Rigol DG5500 Pro Series User Manual

Function/arbitrary waveform generator

Hide thumbs Also See for DG5500 Pro Series:

Quick manual (31 pages)

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

page of 155

/ 155
Bookmarks

Quick Links

Download this manual

Need help?

Do you have a question about the DG5500 Pro Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Rigol DG5500 Pro Series

Page 2 • RIGOL products are covered by P.R.C. and foreign patents, issued and pending. • RIGOL reserves the right to modify or change parts of or all the specifications and pricing policies at the company's sole decision. • Information in this publication replaces all previously released materials.
Page 3 4.7.1 To Set Parameters with the Front-panel Keys and Knobs ........4.7.2 To Set Parameters with the Touch Screen ..............27 4.8 To Use the Battery Holder (Option) ....................29 4.9 To Replace the Fuse ..........................29 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 4 8.1 Burst Type ............................8.2 Burst Delay ............................8.3 Burst Phase ............................77 8.4 Burst Period ............................78 8.5 Burst Trigger Source .........................78 8.6 Gated Polarity .............................79 8.7 Idle Level .............................. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 5 17 System Utility Function Setting ................17.1 I/O Setting ............................125 17.2 LXI .................................127 17.3 Basic Settings ........................... 17.4 About this Instrument ........................129 17.5 Print Screen ............................130 17.6 Option ..............................131 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 6 19.1 Remote Control via USB ....................... 19.2 Remote Control via LAN .......................139 20 Troubleshooting ......................141 21 Appendix ........................21.1 Appendix A: Options and Accessories ..................21.2 Appendix B: Warranty ........................DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 7 Figure 7.4 Step Sweep ......................70 Figure 7.5 Sweep ........................72 Figure 8.1 Burst Setting Interface ..................Figure 9.1 Advanced Waveform Setting Interface ............Figure 9.2 Arb Setting Interface (Advanced Mode) .............82 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 8 Figure 13.2 Coupling&Track Setting Menu ..............116 Figure 14.1 Before Aligning Phase .................. Figure 14.2 After Aligning Phase ..................Figure 15.1 Create Session ....................122 Figure 18.1 Preset Menu .....................132 DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 9 Table 9.1 Pattern Preset Amplitude ................... Table 11.1 Sync Signal of Different Output Modes (Positive Polarity) ....Table 12.1 Dual-channel operation parameters ............Table 18.1 Factory Settings ....................Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 11 • Use Proper Fuse. Please use the specified fuses. • Avoid Circuit or Wire Exposure. Do not touch exposed junctions and components when the unit is powered on. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 12 • Do Not Operate With Suspected Failures. If you suspect damage occurs to the instrument, have it inspected by RIGOL authorized personnel before further operations. Any maintenance, adjustment or replacement especially to circuits or accessories must be performed by RIGOL authorized personnel.
Page 13 Terminal Measurement Category Measurement Category This instrument can make measurements in Measurement Category I. WARNING This instrument can only be used for measurements within its specified measurement categories. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 14 Working Environment Temperature Operating: 0℃ to +40℃ Non-operating: -20℃ to +60℃ Humidity • Operating: 0℃ to +40℃: ≤80% RH (without condensation) DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 15 The pollution has no effect. For example, a clean room or air-conditioned office environment. • Pollution Degree 2: Normally only nonconductive pollution occurs. Temporary conductivity caused by condensation is to be expected. For example, indoor environment. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 16 The equipment may contain substances that could be harmful to the environment or human health. To avoid the release of such substances into the environment and avoid harm to human health, we recommend you to recycle this product DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 17 Please contact your local authorities for disposal or recycling information. https://int.rigol.com/services/services/declaration You can click on the following link to download the latest version of the RoHS&WEEE certification file. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 18 Noise Generator, Pulse Generator, Harmonics Generator, and Analog/Digital Modulator. It can be power by a battery holder. It is a multi-functional and cost- effective dual-channel function/arbitrary waveform generator. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 19 This manual gives you a quick overview of the front and rear panels, user interface as well as basic operation methods of the DG5000 Pro Series Function/Arbitrary Waveform Generator. www.rigol.com For the latest version of this manual, download it from RIGOL official website ( Publication Number UGB18100-1110 Format Conventions in this Manual 1.
