  • Page 7: Introduction And Presentation

    Get a basic knowledge of the sensor. Introduction The Spread Sensors Pro are part of a new generation of Marport sensors. They send the spread distance between the doors and clumps, depth, pitch, roll, water temperature and optionally positioning measurements, using whether a PRP or digital communication protocol technology.
  • Page 8 Example of the MultiTrawl and MultiDepth (Door Explorer) views Data displayed with the MultiTrawl 3D view Spread Sensors Pro | V4 | Introduction and Presentation...
  • Page 9 The view displays the warp lengths (1) when received from a winch control system, and the distances between the doors and clumps (2). The doors and clumps are highlighted in green when the position and alignment are correct (3). It switches to red if incorrect. Spread Sensors Pro | V4 | Introduction and Presentation...

  • Page 10: Safety Guidelines

    Install and use this product in accordance with this user manual. Incorrect use of the product may cause damage to the components or void the warranty. Only qualified Marport dealers can do maintenance and repairs on internal components of the sensors.

  • Page 11: Port

    • PRP (Pulse Repetition Period): you must set a telegram and a frequency to each data received from the sensor. The sensor has a longer battery life than with a digital communication protocol. Important: Data received from the PRP sensors cannot be recorded on the SD card.
  • Page 12 Asks for answer Answers Sends data to the receiver (door spread distance, bearing, pitch and roll, depth...) Port Stbd • The port sensor (1) interrogates the clump (2) and starboard sensors (3) to know the distance with each one. Then, it sends the two distances (yellow A, B) to the receiver. •...
  • Page 13 • The port sensor (1) interrogates the port clump sensor (2), the starboard clump sensor (3) and the starboard sensor (4) to know the distance with each one. Then, it sends the three distances (yellow A, B, C) to the receiver. •...

  • Page 14: About Trawl Positioning

    About Trawl Positioning This topic explains how the position of the trawl is calculated. Angles are relative to the stern of the vessel. Angles toward port side are negative and angles toward starboard side are positive. The distance is calculated from the warp lengths sent by a winch control system. Scala2 application can calculate the positioning of the trawl from this distance, the depth and bearing angle.

  • Page 15: Description

    • 2 receiving hydrophones: ◦ 2 passive hydrophones + wideband preamplifier (ref NC-2-02) ◦ OR 2 active wideband hydrophones (ref. NC-1-08) • Warp lengths • Baseline calculation • GPS and heading input Important: The two receiving hydrophones must have a minimum distance of 1 meter between each other.

  • Page 16: Technical Specifications

    Protocol Receiver firmware Scala/Scala2 Mosa2 Digital 07.00.x or later 02.03.x or later • Scala2: 02.00.02 or later / 02.00.03 or later with positioning option • Scala: 01.06.x or later (only single and twin trawls) Technical Specifications Uplink frequency 30 to 60 kHz Range to vessel up to 2500 m Data update rate...
  • Page 17 2 years (Sensor & Battery) 1. Reference only. Depends on functions enabled. / 2. Depends on sensor uplink power and options. / 3. Based on average charging time. / 4. Marport Standard Marine Limited Warranty Spread Sensors Pro | V4 |...

  • Page 18: Main Parts

    Dimensions Main Parts This topic describes the housing and components of the sensor. External View End cap 1. Pressure sensor 2. Temperature sensor 3. Positive charge 4. Water switch 5. Negative charge 6. Shoulder bolts Operational Mode Indicator A LED on the sensor's transducer indicates the operational mode of the sensor. State Situation •...
  • Page 19 State Situation • Startup sequence: LED blinks green/off/red/off/green/red. • Then, fixed green for a 1 sec. • For 1 min.: LED blinks red at • Sensor is in water. Running the beginning of each uplink • Water switch is on. communication cycle.

  • Page 21: Sensor Configuration

    Sensor Configuration Learn how to configure the sensor settings. Note: To configure the sensor on Mosa2: Press command + A or click Menu click User Mode > Advanced. Connecting the Sensor to Mosa2 To configure the sensor, you need to connect it to Mosa2 application, using either the Dock or the Configuration Cable.
  • Page 22 Procedure 1. Connect one Dock charging plug to the sensor's endcap. 2. Mosa2 discovery page opens. The sensor is displayed. ◦ Click open the sensor configuration page. ◦ Click show the deploy animation on the charger plug for 30 seconds. Using the Configuration Cable Connect the Configuration Cable from the computer to the sensor to display the sensor configuration page on Mosa2.

