Dalsa Rad-icon 1520 User Manual page 10

10
Ethernet Connector
Ethernet Connection LED
Stead y orange ind icates that an Ethernet connection is su ccessfu lly established .
Data Transmission LED
Flashing green ind icates that the d etector is transm itting or receiving d at a.
Detector Status LED
The d etector is equ ipped w ith an orange/ green LED u sed to d isplay the statu s of the
d etector‟s operation. The table below su m m arizes the operating states of the d etector and
the correspond ing LED states.
1
2
3
Power Connector
1
2
The d etector requ ires a single voltage inpu t (+10-27V / 10W). There is a protection for
m isconnection, via a resettable fu se. When the fu se has been activated (isolating), pow er
cycling w ill retu rn it to cond u ctive state again thu s restoring norm al operation (assu m ing
pow er has been properly ap plied ).
WARN IN G: When setting u p the d etector pow er su p plies follow these gu id elines:
!
Rad-icon 1520 Detector
Color Of Statu s LED
Orange
Green
Off
Power Connector
1
2
Rear View
Plug
Descrip tion
Supply voltage (+10-27V / 10W)
Ground
Shield ing (chassis)
Meaning
Pow er applied , Stand by m od e
Detector is operational
N o pow er
Pin 1 indicator
Teledyne DALSA
