Related Manuals for Marport PRO TRIDENT

Summary of Contents for Marport PRO TRIDENT

  • Page 2: Table Of Contents

    Contents Sounding Modes Legal Configuring the Echo Sounder History About the Automatic Range Mode Copyright Applying Offsets to Measurements Disclaimer Testing Measures SD Card Recording Saving a Configuration on Mosa2 Exporting Sensor Configuration Introduction and Importing a Sensor Configuration Presentation Introduction Applications Safety Guidelines...
  • Page 3 Contents | iii Maintenance and Troubleshooting Charging the Sensor with the Dock Cleaning the Sensor Maintenance Checklist Troubleshooting Mosa2 does not open due to error message Sensor does not connect correctly with Mosa2 when using the Configuration Cable The Dock screen does not display all the details of the Trident or Door Explorer sensor The echogram has a lot of interference The echogram display is interrupted...

  • Page 4: Legal

    Marport. “Marport”, the Marport logo and Software Defined Sonar are registered trademarks of Marport. All other brands, products and company names mentioned are the trademark and property of its respective owners only. Marport is a division of Airmar Technology Corporation.
  • Page 5 • macOS: from 10.12 (Sierra) to 13.01 (Ventura) • Receiver firmware: from 08.02.11 Trident | V3 | Legal...

  • Page 7: Introduction And Presentation

    Introduction and Presentation Get a basic knowledge of the sensor. Introduction Trident is a netsonder with a wide angle of view. Placed on the headline, it is designed to work primarily on pelagic trawls. The sensor is available in two applications: •...

  • Page 8: Applications

    Applications Overview of the system Examples of data received in Scala2 The image below shows data received from a Trident Down Looking sensor installed on the headline of the trawl gear. Trident | V3 | Introduction and Presentation...

  • Page 9: Safety Guidelines

    Detections Sounding directions a. Fish passing above the headline 1. Up sounding b. Fish inside the trawl 2. Down port sounding c. Footrope 3. Down vertical sounding d. Fish passing below the footrope 4. Down starboard sounding Safety Guidelines Important: To ensure proper and safe use of this equipment, carefully read and follow the instructions in this manual.

  • Page 10: Description

    Notice: Do not open the sensor bottle. Only qualified Marport dealers can do maintenance and repairs on internal components of the sensors. Description System Compatibility The Trident is compatible with the following versions of Marport's software and equipment. Mosa2 02.09.x or later Scala2 02.08.x or later...
  • Page 11 *Reference only. Depends on communication settings and transmission conditions / † Depends on sensor uplink power and options. / ‡ Based on average charging time. / **Marport Standard Marine Limited Warranty The housing is delivered with 4 soft shackles: dimensions 7-10x100x100 mm, resistance up to 1 ton (+/- 10% tolerance).
  • Page 12 Dimensions Beam Angles Trident | V3 | Introduction and Presentation...

  • Page 13: Main Parts

    Main Parts Trident Housing 1. Screw maintaining the bottle inside the housing 2. End cap 3. Transducer: oriented toward the vessel 4. Punches indicating the number of beams Punches in the housing show the direction and number of the beams. Trident | V3 | Introduction and Presentation...
  • Page 14 • Trident Down Looking: the face with one hole is facing up. • Trident Up Looking: the face with three holes and one screw at the bottom is facing up. End Cap 1. Negative charge 2. Water switch 3. Positive charge 4.

  • Page 15: Operational Mode Indicator

    Operational Mode Indicator A LED on the sensor's transducer indicates the operational mode of the sensor. State Situation • Sensor has been switched on in Starting water or with water switch. • Startup sequence: LED blinks green/off/red/off/green/red • Then, fixed green for a 1 sec. •...
  • Page 16 State Situation • LED blinks red. • LED is fixed red after 10 sec. if connected to a charger other than the Dock. • Sensor has been hauled on deck • The virtual water switch is on • The sensor is locked in a low pow­ On deck er state to not switch into running LED blinks green every 4 sec.

