Uniden BW 3102R Owner's Manual

4.3” lcd portable wireless baby monitoring system

Hide thumbs

page of 40

/ 40
Bookmarks

Quick Links

Download this manual

BW31xx Series

4.3" LCD Portable Wireless

Baby Monitoring System

For more exciting new products please visit our website:

Australia: www.uniden.com.au

New Zealand: www.uniden.co.nz

Need help?

Do you have a question about the BW 3102R and is the answer not in the manual?

Questions and answers

Summary of Contents for Uniden BW 3102R

Page 1 BW31xx Series 4.3” LCD Portable Wireless Baby Monitoring System For more exciting new products please visit our website: Australia: www.uniden.com.au New Zealand: www.uniden.co.nz...
Page 2 IMPORTANT SAFETY INSTRUCTIONS This manual contains important information about this product’s operation. If you are installing this product for others, you must leave this manual or a copy with the end user. When using your equipment, always follow basic safety precautions to reduce the risk of fire, electric shock and injury to persons, including the following: • This equipment is NOT waterproof.
Page 3 • Clean only with a dry cloth. Failure to follow the instructions in this operating manual will void the warranty. Uniden assumes no liability for damages to property or injury to persons caused by improper handling or failure to comply with these safety...
Page 4 Contents WHAt’s In tHe BoX? ..................6 InstALLAtIon ....................7 MONITOR INSTALLATION ........................7 CAMERA INSTALLATION ........................7 Wall Mount ................................ 8 Suction Mount ..............................8 Clip Mount ................................8 Connect Power ..............................8 BAsIC oPeRAtIon .................... 9 WIRELESS CAMERA ........................... 9 WIRELESS MONITOR ..........................
Page 5 Viewing Recorded Video ..........................30 Deleting Folders and Video Files .......................30 VIEWING LIVE VIDEO ..........................31 Viewing On Your TV ............................31 Viewing on Your Remote PC or Wireless Device ................... 31 Setup .................................. 31 Remote Viewing ............................. 31 Viewing Recorded Video on your Computer ..................32 ZOOM ................................32 NIGHT LIGHT .............................
Page 6 • If any item is missing or damaged, contact your place of purchase immediately. Never use damaged products! • Need help? Get answers at our website: www.uniden.com.au for Australian model www.uniden.co.nz for New Zealand model. All trademarks are registered trademarks of their respective owners.
Page 7 InstALLAtIon MonItoR InstALLAtIon 1. Place the monitor in a location with clear reception from your camera(s). 2. If you are using the monitor as a stand-alone unit, flip out the stand on the back of the monitor and extend the antenna. Connect an AC adaptor to the power input on the side of the receiver.
Page 8 Wall Mount The BW3000 camera mounting clip has two slots that fit over screws to mount the unit on the wall. WALL 1. Mark the position of the screw holes on the wall. 2. Drill holes and insert the anchors and screws provided.
Page 9 BAsIC oPeRAtIon WIReLess CAMeRA Left side Front Right side NOTE: The RESET button is on the back. Item What it does Camera Antenna: Sends and receives signals to or from the monitor. Temperature sensor: Detects temperature at camera side and displays it on the monitor LCD.
Page 10 Light sensor: Measures light intensity on the camera side. Lens: Camera lens. Microphone: Receives sounds for the area near the camera, and transmits sound from the camera to the monitor. Speaker: Produces the sound transmitted from the monitor. POWER: Turns the camera ON or OFF. NIGHT LIGHT: Press to turn the night light on or off.
Page 11 WIReLess MonItoR NOTE: RESET button on back of monitor. 18 17 ZOOM TALK TALK MENU BACK Item What it does Antenna: Receives video and audio signals from the camera. POWER: Turns the camera on and off. LED light bar. The bottom LED indicates power and the remaining LEDs indicate sound.
