you to change the address & Change Settings IO=2E8h;...
  • Page 77 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ Serial Port 6 Configuration Item Options Description Disabled, Serial Port Enable or Disable Serial Port (COM). Enabled[Default] Auto[Default], IO=2E0h; IRQ=7; , IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; , This item allows you to change the address & Change Settings IO=2E8h;...

  • Page 78: Hardware Monitor

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.7 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. Item Options Description Disabled[Default], Smart Fan Function Enabled or Disable Smart Fan Enabled...
  • Page 79 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ Smart Fan Mode Configuration Item Options Description Manual Duty Mode, Fan1 SmartFan Control Smart Fan Mode Select Auto Duty-Cycle Mode[Default], Temperature 1~4 1~100 Auto fan speed control. SMART FAN IV 20~100 Duty Cycle 1~4 Auto fan speed control.

  • Page 80: Power Ign Mode

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.8 Power IGN Mode Item Options Description Bypass: BIOS will not control IGN Module, Bypass mode[Default] IGN Setting Write IGN: BIOS will write setting to IGN Write IGN module 10 Sec[Default] 20 Sec 30 Sec Power On Delay 40 Sec...

  • Page 81: Serial Port Console Redirection

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.9 Serial Port Console Redirection Item Options Description Disabled[Default], These items allows you to enable or disable Console Redirection Enabled COM1 console redirection...

  • Page 82: Usb Configuration

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.10 USB Configuration Item Options Description Enables Legacy USB support. AUTO option Enabled[Default] disables legacy support if no USB devices are Legacy USB Support Disabled connected. DISABLE option will keep USB Auto devices available only for EFI applications.

  • Page 83: Network Stack Configuration

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.3.11 Network Stack Configuration Item Options Description Disabled[Default] , Network Stack Enable/Disable UEFI Network Stack. Enabled Enable/Disable IPv4 PXE boot support. If Disabled[Default] , IPv4 PXE Support disabled, IPv4 PXE boot support will not be Enabled available.

  • Page 84: Chipset

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference.

  • Page 85: System Agent (Sa) Configuration

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.4.1 System Agent (SA) Configuration Item Options Description Disabled, VT-d VT-d capability. Enabled [Default] Enable/Disable above 4GB MemoryMappedIO Above 4GB MMIO BIOS Enabled[Default] , BIOS assignment\n\nThis is enabled assignment Disabled automatically when Aperture Size is set to 2048MB.
  • Page 86 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ Memory Configuration Item Options Description Dynamic[Default], 1GB, 1.25GB, Maximum Value of TOLUD. Dynamic 1.5 GB, assignment would adjust TOLUD Max TOLUD 1.75 GB, automatically based on largest MMIO length 2 GB, of installed graphic controller 2.25 GB, 2.5 GB,...
  • Page 87 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ Graphic Configuration Item Options Description GTT Size 2MB, Select the GTT Size . 4MB, 8MB[Default] Aperture Size 128MB, Select the Aperture Size. 256MB[Default] , Note : Above 4GB MMIO BIOS assignment is 512MB, automatically enabled when selecting 1024MB...

  • Page 88: Pch-Io Configuration

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.4.2 PCH-IO Configuration Item Options Description Power On, Restore AC Power Specify what state to go to when power is re- Power Off [Default] , Loss applied after a power failure (G3 state). Lase State...
  • Page 89 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ PCI Express Configuration...
  • Page 90 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ PCI Express Root Port 3 /4 /5 /7 Item Options Description PCI Express Root Port Disabled, Control the PCI Express Root Port. Enabled [Default] 3 /4 /5 /7 Set the ASPM Level: Disabled [Default] , L0s, Force L0s - Force all links to L0s State,...
  • Page 91 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ USB Configuration Item Options Description Option to enable Compliance Mode. Default is XHCI Compliance Disabled [Default] , to disable Compliance Mode. Change to mode Enabled enabled for Compliance Mode testing.
  • Page 92 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ HD Audio Configuration Item Options Description Control Detection of the HD-Audio device. Disabled = HDA will be unconditionally Disabled, HD Audio disabled Enabled [Default] Enabled = HDA will be unconditionally enabled.

  • Page 93: Security

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.5 Security Security menu allow users to change administrator password and user password settings. ◼ Administrator Password This item allows you to set Administrator Password. ◼ User Password This item allows you to set User Password.
  • Page 94 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ Security Boot Item Options Description Secure Boot feature is Active if Secure Boot is Enabled,Platform Key(PK) is enrolled and the Disabled [Default] , Secure Boot System is in User mode. Enabled The mode change requires platform reset Secure Boot mode options:Standard or Custom.
  • Page 95 RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup ◼ Key Management Item Options Description Install factory default Secure Boot keys after Disabled [Default] , Factory Key Provision the platform reset and while the System is in Enabled Setup mode...

  • Page 96: Boot

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.6 Boot This menu allows you to setup the system boot options. Item Options Description Number of seconds to wait for setup Setup Prompt activation 1[Default] Timeout key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock On[Default] , Select the Keyboard NumLock state.

  • Page 97: Save & Exit

    RCO-1000-EHL l User’s Manual Chapter 4: BIOS Setup 4.7 Save & Exit This setting allows users to configure the boot settings. ■ Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.

  • Page 98: Appendix Wdt & Gpio

    Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).

  • Page 99: Wdt Sample Code

    RCO-1000-EHL l User’s Manual Appendix – WDT & GPIO WDT Sample Code WDT Setting Psuedo Code // IO Address 0xA16 is time value // IO Address 0xA15 is WDT enable and configuration Example, Set 0xA16=-0x03, 0xA15=0x31, it will reset after 3 seconds #define TimePort 0xA16 #define TimeEnablePort 0xA15...

  • Page 100: Gpio Sample Code

    RCO-1000-EHL l User’s Manual Appendix – WDT & GPIO GPIO Sample Code GPIO Setting IO_DO4 I/O 0xA02h Bit3 IO_DO3 I/O 0xA02h Bit2 IO_DO2 I/O 0xA02h Bit1 IO_DO1 I/O 0xA02h Bit0 IO_DI4 I/O 0xA03h Bit7 IO_DI3 I/O 0xA03h Bit6 IO_DI2 I/O 0xA03h Bit5 IO_DI1 I/O 0xA03h Bit4 The GPIO function is provided by SIO, and it can be accessed through its GPIO port.
  • Page 101 Premio Inc. All Rights Reserved www.premioinc.com...