  • Page 18: Sensor Configuration

    Sensor Configuration Learn how to configure the sensor settings. Note: To configure the sensor on Mosa2: Press command + A or click Menu and click User Mode > Advanced Connecting the Sensor to Mosa2 To configure the sensor, you need to connect it to Mosa2 application, using either the Dock or the Configuration Cable.
  • Page 19 1. Connect one Dock charging plug to the sensor's endcap. 2. Mosa2 discovery page opens. The sensor is displayed. • Click to open the sensor configuration page. • Click to show the deploy animation on the charger plug for 30 seconds. Using the Configuration Cable Connect the Configuration Cable from the computer to the sensor to display the sensor configuration page on Mosa2.

  • Page 20: Battery Information

    1. Move other electrical devices minimum 1 m away from the computer. 2. Connect the USB connector directly to the computer. Mosa2 opens automatically and the startup wizard is displayed. The LED on the plug is solid blue. 3. Connect the three-pin plug to the sensor. The LED on the plug blinks alternatively blue and green.
  • Page 21 You can also check the battery level at anytime from the top bar: Trident | V3 | Sensor Configuration...

  • Page 22: About The Virtual Water-Switch Option

    Note: When you change settings such as the uplink power or sounding range, it affects the battery consumption and remaining lifetime. The battery information will update after the sensor has been switched on and operating for 10 minutes. About the Virtual Water-Switch Option Mosa2 has a virtual water-switch option that changes the conditions under which the sensor is running.

  • Page 23: Diagnostic Information

    • When the virtual water-switch is activated: the sensor runs when the depth is more than 2 meters and the water-switch is in contact with water. We recommend to activate it to prevent the sensor from running outside water. For example, if the sensor is hauled on deck and stays inside the net, the water- switch remains wet and keeps emitting.

  • Page 24: Configuring The Trawl Node

    • The charger plug displays a warning icon: When the alarm appears, take the sensor out of water immediately and contact Marport support. Warning: In case of water ingress in the product, do not charge it: battery may vent or rupture, causing product or physical damage.
  • Page 25 Trawl number Node numbers Trawl 1 10 to 17 Trawl 2 110 to 117 Trawl 3 210 to 217 Trawl 4 310 to 317 Trawl 5 610 to 617 1. Go to the Communications page, then click in Uplink. 2. Enter a node according to the position of the sensor on the trawl. Important: Make sure to put the same number when adding the sensor to Scala2 receiver page.

  • Page 26: Configuring The Uplink Frequency And Power

    3. Click Configuring the Uplink Frequency and Power Configure the settings of the communication link between the sensor and the vessel. 1. Go to the Communications page, then click in Uplink. 2. Choose the communication protocol. 3. Enter a frequency for the communication with the vessel. Default is 44,000 Hz. 4.

  • Page 27: Sounding Modes

    Note: A higher level of uplink power reduces the battery lifetime. Recommended Estimated bat­ Conditions uplink powers tery life Works for most conditions. 104 hours 100% • Sensor is far from vessel (e.g. more than 800 m de­ 18 hours pending on conditions, high depth) •...
  • Page 28 Down + Up The sensor sends three echogram images of the area below and one echogram image of the area above (4). The update rate is lower because the pings are distributed between up and down directions. As a result, data arrives more slowly to the receiver.

  • Page 29: Configuring The Echo Sounder

    Configuring the Echo Sounder You need to configure the echo sounder settings so that they correspond to the fishing conditions. The sounding orientation of the channels changes depending on if the sensor application is down looking or up looking. Transducer's Application Picture Orientation...
  • Page 30 1. Go to the Echo Sounder page, then click in Sounding Mode. 2. Select a Mode: • Trident Down Looking application: ◦ Down only sends three echograms of the area below the sensor. Note: You must select this mode to use the Automatic Range feature.
  • Page 31 • lower than 19 meters to be able to switch to a 20 meter-range. • lower than 9 meters to be able to switch to a 10 meter-range. 5. Ping Level is the strength of the echogram signal. Default is High, but you can lower the level to Medium or Low if you notice that the sensor interferes with other equipment on the vessel.

  • Page 32: About The Automatic Range Mode

    • Short: shallow waters (100 μs) • Medium: moderate depth (300 μs) • Long: deep waters (500 μs) 11. Select a TVG setting to compensate the signal loss in water and have targets or sea bottom displayed in the same color on the echogram, whatever the distance from the sensor: •...

