- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. DELONGHI PACAN140HPEWKC1A Owner's Manual Shop genuine replacement parts for DELONGHI PACAN140HPEWKC1A Find Your DELONGHI Air Conditioner Parts - Select From 155 Models -------- Manual continues below --------...
- Page 2 Important safeguard • The unit should be transported in a vertical position. If this is not possible secure the unit at • Use this appliance only as described in this an angle, do not lie it horizontally. instruction manual. • Before transporting the unit, drain the unit. As with any electrical appliance, the instructions After transportation, wait at least 6 hours before aim to cover as many situations as possible. switching the unit on.
- Page 3 INTRODUCTION Thank you for choosing a De’Longhi product. Please take a few AIR CONDITIONING WITHOUT INSTALLATION moments to read the instructions to avoid risks or damage to the For optimal results set-up in a double-hung window: appliance. 1) Place the bracket in the window sill, extend the bracket DESCRIPTION fully within the window frame, fix the bracket by using the pin then lower the window onto the bracket. (Should the Description of the appliance (see page 3 - A) window bracket be too large for the window. The plastic A1 air outlet grille can be cut with a saw by a qualified professional.) A2 control panel...
- Page 4 1-800-322-3848 [US only] using suitable 1-888-335-6644 [Canada only] insulation. 01-800-711-8805 (Mexico only] or log onto our website at www.delonghi.com As special tools are required for installation, we suggest you have the appliance installed by specialized person- nel. • Fit the wall flange B1 into the hole. • Fit the air exhaust hose B2 in the relevant housing located on the rear side of the appliance. (fig. 1). • Fit the end of the hose B2 to the wall flange B1 as shown in...
- Page 5 When the hose B2 is not connected, the drilled hole can be closed with the flange cap B1. MAX 39 in NOTE: When installing the air conditioner semi-permanently, you should leave a door slightly open little as 1/2“ (1 cm) to guarantee correct ventilation and room pressure. NOTE: Keep the air hoses as short and free of curves as possible to avoid constrictions. MIN 14 in CONTROL PANEL C11 C12 DESCRIPTION OF THE CONTROL PANEL (C) C1 ON/STAND-BY button C13 Heating symbol C2 MODE selection button (conditioning, dehumidifying, fan,...
- Page 6 OPERATING FROM THE CONTROL PANEL HIGH TURNING THE APPLIANCE ON/OFF Operating curve HIGH MEDIUM Before plugging the appliance check the cap on back of the unit are correctly inserted on drainage hose A10 Plug the appliance into the mains. Two lines appear on the dis- TEMPERATURE play indicating that the appliance is in stand-by and the buttons and light on. Touch button (C1) to switch the appliance on. When turned on, the air conditioner starts operating in the same REAL FEEL light (C9) changes color when approaching the best mode as when it was turned off.
- Page 7 You can choose: • Select the fan speed by pressing the button (C6). Minimum speed: for silent operation. You can choose: Medium speed: reduces noise levels while main- Minimum speed: for silent operation. taining a comfortable temperature. Medium speed: reduces noise levels but still main- Maximum speed: to achieve the target tempera- tains a good level of comfort. ture as rapidly as possible. Maximum speed: for maximum fan power. the appliance automatically selects the most suitable fan speed in relation to the temperature set on the HEATING MODE digital display and current room temperature. The most suitable temperature for the room during the summer varies from 75°F to 81°F (24 to 27°C).
- Page 8 SETTING THE TIMER DESCRIPTION OF THE REMOTE CONTROL (D) D1) ON/STAND-BY button D2) Increase/decrease temperature/programmed operation D3) “ MODE” selection button D4) Fan speed selection button ( D5) REAL FEEL selection button The timer can be used to delay appliance start up or shutdown. D6) WHISPER COOL selection button This avoids wasting electricity by not operating the appliance D7) Switch button °C/°F when it is not needed. D8) TIMER button How to program delayed start up •...
