3
• If you have a casement window (figure 4) follow steps 2 &
3 and place the window outlet B7 outside the window to
exhaust the hot air.
4
For help with installation, operation, and for all
accessories and spare/replacement parts, please contact
our toll free customer service call center at:
1-800-322-3848 [US only]
1-888-335-6644 [Canada only]
01-800-711-8805 (Mexico only]
or log onto our website at www.delonghi.com
SEMI-PERMANENT INSTALLATION
If required, your appliance can also be installed semi-perma-
nently (Fig. 5).
5
min. 11,8 in
min. 30cm
Proceed as follows:
• Drill a hole ø 5,25 inches (134 mm) in an outside wall or
through a window pane. Respect the dimensions and
height of the hole given in figure 6 and 7.
6
in the in the wooden
window kickboard
panel of a French
window
As special tools are required for installation, we suggest
you have the appliance installed by specialized person-
nel.
• Fit the wall flange B1 into the hole.
• Fit the air exhaust hose B2 in the relevant housing located
on the rear side of the appliance. (fig. 1).
• Fit the end of the hose B2 to the wall flange B1 as shown in
fig. 7.
6
min. 11,8 in
min. 30cm
in the wall:
you are
recommended
to insulate the
section of wall
using suitable
insulation.