Page 12 ▲Vol: • Increase speaker volume. • In Menus: Scroll up. • In Lullaby: Increase volume. • In Zoom: Scroll up. • In Video Playback - Restart playback. CH◄: • In Menus: Scroll left. • In Zoom: Scroll left. • In Live view: Switch between available cameras. • In Video Playback - Reverse. ▼Vol: • Decrease speaker volume. • In Menus: Scroll down. • In Lullaby: decrease volume. • In Zoom: Scroll down. • In Video Playback - Pause playback. CH►: • In Menus: Scroll right. • In Zoom: Scroll right. • In Live view: Switch between available cameras • In Video Playback - Fast forward. MENU/OK: Select a menu option or accept a setting. PLAY RECORD Microphone BACK: • In Menus: Back one level. • In Video Playback: Back out of Video Playback function one screen at a time. DC 5V: Connects the DC 5V power adaptor to the monitor.
Page 13 Charge LED • Green = Battery is fully charged. • Orange = Battery is almost charged. • Red = Battery is charging. If the monitor becomes unplugged from the adaptor, this LED turns off. AV Out jack: Connect the included A/V cable to view video from the TV or computer monitor. PC Only (USB Port):Use the included USB cable to connect your computer to the BW31xx series monitor to view video remotely or from your PC.
Page 14 LCD Display Cam 1 21°C REC063020-1.AVI Item Icon What it does Signal Indicator (displays in full screen mode only). The number of bars in the signal indicator shows the strength of the signal received from the camera. One or no bars indicates the signal is poor, and 4 bars indicate a very strong signal.
Page 15 New Record Indicator. This icon indicates when a new video record is available. Temperature indicator (displays in full screen mode 21°C only). Displays the temperature on the camera side. Night light indicator (displays in full screen mode only). Displays when the night light is turned on. (See page 32) Battery level.
Page 16 UsInG tHe BW31XX seRIes Viewing Modes Live view displays live images from the cameras in the following modes: • Quad mode: Monitor displays video from all cameras on a single screen in 4 quadrants. Any channel that does not have a camera is blank. • Single mode: Monitor displays video from one camera at a time. • Scan mode: Monitor displays video from one camera at a time, but cycles through all cameras one by one.
Page 17 Use the Intercom 1. Press and hold TALK on the monitor. 2. Speak into the microphone. 3. Release to hear reply. View video from TV See page 31. View video from remote See page 31. device through Skype...
Page 18 sYsteM MenUs Press MENU/OK to access system menus. Use the navigating buttons to navigate up (▲Vol), down (▼Vol ), left (CH◄), and right (CH►) in the menus, then press MENU /OK to confirm a setting. Use CH► or CH◄ to focus on the 5 different system menu selections on the clothesline. • System • Power Save • Camera • Record • Alert sYsteM Move the focus to the System option and press MENU/OK to access the eight System options:...
Page 19 Date/Time This option allows you to set the system date and time. The display format is Year.Month.Day Hour:Minute 1. From the System menu, select Date/Time and press MENU/OK. The Date/Time screen displays. 11 30 10 30 2. Press ▲Vol or ▼Vol to increase/decrease the number for that setting. 3. Press CH► or CH◄ to save the current setting and move to the next setting. 4.
Page 20 AV Out This option allows you to select the TV standard. (Default = PAL) 1. From the System menu, select AV Out and press MENU/OK. The AV Out screen displays. 2. Press ▲Vol or ▼Vol to select NTSC or PAL 3. Press MENU/OK to save the setting and return to the main System options Format Storage...
Page 21 Language This option allows you to select the system’s display language from English, Español, or Français. (Default = English) 1. From the System menu, select Language and press MENU/OK. The Language screen displays. 2. Press ▲Vol or ▼Vol to select a language. 3. Press MENU/OK to save the setting and return to the main System options. Temperature Display Unit This option allows you to set the temperature to display in Celsius (C) or Farenheit (F).
Page 22 Temperature Alert Range Your BW31xx Series measures the ambient room temperature where the camera is. If the temperature falls outside of a preset range, the system alerts you. Temp. alert range lets you set that range. [Default = Low Temperature: 16°C ; High Temperature: 25°C; Off] 1. From the System menu, select Temp. alert range and press MENU/OK. The Temp.
Page 23 ALeRt Temperatures out of range or a camera out of range triggers alerts. This option allows you to set the alert volume. There are 6 levels available. [Default = Zero (Mute)] 1. From the main menu selections, select Alert and press MENU/OK. The Alert Volume screen displays.
