Marport PRO User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Marport PRO

Summary of Contents for Marport PRO

  • Page 2 Connecting the Sensor to Mosa2 Battery Information About the Virtual Water Switch Option Installation Diagnostic Information Installing the Speed Sensors on the Configuring the Trawl Node Trawl Configuring the Uplink Signal Configuring the Telegrams Speed Explorer Pro Specific Settings Sounding Modes...
  • Page 3 Contents | iii Maintenance and Troubleshooting Charging the Sensor with the Dock Cleaning the Sensor Maintenance Checklist Troubleshooting Warning icon on the Dock charger plug Mosa2 does not open due to error message Sensor does not connect correctly with Mosa2 when using the Configuration Cable The sensor is not running when testing out of water...
  • Page 4 Marport is a division of Airmar Technology Corporation. Disclaimer Marport endeavors to ensure that all information in this document is correct and fairly stated, but does not accept liability for any errors or omissions. The present user guide is applicable for the following versions: •...
  • Page 5 Get a basic knowledge of the sensor. Introduction The Speed Pro sensors are part of Marport’s latest generation of sensors, featuring significant upgrades from earlier models. These enhancements include compatibility with the latest Mosa2 and Scala2 software features, with the Dock smart charger, and higher-definition echogram images.
  • Page 6 Install and use this product in accordance with this user manual. Incorrect use of the product may cause damage to the components or void the warranty. Notice: Do not open the sensor bottle. Only qualified Marport technicians can do maintenance and repairs on internal components of the sensors.
  • Page 7 Grid sensor display 1. Control the angle of the grid (45°). / 2. Check the water flow to know if the grid is blocked. Speed Explorer display Speed Pro Sensors | V1 | Introduction and Presentation...
  • Page 8 2. Control the speed of the water along the trawl, and adjust your speed according to the currents. Description System Compatibility The Speed Pro sensors are compatible with the following versions of Marport's software and equipment. Mosa2 02.13.03 or later Scala2 02.14.00 or later...
  • Page 9 13 kg cage) in water Weight of Grid sensor and protection cage in 19 kg Weight of Grid sensor and protection cage in 11.3 kg water Warranty 2 years (Sensor & Battery) Speed Pro Sensors | V1 | Introduction and Presentation...
  • Page 10 2 years (Sensor & Battery) 1. Reference only, depends on functions enabled. / 2. Depends on sensor uplink power and options. / 3. Based on average charging time. / 4. Marport Standard Marine Limited Warranty Speed Pro Sensors | V1 |...
  • Page 11 46° 40° 30° Beamwidths for Up and Down pings: Beamwidth @ 125 kHz @ 160 kHz @ 200 kHz -3dB 26° 24° 22° Outline Dimensions Trawl Speed and Speed Explorer sensors Speed Pro Sensors | V1 | Introduction and Presentation...
  • Page 12 Speed Explorer with a board for inverted installation Grid sensor Firmware and Features This section describes the firmware and features that must be configured on MASP to set up the sensor. Speed Pro Sensors | V1 | Introduction and Presentation...
  • Page 13 This option is useful for troubleshooting support. Measures • Battery (always activated) • Pressure • Temperature • Pitch • Roll • Along Speed (always activated) • Across Speed (always activated) Speed Pro Sensors | V1 | Introduction and Presentation...
  • Page 14 • Across Speed (always activated) Main Parts External View 1. Temperature 6. Pressure-relief spring sensor 7. Pressure sensor 2. Negative charge 8. EM log pins 3. Water switch 9. Latch 4. Positive charge Speed Pro Sensors | V1 | Introduction and Presentation...
  • Page 15 • Do not put foreign objects into pressure sensor opening or try to open it. • Do not remove the shoulder bolts from the outside of the sensor. It may damage the components. Speed Pro Sensors | V1 | Introduction and Presentation...
