- Page 1 CORE HEALTH & FITNESS MPower™ Echelon2 Console MPower™ Echelon2 Power Upgrade MPower™ Echelon2 External Wiring Kit OWNER'S MANUAL...
- Page 2 TABLE OF CONTENTS TABLE OF CONTENTS ........................1 IMPORTANT SAFETY INSTRUCTIONS ........................2 COMPLIANCE AND CERTIFICATIONS ............3 ASSEMBLY ........................4 REQUIRED TOOLS ..............4 ECHELON 2 ........................6 CONSOLE FEATURES ..............6 CONSOLE OPERATION ..............8 DETAILED DESCRIPTION OF RIDE METRICS ..........11 EXPECTATIONS FOR AVERAGE POWER, CALORIES, AND DISTANCE ...
- Page 3 IMPORTANT SAFETY INSTRUCTIONS WARNING! Before using this product, it is essential to read the ENTIRE Owner’s Manual and ALL installation instructions. The Owner’s Manual describes equipment operation and instructs members on how to use correctly and safely. Read all warnings posted on the machine. Health related injuries may result from incorrect or excessive use of exercise equipment.
- Page 4 COMPLIANCE AND CERTIFICATIONS FCC Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide a reasonable protection against harmful interference in a residential installation.
- Page 5 ASSEMBLY REQUIRED TOOLS Required Tools: • #2 Phillips Screwdriver • 2.5mm Allen Key • 3mm Allen Key Parts Included In the Box Description 740-8875_001 EXTERNAL CABLE COVER ASSY 740-8875_005 CABLE CLAMP 740-8875_006 POWER SENSOR UPGRAGE PACKAGING Fig. 3 740-8875 Shown Description 637-4400 INSTALLATION POINTS, ECHELON 2 UPGRADE...
- Page 6 Fig. 5 740-8875 Shown Description 110-3561 MANUAL, INSTALLATION, MPower Echelon2 Console 110-3640 MANUAL, OWNERS, MPower ECHelon2 Console 110-3642 RJ45 2-PIN LONG CABLE 110-3643 SRB MOUNT, M POWER Q 140-3585 COSMETIC CAP ASSY 620-8310 BATTERY, C CELL 620-8327 MOUNT, M POWER Q 740-8727-016 SCREW, M5x0.8, 16mm, PHM, PH, SS, BO...
- Page 7 ECHELON 2 CONSOLE FEATURES Fig. 6 The Echelon2 provides riders with real-time user metrics that can be used to improve the current and future workouts. Watts, time, kcal, distance, RPMs, speed, distance, and heartrate are displayed on an intuitive display that allows for ease of use during high intensity rides.
- Page 8 Fig. 7 Echelon 2 Display Features Description Function Power Rider’s instantaneous power measured in watts. Rider’s instantaneous RPM (aka. cadence), or rotations per minute of the crank arm. Rider’s heart rate in beats per minute (BPM) when paired with a compatible Heart Rate heart rate monitor.
- Page 9 CONSOLE OPERATION Before Beginning a Ride • If you want to record ride data onto a USB stick, insert a FAT32 formatted USB 2.0 or later stick into the USB drive before powering up the console. NOTE: If the USB stick is not 2.0 or later and formatted with the FAT32 format, it may not record data. •...
- Page 10 Pairing a Compatible Sport Watch • Some versions of sport watches can be paired to the Echelon2 console to record and store data. • To determine if your device is compatible, check the product directory at https:// www.thisisant.com/directory/mpower-Echelon2-cosole/ to verify your device is compatible.
- Page 11 • The numbers on the screen will flash. • The timers will continue timing—including the Total and Stage timers—for 5 minutes. Schwinn added this functionality to allow instructors to get off the bike and coach off the bike while trusting their timers will remain in sync with all the riders in the room.