Page 20 The consigner or carrier shall be liable for the damage to the instrument resulting from shipment. RIGOL would not be responsible for free maintenance/rework or replacement of the instrument. 2. Inspect the instrument In case of any mechanical damage, missing parts, or failure in passing the electrical and mechanical tests, contact your RIGOL sales representative.
Page 23 : Burst key. Press the key to set the output mode to Burst or Continuous Burst for the current channel. For details about the Burst mode, please refer to Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 24 : Noise key. Press the key to set the basic waveform to Noise for the To Output Noise current channel. For details about the Noise, please refer to 5. Amplitude/High Level and Offset/Low Level Keys DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 25 : channel on/off key. Press the key to enable or disable the corresponding channel output. When the channel output is enabled, the backlight of the corresponding key is illuminated. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 26 : manual trigger key. When the trigger source is set to manual, the key backlight will be on. At this time, a manually triggered output is generated each time you press the key. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 27 BNC type connector, can output a 10 MHz clock signal generated by the instrument's internal crystal oscillator. 2. 10 MHz REF IN BNC type connector. When external clock source is selected, this connector accepts an external clock signal. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 28 TTL-compatible pulse signal as the trigger input signal. - Digital modulation input: When the channel output is set to ASK/FSK/PSK modulation, the modulation source is set to External, and the modulation port DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 29 4. Notification Area Displays the USB icon, LAN icon, sound icon, and remote control icon. You can click or tap this area to open the "Utility" menu. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 30 Click or tap the icon to open the function navigation menu in which you can access the specified function menu by clicking or tapping the corresponding function key (Utility, Preset, Help, Channel Group, Arb Build, Shut Down). 12. Waveform Tab DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 31 115 V, 360 Hz to 440 Hz. Please use the power cord provided in the accessories to connect the instrument to the AC power source, as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 32 Click or tap Shut Down to shut down the instrument. • Press twice to shut down the instrument. • Press for three seconds to shut down the instrument. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 33 Tap the close button at the upper-right corner of the message box to close the prompt window. • Tap other windows on the touch screen and operate on the windows. Figure 4.10 Tap Gesture Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 34 You can use the front-panel parameter input area to set some parameters of the instrument. The parameter input area consists of a knob, a numeric keyboard, unit selection keys, and arrow keys, as shown in the figure below. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 35 "."; press to input "-" or "+". When using the numeric keyboard, you can also perform the following operations: • Press the knob to confirm the input. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 36 • When inputting parameters using the numeric keyboard, is used to delete the character while is used to cancel the input and close the input field. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 37 3. Input the lower-case letter Refer to the operation specified in the previous step. If the Caps key is not selected, directly input the lower-case letter. 4. Input numbers or symbols Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 38 You can also click or tap the unit drop-down button to select the desired unit when multiple units are available. Then click or tap "Enter" to confirm input and close the numeric keypad. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 39 BatHolder138 User For how to use the battery holder and safety precautions, refer to Guide . For the latest version of this manual, download it from RIGOL official website www.rigol.com CAUTION The battery holder does not support hot swapping. Before installing and removing the battery holder, power off the instrument and disconnect all power cables to avoid damaging the instrument or battery holder.