  • Page 33: Applying Offsets To Measurements

    • Automatic Range must be activated. • The Mode must be set to Down only. • The Trawl Opening: ◦ must be lower than 19 meters to be able to switch to a 20-meter range. ◦ must be lower than 9 meters to be able to switch to a 10-meter range. Note: The trawl opening value sets the minimum distance to see inside the trawl.

  • Page 34: Testing Measures

    The measured value becomes the same as the target value. The value of the offset is displayed. 3. If you need to reuse offsets from a previous configuration, click then select the configuration file (*.A2C). Testing Measures You can test the measures taken by the sensor (e.g. battery level, temperature, depth) to check that there are no faults.
  • Page 35 You can check information about the battery, board and sensor. 3. Go to the Measurements page. You can see the values of the activated measures, such as depth, temperature. If the sensor is working correctly, measures are updating. 4. Click to check and, if necessary, adjust data measured by the sensor: •...

  • Page 36: Sd Card Recording

    SD Card Recording This topic explains the SD card recording feature (this feature is optional). Overview Data recorded on the SD card are in higher resolution, with a higher refreshing rate. You can see on Mosa2 main page if the SD card recording feature is activated: Additional settings We recommend to activate the support logs to help support teams for error diagnosis.
  • Page 37 Getting data from the SD card The last 99 recorded sensor data files and last 99 battery files are displayed. Two types of files are on the SD card: • Files containing measures recorded by the sensor. Their name begins by "450". These data are more precise and recorded more often than data received on the receiver.

  • Page 38: Saving A Configuration On Mosa2

    Recorded files are displayed. Click the title of the columns to sort them by their name, date or size. 1. Time of end of towing 2. Free memory 3. Total memory size 4. Index of the last file written Saving a Configuration on Mosa2 You can save different configurations of the sensor to be able to quickly change the configuration when you change your fishing method.
  • Page 39 • If fishing in shallow water, you can use a configuration with an uplink level of 20%, a short pulse and a short range. • If fishing in greater depths, you can change for a configuration with an uplink level of 60%, a long pulse and a long range. 1.
  • Page 40 4. When you are finished, click the second wheel icon and save the configuration. 5. If you need to change the sensor configuration back to the first configuration (shallow water), click the corresponding wheel. The configuration is applied. 6. If you need to make changes to a configuration: a.

  • Page 41: Exporting Sensor Configuration

    Exporting Sensor Configuration You can export the sensor settings you configured on Mosa2 on a file. You can afterward use this file when configuring a similar sensor. • You are finished configuring the sensor. If you have issues with your sensor, send this file to support teams. 1.
  • Page 42 Only the following settings are imported: trawl node, recording settings (SD card, support logs), communication options (virtual water switch, simulation mode), uplink level and frequency, echo sounder settings. Important: If the new configuration changes the echo sounder settings, you must re-calibrate the sensor for target strength value. 1.

  • Page 44: System Configuration And Display

    System Configuration and Display Learn how to configure the receiver and display the sensor data in Scala2 application. Adding the Sensor to the Receiver You need to add the sensors to the receiver in order to display their data on Scala2. For compatibility details, see System Compatibility (on page 10).

  • Page 45: Configuring Sensor Settings

    4. From the page Add Sensor Product select: a. Product Category: Trawl Explorer b. Product Name: Trident Down Looking or Trident Up Looking. c. Trawl Gear Location: same as defined in Mosa2 (see Configuring the Trawl Node (on page 24)). Configuring Sensor Settings You need to complete communication settings when you add the sensor to the receiver.
  • Page 46 Sensor name displayed in Scala2 and its features. Not used. Leave default setting at SynchroFT. Enter the same frequency as the one entered for the uplink frequency in Mosa2. Click Configure to change filters applied on incoming data. Filters are particularly useful to re­ duce interferences on the echogram data.

  • Page 47: Configuring Data Display On Scala2

    Note: Filters should not be necessary. However, if you notice interference, you can ap­ ply filters such as Some Smoothing, More Smoothing or Rate of Change. Be aware that echogram filters such as Echosounder and Interference Reduction may remove small targets on the echogram.
  • Page 48 1. Open the control panels and go to the Mx tab. 2. To display the echograms, click + hold Sonar Data from a Trident sensor and drag it to the page display. 3. Select the sounding direction from the menu on the top of the echogram. 4.
  • Page 49 5. Click + hold other data, such as depth, pitch, roll, and drag it as well to the page display. 6. Select the type of display. Trident | V3 | System Configuration and Display...
  • Page 50 7. Drag the lines around the blocks of data to resize them. 8. Right-click the title or the values of the data to display customization options. 9. To save the changes, right-click the tab with the name of the page and click Save Changes.

