Core Health & Fitness
MPower™ Echelon2G Console
ASSEMBLY
MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the MPower Echelon2G Console and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Schwinn MPower Echelon2G Console

Summary of Contents for Schwinn MPower Echelon2G Console

  • Page 1 Core Health & Fitness MPower™ Echelon2G Console ASSEMBLY MANUAL...
  • Page 2 Echelon2G Assembly Manual Applies to: Echelon2G Required Tools: • #2 Phillips Screwdriver • 2.5mm Allen Key Identify which handlebar style is present on the bike. If the handlebars are the Performance-style (pictured right), please proceed to Page 2 - Step 1.
  • Page 3 Use a #2 phillips screwdriver to secure the con- sole bracket to the handlebars using three (3) pieces of the M4 x 10mm screws. Slide the console onto the console bracket, then secure the console to the bracket using one (1) piece of the M3 x 6mm screw.
  • Page 4 Attach the console bracket cover to the console bracket using one (1) piece of the M5 x 16mm screw. Open the 4iiii Powermeter battery compartment on the user left side crank arm using a #2 phillips screwdriver, then install the two AA batteries. After completing this step, please proceed to Page 6 - Step 1.
  • Page 5 Use a 2.5mm allen key to secure the console bracket to the handlebars using four (4) pieces of the M4 x 14mm screws. Use a #2 phillips screwdriver to secure the brack- et cover to the bracket using one (1) piece of the M5 x 16mm screw.
  • Page 6 Plug the console data cable into the back of the console, insert the strain relief grommet into the strain relief cover, then use a 2.5mm allen key to attach the strain relief cover to the console brack- et using two (2) pieces of the M3 x 12mm screws. NOTE: Ensure that the hole for the data cable is fac- ing upwards, otherwise the data cable will interfere with installation of the console bracket cover.
  • Page 7 Ensure that the 4iiii crank is up to date. To do this, heck that Bluetooth is enabled on the phone then follow the proceeding directions. Download the 4iiii app from the app store BUT Android DO NOT CREATE A LOGIN. Record the ANT+ ID of the powermeter that needs to be updated.
  • Page 8 Open the 4iiii app and select the “Profi le” menu in the upper left corner of the main screen then select “PRECISCION Confi guration” Spin the 4iiii crank arm of the target bike >30 RPM; the 2-5 digit ANT+ ID should show up on the “Select your Powermeter”...
  • Page 9 On the next screen, a fi rmware update prompt should appear if newer fi rmware is available. Select “Upgrade” to begin the update. The update procedure will now run. This may take several minutes to complete. Page 8...
  • Page 10 Once the update is complete, select “Continue. ” Enable the “3rd Party Apps” option. Select “Forget” to disconnect from this poweme- ter once the fi rmware has been updated. On the Echelon2G console, press and hold STAGE and “AVG/MAX” for 3-5 seconds to access the service menu.
  • Page 11 If the sensor type is set to “Echelon 2” press the back-light button to select the sensor type, use the AVG/MAX button to select “4iiii” then press the back-light button again. Once “4iiii” is selected the console will enter the pairing process, check the side of the power sen- sor for a 4 OR* 5-digit ANT+ ID code.
  • Page 12 © 2018 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8594, REV D...
