Page 1: Qbix Industrial Embedded System
QBiX-RPLA1355H-A1/ QBiX-RPLA1335H-A1/ QBiX-RPLA1315EH-A1 QBiX Industrial Embedded System Quick Start Guide www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation ITE is a trademark of Integrated Technology Express, Inc. • • IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
19.5V/ 135W adapter Power cord (May vary based on local distribution) Wall Mount Bracket HDD screw, M3 x 8L Thermal pad for DRAM2 If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 19. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Skilled person have to pay special attention or take special protection. Only authorized by well trained professional person can access the restrict access location. (2) External metal parts are hot!! Before touching it, special attention or protection is necessary www.gigaipc.com... -
Page 9: Table Of Contents
(Wireless Module inclusion may vary based on local distribution) ..............21 C) Memory Installation: DDR5 SO-DIMM ....22 D) 2.5” HDD/SSD installation: How to install 2.5” HDD/ SSD ................23 Antenna Installation (Antenna inclusion may vary based on local distribution) ............ 24 www.gigaipc.com... - Page 10 3.2.15 USB32_2 (USB 3.2 Gen 2x1 Port) ........47 3.2.16 PWR_BT (Power button with LED) ........ 48 3.2.17 DC_IN (Screw type DC Jack connector) ......49 3.2.18 LAN1 (2.5GbE LAN port connector) ......50 3.2.19 LAN2 (1GbE LAN port connector) ......... 51 www.gigaipc.com...
- Page 11 (MAC address may varied based on different mother- board) ................69 4.3.12 Realtek PCIe GBE Family Controller(MAC:10:FF:E0: 34:83:E1) (MAC address may varied based on different motherboard)..............70 Chipset ................71 Security ................. 72 Boot ................75 Save & Exit ..............76 www.gigaipc.com...
-
Page 12: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 13 118.0 130.14 59.0 48.0 48.0 46.30 46.30 80.0 www.gigaipc.com...
-
Page 14: Specifications
USB Type C (DP Alt. of 7680x4320 @30Hz, requires designated mode), supporting a graphic driver maximum resolution of 7680x4320 @30Hz, (3 independent display outputs) requires designated graphic driver (3 independent display outputs) Audio Realtek® ALC269 Storage 1 x 2.5” HDD/SSD (SATA 6Gb/s) www.gigaipc.com... - Page 15 Power Cord : Optional (by region) Wall Mount Bracket x 2 (P/N: 25HB2-CGAA20-CHR) Screw I Head for 25HDD M3x8L x 4 (P/N: 25KSG-130081-K1R) Thermal PAD for DRAM2 x 1 (P/N: 25ST3-200086-T5R) Order System: System: System: Information 6BQB1355AMR-SI 6BQB1335AMR-SI 6BQB1315AMR-SI www.gigaipc.com...
-
Page 16: Chapter 2 - Qbix Industrial Embedded System Kit
Chapter 2 Chapter 2 – QBiX Industrial Embedded System Kit www.gigaipc.com... -
Page 17: Dimension
Dimension 118.0 130.14 59.0 48.0 48.0 46.30 46.30 80.0 www.gigaipc.com... -
Page 18: Getting Familiar With Your Unit
PWR button with LED HDD LED 1 x COM Port [Right Side] (RS-232/422/485) 1 x Combo Audio Jack 2 x USB 3.2 Gen 2x1 (Headphone & Headset) 1 x USB 3.2 type C with DP 1.4b (DP Alt. mode) [Bottom Side] www.gigaipc.com... - Page 19 * Before Connecting the power, make sure to fasten the case securely. [Bottom PCB Side] Information Information 1 x M.2 slot, 2280 M-key 2 x DDR5 SO-DIMM sockets 1 x M.2 slot, 2230 E-key support 2.5’’ Hard drive/SSD www.gigaipc.com...