- Page 9 TURNING THE APPLIANCE ON ing the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following • Plug into the outlet. measures: • Press the button (D1) (when turned on, the air con- - Reorient or relocate the receiving antenna. ditioner starts operating in the same mode as when it was - Increase the separation between the equipment and turned off) . receiver. • To switch the appliance off, press button (D1) , then - Connect the equipment into an outlet on a circuit differ- remove the plug. ent from that to which the receiver is connected. NOTE: Never switch the appliance off by removing the plug. - Consult the dealer or an experienced radio/TV technician Always switch it off by pushing on the button and...
- Page 10 TIPS FOR CORRECT USE CLEANING To ensure optimal results from your air conditioner, follow these Before cleaning or maintenance, turn the appliance off by recommendations: touching the button, then unplug from the outlet. • close the windows and doors in the room to be air condi- tioned When installing the air conditioner semi-perma- CLEANING THE CABINET nently, you should leave a door slightly open (as little as You should clean the appliance with a slightly damp cloth then 0.39 inch. (1 cm)) to guarantee proper ventilation. dry with a dry cloth. For safety reasons, never wash the air con- ditioner with water. Precautions Never use petrol, alcohol or solvents to clean the appliance. Never spray insecticide liquids or similar.
- Page 11 END OF SEASON OPERATIONS sure proper function. Without allowing the unit this time (6-24 To drain all water from the circuit, remove the external cap by hours) the unit may function for only a short time, and then the unscrewing it in the anticlockwise direction then, remove the compressor will break down from lack of oil. internal cap from the drainage on the back of the appliance and ELECTRICAL CONNECTION allow the water to drain out into a basin (fig. 13). In order to properly storage the appliance at the end of the sea- This appliance is equipped with a 3 prong grounded plug. The son, we suggest you cover it with the supplied end of season plug must be connected into an outlet that is properly installed dust cover B9 and you put the accessories in the relevant and grounded in the accordance with all local codes and ordi- end of season accessories bag B10. nances. Do not modify the plug provided with the appliance. If it will not fit the outlet, have a proper outlet installed by a qualified electrician or relocate the unit to a proper outlet. If the household electrical supply does not meet the above specifica- tions, or if you are not sure your home has an effective electrical ground, have a qualified electrician or your local electrical utility...
- Page 12 TROUBLESHOOTING PROBLEM CAUSE SOLUTION The air conditioner does not come on it is not plugged into the outlet plug into the outlet there is no current wait the internal safety device has tripped call the Service Center The air conditioner works for a short there are bends or kinks in the air position the air hose correctly, keeping it time only exhaust hose as short and free of curves as possible to avoid bottleneck something is preventing the air from check and remove any obstacles being discharged obstructing air discharge The air conditioner works, but does not windows, doors and/or curtains open close doors, windows and curtains, cool the room bearing in mind the “ TIPS FOR CORRECT USE” given above there are heat sources in the room (oven, eliminate the heat sources hairdryer, etc the air exhaust hose is detached from fit the air exhaust hose in the housing at the appliance the back of the appliance (fig. 1). dust filters clogged clean or replace the filters as described above the technical specification of the appliance is not adequate for the room in which it is located.
- Page 13 If repairs become necessary, see contact information below: U.S. Residents: Please contact our toll free hotline at 1-800-322-3848 or log onto our website at www.delonghi.com CANADA Residents: Please contact our toll free hotline at 1-888-335-6644 or log onto our website at www.delonghi.com MEXICO Residents: Please contact our toll free hotline at 01-800-711-8805 or log onto our website at www.delonghi.com The above warranty is in lieu of all other express warranties and representations. All implied warranties are limited to the applicable warranty period set forth above. This limitation does not apply if you enter into an extended warranty with De’Longhi. Some states/countries do not allow limitations on how long an implied warranty lasts, so the above exclusions may not apply to you. De’Longhi does not authorize any other person or company to assume for it any liability in...
