- Page 1 BW30xx Series 2.3” LCD Portable Wireless Baby Monitoring System For more exciting new products please visit our website: Australia: www.uniden.com.au New Zealand: www.uniden.co.nz...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS This manual contains important information about this product’s operation. If you are installing this product for others, you must leave this manual or a copy with the end user. When using your equipment, always follow basic safety precautions to reduce the risk of fire, electric shock and injury to persons, including the following: • This equipment is NOT waterproof.
- Page 3 • Clean only with a dry cloth. Failure to follow the instructions in this operating manual will void the warranty. Uniden assumes no liability for damages to property or injury to persons caused by improper handling or failure to comply with these safety...
-
Page 4: Table Of Contents
CONTENTS WHAT’S IN THE BOX? ..................5 INSTALLATION ....................6 Monitor ................................. 6 Camera ................................6 BASIC OPERATION .................... 8 Wireless Camera ............................8 Wireless Monitor ............................10 LCD Display ............................... 12 USING THE BW30XX SERIES ................14 SYSTEM MENU DESCRIPTIONS ............... 15 System ................................ -
Page 5: What's In The Box
1 x Monitor Power Adaptors • If any item is missing or damaged, contact your place of purchase immediately. Never use damaged products! • Need help? Get answers at our website: www.uniden.com.au for Australian model www.uniden.co.nz for New Zealand model. -
Page 6: Installation
INSTALLATION MONITOR 1. Place the monitor in a location with clear reception from your camera(s). Place it a minimum of 1m from the crib. 2. Plug the AC adaptor power plug into the monitor’s DC adaptor input jack. 3. Plug the power plug into a 240 volt AC (standard indoor) power outlet or surge protector. - Page 7 Wall Mount The Indoor Camera mounting clip has two slots that fit over screws to mount the unit on the wall. WALL 1. Mark the position of the screw holes on the wall. 2. Drill holes and insert the anchors and screws provided.
-
Page 8: Basic Operation
BASIC OPERATION WIRELESS CAMERA Left side Front Right side NOTE: The RESET button is on the back. No Keys/Indicators Function Camera Antenna Sends and receives signals to and from the monitor Temperature Detects temperature at camera side and displays it on sensor the monitor LCD Pair... - Page 9 Light Sensor Measures light intensity on the camera side. Camera Lens Microphone Receives sounds for the area near the camera, and transmits sound from the camera to the monitor. Speaker Produces the sound transmitted from the monitor. POWER Turns the camera ON or OFF. NIGHT LIGHT Press to turn the night light ON or OFF.
-
Page 10: Wireless Monitor
WIRELESS MONITOR NOTE: The RESET button is on the back behind the kickstand. No Keys/Indicators Function Monitor Antenna Sends and receives signals to and from the monitor. LED light bar The left LED indicates power and remaining LEDs indicate sound. POWER Turns the camera on and off. - Page 11 Microphone ▼Vol • Decrease speaker volume. • In Menus: Scroll down. • In Lullaby: decrease volume. • In Zoom: Scroll down. MENU/OK Select a menu option or accept a setting. TALK Activate Intercom function (see page 25). BACK In Menus: Back one level. CH►...
-
Page 12: Lcd Display
LCD Display CAM1 21°C 2013.02.02 12:26:00 No Icon What it indicates Signal Indicator (displays in full screen mode only). The number of bars in the signal indicator shows the strength of the signal received from the camera. One or no bars indicates the signal is poor, and 4 bars indicate a very strong signal. - Page 13 Camera Indicator. indicates which camera is CAM1 displaying. Press CH► or CH◄ on the monitor to switch between available cameras. It will cycle in the following order: CH► : CAM1—CAM2—CAM3—CAM4—QUAD— AUTO SCAN — CAM1 CH◄ : CAM1—Auto SCAN—QUAD—CAM4— CAM3—CAM2—CAM1 21°C Temperature indicator (displays in full screen mode only). Displays the temperature on the camera side. Night light indicator (displays in full screen mode only).
-
Page 14: Using The Bw30Xx Series
USING THE BW30XX SERIES Viewing Modes Live view displays live images from the cameras in the following modes: • Quad mode: Monitor displays video from all cameras on a single screen in 4 quadrants. Any channel that does not have a camera remains blank. • Single mode: Monitor displays video from one camera at a time. • Scan mode: Monitor displays video from one camera at a time, but cycles through all cameras one by one. -
Page 15: System Menu Descriptions
SYSTEM MENU DESCRIPTIONS Press MENU/OK to access system menus. Use the navigating buttons to navigate up (▲Vol), down (▼Vol ), left (CH◄), and right (CH►) in the menus, then press MENU /OK to confirm a setting. Use CH► or CH◄ to focus on the 5 different system menu selections on the clothesline. • System • Power Save • Camera • VOX • Alert... -
Page 16: System
SYSTEM Move the focus to the System option and press MENU/OK to access the six System options: • Date/Time • Brightness • Factory Reset • Language • Temp. display unit • Temp. alert range Date & Time This option allows you to set the system date and time. The display format is Year.Month.Day. - Page 17 Brightness This option allows you to adjust the brightness level for each camera. (Default = 3) 1. From the System menu, select Brightness and press MENU/OK. The Brightness screen displays. 2. Press CH► or CH◄ to increase or decrease the brightness level (6 levels). 3. Press MENU/OK to save the setting and return to the main System options. The new brightness level displays in the Live view.