  • Page 16 To configure the sensor, you need to connect it to Mosa2 application, using either the Dock or the Configuration Cable. Using a Dock Charger Plug Tip: Refer to Dock user manual to have more details about the use of this product. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 17 Connect the Configuration Cable from the computer to the sensor to display the sensor configuration page on Mosa2. Tip: Refer to the Configuration Cable Quick Reference Guide available on our website for more details about the use of this product. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 18 > Eject Config Plug or Connect Config Plug. When ejected, you come back to the discovery page. It stays disconnected until you virtually connect to it or manually disconnect then connect it. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 19 Battery Information The battery lifetime is displayed on the first page. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 20 Note: When you change settings such as the uplink power or sounding range, it affects the battery consumption and remaining lifetime. The battery information will update after the sensor has been switched on and operating for 10 minutes. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 21 Mosa2 has a virtual water switch option that changes the conditions under which the sensor is running. Note: The virtual water switch is available only for the Pro line of sensors (PCBA A2S Gen 2 and later, and all A2H versions). It is activated by default.
  • Page 22 The charger plug displays a warning icon: When the alarm appears, take the sensor out of water immediately and contact Marport support. Warning: In case of water ingress in the product, do not charge it: battery may vent or rupture, causing product or physical damage.
  • Page 23 2. Enter a node according to the position of the sensor on the trawl. Important: Make sure to put the same number when adding the sensor to Scala2 receiver page (on page 44). If not, change it accordingly. 3. Click Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 24 Uplink. Speed Explorer Pro Speed Pro 2. Speed Explorer Pro only: Choose a communication protocol. ◦ NBTE V4: latest protocol, for A2S sensors. ◦ Select previous versions if the sensor needs to be compatible with versions of the Mx receiver earlier than 08.03.04.
  • Page 25 ◦ Issues receiving data ◦ Low SNR 5. Speed Explorer Pro only: In Refresh Rate, leave Fast selected. Configuring the Telegrams You change the telegram assigned to each type of data. Telegrams are used to define the acoustic communication between the sensor and the receiver.
  • Page 26 Battery Every 60 to 70 sec. Note: Using telegrams that send data more often reduces the battery life. 3. To configure a Catch Twister (±180° roll), set the roll telegram to D6. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 27 Speed Explorer Pro Specific Settings Configure the settings of the Speed Explorer Pro echo sounder. Sounding Modes The sensor can send pings according to three different sounding modes.
  • Page 28 You can configure the order and types of measurements (e.g. temperature, pitch, roll...) sent to the receiver. 1. Press command + A or click Menu and click User Mode > Advanced. 2. In Communications page, click in Data Sequence. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 29 The sequence begins by the top. Trouble: If you do not see some data, it means it is not activated on the sensor (application file). 4. To delete data, click in front of data. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 30 Down + Down2 option allows you to compare two different settings on the down sounding (for example, 2 ping lengths or 2 frequencies). The sensor will send two consecutive pings toward down direction. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 31 6. If you want the range of the down sounding to automatically change to 20 m when the bottom is closer, see About the Automatic Range Mode (on page 33). Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 32 You can choose between three different TVG modes: • 20 log: focus on the bottom, footrope or a school of fish. • 40 log: focus on individual targets. • 30 log: compromise between the two others. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 33 The echogram can automatically switch to a 20-meter range when the distance to the bottom is less than 20 meters (1). The change of range depends on the settings configured on Mosa2. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 34 1. Go to Measurements page and click next to depth or temperature to apply offsets. 2. Enter a target value. Click The measured value becomes the same as the target value. The value of the offset is displayed. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 35 You can test the sensor in water or in air. In air, the following measures will be wrong: height, conductivity. 1. Press command + A or click Menu and click User Mode > Advanced. 2. Go to the Monitoring page. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 36 ◦ Depth: place your sensor on a desk or on the ground and enter 0 in Target Depth. ◦ Temperature: enter the estimated temperature of your environment. ◦ Emlog Speed: calibrate the speed measurements. Memory Card Recording This topic explains the memory card recording feature (this feature is optional). Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 37 Data recorded on the sensor memory card are in higher resolution, with a higher refreshing rate. For sensors with echograms, you can see target strength values without uplink sound transmission loss. You can see on Mosa2 main page if the memory card recording feature is activated: Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 38 Note: When downloading the files, we recommend to connect the sensor to Mosa2 using the Dock or the Configuration Cable for a better transfer of data. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 39 See Replaying Data Recorded on a Memory Card (on page 53) to learn how to replay these data in Scala2. Saving a Configuration on Mosa2 You can save different configurations of the sensor to be able to quickly change the configuration when you change your fishing method. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 40 The wheel icon becomes orange and the name of the configuration is displayed underneath. 3. To create another configuration, for example this time to use the sensor in deep waters, change the settings of the sensor on Mosa2. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 41 Exporting Sensor Configuration You can export the sensor settings you configured on Mosa2 on a file. You can afterward use this file when configuring a similar sensor. • You are finished configuring the sensor. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 42 (virtual water switch, simulation mode), uplink level and frequency, echo sounder settings. Important: If the new configuration changes the echo sounder settings, you must re- calibrate the sensor for target strength value. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 43 1. Press command + A or click Menu and click User Mode > Advanced 2. Click Menu > Import. 3. From the window that appears, select the *.A2C or XML configuration file. The configuration is loaded into the sensor. Speed Pro Sensors | V1 | Sensor Configuration...
