Delfield ColdPro R1FL 1 Specifications

ColdPro®
Self-Contained Solid Door Reach-In Refrigerators

Model

R1FR 1 section, full door, hinged right
R1FL 1 section, full door, hinged left
R1HR 1 section, half door, hinged right
R1HL 1 section, half door, hinged left
R2FH

Specifications

Exterior: Cabinet exterior front, including door, is
constructed of heavy gauge stainless steel. Exterior
sides are gray coated heavy gauge steel. Back is
aluminum.
Interior: Cabinet interior, including door liner is
constructed of white coated, corrosion resistant
aluminum. Interior floor is heavy gauge stainless
steel. Radius corners are provided in the front, rear
and at the floor. Three white epoxy coated shelves
are supplied per full door section. Shelves rest on
clips which are adjustable on 1" incements on pilasters
affixed to the cabinet interior. Pilasters are removable
without tools for cleaning. Interior light mounted
to the side wall is controlled automaticaly through
a switch mounted at the top of the door opening.
Door openings have plastic breaker strips to retard
condensate formation.
Doors: Exterior is heavy gauge stainless steel, interior
liner is white coated aluminum and is formed to
protrude past the gasket to provide protection. Door
hinges are concealed within the door. Full vertical
Phone: 800-733-8948
980 S. Isabella Rd.
Fax: 800-669-0619
Mt. Pleasant, MI 48858
R2FH 2 section, full doors
R2HH 2 section, half doors
R3FH 3 section, full doors

Standard Features

• Ceiling mounted interor evaporator coil
• Bottom mounted condensing unit
• Hot gas condensate removal
• 6' attached cord and plug
• Exterior digital thermometer
• Stay open door
• No tools magnetic door gasket
• Epoxy coated shelves - 3 per section
• One piece formed interior door liner
• Full integral, vertical door handle
• Casters mounted from factory
• One year parts and labor warranty
• Additional 4 year compressor part
warranty
length door handle is integrated into the door exterior.
Keyed door lock is mounted in the top of the door and
engages into a strike mounted at the top of the door
opening. Door gaskets are magnetic and mount to the
door, snapping into place and are removable without
tools.
Refrigeration system: Evaporator coil is mounted
to the interior ceiling. Condensing unit is located at
the bottom of the cabinet, below the storage area.
Environmentally freindly R134A refrigerat is used.
System has the capability of maintaining between
36˚F and 40˚F in normal foodservice operational use.
Refrigerant is metered using a capillary tube. Operation
is controlled through an adjustable electromechanical
thermostat located on the evaporator coil on the interior
of the cabinet. Airflow discharges from te rear of the
evaporator coil down the back wall. Return air is drawn
into the evaporator coil from the front with the assist for
fans. Condensate evaporation is automatic using hot gas
from normal refrigeration system operation.
Other: Unit is supplied with a 6' cord and plug attached.
4" casters with an overall height of 5" are mounted on the
unit from the factory.
www.delfield.com
Project __________________________________
Item _____________________________________
Quantity _________________________________
CSI Section 11400
Approved ________________________________
Date ____________________________________
Options & Accessories
• 6" adjustable legs
• Additional epoxy coated shelves