  • Page 23: Battery Information

    About this task Tip: Refer to the Configuration Cable Quick Reference Guide available on our website for more details about the use of this product. Procedure 1. Move other electrical devices minimum 1 m away from the computer. 2. Connect the USB connector directly to the computer. Mosa2 opens automatically and the startup wizard is displayed.
  • Page 24 The battery lifetime is displayed on the first page. You can also check the battery level at anytime from the top bar: Spread Sensors Pro | V4 | Sensor Configuration...
  • Page 25 Note: When you change settings such as the uplink power or sounding range, it affects the battery consumption and remaining lifetime. The battery information will update after the sensor has been switched on and operating for 10 minutes. Spread Sensors Pro | V4 | Sensor Configuration...

  • Page 26: About The Virtual Water Switch Option

    About the Virtual Water Switch Option Mosa2 has a virtual water switch option that changes the conditions under which the sensor is running. Note: The virtual water switch is available only for the Pro line of sensors (PCBA A2S Gen 2 and later, and all A2H versions). It is activated by default. •...

  • Page 27: Configuring The Door Spread Settings

    • The charger plug displays a warning icon: When the alarm appears, take the sensor out of water immediately and contact Marport support. Warning: In case of water ingress in the product, do not charge it: battery may vent or rupture, causing product or physical damage.

  • Page 28: Starboard

    Procedure 1. Go to the Door Spread page, then click in Door Spread. 2. Enter a frequency for the communication between all spread sensors. Note: The frequency must be the same for all of them. 3. Enter the maximum spread between: ◦...

  • Page 29: Configuring The Trawl Node

    Trouble: If you have communication issues, you can set a maximum spread higher than 200 meters, even if the real spread value is lower. This will increase the emission power level of 6 dB more than the default level. Be aware that this will reduce the battery life.

  • Page 30: Configuring The Uplink Frequency And Power

    Sensor location Trawl gear node Clump ◦ Twin trawls: 26 ◦ Triple trawls: 26, 123 ◦ Quadruple trawls: 26, 123, 223 Important: Make sure to put the same number when adding the sensor to Scala2 receiver page. If not, change it accordingly. 3.
  • Page 31 Procedure 1. Go to the Communications page, then click in Uplink. 2. Enter a frequency for the communication with the vessel. Default is 44,000 Hz. Note: The uplink frequency of a PRP spread sensor is not configurable. 3. Drag the slider to change the power of the uplink signal. Note: A higher level of uplink power reduces the battery lifetime.

  • Page 32: Configuring Prp Spread Sensors Telegrams

    Recommended Sensor Conditions Battery Life Uplink Powers ◦ Sensor is far from vessel - e.g. more than 800 m depending on conditions, high depth 100% ◦ High level of interferences ◦ Issues receiving data ◦ Low SNR Configuring PRP Spread Sensors Telegrams You change the telegram assigned to each type of measurement.
  • Page 33 Option Telegram Value and/or update rate Less than 610 m, every 11 to 14 sec. Less than 610 m, every 3 to 8 sec. 300 m, every 3 to 8 sec. Depth 600 m, every 3 to 8 sec. 1,200 m, every 3 to 8 sec. Every 11 to 16 sec.

  • Page 34: Calibrating The Pitch And Roll

    Note: Using telegrams that send data more often reduces the battery life. 3. Click and drag it to change the order in which data are sent. Calibrating the Pitch and Roll You need to calibrate the pitch and roll of the sensors when placed on the trawl doors. Before you begin Tip: Some trawl door manufacturers measure the pitch and roll offsets themselves and write them on the doors.
  • Page 35 • Automatic: select if you do not know the offsets. In this case, the doors need to be taken out and placed on the ground in order to calibrate the pitch and roll. • Manual: select if you already know the pitch and roll offsets, for example if they are written on the doors.
  • Page 36 attack. If you cannot know the angle, you can put 35° but be aware that a wrong angle impacts pitch and roll measurements. 10. Select the Calibration type: ◦ Automatic: make sure the doors are in vertical position, then click Calibrate. ◦...

  • Page 37: Applying Offsets To Measurements

    Import offset 12. If you need to update the Accelerometer coefficients, download the last XML test file from MASP and connect in Expert mode. Results The sensor is calibrated. Applying Offsets to Measurements You can apply offsets to temperature and depth measurements if the measured values do not correspond to the environment of the sensor.
  • Page 38 About this task You can test the sensor in water or in air. In air, the following measures will be wrong: height, conductivity. Procedure 1. Press command + A or click Menu and click User Mode > Advanced. 2. Go to the Monitoring page. You can check information about the battery, board and sensor.

  • Page 39: Memory Card Recording

    ◦ Depth: Place your sensor on a desk or on the ground and enter 0 in Target Depth. ◦ Temperature: Enter the estimated temperature of your environment. ◦ Motion: Calibrate the door sensors. Memory Card Recording This topic explains the memory card recording feature (this feature is optional). Overview Data recorded on the memory card are in higher resolution, with a higher refreshing rate and you can see target strength values without uplink sound transmission loss.