-
Page 20: A) M.2 Ssd Installation: How To Safely Install The
Remove the screw from the screw Carefully insert the M.2 SSD into the Carefully insert the wireless module into Lock the screw in the middle. the M.2 slot hole. (Location : MSO2) slot, and secure with the screw. 鎖入固定於無線模組中央頂端的螺 小心地將無線模組安裝於M.2插槽中。 絲。 www.gigaipc.com... -
Page 21: B) Wireless Module : How To Safely Install The Module (Wireless Module Inclusion May Vary Based On Local Distribution)
Remove 1 screw from the screw hole. (Location : MSO1) Carefully insert the wireless Lock the screw in the middle. Install the antenna on the le� module into the M.2 slot. side of the connec�on wireless module down. 小心地將無線模組安裝於M.2插槽中。 www.gigaipc.com... -
Page 22: C) Memory Installation: Ddr5 So-Dimm
C) Memory Installation: DDR5 SO-DIMM www.gigaipc.com... -
Page 23: D) 2.5" Hdd/Ssd Installation: How To Install 2.5" Hdd/Ssd
Carefully insert the wireless module into the M.2 slot First : assemble the SATA cable and 2.5" HDD/SSD. Second : install 2.5" HDD/SSD (Gold finger of 2.5" HDD/SSD must face down), 小心地將無線模組安裝於M.2插槽中。 and secure with 4 screws. Lock the bottom cover. www.gigaipc.com... -
Page 24: Antenna Installation (Antenna Inclusion May Vary Based On Local Distribution)
Antenna Installation (Antenna inclusion may vary based on local distribution) www.gigaipc.com... -
Page 25: Wall Mount Bracket Installation
Install the system, suggest using 4 x M4x10L type screws to fix Please make sure the direction of installation. on the wall. (not included in the shipment) suggest screw type : M4x10L pan head with Spring washer + flat washer (3 in 1), P/N : 25983G-1C017-S00 www.gigaipc.com... -
Page 26: Ral
This equipment is intended to be used in Restrict Access Location. The access can only be gained by Skilled person. Only authorized by well trained professional person can access the restrict access location. www.gigaipc.com... -
Page 27: Support
Support ● For a list of tested memory, M.2, 2.5’’ SSD, wireless adapters and OS supported, go to: http://www.gigaipc.com ● To download the latest drivers and BIOS updates, go to: http://www. gigaipc.com ● For product support, go to: http://www.gigaipc.com www.gigaipc.com... -
Page 28: Safety And Regulatory Information
At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal. www.gigaipc.com... -
Page 29: Chapter 3 - Hardware Information
Chapter 3 Chapter 3 – Hardware Information www.gigaipc.com... -
Page 30: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com... - Page 31 Code Description ATX_IN ATX IN Connector SATA SATA 6Gb/s connector SATA_PWR SATA power connector M.2 Slot, 2230 E-key M.2 Slot, 2280 M-Key BATTERY Battery Connector FUSB USB 2.0 header F_PANEL Front panel header www.gigaipc.com...