- Page 18 Language This option allows you to select the system’s display language from English, Español, or Français. (Default = English) 1. From the System menu, select Language and press MENU/OK. The Language screen displays. 2. Press ▲Vol or ▼Vol to select a language. 3. Press MENU/OK to save the setting and return to the main System options. Temperature Display Unit This option allows you to set the temperature to display in Celsius (C) or Farenheit (F).
- Page 19 Temperature Alert Range BW30xx Series measures the ambient room temperature where the camera is. If the temperature falls outside of a preset range, the system alerts you (the temperature indicated on the display screen turns red and starts to flash). Temp.
-
Page 20: Alert
ALERT Temperatures out of range or a camera out of range triggers alerts. This option allows you to set the alert volume. There are 6 levels available. [Default = Zero (Mute)] 1. From the main menu selections, select Alert and press MENU/OK. The Alert screen displays. -
Page 21: Vox
This option allows you to set the sound sensitivity for the camera. (Default = High) 1. From the main menu selections, select VOX and press MENU/OK. The VOX sensitivity screen displays. 2. Press ▲Vol or ▼Vol to select a level (High, Low, or Off). 3. Press MENU/OK to save the selection and return to the main menu selections. POWER SAVE Activating the Power Save feature turns off the LCD after two minutes of inactivity. -
Page 22: Camera
2. Press ▲Vol or ▼Vol to toggle between turning the Power Save feature on or off. 3. Press MENU/OK to accept that setting and return to the main menu selections. CAMERA This option allows you to pair the monitor with cameras (up to 4 cameras supported) or to turn on/off an individual camera. The cameras are still powered on but no longer visible to the monitor. - Page 23 Pair Pairing allows you to introduce additional cameras to the monitor. The monitor can then recognize and display video from them. The camera that comes with this system is already paired. # Before pairing additional cameras, be sure they are powered and turned on. See page 6.
-
Page 24: Special Features
SPECIAL FEATURES ZOOM ZOOM displays the camera image in double size. Press ▲Vol, ▼Vol, CH►, or CH◄ to see the parts of the image not displayed on the LCD screen. Press ZOOM again to return to normal view. NIGHT LIGHT You can control the BW30xx Series night light using the NIGHT LIGHT button on the right side of either the monitor or the camera. -
Page 25: Using The Intercom
5. Press LULLABY SKIP to skip to Lullaby #4. The system plays Lullaby #4 then repeats it. 6. Press LULLABY SKIP to skip to Lullaby #1. The system plays Lullaby #1 then cycles through all lullabies. Press ▲Vol and ▼Vol on the monitor or camera to adjust the volume. Press ▼Vol all the way down on the monitor to mute the lullaby playing through the monitor. USING THE INTERCOM The Intercom feature lets you talk to whomever is within camera range. -
Page 26: Solving Problems
SOLVING PROBLEMS If... Try... There is no picture from • checking all connections to the camera. Make the camera sure the adaptor is plugged in. • making sure that the cameras and monitor are both ON. • making sure that the camera is in range of the monitor. -
Page 27: Specification
SPECIFICATION GENERAL Camera Monitor Operating Frequency Range 2.400 ~ 2.4835GHz TX Power 15dBm RX Sensitivity –81dBm Type of Spread Spectrum Used FHSS Type of Modulation Used GFSK Communication Range 150ms Line of Sight CAMERA Image Sensor Type Manufacturer/ Model # 1/6.5” Color CMOS Image sensor Effective Pixel • 640 x 480 Image Processing... -
Page 28: Monitor
MONITOR Display Size/Type 2.3” TFT LCD Resolution 320 x 240 Power Requirement 5.0VDC +/–5% Power Consumption • 260mA Max (Normal) • 740mA Max (Charging) Operating Temperature Range –10°C ~ 40°C (14°F ~ 104°F) Operating Humidity Range Within 85% Relative Humidity RoHS Compliance Battery Life 4.5 hours Housing Material Plastic... -
Page 29: One Year Limited Warranty
Warrantor The warrantor is either Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”) or Uniden New Zealand Limited (“Uniden NZ”) as the case may be. Terms of Warranty Uniden Aust/NZ warrants to the original retail purchaser only that the BW30xx Series (“the Product”), will be free from defects in materials and craftsmanship for... - Page 30 Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden at the addresses shown below. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
- Page 32 ©2013 Uniden Australia Pty Ltd/Uniden New Zealand Limited Printed in PRC...
