Premio RCO-3000-CML User Manual

Small form factor fanless computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S
MANUAL
RCO-3000-CML
Small Form Factor Fanless Computer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RCO-3000-CML and is the answer not in the manual?

Questions and answers

Related Manuals for Premio RCO-3000-CML

Summary of Contents for Premio RCO-3000-CML

  • Page 1 USER’S MANUAL RCO-3000-CML Small Form Factor Fanless Computer...

  • Page 2: Table Of Contents

    RCO-3000-CML l User’s Manual Table of Contents Prefaces …………………………………………………….…………………………………………….04 Revision …………………………………………………………………………………………..……………….……….. 04 Disclaimer ………………………………………………………..…….…….………………………….……………….. 04 Copyright Notice …………………………………….…………………….…………………………………………… 04 Trademarks Acknowledgment …………..………………………………………………………....04 Environmental Protection Announcement …………………………….………………….……………….. 04 Safety Precautions ………………………………………….……………………………….…………….………….. 05 Technical Support and Assistance …………………………………….…………….…………….…………….06 Conventions Used in this Manual ………………………………………………………………….….……….. 06 Package Contents …………………………………………………………………………………………….…………...
  • Page 3 RCO-3000-CML l User’s Manual 4.3.2 CPU Configuration …………………………….………..…………………..…....68 4.3.3 PCH-FW Configuration ……………………………………..……………………..….….. 69 4.3.4 SATA and RST Configuration ………………………….....…………..…... 70 4.3.5 RST (UEFI RAID) Configuration ……………..………………….………….….………. 71 4.3.6 Trusted Computing …………...……………………………………….…………………… 73 4.3.7 ACPI Settings ..………………………………..…….………………………………………… 74 4.3.8 Super IO Configuration …………………………………………….…..…..…………... 75 4.3.9 Hardware Monitor …………………………....……………………………..…...

  • Page 4: Prefaces

    2023/6/19 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.

  • Page 5: Safety Precautions

    Preface RCO-3000-CML l User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible.

  • Page 6: Technical Support And Assistance

    Preface RCO-3000-CML l User’s Manual Technical Support and Assistance 1. Visit the Premio Inc website at www.premioinc.com where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.
  • Page 7 This product is intended to be supplied by a Listed Power Adapter or DC power source, rated 9-48Vdc, 24.4-4.58A minimum, Tma = 60 degree C minimum. If need further assistance, please contact Premio Inc for further information.” If using Class I adapter, power cord shall be connector to a socket-outlet with earthing connection.

  • Page 8: Package Contents

    Preface RCO-3000-CML l User’s Manual Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty RCO-3000-CML Series Embedded System Wall Mount Kit Accessory Kit Ordering Information Model No.

  • Page 9: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 10: Overview

    Chapter 1: Product Introductions 1.1 Overview The Advanced Fanless Embedded Systems RCO-3000-CML series are designed with rich I/O, high flexibility and easy expansion capabilities which are ideal for diverse industrial applications.Support 10th Gen. Intel® Core™ i9-10900TEE (4.5GHz, 10 Cores) / i7-10700TE (4.4GHz, 6 Cores) / i5-10500TE (3.7GHz, 6 Cores) / i3-10100TE (3.6GHz, 4 Cores) or Pentium®...

  • Page 11: Hardware Specification

    RCO-3000-CML l User’s Manual Chapter 1: Product Introductions 1.2 Hardware Specification System Storage 1x M.2 (E Key, PCIe x1, USB 2.0, 2230, Processor Support CNVi) Support 10th Gen Intel® CML S Processor (LGA 1200, 35W TDP) mSATA 1x mSATA - Intel® Core™ i9-10900TE, 10 Cores, 20MB Cache, up to 4.5 GHz, TDP 35W - Intel®...
  • Page 12 RCO-3000-CML l User’s Manual Chapter 1: Product Introductions Audio 1x Line-out 2x CAN 2.0 A/B 2-pin Internal header 3x RS-232/422/485 ; 2x RS-232/422/485 (internal) 8 in / 8 out (Isolated) 2x RJ45 Universal I/O Bracket 1x Universal I/O Bracket (By mini PCIe interface) 6x USB 3.2 Gen 2 (10Gbps)

