Summary of Contents for Avalon A4BLWTRCLR
- Page 1 A few simple steps to ensure perfect water, every time.
- Page 3 Use and Care Guide MODELS: A4BLWTRCLR Registration Please visit the website below to register your new water cooler within the first 30 days of purchase. Registration within the first 30 days will activate your one year warranty. www.avalonh2o.com/register-my-avalon-cooler Please keep your model number, order number and purchase date for future support.
- Page 4 About Your Water Cooler Meet Your Avalon Product Part Names Indicator Lights Tech Specs Getting Started Unpacking your Avalon Water Cooler Install Water Bottle Install/Remove Drip Tray Powering the Dispenser Activate Heating and Cooling User Guide and Maintenance Dispensing Water...
- Page 5 About Your Water Cooler Meet Your Avalon Product Child Safety Feature Energy Star Approved Built-in Nightlight UL Listed Ensures safe hot water Saves the environment Makes late night We design & manufacture flows for the entire family and your wallet...
- Page 6 About Your Water Cooler Part Names 3. Cooling Indicator Light 1. Power Indicator Light 2. Heating Indicator Light 7. Room Temperature Water Push Button 6. Child Safety Lock 8. Cold Water 5. Hot Water Push Button Push Button 10. Hot Water Spout 9.
- Page 7 About Your Water Cooler Part Names 16. Cooling Switch 17. Heating Switch 15. Nightlight Switch 18. Power Cord 19. Drain Outlet 20. Condenser...
- Page 8 About Your Water Cooler Indicator Lights Power Indicator Light This light will remain on as long as the water cooler is plugged in to indicate that the cooler is on. Heating Indicator Light This light will indicate when the water is heating. The light will remain on while the water is heating and will turn off when it has reached the correct temperature of 185°F.
- Page 9 About Your Water Cooler Tech Specs Model A4BLWTRCLR Hot/Cold/Room Temp Output 1.2L/min / 1.2L/min / 1.0L/min Hot Water Capacity 4 L/H ( ≥ 185°F) Hot Tank Volume 1.16 Liters Cold Water Capacity 2.5 L/H ( ≤ 47°F) Cold Tank Volume 3.6 Liters...
- Page 10 Getting Started...
- Page 11 Getting Started Unpacking Your Avalon Water Cooler The unit has been cleaned prior to departing from the factory. To remove any dust and debris that may collect during shipping we recommend cleaning the unit prior to installation. For cleaning instructions, see pages 18-22.
- Page 12 Getting Started Installing the Water Bottle 1. Open the cabinet door. 2. Place the probe assembly on the probe hanger 3. Place a fresh bottle outside of the cabinet. 4. Remove the entire plastic cap from the top of bottle. 5.
- Page 13 Getting Started Installing the Water Bottle 6. Place the probe into the bottle. 7. Slide the collar down until it clicks into place. If you are using a 3 gallon bottle rather than a 5 gallon bottle you can adjust probe by pressing the two tabs at the head of the probe and sliding the collar down to the neck of the bottle.
- Page 14 Getting Started Installing and Removing the Drip Tray No external drain is needed, the overflow will collect here. The red float will rise to indicate when the drip tray needs to be emptied. 1. To install the drip tray, simply slide 2.
- Page 15 Getting Started Powering the Dispenser Plug cord into a properly grounded wall outlet. At this time the pump will begin to move water from the bottle to the hot and cold tanks. It will take up to 12 minutes to fill the tanks for the first time.
- Page 16 Getting Started Activate Heating and Cooling Before turning on the heating (#17) or cooling (#16) switches, ensure water is already filling inside the inner tanks by dispensing a drop of water from the hot (#10) and cold (#12) spouts. To activate the cold water, push the cooling switch (#16) into the on (I) position by pushing the top of the switch in.
- Page 17 User Guide and Maintenance...
- Page 18 User Guide and Maintenance Dispensing Water Cold Water Once you have turned the cooling switch (#16) into the on (I) position it will take initially 1 hour for the water to cool. During this time the cooling indicator light (#3) above the cold water icon will be steady.
- Page 19 User Guide and Maintenance Changing the Bottle When the empty bottle indicator light (#4) is flashing red this is an alert that your bottle is empty and will need to be replaced as soon as possible. Notice: Do not dispense hot, room temperature or cold water if the light is flashing as you could empty the tanks and cause the dispenser to overheat.
- Page 20 User Guide and Maintenance Changing the Bottle 6. Place the probe into bottle. Slide the collar 7. If you are using a 3 gallon bottle rather down until it clicks in place. Push the head than a 5 gallon bottle you can adjust probe down until tube hits the bottom of the bottle.
- Page 21 Cleaning...
- Page 22 Cleaning Rinsing, Cleaning, and Draining To prolong the lifetime of the machine, it is recommended that the unit be cleaned and sanitized manually about every six months. To clean the outside of the unit Use a disinfectant of your choice to wipe down the outside of the machine. Disinfectant does not come with this unit.
- Page 23 Cleaning Rinsing, Cleaning, and Draining 3. Pour 0.6 gallons of clean water into the 4. Place a large bucket beneath the drain cold tank. (The cold water tank is the open outlet (#19) located on the back of the unit. cylinder that the white cover was removed Remove the drain cover and allow the water from).
- Page 24 Cleaning Rinsing, Cleaning, and Draining 5. Once water is completely drained, reposition the drain cover, cold tank cover and the top cover. Ensure that the pipes and wires are connected properly and you may use the dispenser as normal.
- Page 25 Cleaning Cleaning To remove mineral deposits that may have built up inside the the cold tank, mix 4 L of water with 200 g of citric acid crystals (not included) or cleaning solution of your choice. 1. Unscrew the top cover and lift off the cold tank lid. 2.
- Page 26 Cleaning Cleaning 3. Plug in the power cord and turn on (I) 4. Turn off (O) the heating switch the heating switch (#17). Allow the water (#17) and allow the liquid mixture to to heat for 15 minutes. cool down for 20 minutes. 15 min 20 min 5.
- Page 27 Troubleshooting...
- Page 28 Troubleshooting Troubleshooting If you are having trouble with your water cooler please see the following solutions. You can also view our trouble shooting videos at the website below. Please feel free to contact us with any questions. 1-800-256-0695 support@avalonh2o.com www.avalonh2o.com...
- Page 29 Troubleshooting Troubleshooting Water is leaking in the unit Please check to see that all of the connections are tight and there are no loose tubes or connections. Water not dispensing at a hot or cold temperature This could be caused by an over consumption of water in a short period of time causing the tanks to empty.
- Page 30 Safety...
- Page 31 Safety Safety To reduce risk of injury and property damage, user must read this entire guide before assembling, installing and operating the dispenser. Failure to execute the instructions in this manual can cause personal injury or property damage. This product dispenses water at very high temperatures. Failure to use this properly can cause personal injury.
- Page 32 Safety Safety • Ensure dispenser is unplugged prior to cleaning. • Never allow children to dispense hot water without proper and direct supervision. Unplug unit to prevent unsupervised use by children. • Service should be performed only by a certified technician. •...
