Bowflex Max Trainer Max Total 16 Troubleshooting Manual

3/11/24, 9:43 AM
Max Trainer Max Total 16: Why is there no power to my machine or
console?
Follow this troubleshooting guide to help resolve power issues on the Max Trainer Max Total 16.
Some common complaints may include:
Console does not light up
Console lights up, then turns off
Console only lights up partially
Contents:
Power cycle; inspect display and power adapter
Check cable connections:
Behind the console
Bottom of the console mast
Power inlet wire connection
Power cycle; inspect display and power adapter
1.
Power cycle your machine:
a.
Unplug the power cord from both ends (machine and wall)
b.
Leave the cord unplugged for 5 minutes to allow the machine to completely power down.
c.
Plug the power cord back into your machine.
d.
The console may need several minutes to boot up if a firmware update was recently completed
e.
If the console will not boot up after attempting a firmware update,
2.
Check to see if the display will light up at all.
Remove the protective film from the console display if you have not already done so
If the console only turns on partially or flickers/is dim,
3.
Inspect the power adapter for damage.
Unplug the adapter from both ends.
Inspect the entire length of the cord for any visible wires, cuts, breaks, or crimps. If the cord of the power
adapter is damaged,
Inspect the power adapter end for damage, such as bends or the tip being broken. If the tip of the power
adapter is damaged,
4.
Check to see if the power outlet is working properly.
Plug in another device, such as a lamp, and test to see if it turns on.
If the outlet is not working, test your machine on another
5.
If the issue persists, continue to the next section.
about:blank
Max Trainer Max Total 16:  Why is there no power to my machine or console?
order a Power Adapter [11822.E].
order a Power Adapter and Power Plug
order a Console
order a Power Adapter [11822.D].
Inlet [11822.F].
11822
outlet [ .G].
ID: 11822.4
[11822.A]
.
[11822.B]
.
[11822.C]
.
1/5
