StyleView powered carts provide electrical AC power for
mobile point of care computing equipment in a healthcare
environment. The carts are not intended to power medical
products or devices. Outlets are provided to power
information technology equipment only such as computer
equipment and computer peripherals.
Features & Specifi cations ............................................... 3 - 6
Set-up ............................................................................ 7 - 16
Adjustment ........................................................................ 14
Battery Charge/Discharge .................................................15
Auto-Lock Drawer ........................................................ 16 -17
Change Fuse (5 Amp) .........................................................18
Change Power System Batteries ................................ 19 - 20
Cart Storage (long term/short term) .................................21
Ergonomics .........................................................................22
Maintenance & Safety ................................................ 22 - 25
For Warranty visit: www.ergotron.com/warranty
For Service visit: www.ergotron.com
For local customer care phone numbers visit: http://contact.ergotron.com
For the latest User Installation Guide and StyleLink Software Download please visit: www.ergotron.com
User's Guide - English
Guía del usuario - Español
Manuel de l'utilisateur - Français
Gebruikersgids - Deutsch
Benutzerhandbuch - Nederlands
Guida per l'utente - Italiano
Användarhandbok - svenska
ユーザーガイ ド : 日本語
用户指南 : 汉语
888-24-310-G-01 rev. H • 03/18
StyleView® SV44 Cart
with LCD Arm and LiFe Power System
User Guide
1 of 25
Advertisement
Related Manuals for Ergotron StyleView SV44-1212-2
Summary of Contents for Ergotron StyleView SV44-1212-2
- Page 1 For Warranty visit: www.ergotron.com/warranty For Service visit: www.ergotron.com For local customer care phone numbers visit: http://contact.ergotron.com For the latest User Installation Guide and StyleLink Software Download please visit: www.ergotron.com User's Guide - English Guía del usuario - Español Manuel de l’utilisateur - Français...
- Page 2 Changes or modifi cations not expressly approved by Ergotron, Inc. could void the user’s authority to operate the www.ergotron.com equipment.
- Page 3 Features & Specifi cations 4/11 Height Adjustable LCD Mount attaches LCDs or tablet PC's with 75x75 or 100x100mm mounting interface Worksurface 2a. Worksurface Lock and Release User Interface for Power System Secure Storage for Laptop, Thin Client or CPU Front Handle Height Adjustment Brake Handle USB Hub connects keyboard and mouse USB cables Keyboard tray slides out, tilts and allows for right or left mousing with attached mouse holder...
- Page 4 Features & Specifi cations Part Number Auto-Lock Drawer Power System SV44-1212-1 1 Drawer*/16 compartments 1 Drawer*/9 compartments SV44-12B2-1 SV44-1222-1 2 Drawers*/32 compartments SV44-12A2-1 2 Drawers*/8 compartments Input: 120VAC/60 Hz, 5.0A; SV44-12C2-1 2 Drawers*/8 compartments Output: 120VAC/60 Hz, 150VA, 150W. • The cart and power system are certifi ed to UL 60601 and CAN/CSA-C22.2 601.1-M90 SV44-1232-1 3 Drawers*/48 compartments SV44-1242-1...
- Page 5 Features & Specifi cations Weight Capacity <14 lbs (6.4 kg) CAUTION: DO NOT EXCEED MAXIMUM 0 lbs (0 kg) Open Worksurface and during transport LISTED WEIGHT CAPACITY. SERIOUS INJURY <5 lbs (2.3 kg) Closed Worksurface OR PROPERTY DAMAGE MAY OCCUR! <13 lbs (5.9 kg) CPU Compartment <2 lbs (0.9 kg)
- Page 6 Features & Specifi cations 60˚ 7" (178 mm) 5˚ 20" 12˚ (508 mm) 16" (406 mm) 180˚ 90˚ 90˚ 4" - 11" (102-279 mm) 50.5" 3.27" (1283 mm) 13.4" (83 mm) (340 mm) 3.4" 7.4" (86 mm) (188 mm) 31" (787 mm) 8.5"...
- Page 7 Set-up Release Brake to move riser. CAUTION! Completely release brake engagement before raising or lowering the cart. Raising or lowering the cart with the brake partially engaged may cause product damage. 888-24-310-G-01 rev. H • 03/18 7 of 25...
- Page 8 Set-up Connect Keyboard and Mouse to USB Hub USB (Type A) USB (Type A) NOTE: Bar Code Scanner should be connected directly to computer USB port. DO NOT connect Bar Code Scanner to the USB Hub. 888-24-310-G-01 rev. H • 03/18 8 of 25...