-
Page 32: Sodimm1 Sodimm2
USB32_2 USB 3.2 Gen 2x1 Port x 2 PWR_BT Power button with LED DC_IN Screw type DC Jack LAN1 2.5GbE LAN Port LAN2 1GbE LAN Port USB32_1 USB 3.2 Gen 2x1 Port x 2 HDMI2_21 HDMI Port x 2 www.gigaipc.com... -
Page 33: Atx_In (Atx In Connector)
3.2.1 ATX_IN (ATX IN Connector) Pin 1 ATX IN Connector Connector PN Vendor 99-01740-B004-A TCONN Connector type 1x2pin header, pitch 3.0mm Pin No. Definition DC IN www.gigaipc.com... -
Page 34: Sata (Sata 6Gb/S Connector)
3.2.2 SATA (SATA 6Gb/s connector) Pin 1 SATA 6Gb/s connector Connector PN Vendor WATF-07DBLBA1UW WINWIN Pin No. Definition www.gigaipc.com... -
Page 35: Sata_Pwr (Sata Power Connector)
3.2.3 SATA_PWR (SATA power connector) Pin 1 SATA power connector Connector PN Vendor 85205-0570N ACES Connector type 1x5pin header, pitch 1.25mm Pin No. Definition www.gigaipc.com... -
Page 36: M2E (M.2 Slot, 2230 E-Key)
CL_Reset WLAN_RXp CL_DATA WLAN_RXn CL_Clock Clock_Dp Clock_Dn Pin No. Definition Pin No. Definition SUSCLK 3.3V Clock_ USB_D+ 3.3V PLT_Reset Request USB_D- PCIE_Wake up BT_Disable WIFI_Disable 3.3V 3.3V Pin No. Definition Pin No. Definition Connector PN Vendor WLAN_TXp 80152-4221 BELLWETHER www.gigaipc.com... -
Page 37: M2M (M.2 Slot, 2280 M-Key)
SATA_TXp PLT_Reset PCIE_RXn3 CK_Request PCIE_RXp3 Clock_n PCIE_Wake up M2_LED Clock_p PCIE_TXn3 3.3V PCIE_TXp3 3.3V Pin No. Definition Pin No. Definition 3.3V SUSCLK PCIE_RXn2 3.3V PCIE_RXp2 M2_SSD_ 3.3V Detect 3.3V PCIE_TXn2 3.3V PCIE_TXp2 PCIE_RXn1 Connector PN Vendor PCIE_RXp1 2E0BC41-C85CM-LH FOXCONN www.gigaipc.com... -
Page 38: Battery (Battery Connector)
3.2.6 BATTERY (Battery connector) Pin 1 Battery Connector Pin No. Definition Connector type 1x2pin header, pitch 1.25mm www.gigaipc.com... -
Page 39: Fusb (Usb 2.0 Header)
3.2.7 FUSB (USB 2.0 header) Pin 1 USB 2.0 header Connector PN Vendor A1250WV-S- JOINT-TECH 04PNLBT1T00L 50273-0047N-001 ACES Connector type F_USB2.0 1x4pin header, pitch 1.25mm Pin No. Definition D- (USBN) D+ (USBP) www.gigaipc.com... -
Page 40: F_Panel (Front Panel Connector)
3.2.8 F_PANEL (Front panel Connector) Pin 1 Front Panel Connector Connector PN Vendor 50238-01041-001 ACES Connector type 2x5pin header, pitch 1.0mm Pin No. Definition Power Button+ Power Button- PWR LED+ PWR LED- HDD LED- HDD LED+ www.gigaipc.com... -
Page 41: Sodimm1, Sodimm2 (Ddr5 So-Dimm Slot)
3.2.9 SODIMM1, SODIMM2 (DDR5 SO-DIMM Slot) www.gigaipc.com... -
Page 42: Me_Dis (Me Disable Jumper)
3.2.10 ME_DIS (ME Disable jumper) Pin 1 ME Disable jumper Connector type 1x2pin header, pitch 2.0mm ME Disable Jumper Enable Disable www.gigaipc.com... -
Page 43: Cpu Fan (Cpu Fan Connector)
3.2.11 CPU FAN (CPU FAN connector) Pin 1 CPU FAN connector Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Connector type 1x4pin header, pitch 1.25mm Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 44: Com1 (Serial Port Connector, Rs-232/422/485)
3.2.12 COM1 (Serial port connector, RS-232/422/485) Serial port Connector Connector PN Vendor SM41D1P1122N33N1 FENYING Pin No. RS-232 RS-422 RS-485 Full Duplex Half Duplex TXD- TXD+ RXD+ – RXD- – – – – – – – – – www.gigaipc.com... -
Page 45: Usb3Cm (Usb Type C Port)