  • Page 13: System I/O

    RCO-3000-CML l User’s Manual Chapter 1: Product Introductions 1.3 System I/O RCO-3000-CML Rear Panel DP/HDMI port USB 3.2 Gen 2 Port Used to connect a DP/HDMI monitor or connect Used to connect USB 3.2 Gen 2 optional split cable for dual display mode...
  • Page 14 RCO-3000-CML l User’s Manual Chapter 1: Product Introductions RCO-3000-CML Front Panel Remote Power on/off Terminal Block ATX power on/off switch Used to plug a remote power on/off terminal Press to power-on or power-off the system block Power LED PC/Car mode select switch...

  • Page 15: Mechanical Dimension

    RCO-3000-CML l User’s Manual Chapter 1: Product Introductions 1.4 Mechanical Dimensions RCO-3000-CML Unit: mm...

  • Page 16: Chapter 2 Mechanical Specifications

    Chapter 2 Mechanical Specifications...

  • Page 17: Switch And Connector Locations

    RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.1 Switch and Connector Locations 2.1.1 Top View DELAY_TIME1 DC_IN1 LAN2 LAN1 USB3_3 DP1/HDMI M2 KB1 USB1 PSE_M1 M2 KE1 LAN_L1 USB2 RESET1 HDD_LED1 LAN2_LED AT_ATX1 CLR_CMOS1 CAR_PWR1 PWR_LED1 LAN1 LED...

  • Page 18: Bottom View

    RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.1.2 Bottom View SATA1 SATA2 MPCIE1 SIM2 SIM1 PWRBTN2 USB3_1 PWRBTN1 USB3_2 LINE_OUT1...

  • Page 19: Connector / Switch Definition

    RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.2 Connector / Switch Definition Connector Location Definition DC_IN1 3-pin DC +9~48V Power Input Connector DELAY_TIME CAR mode delay time setting LAN1 - 2 LAN Connector USB3_1-3 USB 3.2 Gen 2 Connector...