  • Page 40: Additional Settings

    Additional settings We recommend to activate the support logs to help support teams for error diagnosis. 1. Go to the Communications page, then click in Recording. 2. Activate Additional support Log. Getting data from the memory card The last 99 recorded sensor data files and last 99 battery files are displayed. Two types of files are on the memory card: Spread Sensors Pro | V4 | Sensor Configuration...
  • Page 41 • Files containing measures recorded by the sensor. Their name begins by "450". These data are more precise and recorded more often than data received on the receiver. One file corresponds to a tow (time between entering and leaving water). The recording date displayed in the second column is synchronized with your computer time.

  • Page 42: Saving A Configuration On Mosa2

    1. Time of end of towing 2. Free memory 3. Total memory size 4. Index of the last file written See Replaying Data Recorded on a Memory Card (on page 82) to learn how to replay these data in Scala2. Saving a Configuration on Mosa2 You can save different configurations of the sensor to be able to quickly change the configuration when you change your fishing method.
  • Page 43 Procedure 1. When you are finished configuring the sensor, for example to use the sensor in shallow water, click one of the wheel icon on the first page of Mosa2. 2. In the window that appears, enter a name for the configuration and save it. The wheel icon becomes orange and the name of the configuration is displayed underneath.

  • Page 44: Exporting Sensor Configuration

    4. When you are finished, click the second wheel icon and save the configuration. 5. If you need to change the sensor configuration back to the first configuration (shallow water), click the corresponding wheel. The configuration is applied. 6. If you need to make changes to a configuration: a.

  • Page 45: Importing A Sensor Configuration

    Before you begin • You are finished configuring the sensor. About this task If you have issues with your sensor, send this file to support teams. Procedure 1. Click Menu > Export. 2. From the window that appears, choose a folder on your computer to save the file and click Open.
  • Page 46 About this task Only the following settings are imported: trawl node, recording settings (SD card, support logs), communication options (virtual water switch, simulation mode), uplink level and frequency, echo sounder settings. Important: If the new configuration changes the echo sounder settings, you must re- calibrate the sensor for target strength value.

  • Page 48: System Configuration And Display

    System Configuration and Display Learn how to configure the receiver and display the sensor data in Scala2 application. Adding the Sensor to the Receiver You need to add the sensors to the receiver in order to display their data on Scala2. For compatibility details, see System Compatibility (on page 15).

  • Page 49: Configuring Sensor Settings

    Product Category Product Name Trawl Gear Location ◦ Quadruple trawls: 323 ◦ Quintuple trawls: 623 Spread Clump Spread Clump + options* ◦ Twin trawls: 26 ◦ Triple trawls: 26, 123 Digital Spread Clump ◦ Quadruple trawls: 26, 123, ◦ Quintuple trawls: 26, 123, 223, 323 *The options depend on the firmware installed, e.g.
  • Page 50 PRP Spread Sensors Sensor name displayed in Scala2 and its features. This setting helps detecting the signal of the sensor among other sensor or echosounder signals. Change only if you have issues receiving data. Spread Sensors Pro | V4 | System Configuration and Display...
  • Page 51 • Detection and 2D: default value. This setting helps distinguishing the sensor signals when there are a lot of interferences (e.g. echosounders). It selects the correct signals according to very selective criteria. • Detection: If you do not receive data, it may be because the Detection and 2D setting is too selective with the signal.
  • Page 52 Digital Spread Sensors Sensor name displayed in Scala2 and its features. This setting helps detecting the signal of the sensor among other sensor or echosounder signals. Change default setting only if you have issues receiving data. • Choose between 0-2 only if no interferences on the vessel (not recommended). •...

  • Page 53: Configuring The System With The Positioning Option

    Before you begin You have added the sensors to the receiver. Tip: A spreadsheet is available on the Useful Resources page of Marport support website to help you complete this page. Spread Sensors Pro | V4 | System...
  • Page 54 Procedure 1. From the left side of the screen where the system is displayed, click Positioning. The positioning configuration page appears. 2. In Baseline, enter the baseline distance and the misalignment angle. Note: The baseline is very important to have accurate positions of the doors. Important: If the starboard hydrophone is placed further aft, add a negative (-) sign before the angle.

  • Page 55: Calculations For The Positioning System

    When they are misaligned, you can calculate their misalignment angle with the following calculations. Tip: A spreadsheet is available on the Useful Resources page of Marport support website to help you complete this page.
  • Page 56 The misalignment angle (angular offset around Z axis) is calculated with the following formula: Sign of Angles You need to add a negative sign (-) to the result if the starboard hydrophone is placed further aft. The sign of the angles is important to receive correct positioning data. Spread Sensors Pro | V4 | System Configuration and Display...

