- Page 1 User’s Manual BATTERY PACK BPE36V60AS BPE72V60AS Cyber Power Systems, Inc. www.cyberpower.com K01-0000359-00...
- Page 2 OVERVIEW The CyberPower Battery packs (BPE36V60AS / BPE72V60AS) support 60A polarized plugs, and are designed for variety of CyberPower UPS systems. When combining with the UPS, the Battery pack provides extended runtime with a 36VDC/72VDC external connection. Additional parallel-connected Battery packs provide the UPS for a longer extended runtime operation.
- Page 3 Use this output cable to connect the Battery pack to the UPS or to the qualified personnel. next Battery pack. 2. Input Connector Use this input connector to daisy chain the next Battery pack. Remove the connector cover for access. BPE36V60AS BPE72V60AS Copyright © 2014 Cyber Power Systems, Inc.
- Page 4 BASIC OPERATION CONNECTION #1 : UPS WITH ONE BATTERY PACK Step 1: Loosen the two screws to remove the battery cable retention bracket of the UPS. Step 2: Use the output cable of the Battery pack to connect the Battery pack to the UPS. Step 3: Rotate the battery cable retention bracket and tighten the two screws to fix battery cable.
- Page 5 Only use replacement batteries which are certified by Battery Disposal CyberPower Systems. Use of incorrect battery type is an electrical Batteries are considered hazardous waste and must be disposed of hazard that could lead to explosion, fire, electric shock, or short circuit.
-
Page 6: Trouble Shooting
Over Charge Battery is overcharged. charger voltage. Charger Failure Charger has failed. 2. Contact CyberPower for repair. Cyber Power Systems, Inc. www.cyberpower.com © Entire contents copyright 2014 Cyber Power Systems, Inc., All rights reserved. Reproduction in whole or in ®...
