Marport Door Spread Legacy User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Door Spread Legacy and is the answer not in the manual?

Questions and answers

Related Manuals for Marport Door Spread Legacy

Summary of Contents for Marport Door Spread Legacy

  • Page 2 Contents Legal Configuring Door Spread Settings Calibrating the Pitch and Roll History Configuring Positioning Settings Copyright Door Sounder Pro Specific Settings Disclaimer Configuring Data Sending Sequence Configuring the Echo Sounder About Time Variable Gain About the Automatic Range Mode Introduction and Applying Offsets to Measurements Presentation Testing Measures...
  • Page 3 Contents | iii Adding Data from External Devices Pocket for Stubby Bottles with Slim Housing Receiving Warp Lengths from Scantrol Index Installation Installation Principles Installing Sensor Pockets Installing Door Spread Sensors Installing Door Sounder Sensors Maintenance and Troubleshooting Charging the Sensor with the Dock Cleaning the Sensor Maintenance Checklist Troubleshooting...
  • Page 4 Marport is a division of Airmar Technology Corporation. Disclaimer Marport endeavors to ensure that all information in this document is correct and fairly stated, but does not accept liability for any errors or omissions. The present user guide is applicable for the following versions: •...
  • Page 5 Get a basic knowledge of the sensor. Introduction The Door Spread Legacy and Door Sounder Pro are part of Marport’s latest generation of sensors, featuring significant upgrades from earlier models. These enhancements include compatibility with the latest Mosa2 and Scala2 software features, with the Dock smart charger, and higher-definition echogram images.
  • Page 6 Install and use this product in accordance with this user manual. Incorrect use of the product may cause damage to the components or void the warranty. Notice: Do not open the sensor bottle. Only qualified Marport technicians can do maintenance and repairs on internal components of the sensors.
  • Page 7 5. Depth of doors 3. Distance between doors displayed as text or line graphs Description System Compatibility The Door Pro sensors are compatible with the following versions of Marport's software and equipment. Mosa2 02.13.03 or later Scala2 02.14.00 or later Mx receiver firmware 08.06.00 or later...
  • Page 8 Technical Specifications Door Spread Legacy Uplink frequency 30 to 60 kHz Range to vessel up to 2500 m Data update rate (telegrams) Spread: 3-15 sec. - Depth: 3-8 sec. - Temp: 3-16 sec. - Pitch & roll: 3-15 sec. Depth range...
  • Page 9 2 years (Sensor & Battery) 1. Reference only, depends on functions enabled. / 2. Depends on sensor uplink power and options. / 3. Based on average charging time. / 4. Marport Standard Marine Limited Warranty Door Sounder Beamwidths Beamwidths for Uplink pings:...
  • Page 10 The latest version of the firmware is available for download on MASP. Compatibility: F450-02.03.01 and after Features and Options The features and options are configurable according to the type of hardware and customer's choices. Door Spread Legacy Door Pro Sensors | V1 | Introduction and Presentation...
  • Page 11 Note: Interoperable with previous generation of door spread sensors. Features • Product name: manually entered. • Application: PRP Spread Legacy • Body: Stubby, XL • Battery capacity (not configurable): 1- pack if Stubby, 2-pack if XL Misc. options • Positioning Measures •...
  • Page 12 Door Sounder Features • Product name: manually entered. • Application: Door Sounder • Body: XL • Battery capacity (not configurable): 2- pack Sounding Options • Down (always activated) • Up Misc. options • Memory Card Log: records a log of the sensor activity.
  • Page 13 Stubby bottle XL bottle Stubby bottle with slim housing 1. Pressure sensor 2. Temperature sensor 3. Positive charge 4. Negative charge 5. Water switch 6. Shoulder bolts CAUTION: • Do not put foreign objects into pressure sensor opening or try to open it. •...
  • Page 14 State Situation • Startup sequence: LED blinks green/off/red/off/green/red. • Then, fixed green for 1 sec. • For 1 min.: LED blinks red at • Sensor is in water. Running the beginning of each uplink • Water switch is on. communication cycle. •...
  • Page 15 Sensor Configuration Learn how to configure the sensor settings. Note: This guide refers to the following versions of Mosa2: 02.13.x. If you use another version, the visual interface and options may vary. Note: To configure the sensor on Mosa2: Press command + A or click Menu click User Mode >...