  • Page 57: Configuring Trawl Settings

    Negative sign (-) Positive sign (+) Configuring Trawl Settings You need to configure trawl settings to display the trawl on the chart and vessel 3D overview. Spread Sensors Pro | V4 | System Configuration and Display...

  • Page 58: Adding Data From External Devices

    Procedure 1. Click Menu > Settings. 2. From the tab Trawl, complete Headline (H), Bridle (B) and Sweepline (S) with accurate measurements of your trawl gear. Adding Data from External Devices You need to add to Scala2: warp lengths, GPS coordinates and heading data received from devices such as winch control systems or GPS compass.
  • Page 59 Note: Warp lengths can be received from a winch control system, or entered manually in the control panels, under Manual Estimation. If no warp lengths, the positioning will be calculated from the bearing, spread distance and depth data sent by the Spread sensors.
  • Page 60 a. Enter the IP address of the server and the port. b. Select a different input format if you have Marelec or Rapp Marine/Rapp Hydema equipment. Otherwise, select Standard NMEA format. c. To broadcast the input data to other equipment than Scala2, select Output to UDP, then enter a port above 1000 and enter 255.255.255.255 to broadcast to all equipments, or enter a different subnet mask.

  • Page 61: Receiving Warp Lengths From Scantrol

    Note: In this procedure, data are transmitted via a UDP port but a connection via a serial port can be possible. Procedure 1. Scantrol and Marport computers must be connected together via an Ethernet wired network. Both computers must be on the same sub-network to communicate with each other: 192.168.0.XX.
  • Page 62 2. Go to iSYM's Configure Communication Ports menu, then in 13: NMEA UDP 1 enter a , and set SEND to port number, such as 9000 Note: The port number must be different from the one on which Scala2 sends data (if applicable).

  • Page 63: Configuring Data Display On Scala2

    5. Clear the Validate Checksum checkbox. Important: If you do not clear this checkbox, you will not receive the data from Scantrol. Results Scantrol data are displayed in Scala2. Configuring Data Display on Scala2 Connect in Customize mode to configure the display of data. From the top left corner of the screen, click Menu >...
  • Page 64 Procedure 1. Open the customization panel and go to the Mx panel. Click + drag the Door 3D View to the page and select the fishing gear element. If you have twin trawls, you can display the clump and if you have twin outrigger trawls, you can set which doors are displayed. Repeat for all fishing gear elements.
  • Page 65 Tip: You can change the fishing gear element anytime: right-click the 3D view and click Configure. 2. You can also change the viewing angle: looking from the trawl toward the vessel (front), or from the vessel toward the trawl (back). 3.
  • Page 66 4. To change the view angle of the door, right-click the 3D view and choose: ◦ Horizontal Camera to see the doors from the front. ◦ Or back. Spread Sensors Pro | V4 | System Configuration and Display...

  • Page 67: Using The Multitrawl View On Scala2

    ◦ Vertical Camera to see the doors from above. ◦ Free Camera to adjust the viewing angle yourself, by clicking and dragging the 3D doors. 5. To display the ground, right-click the 3D view and select Display Ground. You should leave the ground displayed in order to see if the doors are touching it.
  • Page 68 Displaying the MultiTrawl View Before you begin • Go to Menu > Settings > Trawl, then select Auto to automatically detect the number of trawls or select manually the type of trawl gear in use. If you change the trawl gear, change this setting accordingly.
  • Page 69 Controls • Trawl Setup: select Auto to automatically detect the number of trawls or select manually the type of trawl gear in use. If you change the trawl gear, change this setting accordingly. • Door Spread: ◦ Current value: current total spread distance. ◦...
  • Page 70 Settings • Camera: change the viewing angle of the 3D view. • Clump Spreads: ◦ Show distances: real values of spread between two door sensors. ◦ Show projections: calculated values of linear spread between door sensors. These values have a yellow dot instead of a green dot.
  • Page 71 Models You can change the model of trawl doors or clumps. Click the arrows to select the model. The 3D view will change accordingly. Spread Sensors Pro | V4 | System Configuration and Display...
  • Page 72 Understanding the MultiTrawl View 1. Warp lengths, received from a winch control system using NMEA sentences. 2. Total spread distance. 3. Spread distances between doors and clumps (or between doors for a single trawl). 4. 3D representation of the position of the doors and clumps. Alignment is correct when the doors are inside their outline, clumps are framed in green and axis is green.
  • Page 73 Examples of data received When a door or clump is out of alignment, it is displayed in red. The distance from the alignment axis is displayed above. In this case, the current spread distance is inferior to the nominal spread distance that was set. Doors are shown out of their expected position and axis is in red.