  • Page 20: I/O Interface Descriptions

    RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3 I/O Interface Descriptions 2.3.1 DC IN/IGN IN (+9V ~ +48V) DC_IN1 Signal +DC_IN IGN_SENSE 2.3.2 Power off delay time setup Switch DELAY_TIME1 Signal 3 sec. ON / ON / ON (Default Shutdown Timer by O.S)
  • Page 21 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.3 LAN1-2 LAN1-2 Signal LAN1_MDI0P LAN1_MDI0N LAN1_MDI1P LAN1_MDI2P LAN1_MDI2N LAN1_MDI1N LAN1_MDI3P LAN1_MDI3N...
  • Page 22 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.4 USB3_1-3 Connector GEN2 x6 ports, Type A Signal Signal USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX-...
  • Page 23 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.5 Display Port Connector DP1/HDMI Signal Signal DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P/ HDMI_DDCCLK DP_LANE1_N HDMI_DAT DP_LANE2_P DP_AUX_N/HDMI_DDCDAT DP_HPD DP_LANE2_N HDMI_HPD DP_LANE3_P +3.3V DP_DET_N...
  • Page 24 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications Display Port Connector DP1 DP2 Signal Signal DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P DP_LANE1_N DP_LANE2_P DP_AUX_N DP_HPD DP_LANE2_N DP_LANE3_P +3.3V...
  • Page 25 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.6 Reset Button RESET1 Signal RESET...
  • Page 26 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.7 LED Status PWR_LED: Power LED Status Definition POWER LED + POWER LED - HDD_LED: HDD Access LED Status Definition HDD LED+ HDD LED-...
  • Page 27 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.8 LAN1, LAN2 LED Status LAN1 LED Act LED Status Definition Blinking Yellow Data Activity No Activity Link LED Status Definition Steady Orange 1Gbps Network Link 100Mbps Steady Green Network Link 10Mbps Network Link...
  • Page 28 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.9 Clear BIOS Switch CLR_CMOS1 Signal Push Clear BIOS open Normal Status (Default) 2.3.2 AT / ATX Power Mode Switch AT_ATX1 Switch Signal ATX Power Mode (Left) (Default) AT Power Mode (Right)
  • Page 29 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.10 PC/Car Mode Switch CAR_PWR1 Switch Signal PC Power Mode (Left) (Default) Power lgnition Mode (Right)
  • Page 30 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.11 SATA with Power Connector SATA1-2 Definition Definition DEVSLP...
  • Page 31 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.12 Mini PCI-Express Socket MPCIE1 Definition Definition WAKE# +3.3V +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RST UIM_VPP RESET# +3.3VAUX +1.5V...
  • Page 32 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications Definition Definition SMB_CLK SMB_DATA USB2_D- USB2_D+ +3.3V +3.3V +1.5V +3.3V...
  • Page 33 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.13 Power Button PWRBTN1 Definition Power Button PWRBTN2 Definition Power Button...
  • Page 34 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.14 Line-out Jack (Green) Connector Type: 5-pin Phone Jack LINE_OUT1 Definition OUT_R OUT_L...
  • Page 35 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.15 Bottom size SIM Card Socket SIM1-2 Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK...
  • Page 36 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.16 M.2 B-Key Socket M2_KB1 Definition Definition +3.3V +3.3V +3.3V +1.8S USB2_D+ +3.3V USB2_D- +3.3V PCIE2/USB_RxN0 PCIE2/USB_RxP0 SIM_RST SIM_CLK PCIE2/USB_TxN0 SIM_DATA...
  • Page 37 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications Definition Definition PCIE2/USB_TxP0 SIM_PWR PCIE1_RxN0 PCIE1_RxP0 PCIE1_TxN0 PCIE1_TxP0 PCIE_RST# REFCLK1- CLK_REQ# REFCLK1+ PCIE_WAKE# +3.3V +3.3V +3.3V +3.3V +3.3V...
  • Page 38 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications 2.3.17 M.2 E-Key Socket M2_KE1 Definition Definition +3.3V USB2_D+ +3.3V USB2_D- PCM_CLK CNV_WR_1_DN PCM_SYNC CNV_WR_1_DP PCM_IN PCM_OUT CNV_WR_0_DN CNV_WR_0_DP UART_BT_WAKE# CNV_WR_CLK_DN CNV_BRI_RSP CNV_WR_CLK_DP CNV_RGI_DT PCIE1_TxP0 CNV_RGI_RSP...
  • Page 39 RCO-3000-CML l User’s Manual Chapter 2: Mechanical Specifications Definition Definition PCIE1_TxN0 CNV_BRI_DT CLINK_RST# PCIE1_RxP0 CLINK_DATA PCIE1_RxN0 CLINK_CLK CNV_BLANKING REFCLK1+ CNV_MFUART2_TXD REFCLK1- CNV_MFUART2_RXD SUSCLK_WIFI CLK_REQ# PCIE_RST# PCIE_WAKE# BT_DIS2# WIFI_DIS1# CNV_WT_1_DN +3.3V CNV_WT_1_DP +3.3V +3.3V CNV_WT_0_DN CNV_WT_0_DP PCIE_RST# CNV_WT_CLK_DN CNV_WT_CLK_DP +3.3V +3.3V...

  • Page 40: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 41: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing

    RCO-3000-CML l User’s Manual Chapter 3: System Setup 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.2 Removing chassis bottom cover In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.

  • Page 42: Removing Chassis Top Cover

    RCO-3000-CML l User’s Manual Chapter 3: System Setup 3.3 Removing chassis top cover 1. Unscrew the four screws (M3x5L) highlighted below. 2. Hold the body of the system and lift it vertically away from the top cover. 3. Top cover separated from the system body.

  • Page 43: Installing Sodimm

    3.4 Installing SODIMM 1. Place the system body with SODIMM socket facing upward. Two SODIMM sockets are available for RCO-3000-CML Series on the top side. 2. Insert memory module from 45 degree direction. 3. Press the memory module vertically downward until you hear the “click” sound. Make sure...

