Summary of Contents for Snom D735
- Page 1 Connecting your business D735 Short User Manual V: 10/29/2024 - 2...
-
Page 2: Getting Started
Footstand Ethernet cable: 1.5 m Documentation (2) Get t ing t o know t he D735 component s The hardware components of the D735 can be summarized as follows: Audio devices → 1 - 4 Display and indicators → 5 - 6 Hard keys →... - Page 3 Ethernet (PoE), IEEE 802.3af, class 3 EHS adapter: RJ12-6P6C socket Corded handset: RJ9-4P4C socket Headset: RJ9-4P4C socket Wireless int erf aces −/− If PoE is not available Not included in delivery Optional V: 10/29/2024 - 2 © 2024 Snom Technology GmbH 3/20...
- Page 4 Ethernet connection line. Snom phones are plug-and-play. Once the phone is connected to your network, it will begin to initialize. If your local network or VoIP provider supports Snom's auto provisioning features , the phone will start up automatically without interruption.
- Page 5 Short User Manual Getting to know the display and controls Display (see → Getting started → Getting to know the D735 components → 5) This display presents the following information: In idle mode: When the phone is active: (1) Inf o bar/st at us line In idle mode: when there are active status messages →...
- Page 6 Depending on the current activity of the phone, the function key line will present various functions that can be Context-sensitive, activated by pressing the function key underneath the respective symbol. (see → programmable function symbols and function keys ) Getting started → Getting to know the D735 components Call indicat or (see → → 6) The bright-red LED situated on the top right corner of the phone indicates incoming, ongoing, held, and missed calls.
- Page 7 Alphanumeric keypad (see → Getting started → Getting to know the D735 components → 9) 1 alphanumeric keypad consisting of 12 hard keys, located in the center of the lower device part. In edit ing mode: Press for one second to change input mode (numerals >...
- Page 8 Short User Manual Getting started → Getting to know the D735 components Audio cont rol keys (see → → 10) 5 audio control keys are used to adjust the volume, for muting and unmuting the microphone, to activate speakerphone and headset mode.
- Page 9 Short User Manual Getting started → Getting to know the D735 components Navigat ion, conf irmat ion, and cancel keys (see → → 12) They can be programmed with the key events available in their drop-down menus. You can select a different key event to be available on each respective key when the phone is in idle mode.
- Page 10 Short User Manual Putting the D735 into operation Init ializing and regist ering t he phone Not e: You will need the regist rat ion inf ormat ion received from your Internet service provider or your network administrator - normally the phone or ext ension number, the password, and the regist rar (SIP domain).
- Page 11 Not e: Snom phones can be operated in administrator or user mode. In administrator mode, all settings are accessible and can be modified; in user mode, a number of settings are not accessible. → Def ault set t ing: administrator mode If your phone is administered centrally, user mode may be the rule.
- Page 12 Navigation also press the blinking line key. key: center Terminat ing calls When using the handset: place the handset in the cradle or Press When using speakerphone or a headset: Cancel V: 10/29/2024 - 2 © 2024 Snom Technology GmbH 12/20...
- Page 13 Hold Retrieve following symbol If the other party hangs up while on hold, the call is terminated on your phone as well and the LED indicators are turned off. V: 10/29/2024 - 2 © 2024 Snom Technology GmbH 13/20...
- Page 14 Hold Establish conference Terminate the conference and → Press the connections to both parties by returning to the conference Back to conference Cancel screen. V: 10/29/2024 - 2 © 2024 Snom Technology GmbH 14/20...
- Page 15 → You may briefly see screen messages Ended C 102 and Ended B 101 indicating that the transfer was completed. B (101) is in a call with C (102) now. V: 10/29/2024 - 2 © 2024 Snom Technology GmbH 15/20...
- Page 16 101 and Ended C 102 indicating that the transfer hold or the first of the was completed. B (101) is in a call with C (102) now. remaining calls on hold will then appear on- screen (D, 103). V: 10/29/2024 - 2 © 2024 Snom Technology GmbH 16/20...
- Page 17 Dial the number (D, 103) you want to transfer the call to blindly (unannounced), or select one from one of the available phone directories. → C (102) is ringing D (103) now. Your active call (B, 101) reappears on- screen. V: 10/29/2024 - 2 © 2024 Snom Technology GmbH 17/20...
- Page 18 The red dot indicates the arrival of new missed messages since the last time the missed calls were viewed. It is removed from the list of all calls and turns blue in the list of missed calls once the list has been viewed. V: 10/29/2024 - 2 © 2024 Snom Technology GmbH 18/20...
- Page 19 Sof t ware updat e Manual updat e Aut o provisioning Go to Snom's Firmware Update Center and find 1. Open the phone’s web user interface (WUI) and navigate to the Advanced Settings page > Update the latest firmware version for your phone.
- Page 20 Perf orming a PCAP t race Important information This Short User Manual f or D735 has been derived from the more extensive user manual to give users a more concise overview in their own language. Please refer to the D735 user manual regarding the following...
