    Proprietary CBT 7800914 Issue 10 1 Scope & Audience This manual provides instructions for safe installation and use of Interrogator Units within the CBT 7800000 series. This covers the QuantX and ODH-5X variants. Operation of the software used to control the IU and record and visualise data is described elsewhere.
  • Page 6: Cbt 7800000 Interrogator Unit (Iu) System Overview

    Proprietary CBT 7800914 Issue 10 2 CBT 7800000 Interrogator Unit (IU) System overview General Description The CBT 7800000 Interrogator Unit (IU) is available in two variants, intended for a variety of Distributed Fibre Sensing (DFS) applications. The QuantX is optimised for monitoring and protection of long linear assets and infrastructure, whereas the ODH-5X variant is optimised for seismic profiling, hydraulic fracture monitoring and flow monitoring in down-hole for fibres longer than 10 km.
  • Page 7: Rear Panel

    Proprietary CBT 7800914 Issue 10 switches are in the Laser Enable position (and the rear panel Interlock Port is enabled) the red “Laser” LED is illuminated. The “Power” LED shows the status of critical internal power supplies. The “Status” LED gives a high level indicator of the IU’s status – red indicating that the IU is in a state where normal data acquisition cannot take place or if persistent, a fault.
  • Page 8: Connections

    Proprietary CBT 7800914 Issue 10 • GPS input & output – (ODH-5X, Option for QuantX) See Section 2.2.6 • Trigger – (ODH-5X variant only) - See Section 2.2.7 The E2000 connector for the sense fibre is mounted on the faceplate, which can be removed for cleaning the connectors –...
  • Page 9 Proprietary CBT 7800914 Issue 10 Figure 2-3 Mellanox Cable Figure 2-4 Mellanox cable orientation in the back of the IU. Figure 2-5 Mellanox cable orientation in the back of the PU Proprietary © OptaSense Ltd 2023 CBT 780000 IU User Manual ENG/TEMP/OPT/342/4.0...
  • Page 10: Laser Interlock

    Proprietary CBT 7800914 Issue 10 2.2.4 Laser Interlock To enable Laser Emission the Front and Rear key-switches must be in the Laser Enable (vertical) position, and connection must be made between pins 1&2 and pins 3&4 of the laser interlock connector The laser interlock connector can be wired to a switch triggered by the opening of a door or enclosure such that when the door/enclosure is opened, the lasers will be automatically disabled.
  • Page 11: Gps (Odh-5X As Standard; Option On Quantx)

    Proprietary CBT 7800914 Issue 10 The IU is designed to operate on any fibre which is single-mode at 1550 nm. We recommend using fibres which are compliant with ITU T G.652 or equivalent (for example Corning® SMF 28®). For operation on other fibres, contact OptaSense for information on optimizing the configuration.
  • Page 12: Installation

    Proprietary CBT 7800914 Issue 10 3 Installation Handling The IU’s mass is 31 kg, therefore care must be taken when lifting: a two person lift may be required. Please consult your HSE function for guidance. Handles are located on the front and rear. These should be used for lifting or manoeuvring the IU.
  • Page 13: Fitting Shipping Mounts

    Proprietary CBT 7800914 Issue 10 Figure 3-1 - Shipping Mount Blanks Diagram 3.3.2 Fitting Shipping Mounts The shipping mounts MUST be replaced prior to shipping the unit by land, sea or air to prevent permanent damage to the IU. Failure to install the shipping mounts prior to transport will invalidate the warranty and may incur additional repair charges.
  • Page 14 Proprietary CBT 7800914 Issue 10 2.1 Secure side locking flanges (2) with M6 x 30mm Tx Csk screw. 2.2 Secure top locking flange (1) with M6 x 50mm Tx Csk screw. 2.3 Secure front locking flange (3) with M6 x 50mm Tx Csk screw. Figure 3-2 - Shipping Mounts Diagram Proprietary ©...
  • Page 15: Cabinet Mounting