  • Page 16 1. Connect one Dock charging plug to the sensor's endcap. 2. Mosa2 discovery page opens. The sensor is displayed. ◦ Click open the sensor configuration page. ◦ Click show the deploy animation on the charger plug for 30 seconds. Using the Configuration Cable Connect the Configuration Cable from the computer to the sensor to display the sensor configuration page on Mosa2.
  • Page 17 Tip: Refer to the Configuration Cable Quick Reference Guide available on our website for more details about the use of this product. 1. Move other electrical devices minimum 1 m away from the computer. 2. Connect the USB connector directly to the computer. Mosa2 opens automatically and the startup wizard is displayed.
  • Page 18 Battery Information The battery lifetime is displayed on the first page. Door Pro Sensors | V1 | Sensor Configuration...
  • Page 19 You can also check the battery level at anytime from the top bar: Note: When you change settings such as the uplink power or sounding range, it affects the battery consumption and remaining lifetime. The battery information will update after the sensor has been switched on and operating for 10 minutes. Door Pro Sensors | V1 | Sensor Configuration...
  • Page 20 About the Virtual Water Switch Option Mosa2 has a virtual water switch option that changes the conditions under which the sensor is running. Note: The virtual water switch is available only for the Pro line of sensors (PCBA A2S Gen 2 and later, and all A2H versions). It is activated by default. •...
  • Page 21 The charger plug displays a warning icon: When the alarm appears, take the sensor out of water immediately and contact Marport support. Warning: In case of water ingress in the product, do not charge it: battery may vent or rupture, causing product or physical damage.
  • Page 22 Sensor location Trawl gear node Door Sounder Pro: • Single trawl: 27 • Twin trawls: 124 • Triple trawls: 224 • Quadruple trawls: 324 Clump Door Sounder Pro: • Twin trawls: 27 • Triple trawls: 27, 124 • Quadruple trawls: 27, 124, 224 1.
  • Page 23 1. Go to the Communications page, then click in Uplink. Door Sounder Pro Door Spread Legacy 2. Door Sounder Pro only: Choose a communication protocol. ◦ NBTE V4: latest protocol, for A2S sensors. ◦ Select previous versions if the sensor needs to be compatible with versions of the Mx receiver earlier than 08.03.04.
  • Page 24 Recommended Conditions uplink powers ◦ Issues receiving data ◦ Low SNR 5. Door Sounder Pro only: In Refresh Rate, leave Fast selected. Spread Sensor Specific Settings Configuring the Telegrams You change the telegram assigned to each type of data. Telegrams are used to define the acoustic communication between the sensor and the receiver. Data (e.g.
  • Page 25 Option Telegram Value and/or update rate Less than 630 m. Sends data every 11 to 14 sec. (compatible with Scanmar system) Less than 360 m. Sends data every 11 to 14 sec. (compatible with Scanmar system) Less than 370 m. Sends data every 11 to 14 sec. (compatible with Scanmar system) SLOW Every 32 to 36 sec.
  • Page 26 Option Telegram Value and/or update rate Every 2 to 4 sec. Battery Every 60 to 70 sec. Note: Using telegrams that send data more often reduces the battery life. 3. To configure a Catch Twister (±180° roll), set the roll telegram to D6. 4.
  • Page 27 1. Go to the Door Spread page, then click in Door Spread. 2. Enter a frequency for the communication between all spread sensors. Note: The frequency must be the same for all of them. 3. Enter the maximum spread between: ◦...
  • Page 28 Trouble: If you have communication issues, you can set a maximum spread higher than 200 meters, even if the real spread value is lower. This will increase the emission power level of 6 dB more than the default level. Be aware that this will reduce the battery life.
  • Page 29 6. Connect the sensor to the Dock or Configuration Cable to connect to Mosa2. 7. From Mosa2, go to Measurements page and click in Motion. 8. Check on the bottom of the window that the pitch and roll of the door are close to 0 degree.
  • Page 30 Automatic calibration Manual calibration Import offset 12. If you need to update the Accelerometer coefficients, download the last XML test file from MASP and connect in Expert mode. The sensor is calibrated. Configuring Positioning Settings Configure the following settings if the sensor has the positioning option. Door Pro Sensors | V1 | Sensor Configuration...
