- Page 1 Günter & Hauer INSTRUCTION MANUAL Built-in Gas Hob GH 43 CI / GH 643 IVR / GL 643 IVR GL 641 TN / GL 641 WTN GL 745...
-
Page 2: Table Of Contents
Günter & Hauer CONTENT PRECAUTIONS USE OF GAS BURNERS CONNECTION INSTALLATION HOB OPERATION CLEANING SPECIFICATIONS... -
Page 3: Precautions
Günter & Hauer PRECAUTIONS Before installing the appliance and using it, please read the instruction carefully. It is very important that the instruction manual is kept with the appliance so that it can be consulted in the future if you have any questions. - Page 4 Günter & Hauer This appliance is not connected to a combustion product disposal device. It must be installed and connected in accordance with current installation rules. Particular attention should be paid to the rules concerning ventilation. The use of a gas appliance for cooking leads to the release of heat and humidity in the room in which it is installed.
-
Page 5: Use Of Gas Burners
Günter & Hauer USE OF GAS HOB On the front of the panel there are handles for controlling gas burners. The symbols depicted next to the handles indicate their correspondence to certain burners. ON/OFF Max. Heat Min. Heat Ignition Burner Place All built-in gas hobs, except for automatic electric ignition, are equipped with a special protective function "gas control". - Page 6 Günter & Hauer BURNER DESIGN 1 – Burner Cap 2 – Burner splitter 3 – Splitter Body 4 – Ignition spark 5 – Gas control Thermoelement SABAF Triple Burner Standard burner SABAF Triple Burner Do not try to turn the control knob without pressing it, as this may cause the gas valve to fail.
-
Page 7: Connection
Günter & Hauer CONNECTION IMPORTANT WARNING: The operations described below must be performed by qualified personnel in accordance with applicable regulations. THE MANUFACTURER IS NOT RESPONSIBLE FOR DAMAGES WHICH RESULT FROM INAPPROPRIATE INSTALLATION OF THE DEVICE AND VIOLATION OF THE ABOVE RULES. Appliance must be disconnected from the mains before carrying out any work on it. - Page 8 Günter & Hauer ELECTRICAL CONNECTION For operation of this gas hob it is necessary to provide power supply from a single-phase electric network with voltage of 220 ~ 230 V. Connection has to be executed according to norms and according to current legislation. Before connecting, make sure that: •...
- Page 9 Günter & Hauer (Grounding) - yellow-green wire Replace the power cord only at a service center or with qualified personnel. If it is necessary to replace the power cord, use a cord type H05VV-F or H05RR-F with a cross section of 3X0.75 mm2 in accordance with current regulations. The connection to the terminal box should be made as shown in the figure above.
-
Page 10: Installation
Günter & Hauer Bypass valve for regulating the minimum mode • If the 20 mbar / 13 mbar methane appliance is readjusted to liquefied gas, screw the bypass valve clockwise as far as it will go. • If the liquefied gas appliance is set to methane at a pressure of 20 mbar, unscrew the bypass valve by about 1/4 turn. - Page 11 In a table-top it is necessary to prepare an aperture for embedding according to the sizes specified in drawing, thus it is necessary to provide that distance between edge of the device and the nearest wall was not less than 50-55 mm. 1. GH 43 CI 2. GH 643 IVR 3. GL 643 IVR...
- Page 12 Günter & Hauer 4. GL 641 TN / GL 641 WTN 5. GL 745 If an extractor hood is to be installed above the hob, it must be at least 750 mm away from it. It is recommended to insulate the hob from the furniture in which it is built, the dividing panel, leaving a distance of at least 100 mm between it and the appliance.
-
Page 13: Hob Operation
Günter & Hauer HOB MOUNTING A special sealing gasket and a set of brackets for fastening are added to the hob. To install the hob, perform the following operations: • Remove the pan support and splitter covers. (A) Sealing gasket •... - Page 14 (see the following table). BURNERS SCHEME GH 43 CI / GH 643 IVR / GL 643 IVR 1 – Semi-Rapid (1750 W) 2 – Semi-Rapid (1750 W) 3 –...
- Page 15 Günter & Hauer GL 745 1 – Rapid (3000 W) 2 – Auxiliary (1000 W) 3 – Triple WOK (3300 W) 4 – Semi-Rapid (1750 W) 5 – Semi-Rapid (1750 W) Burner type Dish Size (cm) Auxiliary 10-14 Semi-Rapid 16-18 Rapid 20-22 Triple...
-
Page 16: Cleaning
Günter & Hauer Carefully control the cooking of oil or fat, because in case of overheating they may ignite. Therefore, it is not recommended to cook for a long time using kitchen stones, in ceramic dishes, or on cast-iron plates. Do not use aluminum foil to protect the hob from contamination. - Page 17 Günter & Hauer Stainless steel parts Stains may appear on stainless steel parts if they come into contact with hard water or abrasive detergents for a long time. It is recommended to wash them with a soap solution and wipe dry with a soft cloth. The shine will be preserved if used regularly with appropriate care products.
-
Page 18: Specifications
Günter & Hauer Keep the area near the flame openings under the hood very clean. Clean the holes of the burner nozzles using only copper wire. Do not use steel wire or open holes. PERIODIC TECHNICAL INSPECTION In addition to the usual care of the hob you need to: •... - Page 19 Günter & Hauer SERVICE AND SPARE PARTS Before leaving the plant, the device has passed acceptance tests, and its adjustment was carried out by qualified specialists to ensure the best performance. Any repairs or adjustments that may be necessary in the future must be carried out with special care and attention.
