CORE HEALTH & FITNESS
MPower™ Echelon2 Console
MPower™ Echelon2 Power Upgrade
MPower™ Echelon2 External Wiring Kit
ASSEMBLY
MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the MPower Echelon2 and is the answer not in the manual?

Questions and answers

Related Manuals for Schwinn MPower Echelon2

Summary of Contents for Schwinn MPower Echelon2

  • Page 1 CORE HEALTH & FITNESS MPower™ Echelon2 Console MPower™ Echelon2 Power Upgrade MPower™ Echelon2 External Wiring Kit ASSEMBLY MANUAL...
  • Page 2 TABLE OF CONTENTS TABLE OF CONTENTS ........................1 IMPORTANT SAFETY INSTRUCTIONS ........................2 COMPLIANCE AND CERTIFICATIONS ............3 ASSEMBLY ........................4 REQUIRED TOOLS ..............4 PROCEDURE ..............6 Installing the Echelon2 with the Speed Sensor, Power Sensor, & External Wiring Kit Installing the Echelon2 with the Speed Sensor & External Wiring Kit CALIBRATION ..............
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS WARNING! Before using this product, it is essential to read the ENTIRE Owner’s Manual and ALL installation instructions. The Owner’s Manual describes equipment operation and instructs members on how to use correctly and safely. Read all warnings posted on the machine. Health related injuries may result from incorrect or excessive use of exercise equipment.
  • Page 4 COMPLIANCE AND CERTIFICATIONS FCC Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide a reasonable protection against harmful interference in a residential installation.
  • Page 5 ASSEMBLY REQUIRED TOOLS Required Tools: • #2 Phillips Screwdriver • 2.5mm Allen Key • 3mm Allen Key Parts Included In the Box Description 740-8875_001 EXTERNAL CABLE COVER ASSY 740-8875_005 CABLE CLAMP 740-8875_006 POWER SENSOR UPGRAGE PACKAGING Fig. 3 740-8875 Shown Description 637-4400 INSTALLATION POINTS, ECHELON 2 UPGRADE...
  • Page 6 Fig. 5 740-8875 Shown Description 110-3561 MANUAL, INSTALLATION, MPower Echelon2 Console 110-3640 MANUAL, OWNERS, MPower ECHelon2 Console 110-3642 RJ45 2-PIN LONG CABLE 110-3643 SRB MOUNT, M POWER Q 140-3585 COSMETIC CAP ASSY 620-8310 BATTERY, C CELL 620-8327 MOUNT, M POWER Q 740-8727-016 SCREW, M5x0.8, 16mm, PHM, PH, SS, BO...
  • Page 7 If you are upgrading to the Echelon2 from a previous version of console, refer to the Schwinn MPower Echelon2 Installation. This page does not apply if using 4iiii power input, please refer to the 4iiii installation Instructions on our support site at https://support.corehandf.com/620-8543...
  • Page 8 110-3640 740-8927 740-8929 Loosen pop pin and slide 110-3561 handlebar forward to maximum extension, then re-tighten pop pin. Secure console mount 740- 8929 to handlebar with three screws 110-3640 Fig. 8 Secure cover 740-8927 to console mount with one screw 110-3561.
  • Page 9 12. Plug the console cable 740- 8931 RJ45 connector into the 740-8930 console then slide the grommet of the cable into the slot on the 110-3642 connector protective cap 740- 740-8931 8930 as shown (Fig. 10 inset). 13. Secure protective cap to console with two screws 110-3642 Fig.
  • Page 10 16. If routing wire outside, prior to installing the upper conduit, CLEAN POST clean head tube with isopropyl PRIOR TO USING ADHESIVE alcohol and allow to air dry. 17. Peel the non-stick strip off the cable cover base. 18. Attach the base aligned to 3M VHB TAPE, 1"...
  • Page 11 23. Verify the updated bolt & magnet are installed on the bike as shown in Fig. 14 inset. (Serials after XXXXXXDAY1642XXXX) Note: For older serials, refer to CSB 637-4413 Fig. 14 24. Plug console cable (blue) into the RJ45 connector at the front of the sensor, and the RPM cable (yellow) into the 2-pin connector on the underside of the power...
  • Page 12 25. Attach sensor case to the resistance mechanism using three screws 110-3644. Use blue thread lock on the screws to ensure the sensor mounts fully. Note: Be sure that sensor case sits tight against the black plate of the resistance mechanism. All wires must be contained within the sensor cover and not protrude from the sensor cover,...
  • Page 13 3.00 mm Fig. 18 31. Position the RPM sensor as shown and reinstall the two chain guard screws. The RPM sensor should be appx. 2-3mm away from the flywheel, or about the width of a credit card. If the RPM sensor is too close, it will rub against the sensor magnet that is embedded in the flywheel. If the RPM sensor is too far away, the sensor will intermittently pick up a signal from the magnet or will not pick up any signal at all;...