  • Page 31 1. Go to Positioning page and click in Chirp. 2. Enter the central frequency of the signal sent by the sensor. 3. Enter the frequency bandwidth. We do not recommend to enter a bandwidth lower than 10000. For example, if the center frequency is 50000 Hz and the bandwidth is 10000 Hz, the signal will cover the frequency from 45000 Hz to 55000 Hz.
  • Page 32 3. To add data, click then select data in the drop-down menu. The sequence begins by the top. Trouble: If you do not see some data, it means it is not activated on the sensor (application file). 4. To delete data, click in front of data.
  • Page 33 5. To activate True mode display, enter a sequence corresponding to the following order: 4 x Depth / 1 x any data / 4 x Depth / 1 x any data, etc. 6. Click Configuring the Echo Sounder Configure the echo sounder settings of the Door. 1.
  • Page 34 3. Go back to the page, then click in front of the sounding direction, depending on the Sounding Mode that was configured. 4. Leave default Frequency (Hz) at 165,000 Hz. 5. Set the Range (m) of the sounding according to the maximum distance at which targets and bottom can be detected.
  • Page 35 7. Select a Pulse Type to have an appropriate length of pulse according to the distance to the bottom: ◦ Short: shallow waters (100 μs) ◦ Medium: moderate depth (300 μs) ◦ Long: deep waters (500 μs) Important: Pulse length is an important setting for the calibration of the sensor. If you change the pulse length on a sensor calibrated for target strength, you need to calibrate the sensor again.
  • Page 36 For example, if you want a good view of the footrope, select a TVG mode at 20 or 30 log. You can see on the images below that the footrope is clearer at 20 and 30 log. If you want a good view of individual targets, you can see that with 40 log, targets in the water column are clearer.
  • Page 37 Note: The sensor requires pitch and roll angles within -25° to 25° for automatic range operation. Mosa2 settings The following Sounding Mode options must be set in Mosa2: • The Mode must be set to Down only. • The Down sounding Range (m) must be more than 20 meters. •...
  • Page 38 3. If you need to reuse offsets from a previous configuration, click then select the configuration file (*.A2C). 4. About the pressure coefficients: you do not need to upload this file, the coefficients are directly included in the application file downloaded from MASP. Note that if you replace the pressure sensor, you need to change the sensor in MASP and upload the application file again.
  • Page 39 You can check information about the battery, board and sensor. 3. Go to the Measurements page. You can see the values of the activated measures, such as depth, temperature. If the sensor is working correctly, measures are updating. 4. Click to check and, if necessary, adjust data measured by the sensor: ◦...
  • Page 40 Overview Data recorded on the sensor memory card are in higher resolution, with a higher refreshing rate. For sensors with echograms, you can see target strength values without uplink sound transmission loss. You can see on Mosa2 main page if the memory card recording feature is activated: Door Pro Sensors | V1 | Sensor Configuration...
  • Page 41 Additional settings We recommend to activate the support logs to help support teams for error diagnosis. 1. Go to the Communications page, then click in Recording. 2. Activate Additional support Log. Getting data from the memory card The last 99 recorded sensor data files and last 99 battery files are displayed. Two types of files are on the memory card: •...
  • Page 42 1. Press command + E or click Menu and click User Mode > Expert. in Data Recording. 2. On the first page, click Recorded files are displayed. Click the title of the columns to sort them by their name, date or size.
  • Page 43 • You have finished configuring the sensor. You can have up to three different configurations for the sensor. When you change your fishing method, you can apply a corresponding configuration in one click. For example: • If fishing in shallow water, you can use a configuration with an uplink level of 33%, a short pulse and a short range.
  • Page 44 4. When you are finished, click the second wheel icon and save the configuration. 5. If you need to change the sensor configuration back to the first configuration (shallow water), click the corresponding wheel. The configuration is applied. 6. If you need to make changes to a configuration: a.
  • Page 45 If you have issues with your sensor, send this file to support teams. 1. Click Menu > Export. 2. From the window that appears, choose a folder on your computer to save the file and click Open. The configuration file is exported and saved on your computer as an A2C file. If you are connected to the internet, it is also automatically sent to MASP in XML and PDF files.