  • Page 51: Displaying The Trident View

    When you have finished customizing the page, you can have a screen display such as in this example. Note: Deactivate the Customize mode when you have finished customizing pages: click Menu > Customize again. Displaying the Trident View Trident sensors have a dedicated 3D view, showing the echogram beams, the sounding range, the depth and roll values of the sensor.
  • Page 52 1. Click Menu > Customize and enter the password eureka 2. Open the Customize panel on the left side of the screen, then drag Trident View to a page. The view is displayed. Port and starboard sides are indicated. The roll values appear in red in the center of the view, on both sides of the sensor.
  • Page 53 4. Click the arrow on the right side of the view to show the display options. Trident | V3 | System Configuration and Display...
  • Page 54 Settings • Display: ◦ Choose the viewing angle of the trawl between front and rear. ◦ Choose to display the filtered or raw data. ◦ True mode: the water surface is fixed so you can see the descent of the sensor. ◦...

  • Page 55: Replaying Data Recorded On A Sd Card

    Palettes Use these palettes to change the echogram col­ ors. Replaying Data Recorded on a SD Card You can replay data that have been recorded in high definition on the SD card . Note: Data in high definition is available only when downloading them from the sensor memory.
  • Page 56 In the replay bar, the recording period of the files in high definition is displayed in green. In the control panels, data that were received in live are displayed in the Mx panel and data recorded on the SD card are displayed in the A2S Data panel. 3.

  • Page 58: Installation

    Installation Learn how to install the sensor on the trawl gear. Installing the Sensor on the Trawl The Trident sensor must be installed on the headrope or footrope of the trawl using appropriate equipment. Two installations are possible: • Installation on the headrope: Trident is configured in Down Looking mode. •...
  • Page 59 • Trident Down Looking: the face with one hole is facing up. • Trident Up Looking: the face with three holes and one screw at the bottom is facing up. Trident | V3 | Installation...
  • Page 60 2. Attach the sensor to the net using four soft shackles. Note: See Technical Specifications (on page 10) for shackles specifications. 3. You can add floats on either sides of the sensor to stabilize it and have pitch and roll values between +/- 5°. Trident | V3 | Installation...

  • Page 62: Maintenance And Troubleshooting

    1. Before charging the sensor: wash with fresh water and dry the sensor. This prevent corrosion of the charging pins. Important: Check that the charging pins are not damaged. If they are, contact you local Marport dealer for replacement. Trident | V3 | Maintenance and Troubleshooting...

  • Page 63: Cleaning The Sensor

    2. Connect the charger plug to one of the 4 charging ports. 3. Connect the 3-pin charging connector to the sensor charging pins. The Dock screen and Virtual Charger Room display the state of charge of the sensor. A full charge takes approximately 7 hours. Cleaning the Sensor You need to regularly clean the sensor for proper performance.

  • Page 64: Maintenance Checklist

    • Wash away mud or debris with warm water. • Use Isopropyl alcohol to clean the end cap and transducer. Use a steel wool pencil to clean the shoulder bolts, and very fine sandpaper (180 grit) to clean between them. Notice: Do not use highly abrasive materials or jet wash.

  • Page 65: Troubleshooting

    If the sensor has not been not used for more than 3 months, we highly recommend to check the following points before using it: • Make sure the sensors on the end cap are in good condition and clean. • Connect the sensor to a charger and check the charging status. •...

  • Page 66: Sensor Does Not Connect Correctly With Mosa2

    • Make sure the three pins are fully inserted inside the sensor. Mosa2 does not automatically open when connecting the Configuration Cable. • Check that you see Marport Captain icon in the desktop taskbar. If you do not see it: close, then open Mosa2. The icon should appear in the taskbar.

