The Catch Pro sensors are compatible with the following versions of Marport's software and
equipment.
Mosa2
Scala2
Mx receiver firmware
Dock
Uplink frequency 30 to 60 kHz
Range to vessel up to 2500 m
Depth range up to 1800 m
Data update rate
Catch full: 20 sec. - Catch empty: 30 sec. - Depth: 3-8 sec. - Temp: 3-16 sec. -
Pitch & roll: 5-14 sec.
Pitch angle ±90°
Roll angle
±90° (±180° for catch twister)
Pitch & roll accuracy ±0.1°
Depth resolution 0.1 m with 0.1% accuracy
Temp measurement -5° C to +25° C
range
Temp accuracy ±0.1° C
Typical battery life Up to 740 hours
Charging time 6-8 hours
Battery type Lithium-Ion
Weight in air 5 kg
Description
System Compatibility
02.13.03 or later
02.14.00 or later
08.06.00 or later
01.02.00 or later
Technical Specifications
Catch Sensor
1
2
3
