- Page 1 G-Ubivis XEA Operating instructions WN 058974 4553215291 – 2020-11...
-
Page 2: Table Of Contents
G-Ubivis XEA. The manual’s text section is supported by figures in the picture section. The 1.5.2 More symbols picture numbers in the text can be found at the bottom left in the figures for the respective chapter. -
Page 3: Safety
Service. high temperatures for long enough. This can cause the batteries in the G-Ubivis XEA Intended use hold-open system to overheat and explode! The hold-open system is used to keep open fire •... -
Page 4: Product Description
Operating instructions Product description Product description G-Ubivis XEA is a battery-powered hold-open system with integrated smoke detector panel. Parts included/Components – 201 1154 Ø Ø iv is leit rieb – 20 3 455 Fig. 2 Parts included/Components End caps... - Page 5 Operating instructions Product description Operating elements TIPS AND RECOMMENDATIONS After changing switch B, the battery must 3.2.1 be disconnected and reconnected after 30 s to take over the set function. 3.2.2 Reset button and control LEDs 3.2.2 3.2.2.1 Reset button The reset buttons are located on the top and bottom of the beam.
- Page 6 LED on the underside of the slide rail will light up. 6 x every Battery empty: if the door holder 28 s is not working, call the dormakaba Service. Smoke alarm: acknowledge with 3 x per s reset button for manual reset.
-
Page 7: Mounting
Operating instructions Mounting Mounting 6A/B Determine the desired size of the door opening 1A/B angle. Drill the holes for the door closer according to the If the door opening angle is less than 105°, then door closer’s assembly instructions. - Page 8 Operating instructions Mounting Open the door to the desired opening angle. ATTENTION ATTENTION! Risk of unit damage Pull the cable out of the slide rail with Setting a release force too high may result a slight tug! Secure the cables that are...
-
Page 9: Check Hold-Open System
(LED flashes yellow 1 x every 7 s). for this by dormakaba. Follow the instructions in the The smoke detector must be replaced after 8 years information sheet on the use of hold-open systems. -
Page 10: Maintenance From Dormakaba
Regular maintenance of your units pays off: weak • Observe the warnings on the battery pack. points are detected and eliminated at an early stage • Only use the dormakaba battery pack with item and your unit’s service life is increased. number 57650000. - Page 11 Operating instructions Mounting Mounting max. 16 min. 860 max. 26 min. 860 max. 16 min. 860 max. 26 min. 860 G-Ubivis XEA WN 058974 45532 2020-11...
- Page 12 Operating instructions Maintenance from dormakaba 5 x 30 mm 5 x 30 mm M5 x 20 mm M5 x 20 mm G-Ubivis XEA WN 058974 45532 2020-11...
- Page 13 Operating instructions Maintenance from dormakaba M5 x 38 mm 2.0 – 2.5 Nm M5 x 38 mm 2.0 – 2.5 Nm M5 x 38 mm 2.0 – 2.5 Nm M5 x 38 mm 2.0 – 2.5 Nm G-Ubivis XEA...
- Page 14 Operating instructions Maintenance from dormakaba <105° <105° >105° >105° <105° <105° >105° >105° M5 x 10 mm 1.5 Nm M5 x 10 mm 1.5 Nm G-Ubivis XEA WN 058974 45532 2020-11...
- Page 15 Operating instructions Maintenance from dormakaba 8 - 10 Nm 2.5 - 3 Nm G-Ubivis XEA WN 058974 45532 2020-11...
- Page 16 Operating instructions Maintenance from dormakaba approx. 2 s <0.5 Nm G-Ubivis XEA WN 058974 45532 2020-11...
- Page 17 Operating instructions Maintenance from dormakaba M3 x 4 mm 1 Nm M4 x 10 mm 1 Nm M4 x 10 mm 1 Nm G-Ubivis XEA WN 058974 45532 2020-11...
- Page 18 Operating instructions Check hold-open system Check hold-open system Completion of mounting G-Ubivis XEA WN 058974 45532 2020-11...
- Page 19 Operating instructions Maintenance and care Maintenance and care G-Ubivis XEA WN 058974 45532 2020-11...
- Page 20 Deutschland GmbH DORMA Platz 1 58256 Ennepetal Germany T: +49 2333 793-0 www.dormakaba.com F: +49 2333 793-4950...