  • Page 44: Installing Cpu

    RCO-3000-CML l User’s Manual Chapter 3: System Setup 3.5 Installing CPU 1. CPU socket is located on the top side. 2. Press down the CPU socket lever in order to open the socket cover.
  • Page 45 RCO-3000-CML l User’s Manual Chapter 3: System Setup 3. Remove the CPU protective cover. 4. Insert CPU gently.
  • Page 46 RCO-3000-CML l User’s Manual Chapter 3: System Setup 5. Press down the lever again to hold the socket cover. 6. Paste thermal pad on the CPU.
  • Page 47 RCO-3000-CML l User’s Manual Chapter 3: System Setup 7. Place the designated heat block onto the CPU with thermal pad. Lock the heat block with three screws (M3x5L). The three screws will safely lock the heat block onto the three copper studs that are screwed into the motherboard.
  • Page 48 RCO-3000-CML l User’s Manual Chapter 3: System Setup 9. Installation complete.

  • Page 49: Installing Mini Pcie Card / Msata / M.2

    RCO-3000-CML l User’s Manual Chapter 3: System Setup 3.6 Installing mini PCIe card / mSATA / M.2 1. One mini PCIe slots are available for RCO-3000-CML series. The mini PCIe support mSATA. M.2 B Key mini PCIe M.2 E Key 2.

  • Page 50: Installing Antenna

    RCO-3000-CML l User’s Manual Chapter 3: System Setup 3.7 Installing antenna 1. Three antenna holes are available for RCO-3000-CML series on the rear panel and two holes are on the front panel. 2. Remove antenna hole cover on the system panel.
  • Page 51 RCO-3000-CML l User’s Manual 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at the cable-end onto the communication module.

  • Page 52: Assembly Chassis Top Cover

    RCO-3000-CML l User’s Manual Chapter 3: System Setup 3.8 Assembly chassis top cover 1. Place the top cover upside down as shown below. 2. Ensure thermal pad is in place on both the CPU thermal block and PCH thermal block.
  • Page 53 RCO-3000-CML l User’s Manual Chapter 3: System Setup 4. Push the system body down until it is firmly in place. 5. Fasten the four screws (M3x5L) to lock the system body with top cover.

  • Page 54: Installing Hdd On Internal Sata Hdd Bay

    Chapter 3: System Setup 3.9 Installing HDD on internal SATA HDD bay 1. One internal SATA HDD bays are available for RCO-3000-CML series. 2. Unscrew the four screws (M3x5L) to remove the internal SATA HDD bay. 3. Lock the 2.5” HDD with HDD bracket using four screws (M3x4L).
  • Page 55 RCO-3000-CML l User’s Manual Chapter 3: System Setup 4. Install the HDD bracket following the direction below. 5. Fasten the four screws to lock the internal HDD bracket.

  • Page 56: Installing Hdd On Removable Sata Hdd Tray

    Chapter 3: System Setup 3.10 Installing HDD on removable SATA HDD tray 1. One removable SATA HDD tray available for RCO-3000-CML Series. 2. Open the tray lock (red circle) ,and remove the tray. 3. Unlock the drive lock and insert the HDD/SSD.

  • Page 57: Assemble Chassis Bottom Cover

    RCO-3000-CML l User’s Manual Chapter 3: System Setup 3.11 Assemble chassis bottom cover 1. Place the bottom cover according to the below direction and make sure the rail is facing inside the system. 2. Lock the bottom cover with the six screws (M3x5L).

  • Page 58: Installing Sim Card

    RCO-3000-CML l User’s Manual Chapter 3: System Setup 3.12 Installing SIM card 1. Insert SIM card into the socket. 2. Please note that the installation of SIM cards has to match the installation of mini PCIeslots M.2 B Key Socket...

  • Page 59: Installing Wall Mount Kit

    RCO-3000-CML l User’s Manual Chapter 3: System Setup 3.13 Installing wall mount kit 1. Wall mount kit is available for RCO-3000-CML series included in the standard package. M4*13 2. Place the system upside down so you can see the bottom cover. The highlighted screw holes...
  • Page 60 RCO-3000-CML l User’s Manual Chapter 3: System Setup 3. Lock the wall mount kit with eight screws (M3x5L, Nylok).

  • Page 61: Installing Din Rail Holder

    Chapter 3: System Setup 3.14 Installing DIN rail holder 1. Din rail holder is available for RCO-3000-CML series as optional accessories. 2. Place the system upside down so you can see the bottom cover with two screw holes for din...
  • Page 62 RCO-3000-CML l User’s Manual Chapter 3: System Setup 3. Place the din rail holder on top of the bottom cover and lock it with two screws (M4x5L, Nylok).

