- Page 1 Installation manual for BCA series BCA12N63 K01-0000775-00...
- Page 2 1 set Breaker Screw 4 pcs Screw 10 pcs M5(for ground) 1 pcs Transparent plate 6 pcs Label Ground / Breaker / Name 1 pcs of each Snap bushing 4 pcs Copyright © Cyber Power Systems, Inc. All rights reserved. WWW.CYBERPOWER.COM...
- Page 3 Procedure Step 1. Fixed the breaker on the breaker holder. Step 2. Buckle the first bracket between the front and rear panels. Copyright © Cyber Power Systems, Inc. All rights reserved. WWW.CYBERPOWER.COM...
- Page 4 Step 3. Fixed the breaker holder on the rear panel (M3 screw*4pcs). Step4 . Please follow the pictures to connect and install batteries. (Cable L1 & L2) 8pcs battery package Left view Right view 4pcs battery package Left view Right view Copyright © Cyber Power Systems, Inc. All rights reserved. WWW.CYBERPOWER.COM...
- Page 5 Step 5. Put the batteries and transparent plates on the bracket then connect the cables.(Transparent plate*3pcs / Battery*20pcs / Cable:L1*15pcs / L2*2pcs / L3*2pcs) Step 6. Connect the cable from breaker(+) to battery 1(+). Copyright © Cyber Power Systems, Inc. All rights reserved. WWW.CYBERPOWER.COM...
- Page 6 Step 7. Buckle the second bracket between the panels. Step 8. Put the batteries and transparent plates on the bracket then connect the cables. (Transparent plate*3pcs/Battery*20pcs/Cable:L1*15pcs/L2*2pcs/L3*2pcs) Copyright © Cyber Power Systems, Inc. All rights reserved. WWW.CYBERPOWER.COM...
- Page 7 Step 9. Connect the cables from breaker to battery. L5: From breaker(N) to battery37(+) L6: From battery37(+) to battery20(-) L7: From breaker(-) to battery24(-) Step 10. Paste the ground label on the cover and tighten the nut(M5 nut*1pcs). Copyright © Cyber Power Systems, Inc. All rights reserved. WWW.CYBERPOWER.COM...
- Page 8 Please let the cables through the snap bushings and connect with breaker when you want to connect battery cabinet from UPS. Step 12. Put on the side panels (from bottom to top). Copyright © Cyber Power Systems, Inc. All rights reserved. WWW.CYBERPOWER.COM...
- Page 9 Step 13. Put on the top panel and tighten the screw(M3 screw*1pcs). Step 14. Fixed the breaker cover and paste the label (M3 screw*4pcs). Copyright © Cyber Power Systems, Inc. All rights reserved. WWW.CYBERPOWER.COM...