  • Page 46 1. Press command + A or click Menu and click User Mode > Advanced 2. Click Menu > Import. 3. From the window that appears, select the *.A2C or XML configuration file. The configuration is loaded into the sensor. Door Pro Sensors | V1 | Sensor Configuration...
  • Page 47 System Configuration and Display Learn how to configure the receiver to be able to receive and display Door data. Note: This guide refers to the following version of Scala2: 02.14.x. If you use another version, the visual interface and options may vary. Adding the Sensor to the Receiver You need to add the sensors to the receiver in order to display their data on Scala2.
  • Page 48 Spread Starboard Spread Starboard 21)). with...* Door Sounder Door Sounder Narrow Band Door Sounder Marport PI PI Sensor PI Spread compatible Spread sensor Note: *Choose the Product Name according to the sensor features chosen in MASP. 5. Click Add Sensor.
  • Page 49 Important: Make sure the settings you enter here are the same as in Mosa2. Door Spread Legacy Sensor name displayed in Scala2 and its features. This setting helps detecting the signal of the sensor among other sensor or echosounder signals.
  • Page 50 Click Configure to change filters applied on incoming data. Apply the same positioning (chirp) settings as those entered in Mosa2. Click Apply when you have finished. Door Sounder Pro Sensor name displayed in Scala2 and its features. The version of the communication protocol must correspond to what was set in Mosa2.
  • Page 51 • Choose between 0 and 2 only if no interferences on the vessel (not recommended). • 3 is default setting. • Choose between 4 and 6 if you have issues receiving data. It allows you to receive more data, but be aware they might be wrong data. This setting also helps detecting the sensor signal.
  • Page 52 1. From the top left corner of the screen, click Menu > Customize and enter the password eureka 2. From the top toolbar, click the add icon 3. Open the customize panel, then go to Mx and drag Door 3D View to the page. 4.
  • Page 53 a. From the top left corner, click Menu > Settings. b. Click the Trawl tab and select the models of doors and clumps from the lists, using left and right arrows. 5. You can also change the viewing angle: looking from the trawl toward the vessel (front), or from the vessel toward the trawl (back).
  • Page 54 ◦ Horizontal Camera to see the doors from the front. ◦ Or back. Door Pro Sensors | V1 | System Configuration and Display...
  • Page 55 ◦ Vertical Camera to see the doors from above. ◦ Free Camera to adjust the viewing angle yourself, by clicking and dragging the 3D doors. 7. To display the ground, right-click the 3D view and select Display Ground. You should leave the ground displayed in order to see if the doors are touching it.
  • Page 56 a. To rename the page, right-click the name of the page and click Rename. b. To save the page, right-click the name of the page and click Save Changes. Displaying Single Trawl Spread You need to have Spread sensors that send distance between port and starboard doors. 1.
  • Page 57 3. In Choose type of display, select History Plot. 4. Right-click the history plot and select Vertical. Door Pro Sensors | V1 | System Configuration and Display...
  • Page 58 The history plot becomes vertical. You can see the distance between the port and starboard door. 5. If you have a firmware version 08.03 and above, you can display the battery level on the plot. Right-click the title of the plot and click Battery Indicator. Displaying Door Sounder Echograms You can display echograms from Door Sounder sensors in order to see how doors are placed above the sea bottom.
  • Page 59 1. From the top left corner of the screen, click Menu > Customize and enter the password eureka 2. Open the control panels and from the Mx tab, click + hold Sonar Data from a Door Sounder or Bottom Explorer (Door Sounder with target strength calibration) and drag it to the page display.
  • Page 60 The echogram is displayed. Changing the Distance from the Door Sounder to the Bottom You can change the distance at which the Door Sounder echogram begins. By default, the echogram is displayed beginning from the sensor position. You can increase the distance at which the echogram begins to: •...
  • Page 61 The image below shows the default echogram from Door Sounder sensors. You can see that the echoes of the shoes (1) appear above the echo of the ground (2). The image below shows the echogram received from Door Sounder sensors when a distance is added.
  • Page 62 Replaying Data Recorded on a Memory Card In Scala2, you can replay data that has been recorded in high definition on the sensor memory card. Note: Data in high definition is available only when downloading it from the sensor memory (A2S files). Data received in Scala2 will have a lower definition (SDS files). 1.