  • Page 74: Displaying Door Positioning Data

    In this case, the current spread distance is superior to the nominal spread distance. One of the clump is out of alignment. In this case, both clumps are out of alignment. Important: If you do not receive warp lengths, Scala2 is not able to show the correct position of the clumps.
  • Page 75 Before you begin Note: Minimum data required to display Doors Positioning are GPS positioning, depth, door spread distance, port and starboard door bearings. However, we strongly recommend to receive warp lengths from a winch control system. Without it, the accuracy of the positioning will be reduced. Procedure In the control panels, go to the trawl data.
  • Page 76 Tip: This panel displays the door horizontal distance (1) and estimated slant distance (2) to the boat: Displaying the Chart View Before you begin • You must be in Customize mode to do this task. You must have: • Incoming GPS data and heading data. •...

  • Page 77: Changing The Number Of Trawls

    The chart view is displayed. The heading of the vessel, the port (red) and starboard (green) door paths appear by default. 4. Click the arrow on the right side of the view to show the display options. Trouble: If the view looks empty it might be because the view is not centered on the vessel.
  • Page 78 Triple trawl Distances sent by Master on port door Distance sent by inner port clump Distance sent by inner starboard clump • Triple trawl: • Triple to twin: keep the inner starboard clump in water. • Triple to single: only keep the starboard and port trawl doors in water. Quadruple trawl Spread Sensors Pro | V4 | System Configuration and Display...
  • Page 79 Distances sent by Master on port door Distance sent by inner port clump Distance sent by center clump Distance sent by the inner starboard clump • Quadruple trawl: • Quadruple to triple: keep the center and inner starboard clump in water. Spread Sensors Pro | V4 | System Configuration and Display...
  • Page 80 • Quadruple to twin: keep the inner starboard clump in water. • Quadruple to single: only keep the port and starboard doors in water. Penta trawl Distances sent by Master on port door Distance sent by inner port clump Distance sent by center clump Distance sent by the inner starboard clump Distance sent by the starboard clump Spread Sensors Pro | V4 | System...
  • Page 81 • Penta trawl: • Penta to quadruple: • Penta to triple: Spread Sensors Pro | V4 | System Configuration and Display...

  • Page 82: Replaying Data Recorded On A Memory Card

    • Penta to twin: • Penta to single: Replaying Data Recorded on a Memory Card In Scala2, you can replay data that has been recorded in high definition on the sensor memory card. About this task Note: Data in high definition is available only when downloading it from the sensor memory (A2S files).
  • Page 83 In the control panels, data that was received in live is displayed in the Mx panel and data recorded on the SD card is displayed in the A2S Data panel. 3. Go to the control panels, then click and drag data from the A2S Data panel to a page. Spread Sensors Pro | V4 | System Configuration and Display...

  • Page 85: Installation

    Installation Learn how to install the sensor on the trawl gear. Installation Principles Door sensors need to be installed in pockets welded on trawl doors. Carefully read these installation principles before installing sensor pockets. Angle of Attack The angle of attack is the angle of the door in relation to the towing direction. This angle is important for the efficiency of the doors.
  • Page 86 Opening and Elevation Angles The opening and elevation angles depend on the pocket installation on the door. The opening angle is the horizontal angle of the pocket in relation to the door. It should be between 25° and 40°. Opening angles should be in line with the angle of attack. You need to indicate the opening angle on Mosa2.
  • Page 87 1. Elevation angle: 15-20° Roll Angles Roll angle of the sensors depends on the tilt of the doors when fishing. If doors are straight during fishing, you can apply a roll angle of 90°. If doors are tilted inward during fishing, slightly Spread Sensors Pro | V4 | Installation...
  • Page 88 roll the pocket so that lines of communication between the sensors stay aligned. If not, you will have sporadic spread readings. 1. Adapt roll angles of pockets according to the tilt of the doors. PRP & Digital Spread Communication Spread sensors communicate with each other and with the receiver. Lines of communication between them and toward the receiver must be unobstructed.

  • Page 89: Installing Sensor Pockets

    Communication toward receiver (46°) Communication between sensors (26°) 1. Master sensor 2. Clump sensor 3. Starboard sensor The side of the transducer with an A/circle must be oriented: • Port sensor: toward starboard • Clump and starboard sensors: toward port Installing Sensor Pockets You need to install pockets on each trawl door to hold the door sensors.
  • Page 90 Procedure 1. Use drawings of door pockets to mark the shape to be cut off: Pocket Drawings (on page 125). Note: Ask your local Marport sales office for scaled templates of door pockets. Spread Sensors Pro | V4 | Installation...
  • Page 91 2. Cut round openings in the doors. 3. Place the sensor pocket with the bottom portion sticking out of back side of the door. Adjust accordingly to the elevation angle and angle of attack you need (see Pocket Angle of Attack (on page 126)). Picture below shows angles of attack seen from above the door.
  • Page 92 a. Weld only a few points on two sides of the pocket to hold it on the door. b. Slide the sensor into the alignment bar inside the door pocket. You can adjust the roll of the sensor using the alignment bar (see Pocket for XL Bottles (on page 127)).
  • Page 93 8. We recommend to use a protective cage made of metal bars around pockets to protect sensors, like the examples below. Note: Make sure there is sufficient space between the protective cage and the sensor pocket, so that if the cage becomes bent, you can still remove the sensor. Spread Sensors Pro | V4 | Installation...

