- Page 1 BSW-350 LED Moving Head...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 13.09.2023, ID: 549467...
-
Page 3: Table Of Contents
7.4 Settings menu........................ 17 7.5 Gobos..........................21 7.6 Functions in 26-channel DMX mode..............21 7.7 Functions in 32-channel DMX mode..............25 Technical specifications....................30 Plug and pin assignments....................31 Troubleshooting........................32 Cleaning............................ 33 Protecting the environment................... 34 BSW-350 LED Moving Head... -
Page 4: General Information
Warning signs Type of danger Warning – high-voltage. Warning – dangerous optical radiation. Warning – suspended load. Warning – danger zone. BSW-350 LED Moving Head... -
Page 5: Safety
Switch off the device before any work is performed in the movement range or immediate vicinity of the device, or if unauthorised persons are in that area. BSW-350 LED Moving Head... - Page 6 Only operate the device from professionally installed mains sockets that are protected by a residual current circuit breaker (FI). As a precaution, disconnect the device from the power grid when storms are approaching or it the device will not be used for a longer period. BSW-350 LED Moving Head...
-
Page 7: Features
Automatic position correction Temperature-controlled fan with silent mode Lens diameter: 150 mm Two moving axes: – Inclination (tilt, 270°) – Rotation (pan, 540°) Frost filter 11 static gobos and 7 rotating gobos (replaceable) 2.4-inch TFT colour display BSW-350 LED Moving Head... -
Page 8: Installation
Switch off the device before any work is performed in the movement range or immediate vicinity of the device, or if unauthorised persons are in that area. BSW-350 LED Moving Head... -
Page 9: Mounting Options
Omega brackets. These are used to attach the flight adapters (half coupler, trigger clamps, C-hooks etc.). The safety cable must be threaded through the cut-outs on the bottom or the carrying handles. A Quick locks for Omega brackets B Openings for safety cable BSW-350 LED Moving Head... -
Page 10: Starting Up
Connect the DMX output of the master device to the DMX input of the first slave device. Then connect the DMX output of the first slave device to the DMX input of the second slave device and so BSW-350 LED Moving Head... -
Page 11: Connections And Operating Elements
8 [RJ45 OUT] | Network connection for additional devices 9 [DMX IN] | DMX output, 3-pin 10 [DMX OUT] | DMX output, 3-pin 11 [DMX IN] | DMX output, 5-pin 12 [DMX OUT] | DMX output, 5-pin BSW-350 LED Moving Head... -
Page 12: Operation
Use [UP] and [DOWN] to select an address between 1 and 512. Confirm your selection with [ENTER]. ð The desired address is saved. To exit the menu, press [MENU], or wait 30 seconds. Make sure that the address matches the configuration of your DMX controller. BSW-350 LED Moving Head... - Page 13 ð The desired mode is saved. To exit the menu, press [MENU], or wait 30 seconds. Inverting the display To rotate the display by 180°, press [DISPLAY REV]. To rotate the display by 180° again, press [DISPLAY REV]. BSW-350 LED Moving Head...
- Page 14 Press [Up] and [Down] to select the required submenu. Confirm your selection with [ENTER]. If you want to reset the respective settings, select ‘Yes’ . If you do not want to reset anything, select ‘No’ . BSW-350 LED Moving Head...
- Page 15 Use [UP] and [DOWN] to select the ‘Factory Reset’ submenu. If you want to reset the device to the factory defaults, select ‘Yes’ . If you do not want to reset anything, select ‘NO’ . To exit the menu, press [MENU], or wait 30 seconds. BSW-350 LED Moving Head...
-
Page 16: Menu Overview
Gobo Wheel 2 0-255 0-255 Cyan Zoom 0-255 Magenta 0-255 Focus 0-255 Yellow 0-255 Prism Wheel 0-255 0-255 Prism Rotation 0-255 Color Wheel1 0-255 Frost 0-255 Gobo Wheel1 0-255 Pan/Tilt Macro 0-255 Gobo1 Rot 0-255 Pan/Tilt Speed 0-255 BSW-350 LED Moving Head... -
Page 17: Settings Menu
Universe 0-255 Celsius Temp LED Temp Temp Unit Fahrenheit 7.4 Settings menu The following basic settings can be adjusted in the settings menu: Tilt Color Gobo 1 Gobo 2 R-Gobo Prism R-Prism Angle/Frost Focus BSW-350 LED Moving Head... - Page 18 Use [UP] and [DOWN] to select a value between –128 and 127. Confirm your selection with [ENTER]. ð The settings are saved and immediately effective. To exit the settings menu, press [MENU] or wait for 30 seconds. BSW-350 LED Moving Head...