  • Page 63 Configuring the Hydrophones You need to configure the hydrophones to correctly receive signals from the sensors. Tip: To help you remembering the configuration, always begin to configure the port hydrophone, then the starboard hydrophone. This way, most of the values associated with port side will be smaller than those of the starboard side (hydrophone number, node numbers...).
  • Page 64 You have added the sensors to the receiver. Tip: A spreadsheet is available on the Useful Resources page of Marport support website to help you complete this page. 1. From the left side of the screen where the system is displayed, click Positioning.
  • Page 65 When they are misaligned, you can calculate their misalignment angle with the following calculations. Tip: A spreadsheet is available on the Useful Resources page of Marport support website to help you complete this page.
  • Page 66 The misalignment angle (angular offset around Z axis) is calculated with the following formula: Sign of Angles You need to add a negative sign (-) to the result if the starboard hydrophone is placed further aft. The sign of the angles is important to receive correct positioning data. Door Pro Sensors | V1 | System Configuration and Display...
  • Page 67 Negative sign (-) Positive sign (+) Configuring Trawl Settings You need to configure trawl settings to display the trawl on the chart and vessel 3D overview. Door Pro Sensors | V1 | System Configuration and Display...
  • Page 68 1. Click Menu > Settings. 2. From the tab Trawl, complete Headline (H), Bridle (B) and Sweepline (S) with accurate measurements of your trawl gear. Adding Data from External Devices You need to add to Scala2: warp lengths, GPS coordinates and heading data received from devices such as winch control systems or GPS compass.
  • Page 69 sensors. However, we strongly recommend to receive warp lengths from a winch control system. Without it, the accuracy of the positioning will be reduced. 1. In the control panels, click NMEA Inputs > Add Input. 2. Choose the type of connection between serial port, UDP or TCP socket. 3.
  • Page 70 NMEA data appears in the NMEA Inputs control panel and in the Ownship panel. LEDs blink green when data is received (it may be steady green if data is received continuously). When communication with the NMEA devices is lost, LEDs do not blink anymore. Trouble: If you see a warning sign in front of data, it means that you receive the same data from more than one device.
  • Page 71 Note: In this procedure, data are transmitted via a UDP port but a connection via a serial port can be possible. 1. Scantrol and Marport computers must be connected together via an Ethernet wired network. Both computers must be on the same sub-network to communicate with each other: 192.168.0.XX.
  • Page 72 4. Set a UDP connection and enter the corresponding port. 5. Clear the Validate Checksum checkbox. Important: If you do not clear this checkbox, you will not receive the data from Scantrol. Door Pro Sensors | V1 | System Configuration and Display...
  • Page 73 Scantrol data are displayed in Scala2. Door Pro Sensors | V1 | System Configuration and Display...
  • Page 74 Installation Learn how to install the sensor on the trawl gear. Installation Principles Angle of Attack The angle of attack is the angle of the door in relation to the towing direction. This angle is important for the efficiency of the doors. It varies between trawl door models, so refer to manufacturer to know the exact angle.
  • Page 75 1. Elevation angle: 15-20° 2. Opening angle: 25-40° 1. Elevation angle: 15-20° Roll Angles for Spread Sensors Roll angle of the sensors depends on the tilt of the doors when fishing. If doors are straight during fishing, you can apply a roll angle of 90°. If doors are tilted inward during fishing, slightly Door Pro Sensors | V1 | Installation...
  • Page 76 roll the pocket so that lines of communication between the sensors stay aligned. If not, you will have sporadic spread readings. Adapt roll angles of pockets according to the tilt of the doors. Door Spread Communication Spread sensors communicate with each other and with the receiver. Lines of communication between them and toward the receiver must be unobstructed.
  • Page 77 Communication toward receiver (46°) Communication between sensors (26°) Communication toward receiver (46°) Communication between sensors (26°) 1. Master sensor 2. Clump sensor 3. Starboard sensor Door Sounder sensors do not communicate with each other, so only lines of communication toward the receiver and bottom must be unobstructed. Installing Sensor Pockets You need to install pockets on each trawl door to hold the door sensors.