  • Page 95: Maintenance And Troubleshooting

    Maintenance and Troubleshooting Read this section for troubleshooting and maintenance information. Important: Only an approved Marport dealer can access the internal unit. Warranty will become void if anyone other than an approved dealer tries to do internal maintenance duties on the product.

  • Page 96: Cleaning The Sensor

    2. Connect the charger plug to one of the 4 charging ports. 3. Connect the 3-pin charging connector to the sensor charging pins. Results The Dock screen and the Virtual Charger Room display the state of charge of the sensor. Cleaning the Sensor You need to regularly clean the sensor for proper performance.

  • Page 97: Maintenance Checklist

    • Every 6 months, put the sensor in charge for less than an hour. Every 2 years The sensor must be returned to an approved Marport dealer for inspection and maintenance. Spread Sensors Pro | V4 | Maintenance and Troubleshooting...

  • Page 98: Troubleshooting

    • If there is an alarm or if the sensor is not detected by Mosa2, disconnect it from the Dock and do not charge it until it is inspected by a technician. • Send the sensor back for servicing to a Marport office. Spread Sensors Pro | V4 |...

  • Page 99: Mosa2 Does Not Open Due To Error Message

    Important: Only Marport technicians can open the sensor to access the internal components. CAUTION: In case of water ingress into the sensor, battery may vent or rupture, causing product or physical damage. Mosa2 does not open due to error message Mosa2 displays an error message saying it cannot be opened.

  • Page 100: Chart And 3D Views Are Wrong

    • Check that you see Marport Captain icon in the desktop taskbar. If you do not see it: close, then open Mosa2. The icon should appear in the taskbar. Note: Marport Captain is a program running in the background. It allows Mosa2 automatic opening and displays shortcuts to Mosa2 and Scala2 applications installed on the computer.
  • Page 101 1. From Scala2, click Menu > Expert Mode. 2. Right-click the IP address of the receiver at the bottom of the page, then click Configure Receiver. 3. From the left side of the screen where the system is displayed, click Positioning. 4.
  • Page 102 1. Open the control panels and check from the Trawl data that you see data in Doors Positioning. 2. Click Menu > Settings > Trawl. 3. Check that Headline (H), Bridle (B) and Sweepline (S) dimensions are completed according to your trawl model. There is no trawl or vessel You may have no GPS coordinates or heading data.

  • Page 103: In Scala2, Lost Is Displayed Instead Of Spread

    Check the baseline dimensions you entered in the positioning settings (on page 53) in the system web page (or Scala2 receiver page). The vessel and trawl have erratic movements: they jump, zigzag, move forward and backward You have two GPS inputs. Coordinates can be slightly different between the two GPS so the position of the trawl changes according to one or the other.
  • Page 104 Port Starboard Clump 1. Down sounder (marked with a circle) Master and Starboard sensors have been inverted on the doors. In that case, you will also have wrong pitch and roll values. • Open the pocket and check the top of the housing of the sensor: the one with a green marker must be on the starboard side and the one with a red marker on the port side.

  • Page 105: The Sensor Is Not Running When Testing Out Of

    The sensor is not running when testing out of water You activated the sensor water switch outside water or in a low level of water (for example for testing purpose) but it does not switch to running mode and does not emit any data. The virtual water switch option may be activated in Mosa2.
  • Page 106 3. Deactivate the Virtual water switch option. Spread Sensors Pro | V4 | Maintenance and Troubleshooting...

  • Page 107: Support Contact

    Support Contact You can contact your local dealer if you need maintenance on your Marport products. You can also ask us at the following contact details: FRANCE ICELAND Marport France SAS Marport EHF 8, rue Maurice Le Léon Tónahvarf 7...