Page 40 The method is as follows: align the lock with the lock hole and plug it into the lock hole vertically, turn the key clockwise to lock the instrument, and then pull the key out. Security Lock Hole Figure 4.15 Use the Security Lock DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 41 1. Obtain an Option License http://www.rigol.com a. Log in to the RIGOL official website ( ), click SERVICE CENTRE > License Activation to enter the software license registration; b. In the software license registration interface, input the correct key, serial number (click or tap >...
Page 42 For SCPI commands, refer to DG5000 Pro Programming Guide. • During the installation process, you are not allowed to power off the instrument. • You are not allowed to modify the license filename. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 44 The waveform amplitude and offset are limited by this value: Amplitude/2 + |Offset| ≤ Maximum Peak Value. To Output Sine Wave In the Continuous mode, you can configure the instrument to output sine in the following ways. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 45 The relationship between Vpp and Vrms varies for different waveforms. Take sine wave as an example. The relationship between the two units is as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 46 The "Ampl" and "Offset" buttons appear at the same time, and so are "HighL" and "LowL" buttons. For example, selecting "Offset" automatically toggles the "Ampl/HighL" parameter to "Ampl". DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 47 "HighL". High Level = Offset + Amplitude/2. The high level range is related to the low level setting value. That is, high level minus low level cannot exceed Table 5.2 Range of Amplitude the current range of amplitude ( Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 48 0.01% to 99.99% (depending on the Frequency/Period setting). By default, it is 50%, and the resolution is 0.01%. To Output Ramp Wave In the Continuous mode, you can configure the instrument to output ramp in the following ways. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 49 Click or tap the Offset/LowL button again or press the key to toggle the parameter to "LowL". Low Level = Offset - Amplitude/2. The low level range is related Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 50 In addition to basic parameters (e.g. Frequency, Amplitude, Offset, Starting Phase, High Level, Low Level) mentioned before, you also need to set the "Pulse Width/Duty Cycle", "Rising Edge", and "Falling Edge". DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 51 Click or tap the Offset/LowL button again or press the key to toggle the parameter to "LowL". Low Level = Offset - Amplitude/2. The low level range is related Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 52 The leading/trailing edge time ranges from 1.4 ns to 1 s (limited by the pulse width). The default value is 1.4 ns and the resolution is 0.1 ns. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 53 "LowL". Low Level = Offset - Amplitude/2. The low level range is related to the high level setting value. That is, high level minus low level cannot exceed the current range of amplitude. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 54 Engine, Seg Mod, Bioelect, Medical, Standard, Maths, Trigonome, Anti Trigonome, and Window Function to select your desired Arb waveform. The selected waveform type is indicated in Shape in the Arb setting interface. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 55 Eight-tone signal LowerSemicircle Lower semicircle Distortion Distorted waveform Dampedsine1 Damped sine wave (1 Hz frequency) Dampedsine3 Damped sine wave (3 Hz frequency) Dampedsine5 Damped sine wave (5 Hz frequency) Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 56 Three Pm Sine piecewise PM waveform Three Pwm Pulse width piecewise FM waveform Bioelectricity Cardiac Cardiac signal Ecg1 Electrocardiogram 1 Ecg2 Electrocardiogram 2 Ecg3 Electrocardiogram 3 Ecg4 Electrocardiogram 4 DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 57 Iso7637 2 Tp2a in wiring Automotive transients due ignition Iso7637 2 Tp2b switching off Iso7637 2 Tp3a Automotive transients due to switching Iso7637 2 Tp3b Automotive transients due to switching Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 58 Maxwell Maxwell distribution Modbesseli0 Modified Bessel function Rayleigh Rayleigh distribution Sphbesselj1 Spherical Bessel function of the first kind Sphbesselj2 Spherical Bessel function of the second kind Versiera Versiera DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 59 Concave arc hyperbolic cosecant Acsch Pro Protuberant arc hyperbolic cosecant Asec Con Concave arc secant Asec Pro Protuberant arc secant Asech Arc hyperbolic secant Asin Arc Sinc Asinh Arc hyperbolic sine Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 61 The max. fundamental frequency ( ) is limited by the harmonic order ( fund N ). Changing the harmonic order may modify harmonic frequency ( = (2 x ÷ fund Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 62 Click or tap the User input field to set the user-defined orders of harmonics. After that, you can click or tap the harmonic editing table to set the amplitude and phase in the pop-up menu. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 64 Table 6.1 Carrier Frequency Range (Modulation Mode) Waveform DG5252 Pro DG5352 Pro DG5502 Pro Sine 1 μHz to 250 MHz 1 μHz to 350 MHz 1 μHz to 350 MHz DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 65 DnRamp with 0% symmetry Noise - white gaussian noise Arb: When the "Shape" is set to Arb, you can click or tap the Shape input field to set the Arb type. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 66 100%, then the output will be at the maximum amplitude when the modulating signal is at +5 V. The output will be at the minimum amplitude when the modulating signal is at -5 V. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 67 Available shapes include: Sine Square with 50% duty cycle Triangle with 50% symmetry UpRamp with 100% symmetry DnRamp with 0% symmetry Noise - white gaussian noise Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 68 Carrier Waveform Available PM carrier waves include sine (default), square, ramp, and Arb (except DC). Click or tap the "Basic Wave Type" drop-down button or press the corresponding DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 69 The phase deviation represents the peak variation in phase of the modulated waveform from the carrier waveform. Click or tap the PM Dev input field to set the Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 70 Port drop-down button to select the input port. Front port: The instrument accepts an external modulation signal from the front-panel [Mod In] connector. The modulation rate is up to 100 kHz. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 71 Available FSK carrier waves include sine (default), square, ramp, and Arb (except DC). Click or tap the "Basic Wave Type" drop-down button or press the corresponding front-panel waveform selection key to select the desired carrier waveform shape. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 72 For details, refer to Polarity Click or tap the Polarity drop-down button to select "Positive" or "Negative" to control the frequency output. The default is "Positive". DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 73 [Mod In] connector. The modulation rate is up to 100 kHz. Rear port: The instrument accepts an external modulation signal from the rear-panel [AUX IN] connector. The modulation rate is up to 10 MHz. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 74 PWM is only available for the Pulse waveform. Click or tap the "Basic Wave Type" drop-down button to select "Pulse" or press the front-panel key to set the To Output Pulse carrier waveform to Pulse. For pulse width/duty cycle setting, refer to DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 75 Carrier (Pulse) setting. For example, if "Width" is selected Pulse Width/Duty Cycle of the Pulse setting, then the PWM deviation setting is automatically set to "Width Dev". • Width Deviation Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 76 Sum Waveform Click or tap the Waveform drop-down button to select the waveform to be added to the current waveform. Available waveform shapes include: • Sine DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 77 50%. The upper limit of the sum ratio is limited by the maximum peak of the current output waveform ( Table 5.2 Range of Amplitude Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 78 This instrument provides three sweep types: Linear, Log, and Step. The default is Linear. Click or tap the "Sweep Type" drop-down button to can select "Linear", "Log", or "Step". DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 81 ±2 x (350 MHz - 300 MHz) = ±100 MHz. To sweep up in frequency, set a positive frequency span; to sweep down, set a negative frequency span. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 82 You can click or tap the Start/Stop input field and use the pop-up numeric keypad to set the start/stop hold time. The default start/stop hold time is 0 s and the resolution DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 83 The default is "Internal". • Internal: The instrument outputs a continuous sweep. The trigger period is determined by the specified sweep time, return time, start hold time, and stop hold time. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 84 If the mark frequency is set to 1 MHz and the sweep points are 0.99 MHz and 1.01 MHz, then 0.99 MHz will be selected as the mark frequency to be applied to the digital system. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 85 The Burst mode cannot be enabled when the fundamental frequency is less than or equal to 125 μHz. Burst Type Figure 8.1 Burst Setting Interface The following table shows the range of the frequency for different carriers in the Burst mode. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 86 It ranges from 1 (default) to 1 M. If you change the burst count, the instrument automatically increases the burst period to accommodate the burst count (but the waveform frequency will not be changed). When the DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 87 -360° to 360°, and the default is 0°. The resolution is 0.01°. • For Sine, Square, Pulse, and Ramp, 0° is the point at which the waveform crosses 0 V (or DC offset) in a positive-going direction. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 88 Ext Trailing: When external trailing edge is selected, the instrument receives the trigger signal from the rear-panel [AUX IN] connector. A burst is generated each time a TTL pulse with trailing edge is received. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 90 It ranges from 0 to 65,535, and the default is 0. When the noise is the carrier waveform, the idle level is fixed to 32768 and cannot be modified. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 91 Advanced Waveform Setting Interface or Channel Setup Interface. For Channel Setup Channel Setup Interface, please refer to . This chapter only describes the advanced waveform settings. Sub Mode Waveform Preview/Editing Figure 9.1 Advanced Waveform Setting Interface Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 92 • Stored waveforms: Arb files (*.arb) stored in the instrument's internal memory (C disk) or in the external memory (D disk). After "Stored Wforms" is selected, select DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 93 In the Advanced Waveform Setting Interface, click or tap the "Sub Mode" drop-down button to select "Sequence" to enter the Sequence Setting Interface, as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 94 In the sequence editing interface as shown in , click or tap the "Waveform Preview/Editing" area to open the sequence editing table, as shown in the figure below. Figure 9.4 Sequence Editing Table DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 95 You can define the conditions (Wait, Event, and Go To) to play the specified step in the sequence using the sequence editing table as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 96 You can set the event input and event jump to for each step. In the sequence editing table, click or tap the cell in the Event row of the step and the "Event" menu as shown in the figure below will be displayed. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 98 Click or tap the Sample Rate input field to set the sample rate for the sequence. The sample rate ranges from 1 μSa/s to 1.25 GSa/s, and the default is 1 MSa/s. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 100 "PRBS" to enter the PRBS Setting Interface, as shown in the figure below. Figure 9.6 PRBS Setting Interface After entering the PRBS Setting Interface, you can set the following parameters. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 101 In the Advanced Waveform Setting Interface, click or tap the "Sub Mode" drop-down button to select "M-Pulse" to enter the Multi-pulse Setting Interface, as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 103 Event Input Cycle ≥ Trigger Delay + High Pulse Width Sum + Low Pulse Width Sum. If the event input cycle is less than the threshold, excess events will be ignored. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 104 In the Advanced Waveform Setting Interface, click or tap the "Sub Mode" drop-down button to select "M-Tone" to enter the Multi-tone Setting Interface, as shown in the figure below. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 105 In the Multi-tone Setting Interface as shown in , click or tap the "Waveform Preview/Editing" area to open the "Multitone Setting" menu, as shown in the figure below. Figure 9.10 Multi-tone Setting Menu Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 106 In the Advanced Waveform Setting Interface, click or tap the "Sub Mode" drop-down button to select "Pattern" to enter the Pattern Setting Interface, as shown in the figure below. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 107 In the Pattern Setting Interface ( ), click or tap the Ampl/HighL or Offset/ LowL input field to self-define the output amplitude. At this point, the Pre Ampl item is displayed as "User". Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 108 The maximum data length of the imported file is related to the data format of the file. The data length is limited to 64M characters for binary and 12M characters for hexadecimal and KD symbol. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 109 4B5B encoding is used to encode 4 bits of data to a 5-bit code. It is available only when the data format of the input pattern or the imported file is set to "Hex". Otherwise, it is grayed out. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 110 In the Advanced Waveform Setting Interface, click or tap the "Sub Mode" drop-down button to select "IQ" to enter the IQ Setting Interface, as shown in the figure below. Figure 9.14 IQ Setting Interface DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 112 The sampling rate is automatically calculated based on the oversampling and symbol rate. The oversampling x symbol rate must be smaller than or equal to the maximum sampling rate (1.25 DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 113 ), click or tap the Power input field to set the power with the pop-up numeric keypad. The available range is from -60 dBm to 25.5 dBm. The actual available range is related to the selected modulation scheme. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 114 Click or tap New Waveform to open the "Waveform" menu. Click or tap the Function input field and select the waveform type in the displayed menu. Set the waveform DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 115 Flip Vertical: Click or tap Flip Ver in the menu bar to flip the selected waveform vertically. • Undo: Click or tap Undo in the menu bar to undo the last edit of the Arb waveform. Only one undo operation is allowed. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 116 You can also use a PC software (e.g. Ultra Station) to edit the Arb waveform and then use a USB storage device or FTP to transfer the file to the instrument's local memory (C disk). DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 117 When the external trigger source or external modulation source is selected, the sync output is disabled. When the trigger output is enabled, the sync output is disabled automatically. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 118 50% duty cycle. In the first half period of the waveform, the sync Modulation signal is a TTL high level. Mode • For AM, FM, PM and PWM, the frequency of the sync signal is the modulation frequency. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 119 Duty cycle is carrier Burst Mode period*cycles/burst period. • Gated Burst: There is no sync signal output. The sync output is disabled when the channel uses the external trigger source. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 120 The waveform is inverted relative to the offset voltage. As shown in the figure below, relative to the offset voltage, the waveform is inverted. Normal Inverted Normal Inverted Offset DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 122 √ √ Frequency Display Mode √ √ Frequency Value √ √ Not available when Frequency Coupling Disabled Coupling is on Period √ √ Amplitude Display Mode √ √ DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 123 Idle Level √ √ Sweep State √ √ Mode √ √ (Trigger) Source √ √ Frequency Display Mode √ √ Start Frequency √ √ Stop Frequency √ √ Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 124 Sync On/Off √ × Sync Mode √ × Sync Polarity √ × Invert √ × Impedance √ √ Trigger Output On/Off √ √ Trigger Output Edge √ √ DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 125 Track : Track-on : Track-inverted CAUTION After modifying the on/off state or parameters of track or coupling, you can only click or tap Apply to validate the modifications. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 126 √ √ × × × × × Coupling Frequency Coupling Frequency coupling allows you to couple frequencies between channels, either by a constant deviation or ratio between them. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 127 - Offset: the phase deviation between CH1 and CH2. Set the phase of base channel to P and the phase deviation to P , then the phase of the other basic channel is P = P basic Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 128 ) is enabled, enabling the Track function automatically disables the channel coupling function. • When the output mode of the base channel is set to "Advanced", the Track function is disabled. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 129 Align Phase key. The waveforms shown on the oscilloscope will have a phase deviation of 180° without any adjustment of the start phase of the generator. Figure 14.1 Before Aligning Phase Figure 14.2 After Aligning Phase Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 130 Tick the check box next to the file or folder and the box will be displayed as You can click or tap the box again to cancel the selection. The check box restores to its original state. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 131 - Protocol: Select FTP. - User Name/Password: Enter the user name and password of DG5000 Pro. The user name is "admin" and the password is "rigol" by default. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 132 After the file transfer is complete, you can close the session to disconnect from DG5000 Pro. You can also use other software to transfer files. For details, see the user manual of the corresponding software. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 133 Under the current directory, select the file or folder (empty) that you want to delete. Click or tap Delete to delete the selected file or folder. You cannot delete folders that are not empty. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 134 3. Refer to . Select the upgrade file and then click or tap Upgrade. In the pop-up menu, click or tap OK to perform the local upgrade operation. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 135 The configuration type of the IP address can be DHCP, Auto IP, or Static IP. In different IP configuration types, the configurations for IP address and other network parameters are different. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 136 0 to 255. You are recommended to ask your network administrator for an address available. Generally, you do not need to set the DNS, therefore this parameter setting can be ignored. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 137 After the mDNS function is enabled, click or tap the Service Name input field to set the service name. 17.3 Basic Settings In the Utility menu, click or tap Setup to access the basic setting menu. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 138 Of course, you can change the phase relationship between two instruments by changing the "Start Phase" of each channel. Follow the steps below to synchronize two or more instruments. • Synchronize two instruments: DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 139 17.4 About this Instrument In Utility menu, click or tap About, and then you can view the model, version, and other information about this instrument. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 140 Then click or tap the Print Screen button at the bottom of the interface. The screen image will be stored in the specified format. By default, the screen capture is saved to internal memory. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 141 There are 15 screen test interfaces. Click or tap the screen to switch to the next screen test interface. Click or tap Exit at the upper-left corner of the interface to exit the screen test interface. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 142 When a state file has been stored in the specified location, you can select the location and then click or tap Apply > OK to recall the state file. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 143 Arb Type Sinc Burst State Burst Type N-Cycle Burst Period 10 ms Trigger Source Internal Cycles Phase 0° Delay 0 ps Gated Polarity Positive Idle Level 1st Pt Modulation Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 144 Pulse Width Modulation Modulation Source Internal Shape Sine Modulation Frequency 100 Hz Duty Cycle Deviation Width Deviation 50 μs SUM Ratio SUM Frequency 1 kHz SUM Waveform Sine DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 145 PRBS Type PRBS3 Edge Time 2 ns Multi-pulse Trigger Delay 500 ms Trigger Source Edge Time 2 ns Idle Level Middle Pulse Count H-Width 5 μs L-Width 5 μs Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 146 Phase Coupling Phase Coupling Mode Offset Phase Coupling Ratio Phase Coupling Offset Amplitude Coupling Amplitude Coupling Mode Offset Amplitude Coupling Ratio Amplitude Coupling Offset Track On/Off Channel Setup DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 147 Sync Mode Normal Sync Polarity Positive Mark Frequency 500 Hz Invert Impedance HighZ Trigger Output Trigger Output Polarity Leading Edge System Utility Beeper Clock Source Internal Print Screen Format Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 148 This instrument can be connected to the PC via the USB and LAN interface to set up communication and realize remote control through the PC. This chapter will illustrate how to use the RIGOL Ultra Sigma software to remotely control the instrument via various interfaces.
Page 149 PC via the USB interface. You can also click USB-TMC to search for the resource. 3. View the device resource The resources found will appear under the "RIGOL Online Resource" directory, and the model number and USB interface information of the instrument will also be displayed.
Page 150 4. View the device resource The resources found will appear under the "RIGOL Online Resource" directory. 5. Control the instrument remotely Right-click the device resource name and select "SCPI Panel Control" to open the remotely command control panel.
Page 151 After restarting the instrument, insert the USB storage device again to check whether it can work normally. d. If the USB storage device still cannot work normally, please contact RIGOL. 4. Performance verification test is failed. a. Check whether the generator is within calibration period (1 year).
Page 152 (e.g. a magnet), please move the instrument away from the magnet field. d. If the problem still persists, please contact RIGOL. DG5000 Pro User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 153 DG5000 Pro-SEQ Multi-tone Option DG5000 Pro-MTONE Pattern Option DG5000 Pro-PJ 128 Mpts/CH (Max.) Arb Length Upgrade Option DG5000 Pro-2RL Function Bundle Option DG5000 Pro-BND DG5000 Pro-IQ/MPUL/SEQ/MTONE/PJ/2RL included Optional Accessories Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DG5000 Pro User Guide...
Page 154 RIGOL guarantees free replacement or repair for the defective product. To get repair service, please contact your nearest RIGOL sales or service office. There is no other warranty, expressed or implied, except such as is expressly set forth herein or other applicable warranty card.

This manual is also suitable for:

Dg5502 pro Dg5252 pro Dg5352 pro Dg5000 pro series