3.2.13 USB3CM (USB Type C Port) USB TYPE C Port Definition Definition TX0_P RX0_P TX0_N RX0_N USB_VBUS USB_VBUS SBU2 USBP5_P USBP5_N USBP5_N USBP5_P SBU1 USB_VBUS USB_VBUS RX1_N TX1_N RX1_P TX1_P Connector PN Vendor WU3CR- WINWIN 24A5L1CU5T41 www.gigaipc.com... -
Page 46: Hp_Mic (Combo Audio Jack (Headphone & Headset))
3.2.14 HP_MIC (Combo audio jack (Headphone & Headset)) HP_MIC Connector Connector PN Vendor 2SJ3082-086111F SINGATRON Definition Definition HPOUT_L MIC_IN_C HPOUT_R HP_JD AGND AGND www.gigaipc.com... -
Page 47: Usb32_2 (Usb 3.2 Gen 2X1 Port)
3.2.15 USB32_2 (USB 3.2 Gen 2x1 Port) USB 3.2 Gen 2x1 connector Connector PN Vendor 18-A5950-6A33-A TCONN Definition Definition USB_D- USB_D- USB_D+ USB_D+ USB3_RX- USB3_RX- USB3_RX+ USB3_RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ www.gigaipc.com... -
Page 48: Pwr_Bt (Power Button With Led)
3.2.16 PWR_BT (Power button with LED) Power button with LED Connector Connector PN Vendor ML3-AG2HW-Q-R DIPTRONICS www.gigaipc.com... -
Page 49: Dc_In (Screw Type Dc Jack Connector)
3.2.17 DC_IN (Screw type DC Jack connector) Screw Type DC Jack Connector Connector PN Vendor 655-360-000 SHEN-MING www.gigaipc.com... -
Page 50: Lan1 (2.5Gbe Lan Port Connector)
State Description Orange On 2.5Gbps data rate Green On 1GMbps data rate 100/10Mbps data rate Link / Connection/ Activity LED Speed LED Pin No. Definition Connector PN Vendor TX+_D1 S22-GB-0006 TX-_D1 JFM4811D-F8AF-4F FOXCONN RX+_D2 BI+_D3 BI-_D3 RX-_D2 BI+_D4 BI-_D4 www.gigaipc.com... -
Page 51: Lan2 (1Gbe Lan Port Connector)
LAN Connector State Description Orange On 1Gbps data rate Green On 100Mbps data rate 10Mbps data rate Link / Connection/ Activity LED Speed LED Pin No. Definition Connector PN Vendor TX+_D1 RT7-GB-0003 TX-_D1 RX+_D2 BI+_D3 BI-_D3 RX-_D2 BI+_D4 BI-_D4 www.gigaipc.com... -
Page 52: Usb32_1 (Usb 3.2 Gen 2X1 Connector)
3.2.20 USB32_1 (USB 3.2 Gen 2x1 connector) USB 3.2 Gen 2x1 connector Connector PN Vendor 18-A5950-6A33-A TCONN Definition Definition USB_D- USB_D- USB_D+ USB_D+ USB3_RX- USB3_RX- USB3_RX+ USB3_RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ www.gigaipc.com... -
Page 53: Hdmi2_21 (Hdmi Connector)
3.2.21 HDMI2_21 (HDMI connector) HDMI Connector Connector PN Vendor QJ11191-DFB1-4F FOXCONN Definition Definition HDMI_D2+ HDMI_CLK- HDMI_D2- HDMI_D1+ HDMI_SCL HDMI_D1- HDMI_SDA HDMI_D0+ HDMI_D0- HDMI_HPD HDMI_CLK+ www.gigaipc.com... -
Page 54: Chapter 4 - Bios
Chapter 4 Chapter 4 – BIOS www.gigaipc.com... -
Page 55: Introduction
Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com... -
Page 56: The Main Menu
ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com... -
Page 57: Advanced
Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com... -
Page 58: Tpm Configuration
4.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM TPM Device dTPM : External TPM (When using External TPM module or Selection having TPM chip on MB) (Default setting) www.gigaipc.com... - Page 59 Trusted Computing : Shows TPM information, and TPM module configuration setting. Item Description Security Device Enabled : Enables TPM feature (Default setting) support Disabled : Disables TPM feature None : (Default setting) Pending operation Disabled : Disables TPM feature www.gigaipc.com...