  • Page 44 2. Right-click the IP address of the receiver at the bottom of the page, then click Configure Receiver. 3. From the left side of the receiver page, click Sensors. 4. From the page Add Sensor Product, select the options corresponding to your type of sensor: Speed Pro Sensors | V1 | System Configuration and Display...
  • Page 45 Configuring Sensor Settings You need to complete communication settings when you add the sensor to the receiver. Important: Make sure the settings you enter here are the same as in Mosa2. Speed Pro Sensors | V1 | System Configuration and Display...
  • Page 46 • High: if the signal of the sensor is low = the trawl is far from the vessel (SNR min. 6 dB). For each option, enter the same frequencies and telegrams as those entered in Mosa2. Click Configure to change filters applied on incoming data. Click Apply when you have finished. Speed Pro Sensors | V1 | System Configuration and Display...
  • Page 47 This setting also helps detecting the sensor signal. Leave default setting at Synchro 1. Enter the same frequency as the one entered for the uplink frequency in Mosa2. Select the same sounding direction and range as those set in Mosa2. Speed Pro Sensors | V1 | System Configuration and Display...
  • Page 48 > Customize and enter the password eureka 2. Open the control panels and go to the Mx tab. Data title should be: ◦ Speed Explorer ◦ Trawl Speed for Grid and Trawl Speed sensors. Speed Pro Sensors | V1 | System Configuration and Display...
  • Page 49 Note: Data displayed (e.g. depth, temperature, pitch & roll) depends on the sensor's features that are enabled. Speed Pro Sensors | V1 | System Configuration and Display...
  • Page 50 3. Click + drag to a page Sonar Data to display the echogram of a Speed Explorer. 4. Hover the mouse over the echogram to display the target strength of the detected targets. The higher is the target strength, the bigger the target is. Speed Pro Sensors | V1 | System Configuration and Display...
  • Page 51 Speed Across data in a TS Dial or in a TS 3D. TS Dial: Note: Bearing angle is negative when the sensor is oriented toward port and positive when oriented toward starboard. Speed Pro Sensors | V1 | System Configuration and Display...
  • Page 52 TS 3D: 6. You can also click and drag the data from the control panels, then choose a type of display from Choose type of display. Speed Pro Sensors | V1 | System Configuration and Display...
  • Page 53 9. Deactivate the Customize mode when you have finished customizing pages: click Menu > Customize again. Replaying Data Recorded on a Memory Card In Scala2, you can replay data that has been recorded in high definition on the sensor memory card. Speed Pro Sensors | V1 | System Configuration and Display...
  • Page 54 SD card is displayed in the A2S Data panel. 3. Go to the control panels, then click and drag data from the A2S Data panel to a page. Speed Pro Sensors | V1 | System Configuration and Display...
  • Page 55 Make sure to always use a protective cage when using the sensor. The protective cage must be approved by Marport. Any additional protective devices installed in front of the head may disrupt the flow and therefore alter the water speed measurements.
  • Page 56 The sensor must be placed in a way that there is less than +/- 5 degrees of pitch and roll. You may need to add floats to the back of the sensor to achieve this. Standard Installation The Speed Explorer Pro and Trawl Speed are placed below the headrope, EM log pins facing down. 1. Cage attached to the headrope 2.
  • Page 57 Trawl Explorer: Reversed Installation In this installation, the EM log pins face up instead of down. In this case, the Speed Explorer Pro is installed on a board to provide more stability. The aim of this installation is to prevent the EM log pins and transducer to hit the deck when the trawl is hauled.
