Schwinn Echelon2 Install Instructions

+ 4iiii powermeter

Hide thumbs Also See for Echelon2:

Download this manual

Echelon2 + 4iiii Powermeter

INSTALL INSTRUCTIONS

AC Performance: If the handlebar style present

on the bike is the AC Performance-style handle-

bars (pictured above), proceed to Page 1, Step 1.

STEP 2: Install the two (2) C-type batteries into the

Echelon2 console.

Document # 620-8634 Rev. A

SC5/SC7: If the handlebar style present on the bike

is the SC5/SC7-style handlebars (pictured above),

proceed to Page 2, Step 1.

STEP 3: Slide the console onto the console

bracket, then secure the console to the bracket

using one (1) piece of the M3 x 6mm screw.

For Installation assistance or missing parts, please call CORE Health & Fitness at 1(800) 503-1221

AC Sport: If the handlebar style present on the

bike is the AC Sport-style handlebars (pictured

above), proceed to Page 3, Step 1.

STEP 4: Use a 2.5mm allen key to attach the rear

cover to the console bracket using two (2) pieces of the

M3 x 12mm screws.

STEP 1: Use a #2 phillips screwdriver to secure

the console bracket to the handlebars using three

(3) pieces of the M4 x 10mm screws.

STEP 5: Attach the console bracket cover to the console

bracket using one (1) piece of the M5 x 16mm screw.

After completing this step, please proceed to Page 4,

Step 1.

PAGE 1 OF 4

Page 1 Echelon2 + 4iiii Powermeter INSTALL INSTRUCTIONS AC Performance: If the handlebar style present SC5/SC7: If the handlebar style present on the bike AC Sport: If the handlebar style present on the STEP 1: Use a #2 phillips screwdriver to secure...
Page 2 Echelon2 + 4iiii Powermeter INSTALL INSTRUCTIONS STEP 2: Use a #2 phillips screwdriver to secure the STEP 1: Use a 2.5mm allen key to secure the console bracket cover to the bracket using one (1) piece of the bracket to the handlebars using four (4) pieces of the M4 x M5 x 16mm screw.
Page 3 Echelon2 + 4iiii Powermeter INSTALL INSTRUCTIONS STEP 4: Use a 2.5mm allen key to attach the rear STEP 3:Slide the console onto the console bracket, STEP 1: Install the console bracket onto the underside of STEP 2: Install the two (2) C-type batteries into the...
Page 4 Echelon2 + 4iiii PAIRING + CALIBRATING 4iiii POWERMETER REQUIRED TOOLS: • Torque Wrench • 8mm Allen Key Socket • Rubber Mallet • Small Phillips Screwdriver 4. Press and hold STAGE and “AVG/MAX” for 3-5 seconds to access the service menu.
