Summary of Contents for Luna LSM10
- Page 1 MAINTENANCE AND USER’S MANUAL IMPORT-EXPORT AKTIVE-REACTIVE SINGLE PHASE ELECTRONIC ELECTRICITY METERS LSM SERIES LSM10 KK_EN_LSM10_19.01...
-
Page 2: Manufacturer Information
MANUFACTURER INFORMATION: LUNA ELEKTRİK ELEKTRONİK SAN. VE TİC. A.Ş. 10001 Str. No:9 Atatürk O.S.B. 35620 Çiğli / İzmir - TÜRKİYE Tel: +90 232 472 15 45 Fax: +90 232 472 15 50 www.lunatr.com SERVICES: Main Technical Service: LUNA ELEKTRİK ELEKTRONİK SAN. VE TİC. A.Ş. - Page 3 Calibration Station, the warranty will be void. Defects due to misuse of determined technical features in user’s manual of LUNA Electronic Electricity Meters (usage out of range set in the manual) are not considered under cover of warranty. LSM Series Active-Reactive Multi Tariff Single Phase Electronic Electricity Meters are, Hardware and software of, designed by R&D department of...
- Page 4 • Despite having OUTDOOR feature, LSM10 Active-Reactive Sing- le Phase Electronic Electricity meters should by no means be exposed to immersion. Outer surfaces of the meters should be cleaned by solvents.
-
Page 5: General Features
1. GENERAL FEATURES 1.1. Metrology LSM Series Active-Reactive Electric Electricity Meters can measure and record active import energy. Voltage and current measurement, and energy calculation is carried out by the microprocessor in the me- ter. If energy is in reverse direction, the import meter takes its absolute value and assumes it as positive. - Page 6 weekly profiles can be defined for seasons. Different tariffs can be assigned for each day in a week. Unlimited holidays can be defined for the next 10 years. 1.3.3. Passive Tariffs (Optional) Passive tariffs are used in order to change the used tariffs structure after a certain date.
- Page 7 Tariff Hours Automatic Daylight Saving • • Parameter Maximum Demand Period • New Password • Load Profile Period • Other than the parameters above, none of the meter parameters can be changed in any way. 1.7. RTC RTC is in compliance with EN 61038 protocol. The maximum time deviation is ±0.5 second daily.
- Page 8 disappears and the fault is cleared when date and time information is written to the meter. The meter can optionally display a constant message on its screen in this case unless the menu button is pressed and auto scrolling is off. 1.9.5.
- Page 9 rently 1: PLC module is connected to the PLC network 1: the current on at least one of the phases is 1: RF module is connected to the RF network reversed 1: reserved 1: reserved 1: phase sequence is correct 1: phase R is on 1: reserved 1: phase S is on...
- Page 10 The statuses can also be easily read with the LSM meter reading software using the Status tab. After reading the statuses, the bits which are set ap- pear in bold on the left with their meanings. Note that, some of the status bits may not be available in all meter models.
- Page 11 The meter can have an integrated RF module to support RF commu- nication. Then, it can be readout and controlled using a Data Concent- rator(DC) or a GSM Modem and from LUNA Metrum remotely. The RF module uses 868MHz ISM band and a custom protocol by LUNA meters for communication.
- Page 12 1.10.8. Calendar Support LSM meters support Gregorian, Hijri and Persian calendars. All re- cords and calendar events are stored according to the calendar type. Default calendar of the meter is Gregorian. 1.10.9. kWh Limitation If the meter includes this feature, it is activated by default. It can be disabled by writing 0 or re-activated by writing 1 to 96.74.22 OBIS code.
- Page 13 the respective event is recorded and the counter and total duration of that event are updated. The start-end time of over voltage and under voltage events can be read using the OBIS codes of 96.77.30*1,...,12 and 96.77.40*1,...,12 respectively. The total number and duration of over voltage events can be read with OBIS codes of 96.77.30 and 96.77.31, whereas those of under voltage events can be read using the OBIS codes of 96.77.40 and 76.77.41 respectively.
- Page 14 disconnect after that. counter_lr_auto_ouv(96.73.23): the number of times the meter is disconnected or connected if feat_lr_auto_ouv_err (96.74.20) is 1 or 3 dur_lr_auto_ouv_err(96.73.26): the event duration after which the latching-relay of the meter will be disconnected if feat_lr_auto_ouv_ err(96.74.20) is not 0 or limit is not reached in limiting modes (1 and 3) feat_lr_reset_limit_endofmonth(96.74.21): If this feature is enabled (value 1), the number of times the meter was disconnected/connected is reset and the blocking of lr is removed at the end of every month.