  • Page 58 / 4. Safety wire between the sensor and the cage to secure the sensor The sensor is attached to the grid with stainless steel plate and fastenings (not supplied by Marport), like on the image below: Speed Pro Sensors | V1 | Installation...
  • Page 59 Maintenance and Troubleshooting Read this section for troubleshooting and maintenance information. Important: Only an approved Marport dealer can access the internal unit. Warranty will become void if anyone other than an approved dealer tries to do internal maintenance duties on the product.
  • Page 60 • Use Isopropyl alcohol to clean the end cap and transducer. Use a steel wool pencil to clean the shoulder bolts, and very fine sandpaper (180 grit) to clean between them. Speed Pro Sensors | V1 | Maintenance and Troubleshooting...
  • Page 61 • Make sure the sensors on the end cap are in good condition and clean. • Connect the sensor to a charger and check the charging status. Speed Pro Sensors | V1 | Maintenance and Troubleshooting...
  • Page 62 • If there is an alarm or if the sensor is not detected by Mosa2, disconnect it from the Dock and do not charge it until it is inspected by a technician. • Send the sensor back for servicing to a Marport office. Speed Pro Sensors | V1 |...
  • Page 63 Important: Only Marport technicians can open the sensor to access the internal components. CAUTION: In case of water ingress into the sensor, battery may vent or rupture, causing product or physical damage. Mosa2 does not open due to error message Mosa2 displays an error message saying it cannot be opened.
  • Page 64 • Check that you see Marport Captain icon in the desktop taskbar. If you do not see it: close, then open Mosa2. The icon should appear in the taskbar. Note: Marport Captain is a program running in the background. It allows Mosa2 automatic opening and displays shortcuts to Mosa2 and Scala2 applications installed on the computer.
  • Page 65 1. Connect the sensor to Mosa2 and check if there is an orange warning sign at the top of the window. If yes, it means the virtual water switch is on. 2. Go to Communications page, then in Options, click Speed Pro Sensors | V1 | Maintenance and Troubleshooting...
  • Page 66 3. Deactivate the Virtual water switch option. Speed Pro Sensors | V1 | Maintenance and Troubleshooting...
  • Page 67 Support Contact You can contact your local dealer if you need maintenance on your Marport products. You can also ask us at the following contact details: FRANCE ICELAND Marport France SAS Marport EHF 8, rue Maurice Le Léon Tónahvarf 7...
  • Page 68 42833 C-1/CH2 41548 C-1/CH3 41852 C-1/CH4 40810 C-1/CH5 42500 C-1/CH6 43200 C-2/CH1 42631 C-2/CH2 41417 C-2/CH3 41690 C-2/CH4 40886 C-2/CH5 42300 C-2/CH6 43100 C-3/CH1 42429 C-3/CH2 41285 C-3/CH3 41548 C-3/CH4 40970 C-3/CH5 42100 Speed Pro Sensors | V1 | Appendix...
  • Page 69 41690 C-5/CH3 41285 C-5/CH4 41060 C-5/CH5 42900 C-5/CH6 43400 C-6/CH1 39062 C-6/CH2 39375 C-6/CH3 39688 C-6/CH4 40000 C-6/CH5 40312 C-6/CH6 40625 C-7/CH1 38906 C-7/CH2 39219 C-7/CH3 39531 C-7/CH4 39844 C-7/CH5 40156 C-7/CH6 40469 Speed Pro Sensors | V1 | Appendix...
  • Page 70 Frequencies and intervals The diagrams below show the bandwidth of the different types of Marport sensors and intervals you must respect when adding other sensors. PRP sensors (e.g. Catch sensor, Trawl Speed, Spread sensor...) Example: If the frequency of the sensor is 40kHz, there should be no sensors between 39.9 and 40.1kHz.
  • Page 71 • We recommend to allocate frequencies between 34 and 56 kHz for wideband hydrophones and between 41 kHz and 44 kHz for narrowband hydrophones. • Echosounders are usually placed around 38 kHz, make sure to allow enough distance with them. Speed Pro Sensors | V1 | Appendix...