  • Page 78 Refer to door manufacturer for details. 1. Use drawings of door pockets to mark the shape to be cut off: Pocket Drawings (on page 99). Note: Ask your local Marport sales office for scaled templates of door pockets. Door Pro Sensors | V1 | Installation...
  • Page 79 2. Cut round openings in the doors. 3. When setting up the alignment bar in the sensor pocket: Note: Master and Starboard sensors need to be oriented in a way they can communicate with each other. The alignment bar in the pocket ensures correct positioning.
  • Page 80 of Attack (on page 99)). Picture below shows angles of attack seen from above the door. 5. You can trace a line with a marker around the pocket at the point it enters the door to remember the correct position. 6.
  • Page 81 9. We recommend to use a protective cage made of metal bars around pockets to protect sensors, like the examples below. Note: Make sure there is sufficient space between the protective cage and the sensor pocket, so that if the cage becomes bent, you can still remove the sensor. Installing Door Spread Sensors You need to install Spread sensors in pockets welded to the trawl doors.
  • Page 82 1. Remove the screw holding the pocket cover. 2. Install the Master sensor (red marker) on the port door and the Starboard sensor (green marker) on the starboard door. 3. The top of the transducer (side with marker on housing) must be oriented toward the vessel and the side of the transducer with the circle or A letter must be oriented toward the opposite door.
  • Page 83 1. Remove the screw holding the pocket cover. 2. Install Door Sounder sensors inside each door pocket: the top of the transducer (side with marker on housing) must be oriented toward the vessel and the side with the circle/ A must points downwards with an angle of 25° in relation to the door. Note: For bottom trawling, install sensors on the lower part of doors.
  • Page 84 Maintenance and Troubleshooting Read this section for troubleshooting and maintenance information. Important: Only an approved Marport dealer can access the internal unit. Warranty will become void if anyone other than an approved dealer tries to do internal maintenance duties on the product.
  • Page 85 2. Connect the charger plug to one of the 4 charging ports. 3. Connect the 3-pin charging connector to the sensor charging pins. The Dock screen and Virtual Charger Room display the state of charge of the sensor. Cleaning the Sensor You need to regularly clean the sensor for proper performance.
  • Page 86 Every 2 years The sensor must be returned to an approved Marport dealer for inspection and maintenance. If the sensor has not been not used for more than 3 months, we highly recommend to check the following points before using it: •...
  • Page 87 • If there is an alarm or if the sensor is not detected by Mosa2, disconnect it from the Dock and do not charge it until it is inspected by a technician. • Send the sensor back for servicing to a Marport office. Door Pro Sensors | V1 |...
  • Page 88 Important: Only Marport technicians can open the sensor to access the internal components. CAUTION: In case of water ingress into the sensor, battery may vent or rupture, causing product or physical damage. Mosa2 does not open due to error message Mosa2 displays an error message saying it cannot be opened.
  • Page 89 • Check that you see Marport Captain icon in the desktop taskbar. If you do not see it: close, then open Mosa2. The icon should appear in the taskbar. Note: Marport Captain is a program running in the background. It allows Mosa2 automatic opening and displays shortcuts to Mosa2 and Scala2 applications installed on the computer.
  • Page 90 The sensor is not running when testing out of water You activated the sensor water switch outside water or in a low level of water (for example for testing purpose) but it does not switch to running mode and does not emit any data. The virtual water switch option may be activated in Mosa2.
  • Page 91 3. Deactivate the Virtual water switch option. Door Pro Sensors | V1 | Maintenance and Troubleshooting...
  • Page 92 Support Contact You can contact your local dealer if you need maintenance on your Marport products. You can also ask us at the following contact details: FRANCE ICELAND Marport France SAS Marport EHF 8, rue Maurice Le Léon Tónahvarf 7...
  • Page 93 Appendix Frequency Plan It is important to carefully plan the setup of your sensors before adding them to the system. You can create a table with a list of frequencies and complete it when you add sensors. Boat & Channel Codes This list shows the standard frequencies for PRP telegrams.
  • Page 94 C-3/CH6 43000 C-4/CH1 42226 C-4/CH2 41852 C-4/CH3 41417 C-4/CH4 41160 C-4/CH5 42700 C-4/CH6 43300 C-5/CH1 42024 C-5/CH2 41690 C-5/CH3 41285 C-5/CH4 41060 C-5/CH5 42900 C-5/CH6 43400 C-6/CH1 39062 C-6/CH2 39375 C-6/CH3 39688 C-6/CH4 40000 C-6/CH5 40312 C-6/CH6 40625 C-7/CH1 38906 C-7/CH2 39219 C-7/CH3...
