GP1100
Glass panic device - down latching dummy glass mount
(use with exterior pull types: A, B, C, F, G, H, K, KS, L, LS, X, Z)
Installation instructions
974010 – 10-2020
| EN |

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP1100 and is the answer not in the manual?

Questions and answers

Related Manuals for Dormakaba GP1100

Summary of Contents for Dormakaba GP1100

  • Page 1 GP1100 Glass panic device - down latching dummy glass mount (use with exterior pull types: A, B, C, F, G, H, K, KS, L, LS, X, Z) Installation instructions 974010 – 10-2020 | EN |...

  • Page 2: Table Of Contents

    GP1100 Dummy Glass Mount (for down latching) Table of Contents Installation Instructions Table of contents 1  Technical specifications Overview 1.1.1 General information 1.1.2 Intended use 1.1.3 Glass requirements/fittings/mounting 1.1.4 Requirements for glass panel 1.1.5 Safety instructions 1.1.6 Symbols used - Safety/Installation 1.1.7 Maintenance, care, repair...

  • Page 3: Technical Specifications

    GP1100 Dummy Glass Mount (for down latching) Technical specifications Installation Instructions 1  Technical specifications Overview These instructions are for installation of GP1100 Dummy Glass Panic Device for the following mounting and style versions: 1. Down latching glass mount 1.1.6 Symbols used - Safety/Installation 1.1.1...

  • Page 4: Adhesive Specifications

    GP1100 Dummy Glass Mount (for down latching) Technical specifications Installation Instructions Overall 1.1.9 Adhesive specifications Table 1 Adhesive required for GP1100 (not included) Loctite® Threadlocker Handling description Time Blue 242® Set time (time between application and 10 minutes on active metals (steel) tightening of screw) Longer for less active metals.

  • Page 5: Mount Exterior Pull Components - Disassemble Actuator Parts

    GP1100 Dummy Glass Mount (for down latching) Exterior Pull - Actuator Installation Instructions Mount exterior pull components - disassemble actuator parts Fig 3 NOTE: PANIC DEVICE SHOULD BE MOUNTED TO DOOR IN A HORIZONTAL POSITION. LAY GLASS PANEL FLAT ON SAW HORSES AND MOUNT THE FOLLOWING EXTERIOR PULL COMPONENTS FIRST.

  • Page 6: Mount Exterior Pull Components - Top Standoff

    GP1100 Dummy Glass Mount (for down latching) Exterior pull - top standoff Installation Instructions Mount exterior pull components - top standoff Fig 4 Pull Options Door side Pull type Interior Back-to- INTERIOR Back top Exterior F (shown) glass mount...

  • Page 7: Mount Exterior Pull Components - Bottom Standoff

    GP1100 Dummy Glass Mount (for down latching) Exterior pull - bottom standoff Installation Instructions Mount exterior pull components - bottom standoff Fig 5 Single-sided application Back-to-back application Pull Options Pull Options Door side Pull type Door side Pull type...

  • Page 8: Return Tube (D-Pull; Back-To-Back)

    GP1100 Dummy Glass Mount (for down latching) Exterior pull - back-to-back return tube Installation Instructions Mount exterior pull components - return tube (back-to-back) Fig 6 Pull Options Door side Pull type Interior INTERIOR Exterior C (shown) Back-to- Back glass mount 2.5.1 Disassemble return tube components.

  • Page 9: Mount Interior Pull Components - Dummy Actuator/Int. Pull

    GP1100 Dummy Glass Mount (for down latching) Interior Pull - Actuator Installation Instructions Mount interior pull components - dummy actuator/int. pull Fig 7 NOTE: FLIP DOOR OVER AND LAY FLAT ON SAW HORSES TO MOUNT THE INTERIOR SIDE COMPONENTS.

  • Page 10: Mount Interior Pull Components - Bottom Standoff

    GP1100 Dummy Glass Mount (for down latching) Interior pull - bottom standoff Installation Instructions Mount interior pull components - bottom standoff Fig 8 Back-to-back mount Single-sided mount INTERIOR INTERIOR Pull Options Pull Options Door side Pull type Door side...

  • Page 11: Mount Interior Pull Components - Return Tube (Single-Sided)

    GP1100 Dummy Glass Mount (for down latching) Interior pull - single sided return tube Installation Instructions Mount interior pull components - return tube (single-sided) Fig 9 Pull Options Door side Pull type Interior INTERIOR Exterior none (Z) (shown) Interior...

  • Page 12: Mount Interior Pull Components - Return Tube (Back-To-Back)

    GP1100 Dummy Glass Mount (for down latching) Interior pull - back-to-back return tube Installation Instructions Mount interior pull components - return tube (back-to-back) Fig 10 Pull Options Door side Pull type Interior INTERIOR Exterior C (shown) Back-to- Interior Back glass...

  • Page 13: Adjustments

    GP1100 Dummy Glass Mount (for down latching) Adjustments: clearances Installation Instructions 3 Adjustments Clearances Fig 11 Dummy Glass Exterior Interior Pull Panic Patch fitting 1/4” ENSURE THE DISTANCE 2” FROM THE FACE OF THE [51] GLASS (F.O.G.) TO THE CENTERLINE OF THE INTERIOR PULL IS 2”...

  • Page 14: Final Adjustments (Tube Height Or Length)

    GP1100 Dummy Glass Mount (for down latching) Adjustments: tube height or length Installation Instructions Loctite Final adjustments (tube height or length) Fig 12 Interior Panic Tube shown Bottom section of tube Interior Panic Tube shown Return tube 3.2.1 Ensure interior and exterior tubes are at the 3.2.3 To adjust length of tube:...
  • Page 15 USA, Inc. 1 Dorma Drive, Drawer AC Reamstown, PA 17567 T: 717-336-3881 F: 717-336-2106 www.dormakaba.com...