  • Page 72 Example of a system with Spread, Catch, Trawl Speed sensors and Speed Explorer, Catch Explorer, HDTE and Door Sounder. Example of a system with Spread sensors with positioning, Catch sensors, Trawl Explorer and Catch Explorer. Speed Pro Sensors | V1 | Appendix...
  • Page 73 Example of a system for purse seining, with a Seine Explorer and depth Seine sensors. Bandwidth Mandatory distance with other sensors Avoid allocating frequencies between 37 and 39 kHz because this range is generally used by echosounders. Speed Pro Sensors | V1 | Appendix...
  • Page 74 2. GLL: Sentence formatter* 1.2.6.0 Position - Latt/Long 3. aaaa.aa,L: Latitude North/South (N/S)* 4. bbbbb.bb,L: Longitude East/West (E/W)* 5. hhmmss.ss: UTC of position* 6. C: status (A: data valid / V: data not valid)* Speed Pro Sensors | V1 | Appendix...
  • Page 75 4. b.b,M: Magnetic deviation (degrees), Easterly/ 1.0.0.0 Deviation & Variation Westerly (E/W)* 5. c.c,M: Magnetic variation (degrees), Easterly/ Westerly (E/W)* 6. *hh: Checksum* $--HDT,a.a,T*hh<CR><LF> HDT - Heading, True 1.0.0.0 1. $--: Talker identifier* 2. HDT: Sentence formatter* Speed Pro Sensors | V1 | Appendix...
  • Page 76 1. $--: Talker identifier* 2. VHW: Sentence formatter* VHW - Water Speed 3. a.a,T: Heading, degrees True* 1.4.0.0 and Heading 4. b.b,M: Heading, degrees Magnetic* 5. c.c,N: Speed, knots* 6. d.d,K: Speed, km/hr 7. *hh: Checksum* Speed Pro Sensors | V1 | Appendix...
  • Page 77 10. iiiii: RPM middle 11. jjjjj: Line speed starboard (meter or feet/min) 12. kkkkk: Line speed port (meter or feet/min) 13. lllll: Line speed middle (meter or feet/min) 14. mm:mm: Towing time (meter or feet/min) Speed Pro Sensors | V1 | Appendix...
  • Page 78 10. gg: system in 00 = MANUAL (stop), 10 = auto shooting, 20 = auto fishing, 30 = auto hauling, 40 = slow tension alarm without propeller reduction, 41 = slow tension alarm with Speed Pro Sensors | V1 | Appendix...
  • Page 79 2. aaa.a: winch starboard length in meters* 3. bbb.b: winch inner starboard length in meters* 4. ccc.c: winch inner port length in meters* 5. ddd.d: winch port length in meters* 6. ee.e: winch starboard tension in tons* Speed Pro Sensors | V1 | Appendix...
  • Page 80 1. $SIWCT: Talker identifier + sentence formatter* WCT - Warp length 1.2.6.0 2. aaa: Port winch cable, meters* and tension (Silecmar) 3. bbb: Starboard winch cable, meters* 4. ccc: Clump winch cable, meters* Speed Pro Sensors | V1 | Appendix...
  • Page 81 WLP - Scantrol 1.0.6.0 2. a.a,M: paid out wire in meters* winch length (port) 3. b.b,M: wirespeed in meters/sec., positive when paying out wire 4. *hh: Checksum* WLS - Scantrol winch 1.0.6.0 $SCWLS,a.a,M,b.b,M*hh<CR><LF> length (starboard) Speed Pro Sensors | V1 | Appendix...
  • Page 82 3. b.b,M: wirespeed in meters/sec., positive when paying out wire 4. *hh: Checksum* $SCWTP,a.a,T*hh<CR><LF> WTP - Scantrol 1. $SCWTP: Talker identifier + sentence formatter* 1.0.6.0 winch tension (port) 2. a.a,T: tension in tons* 3. *hh: Checksum* Speed Pro Sensors | V1 | Appendix...
  • Page 83 2. a.a,T: tension in tons* 3. *hh: Checksum* WTE - Scantrol winch $SCWTD,a.a,T*hh<CR><LF> tension (quad trawl - center clump) 2.0.0.0 1. $SCWTD: Talker identifier + sentence formatter* 2. a.a,T: tension in tons* 3. *hh: Checksum* Speed Pro Sensors | V1 | Appendix...
