  • Page 1 Gunter & Hauer INSTRUCTION MANUAL Built-in Gas Hob GL 6 B GL 643...
  • Page 3: Table Of Contents

    Content Important notes and precautions for use………………..4 Description of the appliance……………………………6 Instructions for the user…………………………...6 Instructions for the user: cleaning and maintenance……9 What to do if……………………………………………10 Instructions for the installer…………………………….10 Technical features………………………………………19...
  • Page 4: Important Notes And Precautions For Use

    1. IMPORTANT NOTES AND PRECAUTIONS FOR USE This new appliance is easy to use but before installing and using it, it is important to read this Instruction Manual through carefully. It provides information for a safe installation, use and maintenance. Keep this Instruction Manual in a safe place for future reference.
  • Page 5 responsibility if these instructions are not followed. Should you have any doubts ask for an accurate control of the system by qualified personnel. • Prior to connecting the appliance ensure that the rating plate data correspond to those of the gas and electricity mains (see part “7. TECHNICAL FEATURES”).
  • Page 6: Description Of The Appliance

    2. DESCRIPTION OF THE APPLIANCE 1.Wok gas burner 3.Semi-Rapid gas burner (SR) 4.Auxiliary gas burner (Aux) 5.Gas burner control knob 6.Pan support for burners INSTRUCTIONS FOR THE USER: USE PRESENTATION The burners are graduated in their size and rating to provide the exact heat required for every style of cooking.
  • Page 7: Gas Burners

    GENERAL NOTES ON SAFETY • When the burners or plates are in use do not leave them unattended and make sure there are no small children in the vicinity. Check that pan handles are positioned correctly and always keep an eye on the pan whenever oils or fats are used as they are easily inflammable.
  • Page 8 Automatic electrical ignition (only certain versions, see fig. 5, ref. The command of lighting is integrated in the control knob. Press and turn anclockwise the knob corresponding to the burner you wish to use from “Off” position (full disk symbol on control panel), until it reaches the “Maximum”...
  • Page 9: Instructions For The User: Cleaning And Maintenance

    Burners Rapid Semi-Rapid Auxiliary Ø pans in cm 24-26 24-26 22-24 10-14 When a gas appliance is being used it produces heat and humidity in the room where it is installed. For this reason, the room must be well ventilated, keeping the natural ventilation openings free (fig. 6) and switching on the mechanical aeration system (suction hood or electric fan - Figs.
  • Page 10: What To Do If

    Never clean when the top and components are still warm. Do not use metal or abrasive pads, abrasive powders or corrosive spray products. Never leave vinegar, coffee, milk, salty water, lemon or tomato juice for any length of time on the surfaces. WARNINGS Accessible parts may be hot, when the pan support is in use.
  • Page 11: Installation

    in this part must only be carried out by qualified. The manufacturer cannot be held responsible for any damage to persons or things deriving from an incorrect installation of the appliance. • The safety and adjustment devices of the appliances may, during their life, only be modified by the manufacturer or duly authorised supplier.
  • Page 12: Unpacking The Appliance

    LOCATION AND AERATION Gas appliances must always discharge the products of combustion through extractors connected to flues or directly to the outside (see fig. 7). If it is impossible to use an extractor, a fan installed on the window or on a wall facing the outside is allowed and should be switched on each time the appliance is used (see fig.
  • Page 13 IMPORTANT! Under the hob it is necessary to always apply a panel of separation in wood, positioned to a least distance of 70 mm by the bottom of the same, which has to easily be removable to allow possible operations of maintenance (see fig.
  • Page 14: Gas Connection

    GAS CONNECTION Before to connect the appliance to the gas network, check that the adjustment sticker data plate, put on the bottom of the appliance, correspond to the available one in the gas network. The adjustment sticker data plate, gives all the appliance’s setting conditions as: gas type and gas operating pressures.
  • Page 15: Electrical Connection

    Anyway, the pipe connecting the appliance with the gas mains should lie with smooth bends, and the rubber gasket preventing leakage added by user between the appliance’s gas inlet fitting and the pipe connection must comply with the Standard EN 549 (get it in proper Technical Assistance Centres or authorised dealers).
  • Page 16 When connecting directly to the mains: Install a multipolar switch that can withstand the appliance load, with a minimum opening between the contacts of 3 mm, not less! Remember that the earth wire must not be cut out by the switch. As an alternative, the electrical connection can also be protected with a high sensitivity RCD.
  • Page 17: Changing The Injectors

    to the low position. In the case of taps with safety thermocouples, the adjustment screw is on the side of the stem. • Make sure that when turning quickly from “Maximum” position to “Minimum” one, the burner does not extinguish. Attention if the tap, after long use of the hob, present some friction to rotation, do not insist to use it.
  • Page 18: Maintenance

    MAINTENANCE Prior to any maintenance work or before changing parts, disconnect the appliance from the gas and electricity power sources. REPLACING COMPONENTS • To access the terminal board and the power cable, it is necessary to remove the hob from the cabinet by unscrewing the relative fixing screws (V) (see fig.
  • Page 19: Technical Features

    7. TECHNICAL FEATURES BURNERS INJECTORS AND HEAT INPUTS TABLE (for the hob burners lay-out, see on page 4) Gases and Injectors Heat Inputs Burners pressures diameter Denomination mbar 1/100 mm (kW) G30 (Butane) at 28-30 mbar G31 (Propane) 1 Rapid (R) at 37 mbar G20 (Natural) at 20 mbar...
  • Page 20 CAUTION! Carry out the connection avoiding all kinds of stress to the appliance A, This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
