StyleView powered carts provide electrical AC power for
mobile point of care computing equipment in a healthcare
environment. The carts are not intended to power medical
products or devices. Outlets are provided to power
information technology equipment only such as computer
equipment and computer peripherals.
Features & Specifi cations ............................................... 3 - 6
Set-up ............................................................................ 7 - 17
Adjustment ........................................................................ 15
Battery Charge/Discharge .................................................16
Auto-Lock Drawer ....................................................... 17 - 18
Change Fuse (5 Amp) and Reset Circuit Breakers ............19
Change Power System Batteries ................................ 20 - 21
Cart Storage (long term/short term) .................................22
Ergonomics .........................................................................23
Maintenance & Safety ................................................ 23 - 26
For Warranty visit: www.ergotron.com/warranty
For Service visit: www.ergotron.com
For local customer care phone numbers visit: http://contact.ergotron.com
For the latest User Installation Guide and StyleLink Software Download please visit: www.ergotron.com
User's Guide - English
Guía del usuario - Español
Manuel de l'utilisateur - Français
Gebruikersgids - Deutsch
Benutzerhandbuch - Nederlands
Guida per l'utente - Italiano
Användarhandbok - svenska
ユーザーガイ ド : 日本語
用户指南 : 汉语
888-24-304-G-01 rev. D • 09/15
StyleView® SV44 Cart
User Guide
with LCD Arm
Includes
Constant Force™
Technology
1/26
Advertisement
Table of Contents
Related Manuals for Ergotron StyleView SV44-12B1-1
Summary of Contents for Ergotron StyleView SV44-12B1-1
-
Page 1: Table Of Contents
Maintenance & Safety ..........23 - 26 For Warranty visit: www.ergotron.com/warranty For Service visit: www.ergotron.com For local customer care phone numbers visit: http://contact.ergotron.com For the latest User Installation Guide and StyleLink Software Download please visit: www.ergotron.com User's Guide - English Includes Guía del usuario - Español Constant Force™... - Page 2 Changes or modifi cations not expressly approved by Ergotron, Inc. could void the user’s authority to operate the equipment. 826-501 Please contact Ergotron for complete EMC compatibility information.
-
Page 3: Features & Specifi Cations
Features & Specifi cations 4/11 Height Adjustable LCD Mount attaches LCDs or tablet PC's with 75x75 or 100x100mm mounting interface Worksurface 2a. Worksurface Lock and Release User Interface for Power System Secure Storage for Laptop, Thin Client or CPU Front Handle Height Adjustment Brake Handle USB Hub connects keyboard and mouse USB cables Keyboard tray slides out, tilts and allows for right or left mousing with attached mouse holder... - Page 4 Features & Specifi cations Part Number Auto-Lock Drawer Power System SV44-1211-1 1 Drawer*/16 compartments SV44-12B1-1 1 Drawer*/9 compartments SV44-1221-1 2 Drawers*/32 compartments SV44-12A1-1 2 Drawers*/8 compartments Input: 120VAC/60 Hz; 5.1A SV44-12C1-1 2 Drawers*/8 compartments Output: 120VAC/60 Hz, 400VA/300W. • The cart and power system are certifi ed to UL 60601 and CAN/CSA-C22.2 601.1-M90 SV44-1231-1 3 Drawers*/48 compartments SV44-1241-1...
- Page 5 Features & Specifi cations Weight Capacity <14 lbs (6.4 kg) 0 lbs (0 kg) Open Worksurface <5 lbs (2.3 kg) CAUTION: DO NOT EXCEED MAXIMUM Closed Worksurface <13 lbs (5.9 kg) CPU Compartment LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! <2 lbs (0.9 kg) see inset, below CAUTION:...
- Page 6 Features & Specifi cations 60˚ 7" (178 mm) 20" 5˚ (508 mm) 12˚ 180˚ 90˚ 90˚ Dimensions 4" - 11" (102-279 mm) 50.5" 3.27" (1283 mm) (83 mm) 13.4" (340 mm) 3.4" (86 mm) 7.4" (188 mm) 31" (787 mm) 8.5"...
-
Page 7: Set-Up
Set-up Release Brake to move riser. CAUTION! Completely release brake engagement before raising or lowering the cart. Raising or lowering the cart with the brake partially engaged may cause product damage. 7/26 888-24-304-G-01 rev. D • 09/15... - Page 8 Set-up Connect Keyboard and Mouse to USB Hub USB (Type A) USB (Type A) NOTE: Bar Code Scanner should be connected directly to computer USB port. DO NOT connect Bar Code Scanner to the USB Hub. 8/26 888-24-304-G-01 rev. D • 09/15...
- Page 9 Set-up 0˚ 0˚ M4 x 5mm 75x75mm / 100x100mm WARNING Impact Hazard! Moving Parts can Crush and Cut. M4 x 10mm Raise monitor to top of vertical adjustment BEFORE removing. Failure to heed this warning may result in serious personal injury or property damage! 826-504 AVERTISSEMENT...