    Proprietary CBT 7800914 Issue 10 Cabinet Mounting 3.4.1 CAUTION for Cabinet Mounting The mass of the IU is 31 kg. The user must ensure that the cabinet will remain stable, particularly when the IU is to be mounted high in the cabinet. It may be necessary to secure the cabinet to the floor or walls to ensure stability both during and after installation.
  • Page 16 Proprietary CBT 7800914 Issue 10 11. Slide bracket to rack fixings: a. 10 off M5 x 12 Flanged Tx Button ISO 7380-2 A2 ST/ST b. Tx 25 driver 12. Optional Washers for slide bracket to rack fitting: a. 10 off M5 DIN 9021 Flat Washer A2 ST/ST 13.
  • Page 17 Proprietary CBT 7800914 Issue 10 Figure 3-5 - Assembly of Front bracket (5) and Slide Outer (2) • Add appropriate rear bracket depending on rack depth and fit using fixings (10) as above. Figure 3-6 - Assembly of Rear bracket (3) and slide outer (2) •...
  • Page 18 Proprietary CBT 7800914 Issue 10 Figure 3-7 - Slide bracket assembled into rack, cage nuts also fitted. • Place slide bracket assembly between the front and rear rack uprights and fix in place using Accuride M5 Bar Nut (8) and M5 Tx Flanged fixings (11). Depending on the rack being used, it may be necessary to use the M5 washers (12) to get a good bearing surface, as shown in Figure 3-7.
  • Page 19 Proprietary CBT 7800914 Issue 10 Step 5 – Insert IU into rack (2 persons required) • Carefully insert the IU into the rack, ensuring the slide inner engages with the bracket assembly. • After around 100 mm of insertion the extraction locks will engage which need to be depressed to allow the slide to be fully inserted.
  • Page 20: Thermal Management

    Proprietary CBT 7800914 Issue 10 Thermal Management The maximum operating ambient temperature (measured 25 mm in front of the Front Panel air intakes) is 50°C. The built-in Fan Module must be fitted and connected at all times. The installation location must allow air to enter the front panel intakes and to circulate freely around the Heatsink, and with clear space for the fan exhaust above the rear panel heatsink.
  • Page 21: Laser Safety

    Proprietary CBT 7800914 Issue 10 4 Laser safety The QuantX and ODH-5X IUs generate Class 3R invisible laser radiation. When correctly connected to an optical fibre, the emitted radiation is completely enclosed within the optical fibre cable, however, if the continuity of the optical fibre is broken (deliberately or accidentally) then Invisible Laser Radiation will become accessible.
  • Page 22: Operation

    Proprietary CBT 7800914 Issue 10 5 Operation Connection To operate the IU system, first connect the sense fibre, control ethernet cable, optical data cable and power as per Section 2.2. Trigger and GPS cables should also be connected where these functions are required. Start up Turn on the main power switch on the rear panel.
  • Page 23: Modes Of Operation

    Proprietary CBT 7800914 Issue 10 5.3.1 Modes of Operation The IU produces Quantitative phase and amplitude in all operating modes. Additionally, the user has the flexibility of operating in either “Single Carrier” or “Dual Carrier” mode. In Single Carrier mode a single pulse is launched, and the backscatter analyzed to produce the quantitative data set.
  • Page 24 Proprietary CBT 7800914 Issue 10 Figure 5-2 – Performance envelope graphs for 8 m Gauge Length for Dual Carrier operation. Figure 5-3 – Achievable fibre interrogation length at selected Gauge Length operation for Dual and Single Carrier modes Proprietary © OptaSense Ltd 2023 CBT 780000 IU User Manual ENG/TEMP/OPT/342/4.0...
  • Page 25: Maintenance