  • Page 14 AC™ SPORT & AC™ PERFORMANCE Installing the Echelon2 with the Speed Sensor & External Wiring Kit 110-3640 Insert batteries into console following the pattern in the case. 740-8927 (See Fig. 7 on page 6). 740-8929 CAUTION: There is risk of 110-3561 explosion if the battery is replaced with an incorrect type.
  • Page 15 Plug the console cable 740- 8928 RJ45 connector into the console then slide the grommet of the cable into the slot on the connector protective cap 740- 8930 as shown (Fig. 10 inset). Secure protective cap to console with two screws 110-3642 740-8930 Remove the screw 110-3686 110-3642...
  • Page 16 15. Remove the RPM sensor from the box and disassemble. DISCARD Discard the adapter plate (Fig. 24 blue) which is not used on 110-3643 this model bike. Do not discard screw 110-3643. 902-5550 16. Plug the RPM sensor cable 2-pin connector into the RPM sensor connector.
  • Page 17 21. Prior to applying the lower conduit, clean the surface of the inner right fork with isopropyl alcohol and allow to air dry. 22. Peel the non-stick strip off the cable cover base. 23. Attach the base firmly on the inside of the right hand fork. There should be about one inch gap between chain guard/ rpm sensor bracket and the wire conduit.
  • Page 18 CALIBRATION Turn on console. Press and hold STAGE “AVG/MAX” for 3-5 seconds to access the service menu. (See Fig. 27) Once in the service menu, use the AVG/MAX button to scroll to the CALIBRATE menu. Press and release the LIGHT button to enter the menu.
  • Page 19 Turn the brake knob clockwise until the brake mechanism makes contact with the calibration tool and press the LIGHT button. CAUTION: Do not over-tighten. Fig. 29 The console will display that the Zeropoint is now set. Press the LIGHT button to exit CALIBRATE ZEROPOINT.
  • Page 20 If the passcode is set, enter the passcode to access. The passcode is a 3-digit number assigned by Schwinn and cannot be changed. Contact Schwinn support to obtain the passcode. To enter the passcode, use the or AVG/MAX buttons to scroll to the desired number, then press the button to accept the number and advance to the next number.
  • Page 21 The menu maps shown below apply to firmware version 1.7 or later. If your console has an older version of firmware, Schwinn recommends upgrading to the latest version of firmware. The latest version can be downloaded from the Schwinn Support website at https://support.corehandf.com/Software/ Instructions for updating firmware are found at https://service.corehandf.com/637-4296 or can be viewed on...
  • Page 22 Calibration Menu - 4iiii • Zero Reset: Spin crank then push Left crank to 6 O’Clock Push to set • Power Adjust: Fig. 33 System Menu • System Summary Software Revision Hours • System Reset • System Load FW • System Serial Number Fig.
  • Page 23 PAIRING AND CALIBRATING THE 4IIII POWERMETER Press and hold STAGE and “AVG/MAX” for 3-5 seconds to access the service menu. Use AVG/MAX to scroll until SENSOR TYPE is displayed then push the back-light button to access the sensor menu. Ensure that “4iiii” is displayed as the sensor type. If the sensor type is set to “Echelon 2”...
  • Page 24 MAINTENANCE MAINTENANCE SCHEDULE With durable, high performance components, this equipment is designed for heavy usage with minimal mainte- nance required. To keep it in top condition, perform regular daily, weekly and monthly preventive maintenance routines outlined below. Daily Weekly Monthly Bi-Annually General Maintenance Inspect each console, sensor, and cables for loose...
  • Page 25 CHANGING THE BATTERIES To change the batteries in the Echelon2 console, you will need the following tools: • 2.5 mm hex (allen) wrench • Philips screwdriver To change the batteries, do the following: 1. Remove the two hex head screws that hold the connector protective cap in place and remove the cap.
  • Page 26 SUPPORT & SERVICE CORE CONNECT Core Connect is your portal to all things service! Whether you need to order parts or register your warranty, Core Connect is the most effective way to get what you need fast and keep your facility operating smoothly. OFFERS 24-HOUR SELF SERVICE ACCESS TO: •...
  • Page 27 THIS PAGE INTENTIONALLY BLANK Page 26...
  • Page 28 PART NUMBER 620-8327, REV I All rights reserved. Star Trac, the Star Trac logo and StairMaster are registered trademarks of Core Health & Fitness, LLC. Schwinn and Nautilus are registered trademarks of Nautilus Inc. used under license to Core Health & Fitness LLC. Throwdown is a registered trademark of Throwdown Industries, LLC.