- Page 10 Set-up Plug in power cables. Route power cable down along tower. If you do not have power outlets located here, then follow steps 'a' - 'd' to route power cables. 6' (1.8 m) Power cables need to be 6' (1.8 m) long. WARNING! Connecting electrical equipment to the outlet eff ectively leads to creating a medical system and the result can be a reduced level of safety.
- Page 11 Set-up WARNING! Connecting electrical equipment to the outlet eff ectively leads to creating a medical system and the result can be a reduced level of safety. 11/26 888-24-304-G-01 rev. D • 09/15...
- Page 12 USB Hub, Keyboard Lights and Fan to function). Optional StyleLink: This USB cable runs from the power system to your computer for StyleLink Software. For more info on StyleLink visit: http://4support.ergotron.com . WARNING: Fan must always be running when computer is on.
- Page 13 Set-up Placement of CPU's in Secure Storage Area: USFF (Ultra Small Form Factor) Thin Client DO NOT OBSTRUCT AIR VENTS! Obstructing air vents may cause overheating and result in equipment damage. Center CPU in storage area. To increase space and improve airfl ow, power brick may be stored under the storage area.
- Page 14 Set-up 14/26 888-24-304-G-01 rev. D • 09/15...
-
Page 15: Adjustment
Adjustment It is important that you adjust this product according to the weight of the mounted equipment as described in the following steps. Any time equipment is added or removed from this product, resulting in a change in the weight of the mounted load, you should repeat these adjustment steps to ensure safe and optimum operation. Adjustments should move smoothly and easily through the full range of motion and stay where you set it. -
Page 16: Battery Charge/Discharge
Battery has less than 30% charge. Light is red and alarm beeps. Plug-in power cord and charge contact Ergotron Customer Care. to 100%! You can use cart while charging. Alarm Mute button. Pressing this will temporarily mute alarm. -
Page 17: Auto-Lock Drawer
- PINs entered on the cart and not managed by StyleLink may vary in length from 4-7 digits. - Ergotron recommends the following for choosing PIN digit length (assumes less than 1 in 25 chance of guessing random User PIN): Max number of User PINs >50, 5+digit length recommended... - Page 18 Auto-Lock Drawer Unlock Drawer (2 methods): NOTE: All Drawers in row must be closed before a new row can be unlocked. • Enter User PIN and press ENTER (only numbers for available drawer rows fl ash green), then press desired drawer row number*. •...
-
Page 19: Change Fuse (5 Amp) And Reset Circuit Breakers
AC Outlet Power button for 1 - 3 seconds. Power light will shut off . 5 Amp Fuse Recommended: Before reseting circuit breakers, contact Ergotron to determine cause of trip. Littelfuse 312005HXP FUSE RATING VOLTAGE 250V CURRENT... -
Page 20: Change Power System Batteries
• Replace batteries with same Amp/Hour rating batteries only. and possible fire hazard. pourrait provoquer un incendie. • Only Ergotron-specifi ed batteries may be used in the StyleView Power System. Please call customer care for more details. • Recycle battery or contact Ergotron for proper battery disposal www.ergotron.com... - Page 21 Caution: Replace only one battery at a time. Do NOT swap battery cables, doing so will cause sparking and trip the circuit breakers. Black Caution: Remove Black (-) before removing Red (+). LEAD Recycle battery or contact Ergotron for proper battery disposal guidelines. BATTERY Black Caution: Connect Red (+) before connecting Black (-).
-
Page 22: Cart Storage (Long Term/Short Term)
Store battery in cool, dry area while Cart is out of use. Optimal storage temperature is 15°C/59°F. Battery voltage should be checked every three (3) months. If voltage drops below 12.5VDC, fully recharge battery. Contact Ergotron Customer Care for information about how storage might impact the battery warranty. -
Page 23: Ergonomics
Ergonomics Working Moving customize - to your size stow - before you go 1 Set top of monitor screen about one inch below eye level - Release brake and lift or lower riser 1 During normal movement, release brake and lower worksurface to lowest as needed. - Page 24 CAUTION: Release Lift Brake before moving work surface! Moving work surface while Lift Brake is engaged may cause serious damage to Lift Engine. WARNING: In the event that repair of the StyleView Cart is needed, contact Ergotron Customer Care immediately. Cart repair can only be performed by Ergotron, Inc. or by an Ergotron authorized agent.
- Page 25 Maintenance & Safety Recommended Periodic Inspection and Maintenance Component Action How often By whom UI, Ethernet, USB Inspect for wear, pinching, bad Monthly Any user cables connectors Casters Inspect for wear and debris Monthly Any user Inspect to ensure that maximum Maximum Load recommended loads are not Daily...
- Page 26 Maintenance & Safety Ergotron Electromagnetic Guidance and Manufacturer’s Declaration Guidance and Manufacturer’s Declaration – Electromagnetic Emissions The Powered Computer Cart is intended for use in the electromagnetic environment specifi ed below. The customer or the user of the Powered Computer Cart should assure that it is used in such an environment.