- Page 15 This feature works independently from Over/Under Voltage Record feature. Moreover, this feature overrides Auto Disconnect LR on Over/ Under Voltage (96.74.20) feature. In other words, if both features (96.74.26 and 96.74.20) are enabled, 96.74.26 feature will be used; whereas, if 96.74.26 is disabled (value 0) and 96.74.20 is enabled (value 1), 96.74.20 feature will be used.
-
Page 16: Operating Elements
After the mounting the meters, in case of intervention by any individual or organization apart from authorized personnel, the non-volatile me- mory will record this intervention. 4. LCD SCREEN INFORMATION By the definition of MID regulation, on the LCD screen of LSM10 FK.104 (Rev.01) 19.10.2018... - Page 17 meters, there is 6 integers and 3 decimals. Option 1 Option 2 Option 3 5. MENUS 5.1. Main Menu When the device is connected to energy, the list indicating Total Im- port Active Energy menu will appear in terms of kWh on the LCD scre- en.
-
Page 18: Time Screen
REACTIVE-CAPACITIVE SCREEN Indicates the consumed reactive- ca- pacitive energy. DEMAND SCREEN Indicates maximum positive active energy demand value for determined time interval. EXPORT T TOTAL TARIFF The menu that shows total export energy amounts, recorded from other defined tariff segments. EXPORT T1 TARIFF The menu is as records of the export energy used at the specified time in-... - Page 19 LOW BATTERY NOTIFICATION This notice appears on the screen when the battery level is lower than a certain voltage level.. When you see this sign, please inform authorized personnel and/or organization. REAL TIME CLOCK FAILURE NOTIFICATION This sign means Real-time clock is disrupted for any reason. In this case, the meters write the values at the “Tariff T1”.
- Page 20 Instant power factor screen Instant frequency screen Total consumed active energy in previous month menu (T blinks) Total consumed energy T1 tariff in previous month menu (T1 blinks) Total consumed energyT2 tariff in previous month menu (T2 blinks) Total consumed energy T3 tariff in previous month menu (T3 blinks) Total consumed energy T4 tariff in previous month menu (T4 blinks)
- Page 21 6. SPHYSICAL DIMENSIONS OF THE METER 78 mm 102 mm 58 mm FK.104 (Rev.01) 19.10.2018...
- Page 22 7. CONNECTIONS 7.1. Option 1 Phase LOAD Neutral L - L - N Connection Diagram 7.2. Option 2 Phase LOAD Neutral L - L - N - N* Connection Diagram FK.104 (Rev.01) 19.10.2018...
- Page 23 8. GENERAL MECHANICAL SCHEME HANGER LCD SCREEN ACTIVE ENERGY LED REACTIVE ENERGY LED MENU BUTTON OPTICAL PORT Seal of LUNA Elektrik Elektronik San. Tic. A.Ş. Distribution Company Seal Spots FK.104 (Rev.01) 19.10.2018...
-
Page 24: Ab Uygunluk Beyani
AB UYGUNLUK BEYANI ( No 0002 ) EU DECLARATION OF CONFORMITY Cihaz modeli/Cihaz : LSM10 Instrument model/Instrument Sayacın seri numarası: Serial number of the meter: Üretici adı ve adresi : LUNA A.S. Name and address of the manufacturer 10.001 Str. No:9 Ataturk O.S.B. - Page 25 FK.103 (Rev.00) 21.10.2015...
- Page 26 FK.103 (Rev.00) 21.10.2015...
-
Page 27: Technical Specifications
TECHNICAL SPECIFICATIONS LSM10 TYPE Serial Number Nominal Voltage 230V Oprating -20%Un, +15%Un Voltage Nominal Current 5(100)A (max) AC 1000 imp/kWh Test Output Starting Current 20mA Nominal 50 Hz ± %2 Frequency Hz Directly connected to primary Method of active-reactive meter... - Page 28 ELECTRONIC ELECTRICITY METERS SMART GRID SYSTEMS Phone: +90 232 472 15 45 Fax: +90 232 472 15 50 info@lunatr.com www.lunatr.com...