    Proprietary CBT 7800914 Issue 10 6 Maintenance General In normal use the IU should not require any user maintenance other than ensuring the cleanliness of the optical connector. If required, the outer surface of the system can be cleaned using a cloth moistened with water or Isopropanol (IPA).
  • Page 26 Proprietary CBT 7800914 Issue 10 Figure 6-2 - Removal of fibre connector panel fixings Remove the internal Diamond 0.1dB E2000-APC connector from the uniter, taking care to avoid damage to the end face of the ferrules. Using a proprietary lint-free bud, clean the bore of the uniter ensuring it is free of all contamination.
  • Page 27: Fuse Replacement

    Proprietary CBT 7800914 Issue 10 Fuse Replacement If a fuse requires replacement this can be carried out by withdrawing the fuse drawer from the IEC inlet, removing the failed fuse and replacing it with a suitable 5 mm x 20 mm 4 A anti-surge fuse [LitelFuse 0213004.MXP].
  • Page 28: Fan Module Replacement

    Proprietary CBT 7800914 Issue 10 Figure 6-6 - Fuse location Fan Module Replacement In the event of fan failure, diagnosed by an alarm generated by the IU, or by over-temperature alarms being shown to be due to failed fan, a replacement CBT 7807000 Fan Module supplied with the IU should be fitted. To replace the Fan Module, switch off the two laser key switches and remove the keys to prevent the lasers being re-activated, set the mains switch to Off and remove the IEC power cable.
  • Page 29 Proprietary CBT 7800914 Issue 10 Figure 6-8 – Removal of the Fan Module Fit Replacement Module into the socket underneath the Heatsink, paying specific attention that the Fan Cable routes through the slot on the bottom-left side of the Heatsink. To avoid the cable getting caught between the work surface and the Heatsink, slightly lift the IU by the Rear Handle.
  • Page 30: Service

    Proprietary CBT 7800914 Issue 10 7 Service Other than the maintenance procedures described in Section 6, the CBT 7800000 Interrogator Unit is not user serviceable. If a fault occurs the device should be returned to OptaSense for repair. Proprietary © OptaSense Ltd 2023 CBT 780000 IU User Manual ENG/TEMP/OPT/342/4.0...
  • Page 31: Specifications

    Proprietary CBT 7800914 Issue 10 8 Specifications Compliance The CBT 7800000 is CE and UKCA marked, EU and UK declarations of conformity available on request. 8.1.1 Standards The CBT 7800000 is designed and tested to the following standards: Laser Products EN 60825-1:2014 Safety of Laser Products 21 CFR 1040.10...
  • Page 32: Electrical Specifications

    Proprietary CBT 7800914 Issue 10 Electrical Specifications 8.3.1 Power The IU is designed for operation on a wide range of mains input. The IU contains surge suppression, however for maximum reliability an external surge suppressor and/or UPS is recommended. Where a UPS is used the provision of cooling during a power outage must be considered to prevent overheating of the IU.
  • Page 33: Physical Specifications

    Proprietary CBT 7800914 Issue 10 Physical Specifications The principal dimensions are as follows: Width (in rack) To fit 19” Rack Depth (in rack) Depth (including handles) Height Mass Rack Depth (between vertical rails, mounting using supplied kit) 350 - 700 A General Arrangement drawing is shown in Figure 8-3.
  • Page 34 Proprietary CBT 7800914 Issue 9 Figure 8-1 – QuantX & ODH-5X Warning labels. Confidential © OptaSense Ltd 2021 CBT 7800000 IU User Manual...
  • Page 35 Proprietary CBT 7800914 Issue 9 Figure 8-2 - Rear Panel showing location of Laser Enable Key-switch, Interlock Connector and labelling. Proprietary © OptaSense Ltd 2021 CBT 7800000 IU User Manual ENG/TEMP/OPT/342/4.0...
  • Page 36 Proprietary CBT 7800914 Issue 9 Figure 8-3 - General Arrangement of the Interrogator Unit Proprietary © OptaSense Ltd 2021 CBT 7800000 IU User Manual ENG/TEMP/OPT/342/4.0...