  • Page 67: The Dock Screen Does Not Display All The Details

    • Disconnect both USB connector and three-pin plug. Then, connect again the Configuration Cable. If the message is still displayed, it means there is an issue with the sensor’s components. Contact Marport support. The Dock screen does not display all the...
  • Page 68 1. From Scala2, click Menu > Expert Mode and enter the password copernic 2. Right-click the IP address of the receiver at the bottom of the page, then click Configure Receiver. 3. Click the name of the sensor in the system tree view. 4.

  • Page 69: The Echogram Display Is Interrupted

    1. Noisy echogram with default filter ( Echosounder and Interference Reduction Low) 2. With Echosounder and Interference Reduction High filter applied. The echogram display is interrupted The echogram displayed in Scala2 has black gaps, as shown on the picture below. There is a loss of communication between the sensor and the boat.

  • Page 70: The Sensor Is Not Running When Testing Out Of

    1. Check the frequencies of the other sensors and make sure there is enough distance between them. 2. Check the noise on the spectrum (see ). If the frequency where the sensor is placed is too noisy, change for a less noisy frequency. Important: Do not forget to also change the frequency on the system web page in Scala2.
  • Page 71 1. Connect the sensor to Mosa2 and check if there is an orange warning sign at the top of the window. If yes, it means the virtual-water switch is on. 2. Go to Communications page, then in Options, click 3. Deactivate the Virtual water switch option. Trident | V3 | Maintenance and Troubleshooting...

  • Page 72: Support Contact

    Support Contact You can contact your local dealer if you need maintenance on your Marport products. You can also ask us at the following contact details: FRANCE ICELAND Marport France SAS Marport EHF 8, rue Maurice Le Léon Tónahvarf 7...

  • Page 73: Appendix

    You can create a table with a list of frequencies and complete it when you add sensors. Frequencies and intervals The diagrams below show the bandwidth of the different types of Marport sensors and intervals you must respect when adding other sensors. Figure 1. PRP sensors (e.g. Catch sensor, Trawl Speed, Spread sensor...) Example: If the frequency of the sensor is 40kHz, there should be no sensors between 39.9 and 40.1kHz.
  • Page 74 Figure 3. NBTE sensors (e.g. Speed Explorer, Trawl Explorer, Catch Explorer, Catch Navigator, Door Sounder) Example: If the frequency of the sensor is 40kHz, there should be no sensors between 39.8kHz and 40.6kHz. Figure 4. HDTE narrow band mode Example: If the frequency of the sensor is 40kHz, there should be no sensors between 39.8kHz and 41kHz.
  • Page 75 Examples of frequency allocations • We recommend to allocate frequencies between 34 and 56 kHz for wideband hydrophones and between 41 kHz and 44 kHz for narrowband hydrophones. • Echosounders are usually placed around 38 kHz, make sure to allow enough distance with them.
  • Page 76 Example of a system with Spread, Catch, Trawl Speed sensors and Speed Explorer, Catch Explorer, HDTE and Door Sounder. Example of a system with Spread sensors with positioning, Catch sensors, Trawl Explorer and Catch Explorer. Trident | V3 | Appendix...
  • Page 77 Example of a system for purse seining, with a Seine Explorer and depth Seine sensors. Bandwidth Mandatory distance with other sensors Avoid allocating frequencies between 37 and 39 kHz because this range is generally used by echosounders. Trident | V3 | Appendix...
  • Page 78 Index Connecting to Mosa2 18 Alarms Concept 23 Automatic range 29, 32 Echo sounder 29 End cap 13 Battery Lifetime 20 Boat code 73 Frequency plan 73 Channel code 73 Charging see     D ock     Housing Cleaning 63 Description 13 Components 13 Trawl Navigator 13 Configuration Cable 18 Trident 13 Troubleshooting 66 Maintenance Diagnostic 23 Schedule 64 Dimensions 10...
  • Page 79 Delete 38 SD card 55 Export 41 Import 41 Save 38 Scala2 47 SD card Downloading data 36 Offsets Recording 36 Depth 33 Time synchronization 36 Temperature 33 Sounding mode 29 Operational modes 15 Technical specifications 10 PCBA 13 Trawl Ping level 29 Node 24 Pulse frequency 29 Trawl opening 29 Pulse type 29 TVG (Time Variable Gain) 29 Range 29 Uplink Receiver Frequency 26 Adding to 44...
  • Page 80 Virtual water-switch 22, 70 Warning 23...
