Tech Controllers EU-WiFi X User Manual page 17

VI. SOFTWARE UPDATE
To update the driver and module, select the "Setup Portal" tab on your phone and select the ".... update" option or
download and upload the file.
This option also allows you to view the current version of the program, which is needed to contact the Tech Sterowniki
service.
NOTE
The update is performed separately for the controller and the module.
VII. TECHNICAL DATA
Specification
Power supply
Max. power consumption
Operation temperature
Potential-free cont. nom. out. load
Frequency
Transmission
* AC1 load category: single-phase, resistive or slightly inductive AC load.
** DC1 load category: direct current, resistive or slightly inductive load.
230V +/-10% / 50Hz
230V AC / 0,5A (AC1) *
24V DC / 0,5A (DC1) **
IEEE 802.11 b/g/n
17
Value
1,3W
o
5÷50 C
868MHz