  • Page 109: Appendix

    Appendix Frequency Plan It is important to carefully plan the setup of your sensors before adding them to the system. You can create a table with a list of frequencies and complete it when you add sensors. Boat & Channel Codes This list shows the standard frequencies for PRP telegrams.
  • Page 110 C-3/CH6 43000 C-4/CH1 42226 C-4/CH2 41852 C-4/CH3 41417 C-4/CH4 41160 C-4/CH5 42700 C-4/CH6 43300 C-5/CH1 42024 C-5/CH2 41690 C-5/CH3 41285 C-5/CH4 41060 C-5/CH5 42900 C-5/CH6 43400 C-6/CH1 39062 C-6/CH2 39375 C-6/CH3 39688 C-6/CH4 40000 C-6/CH5 40312 C-6/CH6 40625 C-7/CH1 38906 C-7/CH2 39219 C-7/CH3...
  • Page 111 C-7/CH6 40469 Frequencies and intervals The diagrams below show the bandwidth of the different types of Marport sensors and intervals you must respect when adding other sensors. PRP sensors (e.g. Catch sensor, Trawl Speed, Spread sensor...) Example: If the frequency of the sensor is 40kHz, there should be no sensors between 39.9 and 40.1kHz.
  • Page 112 Marport Pro sensors (e.g. Trident, Door Explorer, Door Sensor Pro, all Navigator range except Catch) Example: If the frequency of the sensor is 40kHz, there should be no sensors between 39.8 and 41.2kHz. NBTE sensors (e.g. Speed Explorer, Trawl Explorer, Catch Explorer, Catch Navigator, Door Sounder) Example: If the frequency of the sensor is 40kHz, there should be no sensors between 39.8kHz...
  • Page 113 Bandwidth Recommended distance Mandatory distance with Frequency with other sensors other sensors of the sensor Examples of frequency allocations • We recommend to allocate frequencies between 34 and 56 kHz for wideband hydrophones and between 41 kHz and 44 kHz for narrowband hydrophones. •...
  • Page 114 Example of a system with Spread, Catch, Trawl Speed sensors and Speed Explorer, Catch Explorer, HDTE and Door Sounder. Example of a system with Spread sensors with positioning, Catch sensors, Trawl Explorer and Catch Explorer. Spread Sensors Pro | V4 | Appendix...
  • Page 115 Example of a system for purse seining, with a Seine Explorer and depth Seine sensors. Bandwidth Mandatory distance with other sensors Avoid allocating frequencies between 37 and 39 kHz because this range is generally used by echosounders. Spread Sensors Pro | V4 | Appendix...

  • Page 116: Compatible Nmea Sentences From Winch Control Systems, Gps And Compass Devices

    Compatible NMEA Sentences from Winch Control Systems, GPS and Compass Devices You can add to Scala2 measures coming from winch control systems that use the following NMEA sentences. NMEA 0183 Standard Sentences Symbol (*) indicates which parts of the sentence Scala2 uses. First compliant NMEA Sentence Format...
  • Page 117 First compliant NMEA Sentence Format version of Scala 7. d: Mode indicator 8. *hh: Checksum* $--GNS,hhmmss.ss,aaa.aa,L,bbbbb.bb,L,c--c, dd,e.e,f.f,g.g,h.h,i.i,a*hh<CR><LF> 1. $--: Talker identifier* 2. GNS: Sentence formatter* 3. hhmmss.ss: UTC of position* 4. aaaa.aa,L: Latitude North/South (N/S)* 5. bbbbb.bb,L: Longitude East/West (E/W)* 6.
  • Page 118 First compliant NMEA Sentence Format version of Scala 3. a.a,T: Heading (degrees) True* 4. *hh: Checksum* RMC - Recommended Minimum Navigation RMC,aaaaaa,A,bbbb.bbb,B,ccccc.ccc,C,ddd.d,eee.e, Information ffffff,ggg.g,G,H*hh<CR><LF> 1. $--: Talker identifier* 2. RMC: sentence formatter* 3. aaaaaa: Time (UTC)* 4. A: Status, A = data valid, V = navigation receiver warning* 5.