  • Page 95 Frequencies and intervals The diagrams below show the bandwidth of the different types of Marport sensors and intervals you must respect when adding other sensors. PRP sensors (e.g. Catch sensor, Trawl Speed, Spread sensor...) Example: If the frequency of the sensor is 40kHz, there should be no sensors between 39.9 and 40.1kHz.
  • Page 96 Example: If the frequency of the sensor is 40kHz, there should be no sensors between 39.8kHz and 41kHz. HDTE wide band mode Example: If the frequency of the sensor is 40kHz, there should be no sensors between 39.8kHz and 42.6kHz. Bandwidth Recommended distance Mandatory distance with...
  • Page 97 Example of a system with Spread, Catch, Trawl Speed sensors and Speed Explorer, Catch Explorer, HDTE and Door Sounder. Example of a system with Spread sensors with positioning, Catch sensors, Trawl Explorer and Catch Explorer. Door Pro Sensors | V1 | Appendix...
  • Page 98 Example of a system for purse seining, with a Seine Explorer and depth Seine sensors. Bandwidth Mandatory distance with other sensors Avoid allocating frequencies between 37 and 39 kHz because this range is generally used by echosounders. Door Pro Sensors | V1 | Appendix...
  • Page 99 Pocket Drawings Drawings to manufacture door sensor pockets to be placed on trawl doors. Ask your local Marport Office for scaled templates. Pocket Angle of Attack Door Pro Sensors | V1 | Appendix...
  • Page 100 Pocket for XL Bottles Door Pro Sensors | V1 | Appendix...
  • Page 101 Door Pro Sensors | V1 | Appendix...
  • Page 102 Door Pro Sensors | V1 | Appendix...
  • Page 103 Door Pro Sensors | V1 | Appendix...
  • Page 104 Door Pro Sensors | V1 | Appendix...
  • Page 105 Door Pro Sensors | V1 | Appendix...
  • Page 106 Door Pro Sensors | V1 | Appendix...
  • Page 107 Pocket for Stubby Bottles Door Pro Sensors | V1 | Appendix...
  • Page 108 Door Pro Sensors | V1 | Appendix...
  • Page 109 Door Pro Sensors | V1 | Appendix...
  • Page 110 Door Pro Sensors | V1 | Appendix...
  • Page 111 Pocket for Stubby Bottles with Slim Housing Door Pro Sensors | V1 | Appendix...
  • Page 112 Door Pro Sensors | V1 | Appendix...
  • Page 113 Index Dock Charging 84 Alarms Connecting to Mosa2 15 Concept 21 Door sounder angle 74 Angle of attack 74 Door spread Automatic range 36 Settings 26 Battery Echo sounder 33 Lifetime 18 Elevation angle 74 Boat code 93 Features 10 Calibration Firmware 10 Pitch and roll 28 Frequency plan 93 Channel code 93 Charging 84 Cleaning 85 Configuration Cable 15 Troubleshooting 88 Contact 92 Adding 68...
  • Page 114 Hydrophones 63 NMEA inputs Adding 68 Installing Door sounder 82 Offsets Depth 37 Pitch and roll 28 Temperature 37 Opening angle 74 Maintenance Operational modes 13 Schedule 86 MASP Downloading application file 10 Downloading firmware file 10 Measurement sending sequence 31 Measures 38 Pitch and roll Memory card Calibration 28 Downloading data 39 Pocket Recording 39 Door Sounder 100 Replaying 62 Drawings 99...
  • Page 115 Settings 67 Receiver Adding to 47 Compatibility 47 Compatible firmware 47 Hydrophone configuration 63 Uplink Sensor settings 48 Frequency 23 Replay Power 23 A2S files 62 Virtual water switch 20, 90 Sounding Down 33 Frequency 33 Length 33 Range 33 TVG 33 Warning 21 Up 33 Warp length Spread distances Adding 68 Displaying 51 Scantrol 70 Water ingress 6 Technical specifications 8 Telegrams List 24 Order 24...