- Page 12 • Proper calibration of the power sensor is crucial to achieving a high level of accuracy. • Magnet gap is set at the factory, but Schwinn recommends checking magnet gap to ensure it is properly set. • Instructions for checking magnet gap and calibration the power sensor can be found on the Schwinn Equipment support website at http://support.corehandf.com/637-4458...
- Page 13 For use with the 4iiii sensor type: • Power is a direct measurement from the 4iii Powermeter via crank strain • 4iiii validated the power accuracy in-house; margin of error is generally ±1.5%. • Proper calibration of the powermeter via 4iiii app is crucial to achieving a high level of accuracy. •...
- Page 14 Therefore, values for AVERAGE POWER and distance should not be compared to outdoor riding; rather they should be used as standalone performance parameters for training on a Schwinn indoor bike equipped with an Echelon2 console and power sensor.
- Page 15 If the passcode is set, enter the passcode to access. The passcode is a 3-digit number assigned by Schwinn and cannot be changed. Contact Schwinn support to obtain the passcode. To enter the passcode, use the or AVG/MAX buttons to scroll to the desired number, then press the button to accept the number and advance to the next number.
- Page 16 The menu maps shown below apply to firmware version 1.7 or later. If your console has an older version of firmware, Schwinn recommends upgrading to the latest version of firmware. The latest version can be downloaded from the Schwinn Support website at https://support.corehandf.com/Software/ Instructions for updating firmware are found at https://service.corehandf.com/637-4296 or can be viewed on...
- Page 17 Calibration Menu - 4iiii • Zero Reset: Spin crank then push Left crank to 6 O’Clock Push to set • Power Adjust: Fig. 13 System Menu • System Summary Software Revision Hours • System Reset • System Load FW • System Serial Number Fig.
- Page 18 PAIRING AND CALIBRATING THE 4IIII POWERMETER Press and hold STAGE and “AVG/MAX” for 3-5 seconds to access the service menu. Use AVG/MAX to scroll until SENSOR TYPE is displayed then push the back-light button to access the sensor menu. Ensure that “4iiii” is displayed as the sensor type. If the sensor type is set to “Echelon 2”...
- Page 19 • Refer to the Echelon2 Installation Guide for details on how to properly position the RPM sensor • Also check cables and connectors to ensure there is no damage. • If none of these measures correct the issue, contact Schwinn customer support. Why am I getting abnormally low or power readings even at high resistance? •...
- Page 20 • In the rare case of a console display freezing, simply remove and reinstall the batteries—in most cases this solves the problem • Refer to the instructions on removing batteries. • If the problem persists, contact Schwinn customer support. Help!!! I read all the troubleshooting information but still have questions or issues. How can I get additional help or answers? •...
- Page 21 MAINTENANCE MAINTENANCE SCHEDULE With durable, high performance components, this equipment is designed for heavy usage with minimal mainte- nance required. To keep it in top condition, perform regular daily, weekly and monthly preventive maintenance routines outlined below. Daily Weekly Monthly Bi-Annually General Maintenance Inspect each console, sensor, and cables for loose...
- Page 22 CHANGING THE BATTERIES To change the batteries in the Echelon2 console, you will need the following tools: • 2.5 mm hex (allen) wrench • Philips screwdriver To change the batteries, do the following: 1. Remove the two hex head screws that hold the connector protective cap in place and remove the cap.
- Page 23 SUPPORT & SERVICE CORE CONNECT Core Connect is your portal to all things service! Whether you need to order parts or register your warranty, Core Connect is the most effective way to get what you need fast and keep your facility operating smoothly. OFFERS 24-HOUR SELF SERVICE ACCESS TO: •...
- Page 24 PART NUMBER 620-8310, REV I All rights reserved. Star Trac, the Star Trac logo and StairMaster are registered trademarks of Core Health & Fitness, LLC. Schwinn and Nautilus are registered trademarks of Nautilus Inc. used under license to Core Health & Fitness LLC. Throwdown is a registered trademark of Throwdown Industries, LLC.