  • Page 119: Proprietary Sentences

    First compliant NMEA Sentence Format version of Scala $--VTG,a.a,T,b.b,M,c.c,N,d.d,K*hh<CR><LF> 1. $--: Talker identifier* 2. VTG: Sentence formatter* VTG - Course 3. a.a,T: Course over ground, degrees, True* Over Ground and 1.3.3.0 4. b.b,M: Course over ground, degrees, Magnetic Ground Speed 5.
  • Page 120 First compliant NMEA Sentence Format version of Scala $PFEC,GPatt,aaa.a,bb.b,cc.c,*hh<CR><LF> 1. $PFEC: Talker identifier + sentence formatter* 2. GPatt: Global positioning attitude, sentence FEC - Furuno formatter 1.0.5.0 attitude message 3. aaa.a: Heading true* 4. bb.b: Pitch* 5. cc.c: Roll* 6. *hh: Checksum* KW - Karmoy Winch 1.6.25.0 $KWIN,a,b.b,T,c.c,M,d.d,rpm*hh<CR><LF>...
  • Page 121 Format version of Scala propeller reduction, 50 = fast tension alarm without propeller reduction, 51 = fast tension alarm with propeller reduction* MPT TXOR - Marport, 2.0.0.0 $PMPT,TXOR,aa.a,bb.b,cc.c,d*hh transducer orientation 1. $PMPT: talker identifier + sentence formatter. 2. TXOR: Transducer Orientation 3.
  • Page 122 First compliant NMEA Sentence Format version of Scala 7. ff.f: winch inner starboard tension in tons* 8. gg.g: winch inner port tension in tons* 9. hh.h: winch port tension in tons* 10. Other strings are not used. $WMSYN,aaa.a,c,bbb.b,c,ccc.c,c,dd.d,t,ee.e,t,ff.f, t*hh<CR><LF> 1. $WMSYN: Talker identifier + sentence formatter* 2.
  • Page 123 First compliant NMEA Sentence Format version of Scala 5. d.d: Tension in the port winch, tons* 6. e.e: Tension in the starboard winch, tons* 7. f.f: Tension in the clump winch, tons* 8. *hh: Checksum* WIDA1 - Kongsberg warp $WIDA1,aa,bbbb,cc,0,dd,eeee,ff,1,g,h,i,2,k,l,m,3 length (single to triple *hh<CR><LF>...
  • Page 124 First compliant NMEA Sentence Format version of Scala 1. $SCWLS: Talker identifier + sentence formatter* 2. a.a,M: paid out wire in meters* 3. b.b,M: wirespeed in meters/sec., positive when paying out wire 4. *hh: Checksum* $SCWLC,a.a,M,b.b,M*hh<CR><LF> 1. $SCWLC: Talker identifier + sentence formatter* WLC - Scantrol winch 2.

  • Page 125: Pocket Drawings

    1. $SCWTD: Talker identifier + sentence formatter* 2. a.a,T: tension in tons* 3. *hh: Checksum* Pocket Drawings Drawings to manufacture door sensor pockets to be placed on trawl doors. Ask your local Marport Office for scaled templates. Spread Sensors Pro | V4 | Appendix...

  • Page 126: Pocket Angle Of Attack

    Pocket Angle of Attack Spread Sensors Pro | V4 | Appendix...

  • Page 127: Pocket For Xl Bottles

    Pocket for XL Bottles Spread Sensors Pro | V4 | Appendix...
  • Page 128 Spread Sensors Pro | V4 | Appendix...
  • Page 129 Spread Sensors Pro | V4 | Appendix...
  • Page 130 Spread Sensors Pro | V4 | Appendix...
  • Page 131 Spread Sensors Pro | V4 | Appendix...
  • Page 132 Spread Sensors Pro | V4 | Appendix...
  • Page 133 Spread Sensors Pro | V4 | Appendix...

  • Page 134: Example Of Installation On Poly Jupiter Doors

    Example of Installation on Poly Jupiter Doors Spread Sensors Pro | V4 | Appendix...
  • Page 135 Spread Sensors Pro | V4 | Appendix...

  • Page 136: General Installation Instructions And Drawings

    General Installation Instructions and Drawings Spread Sensors Pro | V4 | Appendix...
  • Page 137 Index Cleaning 96 Numerics Communication Between trawls 10 Clump 63 Protocol 10 Doors 63 Compatibility 10 Trawl 68 Configuration Cable 21 Troubleshooting 99 Contact 107 Alarms Concept 26 Angle of attack 85 Diagnostic 26 Dimensions 16 Dock Charging 95 Connecting to Mosa2 21 Door spread Battery Settings 27 Lifetime 23 XLR 23 Bearing 74 Boat code 109 Elevation angle 85 Calibration Pitch and roll 34 Channel code 109 Frequency plan 109 Charging...
  • Page 138 Delete 42 Export 44 Import 45 Adding 58 Save 42 NMEA sentences 116 Motion 34 Multitrawl view Display options 68 Displaying 68 Examples 72 Trawl setup 68 Heading Adding 58 NMEA sentences 116 NMEA inputs Adding 58 Compatibility 116 Installation overview 10 Offsets Lost distance 103 Depth 37 Pitch and roll 34 Temperature 37 Opening angle 85 Operational modes 18 Maintenance Schedule 97 Measures 37 Memory card Replaying 82...
  • Page 139 Installation 89 Order 32 Spread Sensor 127 Tilt angle 85 XL bottle 127 Trawl Positioning 3D 63 About 14 Modeling 57 Calculations 55 Node 29 Data display 74 Settings 57 Receiver settings 53 Setup 77 Trawl settings 57 Uplink Receiver Frequency 30 Adding to 48 Power 30 Compatibility 48 Compatible firmware 48 Sensor settings 49 Replay A2S files 82 Virtual water switch 26, 105 SD card Warning 26 Downloading data 39...
  • Page 140 Housing 18...

This manual is also suitable for:

Door explorerDoor sensor pro