Page 24 ReCoRD This option allows you to set the parameters for your recorded files. The RECORD options are: • Quality • Record Time • Vox • Overwrite Quality This option allows you to choose between a high or low resolution recording quality. (Default = Low 320 x 240) 1.
Page 25 Record Time This option allows you to select how long the camera will record when the VOX sensitivity function is activated. (Default = 30 secs.) 1. From the Record menu, select Record Time and press MENU/OK. The Record Time screen displays. 2.
Page 26 Overwrite Activating this function allows the oldest files to be deleted when you want to record but the memory card is full. 1. From the Record menu, select Overwrite and press MENU/OK. The Overwrite screen displays. (Default = No) 2. Press ▲Vol or ▼Vol to toggle between Yes and No to activate or deactivate this feature.
Page 27 CAMeRA This option allows you to pair the monitor with cameras (up to 4 cameras supported) to turn on/off individual camera. The cameras are still powered on but no longer visible to the monitor. 1. From the main menu selections, select Camera and press MENU/OK. 2.
Page 28 2. Press ▲Vol or ▼Vol to select the camera you want to pair, then press MENU/OK. The monitor prompts you to press PAIR on the back of the camera within 30 seconds. 3. Press PAIR on the back of the camera within 30 seconds. 4. That camera’s video displays on the monitor PAIR when pairing is successful.
Page 29 PoWeR sAVe Activating the Power Save feature turns off the LCD after two minutes of inactivity. Be sure that VOX is activated, however (see page 25). If VOX is deactivated, press any button on the monitor to turn the LCD back on. This option allows you to enable or disable this function.
Page 30 sPeCIAL FeAtURes ReCoRDInG VIDeo You can manually record video to a microSD card (not included). The BW31xx Series supports up to 32GB microSD card. The system records video in 10 minute blocks; however, you can manually stop recording at any time. # During recording, only TALK is active.
Page 31 2. A confirmation screen displays. Use CH► or CH◄ to select Yes. Press MENU/ 3. The system returns to the same screen where you can see that the folder or record has been deleted. VIeWInG LIVe VIDeo The BW31xx Series lets you view live video from your system on your television. You can also use Skype™ to view your system on a remote PC or wireless devices such as an iPhone®, iPad®, or AndroidTM smartphone or tablet.
Page 32 Viewing Recorded Video on your Computer The microSD card saves BW31xx Series video records in AVI format. You can take that card and play it on your computer. You will need a microSD card and adaptor (not included) or an SD card reader for other systems (not included). 1.
Page 33 3. Press LULLABY SKIP to skip to Lullaby #2. The system plays Lullaby #2 then repeats it. 4. Press LULLABY SKIP to skip to Lullaby #3. The system plays Lullaby #3 then repeats it. 5. Press LULLABY SKIP to skip to Lullaby #4. The system plays Lullaby #4 then repeats it.
Page 34 tRoUBLesHootInG If you have problems with the system, there is often a quick and simple solution. Please try the following: There is no picture • checking all connections to the camera. Make sure from the camera the adaptor is plugged in. • making sure that the cameras and monitor are both • making sure that the camera is in range of the monitor.
Page 35 sPeCIFICAtIon GENERAL Camera Monitor Operating Frequency Range 2.400 ~ 2.4835GHz TX Power 15dBm RX Sensitivity –81dBm Type of Spread Spectrum Used FHSS Type of Modulation Used GFSK Communication Range 150ms Line of Sight CAMERA Image Sensor Type Manufacturer/ Model # 1/6.5” Color CMOS Image sensor Effective Pixel 640 x 480 Image Processing...
Page 36 MONITOR Display Size/Type 4.3” TFT LCD Resolution 480 x 272 Power Requirement 5.0VDC +/–5% Power Consumption 350mA Max (Normal) 900mA Max (Charging) Operating Temperature Range –10°C ~ 40°C (14°F ~ 104°F) Operating Humidity Range Within 80% Relative Humidity RoHS Compliance Battery Life 4.5 hours Housing Material Plastic...
Page 37 Warrantor The warrantor is either Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”) or Uniden New Zealand Limited (“Uniden NZ”) as the case may be. Terms of Warranty Uniden Aust/NZ warrants to the original retail purchaser only that the BW31xx Series (“the Product”), will be free from defects in materials and craftsmanship for the duration...
Page 38 Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden at the addresses shown below. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
