Tournai 2 420 x 300cm
Important information
We are pleased that you have chosen a product of SKAN HOLZ.
Please check the construction set for completeness using the position list in good time before starting con-
struction or commissioning your construction team. If individual parts are defective or missing, we will deliver
these as quickly as possible. However, we cannot refund the costs for any resulting construction delays to a
construction company.
Please understand that we cannot assume any guarantee for the following defects:
- incorrect storage before assembly
- incorrect anchoring with the ground or inadequate foundation (foundation according to statics)
- damage due to erection errors, e. g. the house is not level or not right-angled
- damage through a higher level of snow burden than statically envisaged. Recommendation: lad relief of
the roof by removing the snow layer
- storm damage (insurance cases) or violent destruction
- damage through any alteration to the design by the client
- natural formation of cracks, branch holes, twisting, decolouration or similar modification (natural
process; has no influence on the statics)
Storage information until construction :
- store pallet on a level and dry surface.
- Protect from exposure to sunlight and the influences of weather ; wood can warp drastically in a loose
condition!
Maintenance tips:
Please observe the attached information sheet "Care instructions/Colour treatment".
General tips and refers to:
-
1
The packaging foil can be used to keep moisture out of the house. It is laid according to the ground area of the
house under the main bearing.
-
As the house is exposed constantly to the weather, it is necessary to lay a further welding line. You have to make
2
it for your own. We recommend clearing the roof during heavy snowfall!
-
A possibly desired installation of a rain gutter must be done by the building contractor; for this the roofing boards
3
must be cut to the right length.
-
1
Foundation according (to the structural calculations, not included in the scope of delivery): concrete C25/30,
strip foundation: w/h = 30/90cm, each 2 Ø 12 top and bottom, bow Ø 6, e < 20cm. Bottom panel:
t=14cm,Q188A, top and bottom throughout. Anchoring of the floor beams on the strip foundation using bolts M12,
e < 60cm (by customer).
-
2
The wooden parts of the building kit are delivered with a residual moisture content of about 15%.
Wood "works"! This means that the wooden parts will swell during prolonged damp weather and shrink (dry out)
during prolonged dry periods. This only occurs in height or width, not lengthwise.
The block planks are firmly screwed to the vertical corner post during installation. This will not change its length,
but the horizontally attached planks change their height. If damp weather persists, the block planks can swell
slightly after completion. It is therefore important to leave 1mm clearance between the planks when fitting. Use
the enclosed spacer (to avoid unnecessary strains in the structure).
© SKAN HOLZ Europe GmbH / D-21227 Bendestorf. Technical modifications reserved. All dimensions are approximate dimensions. 04/2024
603770
1
EN