- Page 19 Press and hold [ENTER] for about 3 seconds. ð The settings menu opens up. Use [UP] and [DOWN] to navigate to menu item ‘Prism’ . Confirm your selection with [ENTER]. Use [UP] and [DOWN] to select a value between –128 and 127. BSW-350 LED Moving Head...
- Page 20 Use [UP] and [DOWN] to select a value between –128 and 127. Confirm your selection with [ENTER]. ð The settings are saved and immediately effective. To exit the settings menu, press [MENU] or wait for 30 seconds. BSW-350 LED Moving Head...
-
Page 21: Gobos
Pause effect (5 s to 1 s) 128…250 Strobe (ascending) 251…255 Strobe open 0…255 Colour intensity of cyan 0 to 100% 0…255 Colour intensity of magenta 0 to 100% 0…255 Colour intensity of yellow 0 to 100% BSW-350 LED Moving Head... - Page 22 018…029 Gobo 2 030…041 Gobo 3 042…053 Gobo 4 054…065 Gobo 5 066…077 Gobo 6 078…089 Gobo 7 090…101 Gobo 1 shake effect (ascending) 102…113 Gobo 2 shake effect (ascending) 114…125 Gobo 3 shake effect (ascending) BSW-350 LED Moving Head...
- Page 23 110…117 Gobo 2 shake effect (ascending) 118…125 Gobo 3 shake effect (ascending) 126…133 Gobo 4 shake effect (ascending) 134…141 Gobo 5 shake effect (ascending) 142…149 Gobo 6 shake effect (ascending) 150…157 Gobo 7 shake effect (ascending) BSW-350 LED Moving Head...
- Page 24 Circle inverted (small to large) 215…255 Random (small to large) 0…255 Pan and tilt speed (decreasing) Dimmer curve 0…005 No function 006…063 Linear dimmer curve 064…127 Exponential dimmer curve 128…191 Logarithmic dimmer curve 192…255 S-shaped dimmer curve BSW-350 LED Moving Head...
-
Page 25: Functions In 32-Channel Dmx Mode
Inclination (tilt) fine adjustment 0…255 Inclination (tilt) fine adjustment 0…255 Dimmer fine adjustment Strobe 0…005 Open 006…010 Strobe open 011…033 Strobe closed 034…056 Randomly pulsing (ascending) 057…079 Randomly increasing (ascending) 080…102 Randomly decreasing (ascending) 103…127 Random strobe effect (ascending) BSW-350 LED Moving Head... - Page 26 Dark green / lavender 116…125 Lavender 126…135 Lavender / cyan 136…145 Cyan 146…185 Open 186…218 Clockwise run-through (descending) 219…222 Stop 223…255 Anti-clockwise run-through (ascending) 0…005 CRI off 005…255 CRI open Gobo wheel 1 0…005 Open 006…017 Gobo 1 BSW-350 LED Moving Head...
- Page 27 Gobo rotation fine adjustment Gobo wheel 2 0…005 Open 006…013 Gobo 1 014…021 Gobo 2 022…029 Gobo 3 030…037 Gobo 4 038…045 Gobo 5 046…053 Gobo 6 054…061 Gobo 7 062…069 Gobo 8 070…077 Gobo 9 078…085 Gobo 10 BSW-350 LED Moving Head...
- Page 28 Prism rotation (descending) 192…192 Stop 193…255 Prism rotation (descending) 0…255 Frost filter 0 to 100% Macro pan and tilt 0…005 006…040 Pan (small to large) 041…075 Tilt (small to large) 076…110 Pan and tilt (small to large) BSW-350 LED Moving Head...
- Page 29 LED PWM freq. 3600 Hz (press and hold 3 s) 186…200 LED PWM freq. 25 kHz (press and hold 3 s) 201…215 Pan/tilt reset (press and hold 3 s) 216…230 Head reset (press and hold 3 s) 231…255 Full reset (press and hold 3 s) BSW-350 LED Moving Head...
-
Page 30: Technical Specifications
International Protection Rating IP20 Mounting options Hanging, standing Dimensions (W × H × D) 420 mm × 698 mm × 265 mm Weight 25.8 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) BSW-350 LED Moving Head... -
Page 31: Plug And Pin Assignments
The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please refer to the drawing and table below for the pin assignment of a suit‐ able XLR plug. Configuration Ground, shielding Signal inverted (DMX–, ‘cold signal’) Signal (DMX+, ‘hot signal’) BSW-350 LED Moving Head... -
Page 32: Troubleshooting
DMX interface cir‐ cuit. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. BSW-350 LED Moving Head... -
Page 33: Cleaning
The fan grids of the device must be cleaned on a regular basis to remove dust and dirt. Before cleaning, switch off the device and disconnect AC-powered devices from the mains. Use a lint-free damp cloth for cleaning. Never use solvents or alcohol for cleaning. BSW-350 LED Moving Head... -
Page 34: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. BSW-350 LED Moving Head... - Page 36 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
