Delfield KCU-36 Specifications

Short Form Specifications
Exterior Body is seamless, one-piece molded fiberglass, having perfectly smooth
exterior surface with all corners fully rounded. The fiberglass reinforced polyester
(F.R.P.) is molded with permanent color. Stress points are internally reinforced.
Exterior top is constructed of 14-gauge stainless steel, welded, ground and
polished into one integral unit. Top is fabricated with square exterior corners. Top
is reinforced and includes a stainless steel drain trough with a removable stainless
steel anti-splash drip gate. Drain trough has a 1" (2.5cm) I.P.S. drain plumbed to
a drain valve located at the right bottom of the unit. Drain trough is located on
the customer's side of counter top.
Casters; unit is mounted on 5" (12.7cm) diameter swivel casters with non-
marking polyolefin tires and plate brakes. Overall height of caster assembly
is 6" (15.2cm).
The following applies to SCU Series only
KCU units have a single door dry compartment constructed of 18-gauge stainless
steel. Compartment is equipped with stainless steel shelf. Doors are double-wall
construction, with stainless steel front panel. Mechanical access door available
upon request.
KCU-36 one compartment, 24" wide with one door
KCU-50, one compartment, 36" wide with two doors
KCU-60, one compartment, 48" wide with two doors
KCU-74, one compartment, 48" wide with two doors
KCU-96, two compartments, 36" wide with two doors each
Optional Accessories and Modifications
A) 12" (30.5cm) wide stainless steel fold-down tray slide
C) 10" (25.4cm) wide three-bar fold-down tray slide
D) 10" (25.4cm) wide composite fold-down cutting boards
E) 10" (25.4cm) wide stainless steel fold-down work shelf
F) Line-up interlock device
FF) Dual service drain troughs
P) Open understorage with shelf (KCU-NU Series only)
Q) *120V/60Hz/1ø, 10 amp convenience outlet with breaker
SG5A) Single dry insert with doors (KCU-NU Series only)
SG5B) Double dry insert with doors (KCU-NU Series only)
ST) Stainless steel trim strips
U) 14" x 30" (35.6cm x 76.2cm) stainless steel end drop shelf
UU) Molded fiberglass trim strips
V) 6" (15.2cm) high adjustable stainless steel legs in lieu of casters
*Inclusion of this options will alter the electrical specifications of unit.
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
PROJECT
ITEM #
QUANTITY
APPROVAL
KCU & KCU-NU
Mobile Beverage Counters
Model KCU-50-NU
(pictured with optional legs)
DATE