-
Page 60: Cpu Configuration
Enabled : Enables Turbo Mode (Default setting) Turbo Mode Disabled : Disables Turbo Mode Command CPU to enter into low power consumption mode when CPU is under idle mode. C states Enabled : Enables C states (Default setting) Disabled : Disables C states www.gigaipc.com... -
Page 61: Sata Configuration
Intel VMD feature helps you to control and manage NVMe PCIe menu SSD. / Enable VMD Enabled : Enables Intel VMD feature controller Disabled : Disables Intel VMD feature (Default setting) Serial ATA Port shows 2.5" SATA HDD/SSD information shows M.2 SATA interface SSD information www.gigaipc.com... -
Page 62: Super Io Configuration
Enabled : Enables Serial Port function (Default setting) Disabled : Disables Serial Port function Serial Port 1 Configuration Device settings : Display the specified Serial Port base I/O address and IRQ COM Port Mode : Choose RS-232, RS-422, or RS-485 feature www.gigaipc.com... -
Page 63: Hardware Monitor
4.3.5 Hardware Monitor Item Description System Shows current system temperature Temperature Shows current CPU temperature Temperature www.gigaipc.com... -
Page 64: S5 Rtc Wake Settings
Enable or Disable System to wake on a specific time. Disabled : Disables system to wake on a specific time (Default Wake system setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com... -
Page 65: Network Stack Configuration
Disabled : Disables IPv6 HTTP Support Enabled : Enables IPv6 HTTP Support PXE boot wait time Wait time in seconds, or use ESC key to abort the PXE boot. Media detect count Number of times the presence of media will be checked. www.gigaipc.com... -
Page 66: Nvme Configuration
4.3.8 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com... -
Page 67: Offboard Sata Controller Configuration
4.3.9 Offboard SATA Controller Configuration www.gigaipc.com... -
Page 68: Tls Auth Configuration
Press [Enter] to configure advanced items : Server CA Configuration : Enroll Cert : 1. Enroll Cert Using File Enroll Cert 2. Cert GUID : Input digit character in 11111111-2222-3333-4444-1234567 890ab format. 3. Commit Changes and Exit 4. Discard Changes and Exit www.gigaipc.com... -
Page 69: Intel(R) Ethernet Controller I226-V - 10:Ff:e0:34:83:E0 (Mac Address May Varied Based On Different Motherboard)
4.3.11 Intel(R) Ethernet Controller I226-V - 10:FF:E0:34:83:E0 (MAC address may varied based on different motherboard) Shows Intel Ethernet controller information NOTE：MAC address may varied based on different motherboard www.gigaipc.com... -
Page 70: Realtek Pcie Gbe Family Controller(Mac:10:Ff:e0: 34:83:E1) (Mac Address May Varied Based On Different Motherboard)
4.3.12 Realtek PCIe GBE Family Controller (MAC:10:FF:E0:34:83:E1) (MAC address may varied based on different motherboard) Shows Realtek Ethernet controller information NOTE：MAC address may varied based on different motherboard www.gigaipc.com... -
Page 71: Chipset
Enable/Disable Watchdog Timer function Watchdog Timer Enabled : Enables Watchdog Timer function Disabled : Disabled Watchdog Timer function (Default setting) Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com... -
Page 72: Security
To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com... - Page 73 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without full authentication Management Press <Enter> to configure the advanced items www.gigaipc.com...
- Page 74 Boot mode Signatures Remove 'UEFI CA' To remove 'UEFI CA' from database from DB Restore DB variables to fac tor y Restore DB defaults defaults Yes : Agree to restore DB defaults No : Cancel to restore DB defaults www.gigaipc.com...
-
Page 75: Boot
Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Enabled : Enables Built-in EFI Shell Built-in EFI Shell Disabled : Disables Built-in EFI Shell (Default setting) Shows the information of the storage that be installed in the Boot Option system Priorities Choose/set the boot priority www.gigaipc.com... -
Page 76: Save & Exit
Yes : Agree to load optimized defaults Defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