- Page 9 Set-up 0˚ 0˚ M4 x 5mm 75x75mm / 100x100mm WARNING Impact Hazard! Moving Parts can Crush and Cut. Raise monitor to top of vertical M4 x 10mm adjustment BEFORE removing. Failure to heed this warning may result in serious personal injury or property damage! 826-504 AVERTISSEMENT...
- Page 10 Set-up Plug in power cables. Route power cable down along tower. If you do not have power outlets located here, then follow steps 'a' - 'd' to route power cables. 6' (1.8 m) Power cables need to be 6' (1.8 m) long. WARNING! Connecting electrical equipment to the outlet eff ectively leads to creating a medical system and the result can be a reduced level of safety.
- Page 11 USB Hub, Keyboard Lights and Fan to function). Optional StyleLink: This USB cable runs from the power system to your computer for StyleLink Software. For more info on StyleLink visit: http://4support.ergotron.com . WARNING: Fan must always be running when computer is on.
- Page 12 Set-up Placement of CPU's in Secure Storage Area: USFF (Ultra Small Form Factor) Thin Client DO NOT OBSTRUCT AIR VENTS! Obstructing air vents may cause overheating and result in equipment damage. Center CPU in storage area. To increase space and improve airfl ow, power brick may be stored under the storage area.
- Page 13 Set-up 3 Function Caster Wheel Rotation Wheel Rotation and Swivel Locked 888-24-310-G-01 rev. H • 03/18 13 of 25...
- Page 14 Adjustment It is important that you adjust this product according to the weight of the mounted equipment as described in the following steps. Any time equipment is added or removed from this product, resulting in a change in the weight of the mounted load, you should repeat these adjustment steps to ensure safe and optimum operation. Adjustments should move smoothly and easily through the full range of motion and stay where you set it.
- Page 15 Battery has less than 10% charge and alarm beeps. Light is orange and then turns red when 45 min please contact Ergotron battery has less than 5% charge. Plug-in power cord and charge to 100%! You can use cart while Customer Care.
- Page 16 - PINs entered on the cart and not managed by StyleLink may vary in length from 4-7 digits. - Ergotron recommends the following for choosing PIN digit length (assumes less than 1 in 25 chance of guessing random User PIN): Max number of User PINs >50, 5+digit length recommended...
- Page 17 Auto-Lock Drawer Unlock Drawer (2 methods): NOTE: All Drawers in row must be closed before a new row can be unlocked. • Enter User PIN and press ENTER (only numbers for available drawer rows fl ash green), then press desired drawer row number*. •...
- Page 18 How to Change Fuse Turn power system off by Disconnect Power System from power source. Turn off all mounted equipment. holding down the AC Outlet Power button for 1 - 3 seconds. Power light will shut off . 5 Amp Fuse Recommended: Littelfuse 312005HXP FUSE RATING...
- Page 19 • Replace batteries with same Amp/Hour rating batteries only. Batterie Valence modèle numéro : U1-12RT REV2 Numéro de pièce Ergotron : 910-434 • Only Ergotron-specifi ed batteries may be used in the StyleView Power System. Batterie Valence modèle numéro : U1-12RJ Please call customer care for more details.
- Page 20 How to Change Power System Battery Caution: Do NOT swap battery cables, doing so will cause sparking and trip the circuit breaker. Recycle the battery Black according to local regulations. Caution: Remove Black (-) before removing Red (+). Black Torque to Torque to 110 in-lbs 110 in-lbs...
- Page 21 Once the process has fi nished the power system will resume charging as normal. if the low charge recovery process takes longer than 45 min please contact Ergotron Customer Care.
- Page 22 Ergonomics Working customize - to your size Moving 1 Set top of monitor screen about one inch below eye level - Release brake stow - before you go and lift or lower riser as needed. 1 During normal movement, release brake and lower worksurface to lowest position for optimal stability and unobstructed view.
- Page 23 CAUTION: Release Lift Brake before moving work surface! Moving work surface while Lift Brake is engaged may cause serious damage to Lift Engine. WARNING: In the event that repair of the StyleView Cart is needed, contact Ergotron Customer Care immediately. Cart repair can only be performed by Ergotron, Inc. or by an Ergotron authorized agent.
- Page 24 Maintenance & Safety Earth Bond Test: To ensure safety grounding between the Recommended Periodic Inspection and Maintenance power cord ground connection and any accessible metal parts on the cart, although not mandatory, the following test Component Action How often By whom is recommended to be performed every two years using a UI, Ethernet, USB Inspect for wear, pinching, bad...
- Page 25 Magnetic Field location in a typical commercial IEC 61000-4-8 or hospital environment. Note: U is the AC mains voltage prior to application of the test level © 2014 Ergotron, Inc. All rights reserved. 888-24-310-G-01 rev. H • 03/18 25 of 25...
