Max Trainer M9: My machine is seized, why won't it move?
Follow this troubleshooting guide to help resolve issues involving a seized-up Max Trainer M9.
Some common complaints may include:
Pedals are stuck and won't move
Fan making contact with the motor or frame
Jammed upper or lower belts
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
5mm, 6mm hex/Allen wrenches, or Allen wrenches from
the hardware card included with your machine
14mm socket wrench
Crank puller (if removing crank arms for
troubleshooting)
Flashlight
1.
Check that the crank arms are opposite each other 180 degrees (reference 1). If the crank arms are not inline
and opposite each other, reorient the crank arms following the "Replace the Crank Arms" section of the
service manual
about:blank
Max Trainer M9:  My machine is seized, why won't it move?
[11782.A]
.
Diagram showing how the crank arms should be oriented when properly installed.
(Reference 1)