  • Page 63: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 64: Bios Introduction

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.1 BIOS Introduction The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del> immediately allows you to enter the setup screens.

  • Page 65: Main Setup

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu.

  • Page 66: Advanced Setup

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3 Advanced Setup...

  • Page 67: Connectivity Configuration

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.1 Connectivity Configuration Item Options Description CNVi Mode Disable Integrated, This option configures Connectivity. [Auto Auto Detection[Default] Detection] means that if Discrete solution is discovered it will be enabled by default. Otherwise Integrated solution (CNVi) will be enabled;...

  • Page 68: Cpu Configuration

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.2 CPU Configuration Item Options Description Intel (VMX) Virtualization Disabled, When enabled, a VMM can utilize the Technology Enabled[Default] additional hardware capabilities provided by Virtualization Technology. Active Processor Cores All[Default] Number of cores to enable in each processor package.

  • Page 69: Pch-Fw Configuration

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.3 PCH-FW Configuration Item Options Description AMT BIOS Features Disabled, When disabled AMT BIOS Features are no longer Enabled[Default] supported and user is no longer able to access MEBx Setup. Note:This option does not disable Manageability Features in FW.

  • Page 70: Sata And Rst Configuration

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.4 SATA and RST Configuration Item Options Description SATA Controller(s) Disabled, Enable/Disable SATA Device. Enabled[Default] SATA Mode Selection AHCI[Default] , Determines how SATA controller(s) operate. Intel RST Premium With Intel Optane System...

  • Page 71: Rst (Uefi Raid) Configuration

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.5 RST (UEFI RAID) Configuration How to set the UEFI RAID: 1. When set to “Intel RST Premium With Intel Optane System Acceleration“, please save change reset system. 2. After reboot the system, please into BIOS utility and then will see “Intel (R) Rapid Storage...
  • Page 72 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 3. Into Intel(R) Rapid Storage Technology, and start create RAID volume. 4. Start Create the RAID ■ Select Disk that you want to do the RAID ■ Select [x]; No-Select [ ]...

  • Page 73: Trusted Computing

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.6 Trusted Computing Item Options Description Security Device Support Enabled, Enable/Disable BIOS support for security Disabled[Default] , device. O.S. will not show Security Device.TCG EFI protocol and INT1A interface will not be available.

  • Page 74: Acpi Settings

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.7 ACPI Settings Item Options Description Enable Hibernation Disabled , Enables or Disables System ability to Enabled[Default], Hibernate (OS/S4 Sleep State). This option may not be effective with some operating systems. ACPI Sleep State...

  • Page 75: Super Io Configuration

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.8 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA).
  • Page 76 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 1 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=3F8h; IRQ=4; , IRQ settings of the specified serial port.
  • Page 77 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 2 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=2F8h; IRQ=3; , IRQ settings of the specified serial port.
  • Page 78 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 3 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=3E8h; IRQ=7; , IRQ settings of the specified serial port.
  • Page 79 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 4 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=2E8h; IRQ=7; , IRQ settings of the specified serial port.
  • Page 80 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ Serial Port 5 Configuration Item Options Description Serial Port Disabled, Enable or Disable Serial Port (COM). Enabled[Default] Change Settings Auto[Default], This item allows you to change the address & IO=2E0h; IRQ=5; , IRQ settings of the specified serial port.

  • Page 81: Hardware Monitor

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.9 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. Item Options Description Smart Fan Function Disabled[Default], Enabled or Disable Smart Fan...
  • Page 82 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ Smart Fan Mode Configuration Item Options Description Expansion Fan Manual Mode, Smart Fan Mode Select SmartFan Control SMART FAN IV Mode[Default], Temperature 1~4 1~100 Auto fan speed control. SMART FAN IV...

  • Page 83: Serial Port Console Redirection

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.10 Serial Port Console Redirection Item Options Description Console Redirection Disabled[Default], These items allows you to enable or disable Enabled COM1 console redirection...

  • Page 84: Usb Configuration

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.11 USB Configuration Item Options Description Legacy USB Support Enabled[Default] Enables Legacy USB support. AUTO option Disabled disables legacy support if no USB devices are Auto connected. DISABLE option will keep USB devices available only for EFI applications.

  • Page 85: Network Stack Configuration

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.3.12 Network Stack Configuration Item Options Description Network Stack Disabled[Default] , Enable/Disable UEFI Network Stack. Enabled IPv4 PXE Support Disabled[Default] , Enable/Disable IPv4 PXE boot support. If Enabled disabled, IPv4 PXE boot support will not be available.

  • Page 86: Chipset

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.4.1 System Agent (SA) Configuration...
  • Page 87 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ Memory Configuration Item Options Description Max TOLUD Dynamic[Default], Maximum Value of TOLUD. Dynamic 1GB, assignment would adjust TOLUD 1.25GB, automatically based on largest MMIO length 1.5 GB, of installed graphic controller 1.75 GB,...
  • Page 88 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ Graphic Configuration Item Options Description GTT Size 2MB, Select the GTT Size . 4MB, 8MB[Default] Aperture Size 128MB, Select the Aperture Size. 256MB[Default] , Note : Above 4GB MMIO BIOS assignment is...

  • Page 89: Pch-Io Configuration

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.4.2 PCH-IO Configuration Item Options Description M.2 B-Key Selection USB + PCIe x1, Selects M.2 B-KEy function: PCIe x2 or USB + PCIe x2[Default] , PCIe x1. PCH LAN Controller Enabled [Default] , Enable/Disable onboard NIC.
  • Page 90 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ PCI Express Configuration...
  • Page 91 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup • PCI Express Root Port 4 /5 /9 /10 /11 /20 /21 Item Options Description PCI Express Root Port Disabled [Default] , Control the PCI Express Root Port. Enabled 4 /5 /9 /11 /20...
  • Page 92 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ USB Configuration Item Options Description XHCI Compliance mode Disabled [Default] , Option to enable Compliance Mode. Default is Enabled to disable Compliance Mode. Change to enabled for Compliance Mode testing.
  • Page 93 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ HD Audio Configuration Item Options Description HD Audio Disabled, Control Detection of the HD-Audio device. Enabled [Default] Disabled = HDA will be unconditionally disabled Enabled = HDA will be unconditionally enabled.

  • Page 94: Security

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.5 Security Security menu allow users to change administrator password and user password settings. ■ Administrator Password This item allows you to set Administrator Password. ■ User Password This item allows you to set User Password.
  • Page 95 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ Security Boot Item Options Description Secure Boot Disabled [Default] , Secure Boot feature is Active if Secure Boot is Enabled Enabled,Platform Key(PK) is enrolled and the System is in User mode.
  • Page 96 RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup ■ Key Management Item Options Description Factory Key Provision Disabled [Default] , Install factory default Secure Boot keys after Enabled the platform reset and while the System is in Setup mode...

  • Page 97: Boot

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.6 Boot This menu allows you to setup the system boot options. Item Options Description Setup Prompt Timeout 1[Default] Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.

  • Page 98: Save & Exit

    RCO-3000-CML l User’s Manual Chapter 4: BIOS Setup 4.7 Save & Exit This setting allows users to configure the boot settings. ■ Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.

  • Page 99: Appendix Wdt & Gpio

    Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).

  • Page 100: Wdt Sample Code

    RCO-3000-CML l User’s Manual Appendix – WDT & GPIO WDT Sample Code WDT Setting Psuedo Code #define AddrPort 0x2e #define DataPort 0x2f #define SIO_UnLock_Value 0x87 #define SIO_Lock_Value 0xaa #define WATCHDOG_LDN 0x08 #define GPIO_Port 0xF1 //Enter_Config WriteByte (AddrPort, SIO_UnLock_Value); WriteByte (AddrPort, SIO_UnLock_Value);...

  • Page 101: Gpio Sample Code

    RCO-3000-CML l User’s Manual Appendix – WDT & GPIO GPIO Sample Code GPIO Setting PIN# GPIO# Default Configuration XCOM- XCOM+ OUT8 DIO Output8 DIO Input8 OUT7 DIO Output7 DIO Input7 OUT6 DIO Output6 DIO Input6 OUT5 DIO Output5 DIO Input5...
  • Page 102 Premio Inc. All Rights Reserved www.premioinc.com...

This manual is also suitable for:
